Álgebra Linear e Aplicações

LINEAR EQUATIONS

Start with a few examples

• One way of designing a reconstruction kernel
• Cubic B-Spline
• Leads to linear equations
• Two ways of computing the sums of squares
• Both lead to linear equations
• One simpler than the other

Desirable properties

• A smooth, piecewise polynomial function

P3(x) P3(−x) Q3(−x) Q3(x) 1 2

• 1
• 2

P 0

3(0) = 0

Q3(2) = 0 Q0

3(2) = 0

Q00

3(2) = 0

P3(1) = Q3(1) P 0

3(1) = Q0 3(1)

P 00

3 (1) = Q00 3(1)

Z 1 P3(x) dx + Z 2

1

Q3(x) dx = 1 2 P3(x) = ax3 + bx2 + cx + d Q3(x) = ex3 + fx2 + gx + h

Resulting linear equations

• Substituting, we get the linear system

c = 0 8e + 4f + 2g + h = 0 12e + 4f + g = 0 12e + 2f = 0 a + b + c + d − e − f − g − h = 0 3a + 2b + c − 3e − 2f − g = 0 6a + 2b − 6e − 2f = 0

1 4a + 1 3b + 1 2c + d + 15 4 e + 7 3f + 3 2g + h = 1 2

Result: the Cubic B-Spline function

• Solving, we get

P3(x) P3(−x) Q3(−x) Q3(x) 1 2

• 1
• 2

P3(x) = x3/2 − x2 + 2/3 Q3(x) = −x3/6 + x2 − 2x + 4/3

Sum of squares

• Find a formula for the sum of squares
• Seems to be a cubic polynomial
• Use first 4 results to solve for a, b, c, and d

S2(n) =

n

X

i=1

i2 P2(n) = a n3 + b n2 + c n + d P2(0) = d = 0 = S2(0) P2(1) = a + b + c + d = 1 = S2(1) P2(2) = 8a + 4b + 2c + d = 5 = S2(2) P2(3) = 27a + 9b + 3c + d = 14 = S2(3)

Even simpler!

• On one hand
• On the other hand
• Equating coefficient by coefficient

P2(n + 1) − P2(n) = 3a n2 + (3a + 2b) n + a + b + c S2(n + 1) − S2(n) = (n + 1)2 = n2 + 2n + 1 3a = 1 3a + 2b = 2 a + b + c = 1 d = 0 P2(n) = n (n + 1)(2n + 1) 6

Generalizing

• Formulate general problem
• Propose a solution strategy
• Elimination
• Back-substitution
• Propose a convenient notation
• Investigate the cost of solution

Systems of linear equations

• General problem formulation
• aij are the coefficients
• bi is the right-hand side
• xi are the variables or unknowns
• m equations on n unknowns

a11x1 + a12x2 + · · · a1nxn = b1 a21x1 + a22x2 + · · · a2nxn = b2 . . . am1x1 + am2x2 + · · · amnxn = bm

Solutions to linear equations

• There are only three possibilities
• System has unique solution
• System has no solution
• System has infinitely many solutions
• Easy to understand geometrically

The row-view of linear systems

• Imagine m = 2 and n = 2
• Each equation represents a line in R2
• Planes in 3D, hyper-planes in higher dimensions

a11x + a12y = b1 a21x + a22y = b2

How to solve a linear system?

• Transform to an equivalent system
• Same solution set
• Easier to solve
• Method known as Gaussian Elimination

2x + y + z = 1 6x + 2y + z = −1 −2x + 2y + z = 7 2x + y + z = 1 − y − 2z = −4 − 4z = −4

Elementary operations

• Consider the following row operations:
• Exchange two rows
• Multiply a row by a non-zero constant
• Add a multiple of a row into another
• Can these operations change the solution set?
• Are these operations reversible?

