Network Security Fundamentals Security Training Course Dr. Charles J. Antonelli The University of Michigan 2013 Network Security Fundamentals Module 9 Linux Security & Logging Linux Security Real-World Linux Security RHEL

slide-1
SLIDE 1

Network Security Fundamentals

Security Training Course

  • Dr. Charles J. Antonelli

The University of Michigan 2013

slide-2
SLIDE 2

Network Security Fundamentals

Module 9 Linux Security & Logging

slide-3
SLIDE 3

Linux Security

  • Real-World Linux Security
  • RHEL Security Guides
  • Logging

3 04/13 cja 13

slide-4
SLIDE 4

Real-World Linux Security

slide-5
SLIDE 5

Real-World Linux Security

The seven deadly sins

  • Weak/default passwords
  • Open network ports
  • Old software versions
  • Insecure programs
  • Insufficient resources
  • Stale/unnecessary accounts
  • Procrastination

5 04/13 Bob Toxen, “Real World Linux Security: intrusion detection, prevention, and recovery,” 2nd Ed., Prentice-Hall 2003. cja 13

slide-6
SLIDE 6

Turn off insecure passwords

  • Use SHA-512 & passphrases
  • Password hashes in /etc/shadow should

start with $6$

  • Maximum password length is 256 characters
  • Use /etc/shadow
  • Both defined by default

6 04/13 cja 13

slide-7
SLIDE 7

Prevent ARP Cache Poisoning

  • Prevent ARP entries from being spoofed

by making them permanent

  • add known ARP entries to /etc/ethers
  • add following to /etc/rc.d/rc.local

 arp -f /etc/ethers  entries read from file are marked permanent

  • Use network switch port configurations

7 04/13 cja 13

slide-8
SLIDE 8

arp

  • /sbin/arp command
  • w/o args, displays contents of ARP cache
  • -a

show all cache entries

  • -d h

delete entry for host h

  • -s h e set permanent entry for host h with layer 2

address e

  • -s h e temp

set temporary entry for host h with layer 2 address e

  • -f f

read (default permanent) entries from file f

  • -n

don’t convert host addresses to names

8 04/13 cja 13

slide-9
SLIDE 9

arping

  • Similar to ping, but uses ARP requests

and replies for probing

  • Doesn’t require sender to have a IP address
  • Limited to local subnet, unless proxy ARP

04/13 9 cja 13

slide-10
SLIDE 10

arping

  • /sbin/arping destination
  • w/o args, displays usage
  • -I i

use interface i (required)

  • -b

use only Layer 2 broadcasts

  • -s s

use source address s

  • -U

unsolicited ARP

  • -D

detect duplicate IP addr (RFC 2131)

10 04/13 cja 13

slide-11
SLIDE 11

arpwatch

  • Monitors ARP traffic
  • Detects Layer 2 / Layer 3 address pairing changes
  • Records to syslog
  • Emails to administrator
  • Changes detected
  • New station – new pairing using previously unseen layer 2 address
  • New activity – new pairing using previously seen layer 2 address
  • Flip flop – layer 2 address changed in existing pairing
  • Changed ethernet address – layer 2 address changed on host

04/13 11 cja 13

slide-12
SLIDE 12

arpwatch lab

  • Look at man page
  • man arpwatch
  • Display syslog messages
  • Start another terminal window
  • sudo tail –f /var/log/messages
  • Edit config file
  • sudo vi /etc/sysconfig/arpwatch
  • Insert “-i ethN” into OPTIONS if needed, adjust others as necessary
  • (Optional) set arpwatch to start on boot
  • chkconfig –list arpwatch
  • chkconfig arpwatch on
  • chkconfig --list arpwatch
  • Start arpwatch
  • sudo service arpwatch start
  • You should see eth2 entering promiscuous mode in the syslog
  • Generate some ARP traffic
  • Empty, then list your ARP cache
  • You should see something like the following in the log (and in an email message, if you’ve set that up)

Apr 21 16:10:58 localhost arpwatch: new station 172.16.234.2 0:50:56:e7:f7:34

  • No output? Get arpwatch to forget:
  • sudo service arpwatch stop
  • sudo cp /dev/null /var/lib/arpwatch/arp.dat
  • sudo service arpwatch start

