Network Security Fundamentals Security Training Course Dr. Charles J. Antonelli The University of Michigan 2013 Network Security Fundamentals Module 6 Firewalls & VPNs Topics Firewall Fundamentals Case study: Linux iptables

slide-1
SLIDE 1

Network Security Fundamentals

Security Training Course

  • Dr. Charles J. Antonelli

The University of Michigan 2013

slide-2
SLIDE 2

Network Security Fundamentals

Module 6 Firewalls & VPNs

slide-3
SLIDE 3

Topics

  • Firewall Fundamentals
  • Case study: Linux iptables
  • Virtual Private Networks (VPNs)

3 04/13 cja 2013

slide-4
SLIDE 4

Firewalls

04/13 4 cja 2013

slide-5
SLIDE 5

Firewalls

5 04/13 cja 2013

slide-6
SLIDE 6

Firewalls

  • A firewall limits the extent to which hosts
  • n different networks can interact with
  • ne another

6 04/13 cja 2013

slide-7
SLIDE 7

Types of firewalls

  • Packet level
  • Application level
  • Host-based

7 04/13 cja 2013

slide-8
SLIDE 8

Packet level firewalls

  • Firewall inspects incoming packets
  • Blocks packets violating policy rules
  • => packets dropped without

acknowledgement

  • Rules allow blocking based on
  • Source and destination IP address
  • Source and destination port
  • Protocol, flags, TOS, …

8 04/13 cja 2013

slide-9
SLIDE 9

Statelessness

  • Traditional packet level firewalls treated every

packet independently

  • Stateless firewalling
  • Problem
  • Doesn’t relate packet information to overall packet

flow

  • Doesn’t remember anything
  • Results in coarse-grained control
  • Forces overly liberal or conservative policies

9 04/13 cja 2013

slide-10
SLIDE 10

Example

  • H.323 video streaming protocol
  • Initiates two TCP connections and several

RTP (real-time transport protocol) streams

  • The RTP streams contain no information

relating them to the H.323 application

  • How should a stateless firewall decide if

these streams are to be blocked?

10 04/13 cja 2013

slide-11
SLIDE 11

Example

  • IP Fragmentation
  • All but the first fragment don’t specify ports

11 04/13 cja 2013

slide-12
SLIDE 12

Statefulness

  • Solution: firewall keeps state about

recent packet flows

  • Decides to block packet based on packet

contents plus stored state

  • More fine-grained control
  • Obviates application-level firewalls
  • Problem
  • All that state consumes firewall resources

12 04/13 cja 2013

slide-13
SLIDE 13

Canonical firewalled network

13 04/13 cja 2013

slide-14
SLIDE 14

Zones Collection of networks with specified security properties

  • Perimeter
  • DMZ
  • Wireless
  • Intranet

14 04/13 cja 2013

slide-15
SLIDE 15

Perimeter zone The outside world

  • Untrusted zone
  • No control over hosts in this zone
  • Internet rules

15 04/13 cja 2013

slide-16
SLIDE 16

DMZ

Demilitarized zone

  • Contains an organization’s publicly

visible services (email, Web, DNS, FTP, …)

  • Hardened hosts
  • Proxies
  • Semi-trusted zone

16 04/13 cja 2013

slide-17
SLIDE 17

Intranet zone

  • Most trusted zone
  • Organizational assets placed here
  • Access blocked from untrusted zones
  • Access via proxies in the DMZ only

17 04/13 cja 2013

slide-18
SLIDE 18

Wireless zone A perimeter zone!