Elimination step-by-step

• Let each row i be denoted by Ei
• Use Ei to eliminate variable i from Ei+1 to En

2x + y + z = 1 6x + 2y + z = −1 −2x + 2y + z = 7 2x + y + z = 1 − y − 2z = −4 (E2 − 3E1) −2x + 2y + z = 7 2x + y + z = 1 − y − 2z = −4 3y + 2z = 8 (E3 + E1) 2x + y + z = 1 − 1y − 2z = −4 3y + 2z = 8 2x + y + z = 1 − 1y − 2z = −4 − 4z = −4 (E3 + 3E2) 2x + y + z = 1 − y − 2z = −4 − 4z = −4

Back substitution

• Start from triangularized system
• Solve for z in E3
• Solve for y in E2
• Solve for x in E1

2x + y + z = 1 − y − 2z = −4 − 4z = −4 z = 1 y = 4 − 2z = 4 − 2(1) = 2 x = 1 2(1 − y − z) = 1 2(1 − 2 − 1) = −1

Simplifying notation

• Variable names and operators are redundant
• Coefficient matrix A and right-hand side b
• Augmented matrix [A|b]
• A matrix is a rectangular array of scalars
• A scalar is a real or complex number

  2 1 1 1 6 2 1 −1 −2 2 1 7   2x + y + z = 1 6x + 2y + z = −1 −2x + 2y + z = 7

Elimination on augmented matrix

  2 1 1 1 6 2 1 −1 −2 2 1 7   2x + y + z = 1 − y − 2z = −4 − 4z = −4 2x + y + z = 1 6x + 2y + z = −1 −2x + 2y + z = 7   2 1 1 1 −1 −2 −4 3 2 8   R2 − 3R1 R3 + R1   2 1 1 1 −1 −2 −4 −4 −4   R3 + 3R2

Back-substitution on augmented matrix

x = −1 y = 2 z = 1   2 1 1 1 −1 −2 −4 1 1   R3/(−4)   2 1 −1 −2 1 1   R1 − R3 R2 + 2R3   2 1 1 2 1 1   R2/(−1)   2 −2 1 2 1 1   R1 − R2   1 −1 1 2 1 1   R1/2

Origins of method

• Chinese book Chiu-chang Suan-shu
• Nine chapters on arithmetic
• From around 200 B.C.
• Using a “counting board”
• Row manipulations
• Made its way to Japan then Europe
• Gauss was a user of method, not inventor

How much computation?

• Assume an n × n system of equations
• Count number of additions/subtractions
• Count number of multiplications/divisions
• The elimination step is

     a11 a12 · · · a1n b1 a21 a22 · · · a2n b2 . . . . . . ... . . . . . . an1 an2 · · · ann bn           t11 t12 · · · t1n c1 t22 · · · t2n c2 . . . . . . ... . . . . . . · · · tnn cn     

Operation count of elimination step

Pivot Elimination Multiplication & Division Addition & Subtraction 1 (n-1)(1+(n-1)+1) (n-1)((n-1)+1) 2 (n-2)(1+(n-2)+1) (n-2)((n-2)+1) … … … n-1 1(1+(1)+1) 1((1)+1)

n−1

X

i=1

i(i + 2)

n−1

X

i=1

i(i + 1)

How much computation?

• The back-substitution step is
• And the solution is given by

     t11 t12 · · · t1n c1 t22 · · · t2n c2 . . . . . . ... . . . . . . · · · tnn cn           1 · · · s1 1 · · · s2 . . . . . . ... . . . . . . · · · 1 sn           x1 x2 . . . xn      =      s1 s2 . . . sn     

Operation count of back-substitution

Pivot Elimination Back-substitution Multiplication & Division Addition & Subtraction Multiplication & Division Addition & Subtraction 1 (n-1)(1+(n-1)+1) (n-1)((n-1)+1) 1+(0) 2 (n-2)(1+(n-2)+1) (n-2)((n-2)+1) 1+(1) 1 … … … … … n-1 1(1+(1)+1) 1((1)+1) 1+(n-1) n-1

n−1

X

i=1

i(i + 2)

n−1

X

i=1

i(i + 1)

n

X

i=1

i

n−1

X

i=1

i

Total operation count of Gaussian Elimination

• Number of multiplication and divisions
• Number of additions and subtractions
• So about of each operation (n is large!)

n3 3 + n2 − n 3 n3 3 + n2 2 − 5n 6 n3 3

Gauss-Jordan method

• Try to avoid back-substitution
• Modify Gaussian Elimination
• Scale Ei so pivot is 1
• Annihilate all terms above pivot as well
• Intermediate state would look like

       1 c13 · · · c1n d1 1 c23 · · · c2n d2 c33 · · · c3n d3 . . . . . . . . . ... . . . . . . cn3 · · · cnn dn       

Total operation count of Gaussian-Jordan method

• Number of multiplication and divisions
• Number of additions and subtractions
• So about of each operation
• Worse than Gaussian Elimination! Why?

n3 2 + n2 2 n3 2 − n2 2 n3 2

Why do we care about cost?

