SLIDE 1

Álgebra Linear e Aplicações

SLIDE 2

VECTOR SPACES

SLIDE 3

Avoid rediscovering the wheel

Many mathematical objects that seem to have

nothing in common with matrices do in fact share very similar properties

Points in plane, in 3-space, polynomials,

continuous functions, differentiable functions, etc

All possess addition and scalar multiplication
Rather than study these objects separately,

develop a general theory that applies to all

Vector Spaces describe objects of this class

SLIDE 4

Definition of Vector Space #1

Composed of 4 items
A non-empty set V of vectors
For most of this course, n-tuples or matrices
A scalar field F
We will use R or C
Vector addition (x + y) from V × V to V
Scalar multiplication (α x) from F × V to V

SLIDE 5

Definition of Vector Space #2

Required properties of vector addition
(A1) Closure
x + y ∈ V , ∀x, y
(A2) Associative
(x + y) + z = x + (y + z)
(A3) Commutative
x + y = y + x
(A4) Neutral element
∃0 ∈ V, x + 0 = x, ∀x
(A5) Addition inverse
∀x, ∃(–x) ∈ V, x + (–x) = 0,

SLIDE 6

Definition of Vector Space #3

Required properties of scalar multiplication
(M1) Closure
α x ∈ V , ∀α, x
(M2) Associative
(αβ)x = α(βx), ∀α, β, x
(M3) Distributive #1
(α+β)x = αx+βx, ∀α, β, x
(M4) Distributive #2
α(x+y) = αx+αy, ∀α, x, y
(M5) Neutral element
1x = x, ∀x

SLIDE 7

Examples of Vector Space

Rm×n over R, and Cm×n over C
Follows directly from our definitions of matrix

addition and scalar multiplication

Real coordinate spaces R1×n or Rn×1
Special case of above
Will denote as Rn and distinguish only if needed
Focus of this course!

SLIDE 8

Other examples of Vector Space

With function addition and scalar multiplication

defined pointwise

The following are vectors spaces over R
Set of functions mapping [0,1] into R
Set of all real-valued continuous functions on [0,1]
Set of real-valued functions differentiable on [0,1]
Set of all polynomials with real coefficients

(f + g)(x) = f(x) + g(x) (αf)(x) = αf(x)

SLIDE 9

Subspace

Let S be a non-empty subset of a

vector space V over F

S is said to be a subspace of V if it is also

a vector space

Only need to check for closure properties of

addition and scalar multiplication

If closure is respected, other properties follow
r are inherited from V

SLIDE 10

Proof

Only (A1), (A4), (A5), and (M1) are non-trivial
But (A1) and (M1) together give (A4) and (A5)
(M1) gives –x = (-1) x which implies (A5)
Since x and –x are both in V, (A1) implies (A4)

SLIDE 11

Examples of subspaces (or not)

The trivial subspace Z of V contains only one

element, the zero vector 0

Does it satisfy closure?
Every subspace contains the zero vector!
The first quadrant in R2
Does it satisfy closure?
What about lower-triangular matrices?
What about symmetric matrices?

SLIDE 12

Subspaces look “flat”

Can’t be curved
Think “flat” line,

surface, etc

Through the origin

u v αv u + v u v u + v

SLIDE 13

Spanning sets #1

Take a set of vectors

from a vector space V over F

Consider all possible linear combinations of vi
Then span(S) is a subspace of V
Show closure properties
All in span(S)

S = {v1, v2, . . . , vr}

span(S) = {α1v1 + α2v2 + · · · + αrvr | αi ∈ F}

x + y = X

i

(ξi + ηi)vi βx = X

i

(βξi)vi x = X

i

ξivi y = X

i

ηivi

SLIDE 14

Spanning sets #2

Take a set of vectors

from a vector space V over F

Consider all possible linear combinations of vi
We call span(S) the space spanned by S
If U is a vector space such that U = span(S),

we say S is a spanning set for U

In other words, S spans U

S = {v1, v2, . . . , vr}

span(S) = {α1v1 + α2v2 + · · · + αrvr | αi ∈ F}

SLIDE 15

Examples of spanning sets

S = {(1 1), (2 2)} spans the line x = y in R2
The set spans Rn
The set spans the set
f all polynomials of degree n or less

S = {1, x, x2, . . . , xn} S =

ei | i ∈ {1, . . . , n}

SLIDE 16

Important exercise (4.1.7)

Take a subset S with n vectors from V,

a subspace of Rm×1

Form a matrix A in Rm×n in which each

column is a vector of S

Show that S spans V iff for each b in V there is

at least one x in Rn×1 such that Ax = b

In other words, iff Ax = b is a consistent linear

system for each b in V

SLIDE 17

Leads to important test

How can you tell if a subset of vectors, say, in

R3, spans the whole of R3?

