Material Acceptance Requirements for Battery Energy Storage Systems

Alan Price, PE Director, Office of Technical Certification and Research NYC Department of Buildings

build safe | live safe 2

Battery Energy Storage Systems

• What is a Battery Energy Storage System?

– A battery energy storage system (battery ESS) stores energy through an electrochemical process for later use to supply the utility or local grids. – Other energy storage systems (ie flywheels) are not addressed in this presentation.

• Applications for Battery ESS’s

– Uses include peak shaving applications, storage with renewable energy systems, etc.

build safe | live safe 3

Battery Safety Concerns

Source: DailyMail.com, Philadelphia Airport, February 2006 Source: Aircraft Interiors.com, July 22, 2015 Source: NBC29.com.com, December 14, 2015

build safe | live safe 4

Battery Safety Concerns

• Other Safety Concerns:

– Ventilation – Explosion – Off Gassing

build safe | live safe 5

Code Requirements

• Alternative to the Code. Battery ESS’s are

alternative systems in accordance with 28-113.2.2.

• Material Acceptance. Evaluations are performed

under site-specific review only

– OTCR2 Site-specific Application – Supporting documentation (checklist)

• Applications. Interior and exterior applications

build safe | live safe 6

Material Acceptance

FDNY Review* Sustainability Boards Review* OTCR Site-specific Review Material Acceptance

* OTCR Coordinates all reviews

OTCR Site-specific Review

build safe | live safe 7

Material Acceptance

OTCR Site-specific Review

• Site-specific Application.

– Applicants submit OTCR2 form. – OTCR Checklist supporting documents

• OTCR evaluates safety and performance issues

build safe | live safe 8

Material Acceptance

OTCR Site-specific Review

• Checklist items, including:

– Listing certification (UL 1973, UL 1741) – Code Analysis (Ventilation, room separation, fire suppression, etc) – Risk Analysis (address hazard mitigation) – Maintenance procedures – System monitoring – Signage

build safe | live safe 9

Material Acceptance

FDNY Review

• Applicants should contact Technology

Management

• Review includes Hazmat evaluation

build safe | live safe 10

Material Acceptance

Sustainability Boards Review

• Battery ESS review required by BSB and IRB

– BSB/Buildings Sustainability Board (Technical) – IRB/Innovation Review Board (Policy) – Exception: some battery chemistries no longer require BSB/IRB review (VRLA, Lithium-Ion)

• Applicant presents at joint BSB/IRB meeting
• BSB/IRB issue recommendations

build safe | live safe 11

Material Acceptance Criteria

OTCR coordinates all evaluations:

• OTCR satisfactory evaluation
• FDNY Letter of No Objection
• Letter of Recommendations from BSB and IRB

build safe | live safe 12

Permitting

In addition to material acceptance requirements:

• Permitting requirements:

– Construction permit, if applicable – Electrical permit

• Construction document approval/permit

issued at the local borough/hub.

• Material acceptance is required for project

sign-off.

build safe | live safe 13

Inspections

• Special inspections required

– SIA required for applicable installations on the construction permit – TR1 Form completed by SIA

build safe | live safe 14

OTCR Contact Info

Office of Technical Certification and Research (OTCR) 280 Broadway, 7th Floor New York, NY 10007 Attn: Alan Price, Director, OTCR

• tcr@buildings.nyc.gov