• Are there large linear systems?
• Yes, very large systems
• Look at two examples
• Signal reconstruction
• With our Cubic B-Spline!
• Two-point boundary problem
• Solve ODE numerically through discretization

Signal reconstruction

• Assume you have sampled a function f at a

range of integer positions

• Now you want to reconstruct the value of the

function at all reals in a finite range

• Use a compactly supported generating

function and define

• f(0), f(1), f(2), . . .

ϕ(x) ˜ f(x) = X

i

f(i)ϕ(x − i)

• 2
• 1

1 2 0.2 0.4 0.6 0.8 1.0

• 2
• 1

1 2 0.2 0.4 0.6 0.8 1.0

• 2
• 1

1 2 0.2 0.4 0.6 0.8 1.0

Generating functions

• Typical generating functions
• Typical reconstructions

nearest/box linear/tent cubic B-Spline

1 2 3 4 5 6 7 1 2 3 4 5 1 2 3 4 5 6 7 1 2 3 4 5 1 2 3 4 5 6 7 1 2 3 4 5

B-Spline interpolation

• Some generating functions do not interpolate
• What are the interpolation constraints?

1 2 3 4 5 6 7 1 2 3 4 5 1 2 3 4 5 6 7 1 2 3 4 5

˜ f(x) = X

j

cjϕ(x − j) ˜ f(x) = X

i

f(i)ϕ(x − i)

˜ f(i) = X

j

cjϕ(i − j) = f(i)

1 2 3 4 5 6 7 1 2 3 4 5

Results in large linear system

• Digital music is sampled air pressure over time
• Typical CD track runs for 5 minutes @ 44KHz
• Leads to 44,000 × 60 × 5 = 13,200,000 samples
• Each sample leads to one equation
• How much memory would we need?
• Does sparsity help?
• Is there any hope in solving this linear system?
• Does matrix structure help?

Two-point boundary value

• Consider the ordinary differential equation

where and

• We want to find y(t), for t in [a, b]
• u, v, w, and f are known in [a, b]
• It may not be possible to express y in terms of

elementary functions

• Use numerical methods

u(t)y00(t) + v(t)y0(t) + w(t)y(t) = f(t) y(a) = α y(b) = β

Discretize domain and derivatives

• Aproximate y at many discrete positions in [a, b]
• Use Taylor series to approximate derivatives
• Smaller step size h improves approximation

h t0 = a t1 = a + h t2 = a + 2h tn+1 = b tn = a + nh h h

… …

y0(ti) = y(ti + h) − y(ti − h) 2h + O(h2) y00(ti) = y(ti + h) − 2y(ti) + y(ti − h) h2 + O(h2)

Results in large linear system

• Discretizing and substituting approximations
• We reach

u(t)y00(t) + v(t)y0(t) + w(t)y(t) = f(t) y0(ti) ≈ y(ti + h) − y(ti − h) 2h y00(ti) ≈ y(ti + h) − 2y(ti) + y(ti − h) h2 ui(yi+1 − 2yi + yi−1) 1 h2 + vi(yi+1 − yi−1) 1 2h + wiyi = fi (2ui + hvi) yi+1 + (2h2wi − 4ui) yi + (2ui − hvi) yi−1 = 2h2fi

= yi+1 − yi−1 2h = yi+1 − 2yi + yi−1 h2

Machine problem #1

• Use Matlab to solve boundary problem
• See the effect of the step size on precision
• See the effect of dense/sparse matrices
• On system solution
• On memory
• Compare with built-in solver

Lecture 2

• Number representation by computer
• and limitations
• Consequences on Gaussian Elimination
• and solutions

FLOATING-POINT REPRESENTATION

Floating-point numbers

• All real numbers represented in a computer?
• Impossible, of course. Finite memory!
• Can only represent a finite set of values
• Widely accepted IEEE floating-point standard
• Formats, rounding, arithmetic operations
• Represented by familiar scientific notation
• Except, in binary…

