Object-Oriented Design Lecture 13: Use Case Realizations Sharif - - PowerPoint PPT Presentation

Department of Computer Engineering

Object-Oriented Design

Lecture 13: Use Case Realizations

Sharif University of Technology 1

Analysis Workflow: Analyze a Use Case

• The analysis workflow consists of the following activities:
• Architectural analysis
• Analyze a use case
• Outputs:
• analysis classes
• use case realizations
• Analyze a class
• Analyze a package

Sharif University of Technology 2

Use Case Realizations

• Use case realizations show how instances of analysis classes

interact to realize the functional requirements specified by a use case.

• Each use case realization realizes exactly one use case.
• Use case realizations consist of:
• analysis class diagrams - these should "tell a story" about one (or more)

use cases;

• interaction diagrams - these demonstrate how objects interact to realize

the use case behavior;

• special requirements - you always uncover new requirements during use

case realization and you need to record these;

• use case refinement - you may need to change a use case as you begin to

realize it.

Sharif University of Technology 3

Lifelines

• A lifeline represents a participant in an interaction - how an instance of a

classifier participates in the interaction.

• Each lifeline has an optional name, a type, and an optional selector.
• Each lifeline is drawn with the same icon as its type.
• Underline the name, type, and selector to show actual instances .

Sharif University of Technology 4

Messages

• A message represents a specific kind of communication between two lifelines

in an interaction.

Sharif University of Technology 5

Interaction Diagrams

• Sequence diagrams - emphasize time-ordered sequence of

message sends.

• Communication diagrams - emphasize structural relationships

between objects.

• Interaction overview diagrams - emphasize relationships

between interactions.

• Timing diagrams - emphasize real-time aspects of interactions.

Sharif University of Technology 6

Sequence vs. Communication diagram

• Sequence Diagrams: show object interactions arranged in time

sequence, vertically

• Communication Diagrams: show object interactions arranged as a

flow of objects and their links to each other, numerically

• Semantically equivalent, structurally different
• Sequence diagram emphasize time ordering
• Communication diagrams make object linkages explicit

Sharif University of Technology 7

Sequence Diagrams: General Notation

• Time runs top to bottom.
• Lifelines run left to right:
• lifelines have dashed vertical tails that indicate the duration of the lifeline;
• lifelines may have activations to indicate when the lifeline has focus of

control;

• rganize lifelines to minimize the number of crossing lines.
• Place explanatory scripts down the left-hand side of the sequence

diagram.

• State invariants - place state symbols on the lifeline at the appropriate

points.

• Constraints - place constraints in {} on or near lifelines.

Sharif University of Technology 8

9

UML sequence diagrams

• sequence diagram: an "interaction diagram" that models a

single scenario executing in the system

• perhaps 2nd most used UML diagram (behind class diagram)
• relation of UML diagrams to others:
• CRC cards -> class diagram
• use cases -> sequence diagrams
• the axes in a sequence diagram:
• horizontal: which object/participant is acting
• vertical: time (down -> forward in time)

Sequence Diagrams: Realization Example 1

Sharif University of Technology 12

Sequence Diagrams: Realization Example 2

Sharif University of Technology 13

Sequence Diagrams: Realization Example 3

Use Case

Sharif University of Technology 14

Sequence Diagrams: Realization Example 3

Sequence Diagram

Sharif University of Technology 15

Combined Fragments

• Combined fragments - areas within a sequence diagram with

different behavior.

• The operator defines how its operands execute.
• The guard condition defines whether its operand executes.
• The operand contains the behavior.

Sharif University of Technology 16

Combined Fragments: Operators – opt and alt

• pt - there is a single operand that executes if the condition is true (like if ...

then).

• alt - the operand whose condition is true is executed.

Sharif University of Technology 17

Combined Fragments: Operators – opt and alt

Sharif University of Technology 18

Combined Fragments: Operators – loop and break

• loop - loop min, max [condition]
• loop or loop * - loop forever;
• loop n, m - loop (m – n + 1) times;
• loop [ booleanExpression ] - loop while booleanExpression is true;
• loop 1, * [ booleanExpression ] - loop once then loop while

booleanExpression is true;

• loop [for each object in collectionOfObjects] - execute the body of the

loop once for each object in the collection;

• loop [for each object in className] - execute the body of the loop once for

each object of the class.

