MONITORING OF WASTE AND FORMATION WATERS USING RAMAN SPECTROSCOPY AND ARTIFICIAL NEURAL NETWORK K.A. Laptinskiy, S.A. Burikov, T.A. Dolenko, A.O. Efitorov, and S.A. Dolenko Human impact on the environment 3rd Student Workshop on Ecology and

SLIDE 1

MONITORING OF WASTE AND FORMATION WATERS USING RAMAN SPECTROSCOPY AND ARTIFICIAL NEURAL NETWORK

K.A. Laptinskiy, S.A. Burikov, T.A. Dolenko, A.O. Efitorov, and S.A. Dolenko

SLIDE 2

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Human impact on the environment

SLIDE 3

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Problem

?

SLIDE 4

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Problem

?

Express
Remote
Providing both quantitative

and qualitative results

Non contact

SLIDE 5

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Solution

Raman Spectroscopy

SLIDE 6

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Basics of Raman spectroscopy

SLIDE 7

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Raman spectra of aqueous salt solutions

400 800 1200 1600 0.00 0.02 0.04 0.2 0.4 0.6 0.8 Intensity, arb. un.

Wavenumber, cm-1

water KNO3 - 1 M Li2SO4 - 1M 1049 cm

N-O 982 cm

S-O 2800 3000 3200 3400 3600 3800 0.0 0.2 0.4 0.6 0.8 1.0 1.2 Intensity, arb. un. Wavenumber, cm-1 water CsI - 2M NaCl, NH4Br, Li2SO4 - 0.4 M, KNO3 and CsI - 0.6 M

1000 1500 2000 2500 3000 3500 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4

SLIDE 8

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Artificial neural networks

Raman spectrum

f the salt

solution Concentration

f the salt in

solution

SLIDE 9

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017

Our team…

…waits for

YOU

n the poster

session

SLIDE 10

3rd Student Workshop on Ecology and Optics of Coastal Zones, 2017
