Ni-MH battery for embedded systems Battery technologies When a new battery technology is introduced on the market, it does not kill the other battery technologies. Because it comes with new benefits, but also with some weakness.

slide-1
SLIDE 1

Ni-MH battery for embedded systems

slide-2
SLIDE 2

Battery technologies

2

  • When a new battery technology is introduced on the market, it does not

« kill » the other battery technologies.

  • Because it comes with new benefits, but also with some weakness.
  • The best battery technology does not exist. For each particular

application, we have to identify the more relevant battery technology.

  • Today, the oldest battery technology (Lead-acid) is the 1st one in term of

sales.

ARTS Energy Confidential & Proprietary

  • Feb. 2019
slide-3
SLIDE 3

Battery technologies

3

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Lead-acid Li-ion Ni-MH

pros

Price is much lower vs

  • ther battery

technologies. High energy density.

  • 40°C to +85°C.

2000 to 5000 cycles at 100% DOD. Non-flammable.

cons

Discharge at low T°C. Life duration reduced significantly above 45°C. T°C > 60°C. Charge below 0°C. flammable Purchasing price (but TCO is attractive).

Used for …

Applications not so much demanding (performances). Mobile applications. Indoor. Outdoor applications. Strong and deep cycling. Demanding applications.

slide-4
SLIDE 4

Ni-MH battery technology

4

  • Ni-MH is not well-known because it is used in professional applications:

 Lead-acid is known because of the car battery  Li-ion is known because of the smart phone and portable computer battery

  • But Ni-MH is known and appreciated for its robustness by battery experts.

 Used since 20 years inside the Toyota Prius  Used in the Middle-East for solar autonomous devices  More and more used in aviation (safety)

ARTS Energy Confidential & Proprietary

  • Feb. 2019
slide-5
SLIDE 5

ARTS Energy Ni-MH range

5

ARTS Energy Confidential & Proprietary

  • Feb. 2019

VH series VHT series ecolife MH series Low temperature series Very High Power series Benefit 1

High energy density Very large temperature range (-40°C to +85°C) Very large temperature range (-40°C to +85°C) A size Very fast charge

Benefit 2

  • Safety. No

transportation constraints 5 to 10 years life In extreme climates > 10 years life In extreme climates. Intense cycling. Low temperature Low Self Discharge Very high power

slide-6
SLIDE 6
  • Feb. 2019

6

VH series

ARTS Energy Confidential & Proprietary

High energy density

slide-7
SLIDE 7

Ni-MH VH series

7

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Features

High energy density.

  • +50% vs Ni-MH VHT series.

Non-flammable (aqueous electrolyte).

  • No transportation constraints.

Benefits

Interesting solutions when a flammable battery is not considered.

We support you for charge management.

BMS available for SOC, SOH.

Cell product range Battery product range

Ni-MH VH series AA AA Cs D F

1,5 Ah 1,7 Ah 3,2 Ah 9,5 Ah 15 Ah

slide-8
SLIDE 8

Ni-MH VH series

8

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Wi-Fi inside airplanes Transportation (helicopters) of premature baby Security robot (airplanes)

slide-9
SLIDE 9
  • Feb. 2019

9

VHT series

ARTS Energy Confidential & Proprietary

Very large temperature range 5 – 10 years life

slide-10
SLIDE 10

Ni-MH VHT series

10

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Features

Very large temperature range.

  • 40°C to +85°C battery temperature

Long life duration.

  • 5 to 10 years in extreme climates

Benefits

Exceptional robustness in extreme temperatures.

We support you for charge management.

BMS available for SOC, SOH.

Cell product range Battery product range

Ni-MH VHT series AA AA Cs

7/5 Cs

D D F F

0,8 Ah 1,1 Ah 2 Ah 4 Ah 6 Ah 8 Ah 10 Ah 13 Ah

slide-11
SLIDE 11

Life duration @ +50°C permanent

11

ARTS Energy Confidential & Proprietary

  • Feb. 2019

10 000 cycles @ +50°C permanent

slide-12
SLIDE 12

Ni-MH VHT series

12

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Solar tracker (containers, oil & gas platform, security) E-call system E-mobility

slide-13
SLIDE 13
  • Feb. 2019

13

ecolife MH series

ARTS Energy Confidential & Proprietary

Very large temperature range Large & deep cycling > 10 years life

slide-14
SLIDE 14

Ni-MH ecolife MH series

14

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Features

Very large temperature range.