S = {(1 1 1), (1 –1 –1), (3 1 1)}
S = {(1 1 1), (1 –1 –1), (3 1 1)}
Place these rows as columns in a matrix
Run elimination to find the rank
If rank is 3, matrix is invertible, system is

consistent for any right-hand side

If less than 3, certainly does not span R3. Why?

SLIDE 18

Sum of subspaces

Let X and Y be subspaces of a vector space V
Define the sum of X + Y as the set of all

possible sums between vectors of X and Y

The sum X + Y is also a subspace of V
Check closure properties for vectors in X + Y
If SX, SY span X, Y then SX ∪ SY spans X + Y
Write any vector in X + Y as a linear combination
f vectors from SX ∪ SY

X + Y = {x + y | x ∈ X, y ∈ Y}

SLIDE 19

FOUR FUNDAMENTAL SUBSPACES

SLIDE 20

Subspaces and Linear Functions #1

Rules (A1) and (M1) remind us of linearity
Let be a linear function and

let R(f) denote the range of f

The range of any linear function

is a subspace of Rm

Proof
(A1) and (M1)

f : Rn → Rm f : Rn → Rm

αy1 + y2 = αf(x1) + f(x2) = f(αx1 + x2)

R(f) =

f(x) | x ∈ Rn

⊆ Rm

y1 = f(x1) y2 = f(x2)

SLIDE 21

Range spaces #1

The range of a matrix A in Rm×n is the

subspace R(A) of Rm corresponding to the range of f(x) = Ax

The range of AT is the subspace of Rm

R(A) =

Ax | x ∈ Rn

⊆ Rm R(AT ) =

AT y | y ∈ Rm

⊆ Rn

SLIDE 22

Range spaces #2

R(A) is also known as column-space of A
R(AT ) is also known as row-space of A

Ax = X

i

ξi[A]∗i (AT y)

T = yT A =

X

j

ηj[A]j∗ x = ξ1 ξ2 · · · ξn T y = η1 η2 · · · ηn T b ∈ R(A) ⇔ b = Ax a ∈ R

AT

⇔ aT = yT A

SLIDE 23

Equal Ranges

For two matrices A and B of the same shape
Proof
Proof
Similarly,

R(A) = R(B) ⇔ A

col

∼ B R(AT ) = R(BT ) ⇔ A

row

∼ B (⇒)

∀x, ∃y | Ax = By ⇒ A[I]i = [A]i = Byi ⇒ A

col

∼ B

(⇐)

⇒ A = B[y1 y2 · · · yn] = BP A = BP ⇒ b = Ax = BPx ⇒ b = By y = Px

But is P invertible?

SLIDE 24

Testing spanning sets

When do two sets of vectors in Rn span the

same subspace?

Set them as rows of matrices A and B
Run Gauss-Jordan to compute EA and EB
Look at non-zero rows of EA and EB
They must agree!

SLIDE 25

Example

A = 1 2 2 3 , 2 4 1 3 , 3 6 1 4 B = 1 1 , 1 2 3 4 B = ✓0 1 1 1 2 3 4 ◆ A =   1 2 2 3 2 4 1 3 3 6 1 4   EA =   1 2 1 1 1   EB = ✓1 2 1 1 1 ◆

SLIDE 26

Spanning the row and column spaces

Let U be any row echelon form for matrix A
Spanning sets for A and AT are as follows
Nonzero rows of U span R(AT )
Because
Basic columns in A span R(A)
Non-basic columns are combinations of basic columns
They are redundant
If you need one, use the corresponding linear

combination of basic columns instead U

row

∼ A

SLIDE 27

Where are the other two spaces?