12 04/13 cja 13

slide-13
SLIDE 13

RHEL Security Guides

  • Canonical step-by-step guide
  • Security overview
  • Attackers and Vulnerabilities
  • Security Updates
  • Workstation Security
  • Server Security
  • Virtual Private Networks
  • Firewalls
  • Vulnerablity Assessment
  • Intrusion Detection
  • Incident Response

13 04/13 cja 13

slide-14
SLIDE 14

Security Guides

  • Three guides:
  • http://www.nsa.gov/ia/_files/os/redhat/rhel5-guide-

i731.pdf

  • http://people.redhat.com/sgrubb/files/hardening-

rhel5.pdf

  • http://docs.redhat.com/docs/en-US/

Red_Hat_Enterprise_Linux/6/pdf/Security_Guide/ Red_Hat_Enterprise_Linux-6-Security_Guide-en- US.pdf

14 04/13 cja 13

slide-15
SLIDE 15

Logging

slide-16
SLIDE 16

Roadmap

  • Motivation
  • Challenges
  • Syslog
  • Centralized Logging
  • Log reduction
  • Swatch, logwatch

16 04/13 cja 13

slide-17
SLIDE 17

Motivation

  • Administration & debugging
  • Detect & analyze security & performance

incidents

  • Auditing
  • Regulatory requirements
  • HIPAA, SOX, PCI, GLBA, …

17 04/13 cja 13

slide-18
SLIDE 18

Example

Jan 2 16:19:23 host.example.com snort [1260]: RPC Info Query: 10.2.3.4 -> host.example.com:111 Jan 2 16:19:31 host.example.com snort [1260]: spp_portscan: portscan status from 10.2.3.4: 2 connections across 1 hosts: TCP(2), UDP(0)

18 04/13 cja 13

slide-19
SLIDE 19

Example

Jan 02 16:19:45 host.example.com rpc.statd[351]: gethostbyname error for ^X÷ÿ¿^X÷ÿ¿^Y÷ÿ¿^Y÷ÿ¿^Z÷ÿ¿^Z÷ÿ¿^[÷ÿ¿^[÷ÿ¿bffff750 8 0 4 9 7 1 0 9 0 9 0 9 0 9 0 6 8 7 4 6 5 6 7 6 2 7 4 7 3 6 f 6 d 6 1 6 e 7 9 7 2 6 5 2 0 6 5 2 0 7 2 6 f 7 2 2 0 7 2 6 f 6 6 b f f f f 7 1 8 bffff719 bffff71a b f f f f 7 1 b _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ! _ _ ! _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

19 04/13 cja 13

slide-20
SLIDE 20

Example

  • Jan 02 16:20:25 host.example.com

adduser[12152]: new user: name=cgi, uid=0, gid=0, home=/home/cgi, shell=/bin/ bash

  • Jan 02 16:22:02 host.example.com

PAM_pwdb[12154]: password for (cgi/0) changed by ((null)/0)

20 04/13 cja 13

slide-21
SLIDE 21

Challenges

  • Log generation & storage
  • Log CIA
  • Log analysis

21 04/13 cja 13

slide-22
SLIDE 22

CEE - Coming soon?

Common Event Expression

  • Standardizes the way computer events are described,

logged, and exchanged

  • Create an event expression taxonomy for uniform and precise

log definitions that lead to a common event representation.

  • Create logging syntax utilizing a single data dictionary to

provide consistent event specific details.

  • Standardize flexible event transport mechanisms to support

multiple environments.

  • Propose log recommendations for the events and attributes

devices generate.