6.02214179 × 1023 −1.602176487 × 10−19

Binary floating-point

• One sign bit
• w exponent bits
• t mantissa or fraction or significand bits

s

sign exponent fraction

w t e (−1)s × (1.b-1b-2b-3 · · · b-t)2 × 2e-z m = (1.b-1b-2b-3 · · · b-t)2 z = 2w−1 − 1

Representation details

• Normalized representation for mantissa m
• Ensures unique representation for mantissa
• First bit is implicitly set to 1
• Get one extra significant bit!
• Excess encoding for exponent e
• Allows for positive and negative exponents
• Therefore large and small magnitudes
• Subtract from encoded exponent

12 ≤ m < 102 z = 2w−1 − 1 (−1)s × (1.b-1b-2b-3 · · · b-t)2 × 2e-z z = 2w−1 − 1

Special values

• Largest representable exponent is reserved
• m = 0 represents ±Inf
• m ≠ 0 represents NaN (Not-a-Number)
• NaN propagates with any operation
• ex: NaN + x = NaN
• Other special operations

n ÷ ±Inf = ±0 ±0 ÷ ±0 = NaN ±Inf × ±Inf = ±Inf Inf - Inf = NaN n ÷ ±0 = ±Inf ±Inf ÷ ±Inf = NaN Inf + Inf = Inf ±Inf × 0 = NaN

Denormalization

• What happens when exponent is the smallest?
• Normalization causes abrupt underflow
• From to 0
• Introduce denormalized numbers
• When exponent is smallest, no implicit leading 1
• PS: Same number of values in each [2i, 2i+1]

1 2 3 4

1.

t

z }| { 00 · · · 1 ×2-z

0.5

Summary of representation

sign exponent fraction ± not 0…0 or 1…1 any normalized ± 0…0 not 0…0 denormalized ± 0...0 0…0 zero ± 1…1 0…0 Inf ± 1…1 not 0…0 NaN

Typical floating-point formats

Single precision (binary32) Total bits 32 Exponent bits 8 Mantissa bits 23 Exponent range

• 126…127

Smallest magnitude ≈ 10-45 Decimal range ≈ -1038 to 1038 Decimal precision ≈ 7 ditigs

Typical floating-point formats

Single precision (binary32) Double precision (binary64) Total bits 32 64 Exponent bits 8 11 Mantissa bits 23 52 Exponent range

• 126…127
• 1022…1023

Smallest magnitude ≈ 10-45 ≈ 10-324 Decimal range ≈ -1038 to 1038

• 10308 to 10308

Decimal precision ≈ 7 digits ≈ 16 digits

Conversion between bases

• Integer part
• Repeatedly divide by base
• Keep remainders
• Stop when dividend is zero
• Read remainders in reverse order
• Fractional part
• Repeated multiply by base
• Keep integer parts
• Stop when maximum precision reached (or zero)
• Read integer parts in direct order

Conversion to floating-point

• Convert -1313.3125 to single precision
• Integer part is 1313
• Fractional part is .3125
• Therefore 1313.3125
• Normalization gives 1.01001000010101 × 210
• Mantissa is 01001000010101000000000
• Exponent is 10+127 = 137 = 100010012
• Sign is 1

1 10001001 01001000010101000000000 = C4A42A0016

= 101001000012 = .01012 = 10100100001.01012

1 2 3 4 …

Rounding, overflow, and underflow

• Let’s try representing 0.1 in floating point
• Mantissa is 0.0001100110011001100…
• No exact representation possible
• Can happen after each arithmetic operation!
• Errors can grow and dominate results
• This problem often happens in practice

≈ 0 ≈ 2.5 ≈ Inf

Effect on addition accuracy

• May not be exact even when exponents equal
• Ex: 1.1010 + 1.0101 = 1.01111×21 → 1.1000×21
• Problem is worse when exponents differ
• Must pre-shift before adding
• Biggest source of rounding error
• Ex: 1.0000 + 1.0000 × 2-5 = 1.00001 → 1.0000
• When adding large list of numbers
• May need to sort before adding!