  • Untrusted hosts
  • Semi-trusted network

18 04/13 cja 2013

slide-19
SLIDE 19

Application-level firewalls

Application proxy server

  • Accepts client traffic
  • Maintains state, validates traffic
  • Passes validated traffic to server

19 04/13 cja 2013

slide-20
SLIDE 20

Application-level firewalls

  • Firewall worries about security
  • Obviates security-related server changes
  • Hampers defense-in-depth
  • Firewall must understand application

protocol

  • Increased complexity
  • Stateful packet-level firewalls are an

alternative

20 04/13 cja 2013

slide-21
SLIDE 21

Host-based firewalls

  • Firewall run on individual hosts
  • Placed between incoming packets and

the host network stack

  • Acts like a packet-level firewall

21 04/13 cja 2013

slide-22
SLIDE 22

Host-based firewalls

  • Each host requires policy management
  • Administration headache
  • Simple default policies in distributions
  • Defense-in-depth

22 04/13 cja 2013

slide-23
SLIDE 23

References

  • The Tao of Network Security Monitoring,

Richard Bejtlich, Addison-Wesley, 2005. ISBN 0-321-24677-2

  • Information Security Illuminated, Michael

G.Solomon and Mike Chapple, Jones and Bartlett, 2005.

  • http://en.wikipedia.org/wiki/Firewall_(computing)

(accessed March 2013)

23 04/13 cja 2013

slide-24
SLIDE 24

iptables

04/13 24 cja 2013

slide-25
SLIDE 25

IP Tables

  • Linux packet-level firewall
  • Successor to IP Chains
  • NAT/NAPT support
  • Extended functionality via modules
  • Stateful filter support
  • Applications
  • Host based firewall
  • Stateful packet firewall

 net.ipv4.ip_forward=1 in /etc/sysctl.conf

25 04/13 cja 2013

slide-26
SLIDE 26

IP Tables Architecture

  • Three tables for organization
  • filter, nat, mangle
  • Each table contains several chains
  • built-in (invoked at fixed points in network layer)
  • user-defined
  • Each chain contains several rules
  • first rule matched determines action taken
  • Each rule contains matching criteria and target
  • Built-in chains have policies
  • specifies default target if no rule in chain matches

26 04/13 cja 2013

slide-27
SLIDE 27

Rules

  • (Standard) matching criteria
  • protocol
  • source IP (address/mask)
  • dest IP (address/mask)
  • port (source/dest/both)
  • interface (input/output)
  • Target

27 04/13 cja 2013

slide-28
SLIDE 28

Rules

  • Extended matching criteria
  • Implemented via modules
  • Connection state matching
  • INVALID

 packet not associated with any connection

  • NEW

 packet is starting a new connection

  • ESTABLISHED

 packet is associated with existing connection

  • RELATED

 packet is starting a new connection, but is associated with an existing connection

» FTP DATA, ICMP error

  • Several other extended matching criteria

28 04/13 cja 2013

slide-29
SLIDE 29

Predefined targets

  • All terminate processing in this chain for this

packet

  • ACCEPT

 accept packet for processing

  • DROP

 drop packet

  • QUEUE

 pass packet to userland (not common)

  • RETURN

 return to calling chain (use policy if no calling chain)

29 04/13 cja 2013

slide-30
SLIDE 30

Extended targets

  • Both terminating and non-terminating

targets

  • REJECT (terminating)

 return packet indicating error

  • LOG (non-terminating)

 generate log entry

  • …

30 04/13 cja 2013

slide-31
SLIDE 31

filter table

  • Default table
  • Built-in chains
  • INPUT

 incoming network packets

  • FORWARD

 packets being routed by the host

  • OUTPUT

 locally-generated packets output to network

31 04/13 cja 2013

slide-32
SLIDE 32

nat table

  • For network address translation
  • Built-in chains
  • PREROUTING (DNAT)

 alter packets as they arrive

  • OUTPUT

 alter locally-generated packets before routing

  • POSTROUTING (SNAT)

 alter packets as they depart

32 04/13 cja 2013

slide-33
SLIDE 33

mangle table

  • For specialized packet changes
  • change TOS/DSCP header
  • set netfilter mark value
  • …
  • Built-in chains
  • PREROUTING
  • INPUT
  • OUTPUT
  • FORWARDING
  • POSTROUTING