  • http://cee.mitre.org/language/1.0-beta1/overview.html
  • (August, 2012)

22 04/13

cja 13

slide-23
SLIDE 23

syslog

  • UNIX/Linux logging daemon
  • facility (origin) & priority (importance)
  • log entry accepted by daemon
  • logged according to config file
  • Windows third-party tools
  • Windows event log -> syslog

 http://www.eventreporter.com/  http://www.winagents.com/

  • syslog -> Windows

 http://www.winsyslog.com/en/

23 04/13 cja 13

slide-24
SLIDE 24

syslog

  • LogAnalyzer (née phpLogCon)
  • Front end for searching, reviewing and analyzing event data
  • Data sources

 syslog, rsyslog, WinSyslog log files  MySQL databases

» Adiscon MonitorWare, php-syslog-ng schemas

 Any LF-delimited file  Multiple instances

  • Data display

 GUI controls: scroll, search, tooltip, …

  • http://loganalyzer.adiscon.com/

24 04/13

cja 13

slide-25
SLIDE 25

syslog

  • Splunk
  • Indexes log file data, also config files, arbitrary script output
  • Data sources

 syslog, rsyslog, WinSyslog log files  Config files  Arbitrary script outputs  Multiple instances

  • Indexes data

 Free for indexing up to 500 MB/day

  • Data display

 GUI controls: scroll, search, tooltip, …

  • http://www.splunk.com/

25 04/13

cja 13

slide-26
SLIDE 26

rsyslog

  • The reliable & extended Linux logging daemon
  • Upward-compatible with syslogd
  • Provides reliable remote logging

 TCP – ubiquitous, uses reliable connection  RELP- queues locally until loghost accessible

  • man rsyslogd
  • man 5 rsyslog.conf
  • /etc/rsyslog.conf

26 04/13 cja 13

slide-27
SLIDE 27

rsyslog basic lab

  • Edit log destination
  • sudo vi /etc/rsyslog.conf
  • Add line under RULES section

*.debug,mark.debug /var/log/fulllog

  • Tell syslog to re-read config file
  • sudo service rsyslog restart
  • Test the syslog
  • logger ‘Hello, world!’

27 04/13

cja 13

slide-28
SLIDE 28

centralized logging lab

  • Your instructor will provide the identity of a

central logging host

  • pst.merit.edu
  • Edit local /etc/rsyslog.conf
  • Add forwarding rule with remote host

*.* @pst.merit.edu

  • Tell local syslog to re-read config file
  • sudo service rsyslog restart
  • Test with logger

28 04/13 cja 13

slide-29
SLIDE 29

Relay Architecture

29 04/13 cja 13

slide-30
SLIDE 30

Log Reduction

  • Make three piles
  • ignore - don’t want to see these, ever
  • baseline - aren’t likely to contain time-critical

security information

  • investigate - those that do

30 04/13 cja 13

slide-31
SLIDE 31

Log Reduction

  • A simple first step
  • cut -f5- -d\ /var/log/fulllog | sed -e ‘s/[0-9]

[0-9]*/###/g’| sort | uniq -c | sort -nr

  • Use script in /usr/local/lab/syslog/reduce

31 04/13 cja 13

slide-32
SLIDE 32

Baselining I

  • Construct a baseline
  • Measure set of known data to compute range of

“normal” values

  • Examples

 Network traffic by protocol  Logins/logouts  Accesses of admin accounts  DHCP address management  DNS requests  Amount of log data/day  Number of processes running

32 04/13 cja 13

slide-33
SLIDE 33

Baselining II

  • Compare against baseline
  • Anomaly detection

 detecting things you haven’t seen before

  • Thresholding

 identifying data that exceed a given baseline

  • Windowing

 detecting events within a given time period

33 04/13 cja 13

slide-34
SLIDE 34

Log parsing tools

  • swatch
  • logwatch

34 04/13 cja 13

slide-35
SLIDE 35

swatch lab

  • Examine man page
  • man swatch
  • Copy sample rule
  • cp /usr/local/lab/swatch/sample.swatchrc ~lab/.swatchrc
  • Examine sample rule
  • Start swatch
  • sudo swatch -c ~lab/.swatchrc
  • Trigger swatch
  • Start a new terminal window
  • logger ‘Hello, World!’
  • Experiment with different rules

35 04/13 cja 13

slide-36
SLIDE 36

log parsing lab

  • Examine man page
  • man logwatch
  • Examine config and service files
  • System-wide