Multiplication error example

• Closest representable number to 0.110 is
• 0.100000001490116119384765625
• Squaring gives (exactly)
• 0.01000000029802322609739917425031308084

7263336181640625

• Squaring in single precision gives (exactly)
• 0.010000000707805156707763671875
• Closest representable number to 0.0110 is
• 0.009999999776482582092285156250

Integers in floating-point

• Find largest range of integers that can be

represented exactly in single precision

• 23 mantissa bits
• Add implicit normalization bit
• Add sign bit
• From -224+1 = -16,777,215 to 224-1
• After this range, we could have x+1 = x+2!
• 32-bit integer has much larger range!
• from -231 = -2,147,483,648 to 231 - 1

Other weirdness

• Associative property does not hold!
• (a + b) + c ≠ a + (b + c)
• Beware compiler optimizations
• Equality operator not meaningful!
• Returns true only if exactly equal
• Must use special function
• Absolute error vs. relative error

MAKING GAUSSIAN ELIMINATION WORK IN A COMPUTER

Errors during elimination

• 3-digit elimination

✓47 28 19 89 53 36 ◆ ✓ 47 28 19 fl(89 − 88.8) fl(53 − 52.9) fl(36 − 35.9) ◆ ✓47 28 19 .2 .1 .1 ◆ ✓47 28 19 .1 .1 ◆

fl(89/47) = 1.89 fl(1.89 × 47) = 88.8 fl(1.89 × 28) = 52.9 fl(1.89 × 19) = 35.9

Errors during substitution

• 3-digit back-substitution
• Exact solution

✓47 28 19 89 53 36 ◆ ✓47 28 19 −1/47 1/47 ◆ ✓1 1 1 −1 ◆ ✓47 28 19 .1 .1 ◆

fl ✓19 − 28 47 ◆ = fl ✓−9 47 ◆ = −.191 fl (.1/.1) = 1

✓1 −.191 1 1 ◆

Common sources of error

• Some error is unavoidable in general
• How to protect against unnecessary errors?
• Try to avoid rounding after addition
• Most extreme when exponents are very different
• Two strategies against that
• Partial pivoting
• Scaling

Motivation for partial pivoting

• Exact arithmetic
• 3-digit arithmetic

x = 1 1.0001 y = 1.0002 1.0001 ✓−10−4 1 1 104 104 ◆ ✓−10−4 1 1 1 1 2 ◆

fl(2 + 104) = 104 fl(1 + 104) = fl(.10001 × 105) = .100 × 104 = 104

y = 1 ✓−10−4 1 1 10, 001 10, 002 ◆ x = 0

Partial pivoting

• Search column for coefficient of largest magnitude
• Exchange rows to bring it to the pivotal position

✓−10−4 1 1 1 1 2 ◆ ✓ 1 1 2 −10−4 1 1 ◆ ✓1 1 2 1 1 ◆

fl(1 + 10−4) = 1 fl(1 + 2 × 10−4) = 1

x = 1 y = 1

Motivation for row scaling

• 3-digit arithmetic
• Choose proper units for problem
• Scale rows so max magnitude is 1
• Column scaling is typically unnecessary

✓−10 105 105 1 1 2 ◆ ✓−10 105 105 104 104 ◆ y = 1 x = 0

fl(2 + 104) = 104 fl(1 + 104) = 104

Complete pivoting

• At least as good as partial pivoting
• However, not used very frequently. Why?
• What is the computational cost?
• What the number of memory accesses?

      ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ s ∗ ∗ ∗ s ∗ ∗ ∗ s ∗ ∗ ∗             ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ s s s ∗ s s s ∗ s s s ∗      

ILL-CONDITIONED SYSTEMS

Not all systems are born equal

• Gaussian elimination is great
• with partial pivoting
• on a properly scaled system
• But it is not magic!
• Some systems are extraordinarily difficult
• No numerical technique can deal with them

Ill-conditioned systems

• Original system
• Perturbed

.835x + .667y = .168 .333x + .266y = .067 y = −1 x = 1 .835ˆ x + .667ˆ y = .168 .333ˆ x + .266ˆ y = .067 − .001 ˆ y = 834 ˆ x = −666

• Small perturbation in the system can cause a

relatively large change in the solution!

– What if there are measurement errors? – What about floating-point errors?

• “Checking the answer” doesn’t help!

What is the impact to engineering?

• Both matrix and right-hand side are usually

results of measurements

• Even if the exact solution can be obtained,

does it really mean anything?

• The problem is with the system, not with the

solution to the system

• You are solving the wrong problem!
• Find a different experiment
• Hope for better conditioning

The geometric interpretation

• Can we detect this numerically?
• Yes, indeed
• Need more linear algebra

Well-conditioned Ill-conditioned
