Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects Self Heating Effects of Resistive Metals Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects This presentation covers: Transient 3D

slide-1
SLIDE 1

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Self Heating Effects of Resistive Metals

slide-2
SLIDE 2

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

  • This presentation covers:
  • Transient 3D thermal-electrical analysis in fuses and metal

structures

  • Benefits are understanding heat generation inside metal

structures and heat conduction flow

  • 2 -
slide-3
SLIDE 3

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Generation of a 3D Metal Structure for Thermal-Electrical Analysis

2-D cross sectional view Wiring Structure

  • 3 -
slide-4
SLIDE 4

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Generation of a 3D Metal Structure for Thermal-Electrical Analysis

VICTORY Cell is used to create the 3D structure.

  • 4 -
slide-5
SLIDE 5

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Generation of a 3D Metal Structure for Thermal-Electrical Analysis

VICTORY Cell is used to generate the 3D tetrahedral mesh generation.

  • 5 -
slide-6
SLIDE 6

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Transient Analysis of Metal Self Heating

Drain Current Drain Voltage

  • 6 -

Time-dependence of drain voltage and current.

slide-7
SLIDE 7

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Transient Analysis of Metal Self Heating

  • 7 -

Lattice Temperature versus Transient Time VICTORY Device solves the 3D coupled thermal- electrical transient analysis.

slide-8
SLIDE 8

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Transient Analysis of Metal Self Heating

  • 8 -

Potential at t = 100ns Potential at t = 200ns

slide-9
SLIDE 9

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Transient Analysis of Metal Self Heating

  • 9 -

Log(10) of Current Density at T = 100ns

slide-10
SLIDE 10

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Transient Analysis of Metal Self Heating

  • 10 -

Joule Heating Power at t = 100ns

slide-11
SLIDE 11

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Transient Analysis of Metal Self Heating

  • 11 -

Lattice Temperature at t=100ns. Power turns off at this point. Thermal conduction continues even beyond this 200ns.

slide-12
SLIDE 12

Coupled Thermal-Electrical Transient Analysis of 3D Fuses and Interconnects

Summary

  • This presentation demonstrates:
  • Creation of a 3D wiring structure using VICTORY Cell
  • Tetrahedral mesh generation required for arbitrary shaped 3D

structures

  • Self heating simulation capability for metals as well as

semiconductors using VICTORY Device

  • Coupled 3D Thermal-Electrical transient analysis using

VICTORY Device

  • 12 -