/usr/share/logwatch/default.conf/logwatch.conf /usr/share/logwatch/scripts/services

  • Locally-configured

/etc/logwatch/conf/logwatch.conf /etc/logwatch/scripts/services

  • Perform log parse
  • /usr/sbin/logwatch --print [--service

sendmail] [--range all] [--archives]

36 04/13 cja 13

slide-37
SLIDE 37

Maintaining log files

  • Log files expand to fill available space
  • Control by rotation
  • switch over to a new log file periodically
  • overwrite oldest log file
  • logrotate
  • needs logging facility’s cooperation

 /sbin/killall -HUP facility  copytruncate

  • man logrotate
  • /etc/logrotate.conf
  • /etc/logrotate.d/

37 04/13 cja 13

slide-38
SLIDE 38

log analysis lab

  • Enable httpd
  • sudo yum install php
  • sudo service httpd start
  • Install LogAnalyzer (1)
  • wget

http://download.adiscon.com/loganalyzer/loganalyzer-3.0.4.tar.gz

  • tar zxf loganalyzer-3.0.4.tar.gz
  • cd loganalyzer-3.0.4
  • less Install

38 04/13 cja 13

slide-39
SLIDE 39

log analysis lab

  • Install LogAnalyzer (2)
  • sudo cp -r src/* /var/www/html
  • sudo touch /var/www/html/config.php
  • sudo chmod 666 /var/www/html/config.php
  • sudo chcon -hR -t httpd_sys_script_rw_t /var/www/html
  • Install LogAnalyzer (3)
  • sudo setfacl -m u:apache:r /var/log/messages
  • wget http://www-personal.umich.edu/~cja/LPS10/supp/lpspol_log.te
  • checkmodule -M -m -o lpspol_log.mod lpspol_log.te
  • semodule_package -o lpspol_log.pp -m lpspol_log.mod
  • sudo semodule -i lpspol_log.pp

39 04/13 cja 13

slide-40
SLIDE 40

log analysis lab

  • Install LogAnalyzer (4)
  • Browse to http://localhost/
  • Click the word “here” in the Critical Error Notice
  • Accept all defaults except:

 Step 7 – Set Syslog file to /var/log/messages

  • Install LogAnalyzer (5)
  • sudo chmod 644 /var/www/html/config.php
  • sudo restorecon -R /var/www/html
  • Run LogAnalyzer!
  • Browse to http://localhost/
  • When done with lab:
  • sudo setfacl -b /var/log/messages

40 04/13 cja 13

slide-41
SLIDE 41

References

  • “Real World Linux Security: intrusion detection, prevention, and recovery,” 2nd Ed., Bob Toxen, Prentice-Hall

2003.

  • http://www.nsa.gov/ia/_files/os/redhat/rhel5-guide-i731.pdf
  • http://people.redhat.com/sgrubb/files/hardening-rhel5.pdf
  • http://docs.redhat.com/docs/en-US/Red_Hat_Enterprise_Linux/6/pdf/Security_Guide/

Red_Hat_Enterprise_Linux-6-Security_Guide-en-US.pdf

  • “Guide to the Secure Configuration of Red Hat Enterprise Linux 5,” Revision 3, National Security Agency,

October 21, 2009. http://www.nsa.gov/ia/_files/os/redhat/rhel5-guide-i731.pdf (accessed April 2010)

  • Abe Singer and Tina Bird, “Building a Logging Infrastructure,” USENIX Association, ISBN 1-931971-25-0,

2004.

  • The SANS 2007 Log Management Market Report

http://www.sans.org/reading_room/analysts_program/LogMgt_June07.pdf (accessed April 2010)

  • Common Event Expression (Anton Chuvakin, cee@mitre.org)

http://cee.mitre.org/docs/Common_Event_Expression_White_Paper_June_2008.pdf (accessed April 2010)

  • Karen Kant and Murugiah Souppaya,

“Guide to Computer Security Log Management," NIST Publication 800-92, September 2006.

  • LogAnalyzer Documentation, http://loganalyzer.adiscon.com/doc/manual.html (accessed April 2011).

41 04/13 cja 13
