Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges Dr. Muhammad Imran muhammad.imran@ncp.edu.pk National Centre for Physics Islamabad, Pakistan. Optical Interconnects for Cloud Computing Data Centers:

slide-1
SLIDE 1

1/40

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran

muhammad.imran@ncp.edu.pk National Centre for Physics Islamabad, Pakistan.

slide-2
SLIDE 2

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

2/40

Outline

  • Introduction
  • Challenges in Traditional Data Center Network
  • Optical Interconnects

– Optical Switching Techniques – Optical Switches

  • Recent Proposals of Optical Interconnects for DCN

– Architectures based on MEMS: – Architectures based on SOAs – Architectures based on AWGRs – Architectures based on WSSs – Hybrid Architectures based on fast and slow optical switches.

  • Comparison
  • Conclusion and Future work.
slide-3
SLIDE 3

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

3/40

Introduction

  • Exponential increase of internet traffic:

– emergence of cloud computing based applications. – applications run on the servers deployed in the data centres – require huge bandwidths.

  • Importance of Data centres

– Computation and storage away from desktop to large scale data centres. – IP traffic will keep on increasing due to smart devices and multimedia applications.

  • Need of building fast and high bandwidth

interconnect network in the data centre.

slide-4
SLIDE 4

4/40

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

Challenges in Traditional DCNs

  • Power consumption

– ToR, aggregate/core switches and transceivers requiring O-E-O conversion are the main contributions to power consumption. – The power consumption of the interconnection network accounts for 23% of the total IT power consumption

  • It will increase significantly in future

DCNs as data rates increase.

  • Increasing bandwidth demand
  • Latency
  • Network Oversubscription
  • Scalability
slide-5
SLIDE 5

5/40

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.
  • Traffic locality

– Cisco global cloud index reveals that majority of the traffic in future DCNs will remain within data centres while only a very small portion of the traffic will go the external network.

Challenges in Traditional DCNs…(2)

1000 2000 3000 4000 5000 6000 7000 8000 9000 2014 2015 2016 2017 2018 2019

Ebytes/year Year

Data center to user Data center to data center Within data center

slide-6
SLIDE 6

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

6/40

Optical Interconnects

  • Optical networks for data centre networks

(DCNs):

– Key requirement to achieve Internet-scale data centres – Provide huge bandwidths – Low latency – Power Efficient

  • The performance of optical network is related

with optical switching:

– Optical Circuit Switching (OCS) – Optical Packet Switching (OPS) – Optical Burst Switching (OBS)

slide-7
SLIDE 7

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

7/40

Optical Switching Techniques

  • Optical Circuit Switching (OCS):

– Connection Oriented – Suitable for long lasting connections

– Large connection establishment time – Bandwidth underutilization in the case of low traffic load

  • Optical Packet Switching (OPS):

– Connectionless – O-E-O conversion of header for processing in electrical domain – Fiber delay lines (FDLs) for buffering during header processing

– Lack of feasible optical buffer – Packet loss due to output port contention – O-E-O conversion increases energy consumption – Speed of header processing should be compatible with increasing data rate.

slide-8
SLIDE 8

8/40

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.
  • Optical Burst Switching

(OBS):

– Packets are aggregated into a burst at the edge node – Control packet is sent ahead

  • f the burst to reserve

resources – The burst is sent a certain time after the control packet – Burst loss due to output port contention – Poor TCP performance due to burst loss

  • Contention induced losses are

misinterpreted as congestion induced losses

Optical Switching Techniques…(2)

OBS Network

Edge Node Core Nodes Servers Servers Servers Network Users Network Users Servers

slide-9
SLIDE 9

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

9/40

Optical Switches

1. Slow Optical Switches:

– MEMS

  • High port density
  • Transceivers are not required
  • Power efficiency due to passive switching
  • Low insertion loss and crosstalk
  • Data rate independent
  • Support bidirectional communications
  • Less expensive
  • Switching time is in the order of tens of milliseconds

– WSSs

  • Switching time is in the range of micro to milliseconds

2. Fast Optical Switches

– AWGR

  • Nanoseconds switching time.
  • Expensive and are not scalable.

– SOA

  • Nanoseconds switching time.
  • Expensive
slide-10
SLIDE 10

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

10/40

Recent Proposals of Optical Interconnects for Data Centers

slide-11
SLIDE 11

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

11/40

Optical Interconnects

  • 1. Architectures based on MEMS:
  • 2. Architectures based on SOAs
  • 3. Architectures based on AWGRs
  • 4. Architectures based on WSSs
  • 5. Hybrid Architectures based on fast and slow optical

switches.

slide-12
SLIDE 12

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

12/40

Architectures based on MEMS:

  • 1. Helios
  • 2. HyPaC
  • 3. OSA
  • 4. Reconfigurable Architecture
  • 5. HydRA
slide-13
SLIDE 13

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

13/40

Helios

slide-14
SLIDE 14

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

14/40

HyPac

slide-15
SLIDE 15

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

15/40

OSA

slide-16
SLIDE 16

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

16/40

Reconfigurable Architecture

slide-17
SLIDE 17

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

17/40

HydRA

slide-18
SLIDE 18

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

18/40

Architectures based on SOAs

  • 1. OSMOSIS
  • 2. Data Vortex
  • 3. Bidirectional Architecture
  • 4. SW
  • 5. STIA
slide-19
SLIDE 19

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

19/40

OSMOSIS

slide-20
SLIDE 20

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

20/40

Data Vortex

slide-21
SLIDE 21

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

21/40

Bidirectional

slide-22
SLIDE 22

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

22/40

SW

slide-23
SLIDE 23

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

23/40

STIA

slide-24
SLIDE 24

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

24/40

Architectures based on AWGRs

  • 1. LIONS
  • 2. TONAK-LION
  • 3. Petabit
  • 4. IRIS
  • 5. OFDM-b ased
slide-25
SLIDE 25

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

25/40

LIONS

slide-26
SLIDE 26

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

26/40

TONAK LIONS

slide-27
SLIDE 27

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

27/40

Petabit

slide-28
SLIDE 28

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

28/40

IRIS

slide-29
SLIDE 29

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

29/40

OFDM-based Architecture

slide-30
SLIDE 30

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

30/40

Architectures based on WSSs

  • 1. Mordia
  • 2. WaveCube
  • 3. OPMDC
slide-31
SLIDE 31

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

31/40

Mordia

slide-32
SLIDE 32

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

32/40

WaveCube

slide-33
SLIDE 33

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

33/40

OPMDC

slide-34
SLIDE 34

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

34/40

Hybrid Architectures based on fast and slow optical switches.

  • 1. LIGHTNESS
  • 2. Hybrid Optical Switching
  • 3. HOSA
slide-35
SLIDE 35

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

35/40

LIGHTNESS

slide-36
SLIDE 36

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

36/40

Hybrid Optical Switching

slide-37
SLIDE 37

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

37/40

HOSA

slide-38
SLIDE 38

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

38/40

Comparison

slide-39
SLIDE 39

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

39/40

Conclusion & Future Work

  • Every architecture has some pros and cons.
  • The more feasible architecture would be the one which is:

– Scalable – Power efficient – Cost effective – Low latency – High throughput.

  • Software Defined Optical Networking (SDON)

– Inter and Intra Data Centers Interconnect

  • Elastic Optical Network
  • Photonic Integration

– Provide fast optical switching – Increase capacity

slide-40
SLIDE 40

Optical Interconnects for Cloud Computing Data Centers: Recent Advances and Future Challenges

  • Dr. Muhammad Imran, ISGC 2018.

40/40

Thanks