33 04/13 cja 2013

slide-34
SLIDE 34

Firewall traversal

34

Prerouting Route Postrouting Forward Output Local Input

04/13 cja 2013

slide-35
SLIDE 35

Firewall Traversal

35

Rob Mayoff

04/13 cja 2013

slide-36
SLIDE 36

Some caveats

  • iptables and ipchains don’t mix
  • rule additions are atomic
  • … rule set additions are not
  • avoid leaving firewall open while editing
  • … use DROP, DENY, REJECT policies
  • policy actions do not log
  • rules are not removed when an interface goes

down

  • raw sockets are unaffected by rules

36 04/13 cja 2013

slide-37
SLIDE 37

iptables lab

  • Examine iptables man page
  • man iptables
  • Examine existing firewall settings
  • sudo service iptables status
  • sudo iptables -L
  • Add firewall rules
  • sudo iptables -I …

37 04/13 cja 2013

slide-38
SLIDE 38

Virtual Private Networks (VPNs)

04/13 38 cja 2013

slide-39
SLIDE 39

Roadmap

  • Definition
  • VPN Uses
  • Types of VPNs
  • Protocol Details

39 04/13 cja 2013

slide-40
SLIDE 40

Definition

A VPN is a link over a shared public network, typically the Internet, that simulates the behavior of dedicated WAN links over leased lines. A VPN uses encryption to authenticate the communications endpoints and to secure your data as it travels over an insecure network .

40 04/13 cja 2013

slide-41
SLIDE 41

VPN motivators

  • Confidentiality, Integrity & Authentication
  • Encryption
  • Bypass blocks
  • Border
  • Local ISP
  • Extends the office network
  • VoIP
  • Drive mapping
  • Collaboration
  • Enabling technology

41 04/13 cja 2013

slide-42
SLIDE 42

Some VPNs

  • Protocol
  • IPSec

 Standards-based  Varied Encryption Levels  Flexible

  • SSL

 Clientless (Web Browser)

  • Application
  • SSH

VPN is not a single solution

42 04/13 cja 2013

slide-43
SLIDE 43

IPSec Details

IPSec protocol

  • Internet Standard
  • Two complementary protocols
  • Authentication Headers (AH)

Prevents tampering with packet headers

  • Encapsulating Security Protocol (ESP)

Provides confidentiality and integrity of packet contents

43 04/13 cja 2013

slide-44
SLIDE 44

IPSec Details – AH

(Protocol 51)

  • AH Transport – Used to authenticate the integrity of the datagram

All Authenticated (except non mutable fields), e.g., TTL

As the entire packet is authenticated, there are some limitations. If using NAT or a firewall where a gateway changes your address, then the packet will fail to authenticate at the far end as the source IP has changed. This is not to say that you cannot use IPSec with a NAT gateway, just that the Gateway will have to be considered the endpoint.

44

IP Header (with

  • ptions)

A H Transport Layer Header Transport Layer Data

04/13 cja 2013

slide-45
SLIDE 45

IPSec Details – ESP

(Protocol 50)

  • Encapsulation Security Payload
  • ESP will encrypt the payload so that it is private as it passed through

the network

  • As you can note, the ESP authentication does not authenticate the IP

header so this does not have a problem with working behind NAT. 45

IP Header (with options) ESP Header Transport Layer Header Transport Layer Data ESP Trailer ESP

Authentication Encrypted Authenticated

04/13 cja 2013

slide-46
SLIDE 46

Logical Connection to VPN Concentrator

Remote Access client (Split Tunnel )

Public Network

Ethernet

C I S C O S Y S T E M S

Cisco 3030

Ethernet

ARBL COOL ARBL COOL 141 .211.255.196 192.168.4.6 Pool 192.168.4.10 – 192.168.7.249

UM Backbone

Tunneled

Yahoo

Pool 141.211.12.10 – 141.211.12.250 Wireless User (non-split tunnel) Internal Server

46 04/13 cja 2013