• break - if the guard condition is true, the operand is executed, not

the rest of the enclosing interaction.

Sharif University of Technology 19

Combined Fragments: Operators – loop and break

Syntax

Sharif University of Technology 20

Combined Fragments: Operators – loop and break

Example

Sharif University of Technology 21

Combined Fragments: Operators – Other

• ref - the combined fragment refers to another interaction.
• par - all operands execute in parallel.
• critical - the operand executes atomically without interruption.
• seq - operands execute in parallel subject to the following constraint: events

arriving on the same lifeline from different operands occur in the same sequence as the operands occur.

• strict - the operands execute in strict sequence.
• neg - the operand shows invalid interactions.
• ignore -lists messages that are intentionally omitted from the interaction.
• consider -lists messages that are intentionally included in the interaction.
• assert - the operand is the only valid behavior at that point in the interaction.

Sharif University of Technology 22

23

Example sequence diagram

sd Example loop StoreFront Cart Inventory AddItem ReserveItem PlaceItemInOrder Checkout ProcessOrder ConfirmOrder

24

(De)centralized system control

• What can you say about the control flow of each of

the following systems?

• centralized?
• distributed?

Communication (aka Collaboration) Diagrams

• Communication diagrams - emphasize the structural aspects of an interaction:
• lifelines are connected by links;
• messages have a sequence number - they are numbered hierarchically according to

the nesting of the focus of control.

Sharif University of Technology 27

Communication (aka Collaboration) Diagrams

• Objects are rectangular icons
• e.g., Order Entry Window, Order, etc.
• Messages are arrows between icons
• e.g., prepare()
• Numbers on messages indicate sequence
• Also spatial layout helps show flow
• Which do you prefer: sequence or communication?
• Fowler doesn’t use communication diagrams
• Show flow clearly, but awkward modeling alternatives

Sharif University of Technology 28

Iteration

• Iteration - use an iteration specifier (*) and an optional iteration clause on

the message.

• The iteration clause specifies the number of times to loop.
• You can use natural language, pseudocode, source code, or sequence

diagram loop notation for the iteration clause.

• Iteration over a collection of objects:
• Denoted by showing the role name and multiplicity (>1) on the target

end of the link and prefixing the message with *.

• The message is sent to each object in turn.
• Use the parallel iteration specifier *// to indicate that messages are

executed in parallel.

Sharif University of Technology 29

Iteration - Example

Sharif University of Technology 30

Branching

• Branching - prefix messages with guard conditions. The message

executes if the guard condition is true.

• It can be hard to show branching clearly on a communication

diagram - for complex branching, use sequence diagrams instead.

Sharif University of Technology 32

Communication and Class Diagrams

• Links in a communication diagram directly correlate

to associations between classes in a class diagram

Interaction Occurrences

• Interaction occurrences: references to another interaction.
• The flow of the referenced interaction is included in the flow of the

referencing interaction.

• Parameters - interaction occurrences may have parameters - use normal

parameter notation.

• Gates - inputs and outputs of interactions:
• a point on the sequence diagram frame that connects a message
• utside the frame to a message with the same signature inside the

frame.

• Use parameters when you know the source and destination of all

messages - use gates when you don't.

Sharif University of Technology 36

Interaction Occurrences – Example

Use Case and Class Diagram

Sharif University of Technology 37

Interaction Occurrences – Example

SDs

Sharif University of Technology 38

Interaction Occurrences – Parameters

Sharif University of Technology 39

Interaction Occurrences – Gates

Sharif University of Technology 40

Communication Diagram Overview

Sharif University of Technology 41

Sequence Diagram Overview

Sharif University of Technology 42

Reference

• Arlow, J., Neustadt, I., UML 2 and the Unified Process: Practical Object-

Oriented Analysis and Design, 2nd Ed. Addison-Wesley, 2005.
