SLIDE 1
Project Darklight
Rob Buijs Michael Rave
Overview
XS4ALL Darknet Research question Argus Research
Results Zero day warning system Internet Security Index
Conclusion
Future work
2
Overview 2 XS4ALL Darknet Research question Argus Research - - PowerPoint PPT Presentation
Overview 2 XS4ALL Darknet Research question Argus Research - - PowerPoint PPT Presentation
Overview 2 XS4ALL Darknet Research question Argus Research Results Zero day warning system Internet Security Index Conclusion Future work Rob Buijs Project Darklight Michael Rave XS4ALL Darknet 3 Darknets Traffic to the XS4ALL
SLIDE 2
SLIDE 3
Project Darklight
Rob Buijs Michael Rave
XS4ALL Darknet
Darknets Traffic to the XS4ALL darknet
For everyone Not used XS4ALL space For XS4ALL customers Not used XS4ALL space Bogon IP’s
Argus No response
3
SLIDE 4
Project Darklight
Rob Buijs Michael Rave
XS4ALL Darknet
4
SLIDE 5
Project Darklight
Rob Buijs Michael Rave
Research question
5
“What information can be gained from the captured XS4ALL Darknet streams, and could it be used as a zero day warning system?”
SLIDE 6
Project Darklight
Rob Buijs Michael Rave
Argus
Real time flow monitor Fields
Source and destination IP address Source and destination port Type protocol Start time
UDP first 712 bytes payload 4 Months of data Argus tools
6
SLIDE 7
Project Darklight
Rob Buijs Michael Rave
Research - Patterns
Port scans IP scans IP patterns Port patterns Time patterns
7
SLIDE 8
Project Darklight
Rob Buijs Michael Rave
Research - Protocol usage
8
56% 37% 6%
TCP UDP ICMP 3686 IGMP ARP RTCP IPv6 ESP Average Protocol Usage
SLIDE 9
Project Darklight
Rob Buijs Michael Rave
Research - Time pattern
9
25000 50000 75000 100000 125000 150000 175000 200000 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 1 2 3 4 5 6
Average amount of packets per hour
SLIDE 10
Project Darklight
Rob Buijs Michael Rave
Research - Origin
Why
Misconfiguration Viruses, worms and malware Scans
From where
Countries Customers Non customers
10
SLIDE 11
Project Darklight
Rob Buijs Michael Rave
Research - Traffic streams
11
SLIDE 12
Project Darklight
Rob Buijs Michael Rave
Research - Country origin
12
80% 6% 3% 3% 2% 2% 1%
NL FR DE PL IT GN ES HU CN IL Country origin of traffic to not used XS4ALL space
SLIDE 13
Project Darklight
Rob Buijs Michael Rave
Research - Country origin
13
Country origin of traffic to not used XS4ALL space, without XS4ALL customers
57% 16% 6% 5% 3% 3% 2%
NL FR IT GB PL ES HU CN IL KR
SLIDE 14
Project Darklight
Rob Buijs Michael Rave
Research - Analysis
Top N Baseline Trends
14
SLIDE 15
Project Darklight
Rob Buijs Michael Rave
Research - Port analysis
15
Top N
50000 100000 150000 200000 250000 300000 350000 Day 1 Day 2 Day 3 Day 4 Day 5 Day 6 Day 7 Day 8 Day 9 Day 10
65535 8000 4662 137 135 80 ICMP
SLIDE 16
Project Darklight
Rob Buijs Michael Rave
Research - Port trends
16
The coming of the SAV worm
SLIDE 17
Project Darklight
Rob Buijs Michael Rave
Research - Port trend analysis
17
62.50% - Portnumber: 12149 - Port amount: 13 - Overallaverage: 8 40.00% - Portnumber: 12186 - Port amount: 7 - Overallaverage: 5 34.21% - Portnumber: 12183 - Port amount: 51 - Overallaverage: 38 25.00% - Portnumber: 12165 - Port amount: 10 - Overallaverage: 8 18.52% - Portnumber: 12210 - Port amount: 32 - Overallaverage: 27 18.18% - Portnumber: 12204 - Port amount: 13 - Overallaverage: 11 16.67% - Portnumber: 12188 - Port amount: 7 - Overallaverage: 6
Trends calculation with baseline Effective to detect upcoming popularity of ports Important to define minimum port frequency Otherwise:
SLIDE 18
Project Darklight
Rob Buijs Michael Rave
Zero day warning system
Identify and notify upcoming threats in an early stage Trend analysis of darknet data Top N analysis
18
SLIDE 19
Project Darklight
Rob Buijs Michael Rave
Internet security index
Total amount Rapid increase Port rating IP rating
19
SLIDE 20
Project Darklight
Rob Buijs Michael Rave
Conclusion
IP origin, country of IP address Protocol usage Time patterns Port patterns Zero day warning day
Trend analysis Top N
20
SLIDE 21
Project Darklight
Rob Buijs Michael Rave
Future work
Cooperate with Dshield / Internet Storm Center Build zero day warning system Build internet security index Build abuse messages system
21
SLIDE 22
Project Darklight
Rob Buijs Michael Rave
Questions
22