  • 40°C to +85°C battery temperature

Very long life duration.

  • > 10 years in extreme climates

Benefits

Exceptional robustness in extreme temperatures. Large cycling capabilities (more than 10 000 cycles @ 50% DOD) .

Cell product range Battery product range

ecolife MH series AA Cs 0,8 Ah 1,6 Ah

slide-15
SLIDE 15

Performances in back up applications

15

ARTS Energy Confidential & Proprietary

  • Feb. 2019

More than 10 years life @ 40°C permanent

slide-16
SLIDE 16

Performances in back up applications

16

ARTS Energy Confidential & Proprietary

  • Feb. 2019

2 years life @ 70°C permanent

slide-17
SLIDE 17

Performances in back up applications

17

ARTS Energy Confidential & Proprietary

  • Feb. 2019

10 months life @ 80°C permanent

slide-18
SLIDE 18

Ni-MH ecolife MH series

18

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Solar Street Light On-board equipments Off-shore wind turbines

slide-19
SLIDE 19
  • Feb. 2019

19

Low temperature series Low Self-Discharge series

ARTS Energy Confidential & Proprietary

Discharge @ 1C @ -20°C Very low current consumption

slide-20
SLIDE 20

Ni-MH low temperature series

20

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Features

Very low temperature.

  • Discharge @ 1C @ -20°C

Very low Self-Discharge.

  • Less than 20% after one year storage

Benefits

Outdoor applications in cold climates. Very low consumption applications.

Cell product range Battery product range

Low temperature series A 2,5 Ah

slide-21
SLIDE 21

Ni-MH low temperature series

21

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Discharge at -20°C @ 1C

slide-22
SLIDE 22

Ni-MH low temperature series

22

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Train (UPS or communication system) Military drones ATEX lighting (oil&gas platform)

slide-23
SLIDE 23
  • Feb. 2019

23

VHP series

ARTS Energy Confidential & Proprietary

Very High Power Continuous micro-cycling

slide-24
SLIDE 24

VHP series

24

ARTS Energy Confidential & Proprietary

  • Feb. 2019

VHP is an hybride between a supercapacitor and a battery:

  • Can deliver very high current (up to 50C)
  • Can store energy (6 Ah in a D size)

Features Benefits

Very High Power Less expensive vs supercapacitors Much smaller size & cost vs traditional batteries Thousands of cycles Excellent choice for peak Shaving (micro & continuous cycling)

slide-25
SLIDE 25

VHP series

25

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Features

Very High Power.

  • up to 50C

Thousands of cycles.

  • 3000 cycles @ 80% DOD

Benefits

Very attractive power cost.

Very long life duration in micro-cycling applications (peak shaving).

Cell product range Battery product range

VHP series D D 6 Ah 7,5 Ah

slide-26
SLIDE 26

33600 VHP6

26

ARTS Energy Confidential & Proprietary

  • Feb. 2019
slide-27
SLIDE 27

Very High Power series

27

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Hybride boat AGV (logistic robots) Hybride elevators

slide-28
SLIDE 28
  • Feb. 2019

28

Energy conversion

ARTS Energy Confidential & Proprietary

slide-29
SLIDE 29

Battery technologies

29

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Lead-acid Ni-Cd Li-ion Ni-MH

Type of charge

CV CC CCCV CC

Type of charge

Constant voltage Constant current Constant current until a certain voltage. Then constant voltage Constant current

Main charge

  • Approx. 14,2V

According cell manufacturer

Topping charge

  • Approx. 13,6V

C/20 C/100

(intermittent)

slide-30
SLIDE 30

Optimized Ni-MH charge protocol

30

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Trickle charge Topping charge Main charge

slide-31
SLIDE 31

Energy conversion with Ni-MH battery

31

ARTS Energy Confidential & Proprietary

  • Feb. 2019

Partnership to develop fully integrated solutions

slide-32
SLIDE 32

Energy conversion with Ni-MH battery

32

ARTS Energy Confidential & Proprietary

  • Feb. 2019

AC/DC energy conversion

AC/DC rectifier

slide-33
SLIDE 33

Energy conversion with Ni-MH battery

33

ARTS Energy Confidential & Proprietary

  • Feb. 2019

DC/DC energy conversion

DC/DC converter

slide-34
SLIDE 34