Consider a general linear function f from

Rm to Rn and focus on

From linearity, this is certainly a subspace
Check (A1) and (M1)
Given a matrix A, there are two linear

functions to consider

N(f) = {x | f(x) = 0}

f(x) = Ax g(y) = AT y

SLIDE 28

Nullspace

For an m × n matrix A, the set

is the nullspace of A

I.e., the set of solutions for the homogeneous

linear system Ax = 0

The set is the left nullspace of

because it is the set of solutions of yT A = 0T N(AT ) ⊆ Rm N(A) = {x | Ax = 0} ⊆ Rn

SLIDE 29

Example

Find a spanning set for N(A) where
Simply the general solution to Ax = 0

A = ✓1 2 3 4 5 6 ◆ EA = ✓1 2 3 ◆   x1 x2 x3   =   −2x2 − 3x3 x2 x3   = x2   −2 1   + x3   −3 1  

SLIDE 30

Spanning the Nullspace

To find the Nullspace of an m×n matrix A,
Find an echelon form U for A and
Find the general solution to Ux = 0
Then the set spans N(A)
In particular
N(A) = {0} iff rank(A) = n
N(AT ) = {0} iff rank(A) = m

xh = xf1h1 + xf2h2 + · · · + xfn−rhn−r H = {h1, h2, . . . , hn−r}

SLIDE 31

Computing N(AT )

The obvious idea is to run elimination until we

reach an echelon form for AT

Echelon forms of A and AT are not the same
Want to obtain all spaces with a single reduction
Let PA = U, for U in echelon form
Assume rank(A) = r
Then last n – r rows of P span N(AT )

SLIDE 32

Proof

Let
Proof
Proof

(⇒) (⇐)

U = ✓Ur ◆ PA = ✓P1 P2 ◆ A = ✓P1A P2A ◆ = ✓Ur ◆ = U ⇒ P2A = 0 P−1 = Q1 Q2

yT A = 0 ⇒ yT P−1U = 0 ⇒ yT Q1

Q2 ✓Ur ◆ = 0 ⇒ yT Q1Ur = 0 ⇒ yT Q1 = 0 P = ✓P1 P2 ◆ ⇒ yT Q1P1 = 0 ⇒ yT (I − Q2P2) = 0 ⇒ yT = yT Q2P2 ⇒ yT = (yT Q2)P2 PA = U P−1P = I ⇒ Q1P1 + Q2P2 = I yT A = 0 ⇒ yT = uT P2 ⇒ Q1P1 = I − Q2P2

SLIDE 33

Example

Using Gauss-Jordan
Find EA
So
From which

  1 2 2 3 1 2 4 1 3 1 3 6 1 4 1     1 2 2 3 −1/3 2/3 1 1 2/3 −1/3 1/3 −5/3 1   P =   −1/3 2/3 2/3 −1/3 1/3 −5/3 1   N(AT ) = span      1/3 −5/3 1     

SLIDE 34

Additional insights

We have shown that
It turns out that
Proof

N(AT ) = R(PT

2 )

R(A) = N(P2)

R(A) ⊆ N(P2) R(A) ⊇ N(P2) P(A|y) = (PA|Py) y = Ax ⇒ P2y = 0 P2y = P2Ax = (P2A)x = 0x = 0 Py = ✓P1y P2y ◆ = ✓P1y ◆

P2y = 0 ⇒ ∃x | Ax = y

PA = ✓P1A P2A ◆ = ✓Ur ◆ P(A|y) = ✓Ur P1y ◆

SLIDE 35

Equal Nullspaces #1

We already know how to test for equality in

range spaces: row and column equivalence

How do we test for Nullspace equality?
Use equivalence again
For two matrices A and B of the same shape
Similarly,

N(A) = N(B) ⇔ A

row

∼ B N(AT ) = N(BT ) ⇔ A

col

∼ B

SLIDE 36

Equal Nullspaces #2

Let’s prove one of them
Proof (⇒)

N(AT ) = N(BT ) ⇔ A

col

∼ B

N(AT ) = N(BT ) ⇒ R(A) = R(B) ⇔ A

col

∼ B ⇒ z = Ax1 ⇔ z = Bx2 (A | Bx2) → (PA | PBx2) → ✓P1A P1Bx2 P2A P2Bx2 ◆ → ✓P1A P1Bx2 P2Bx2 ◆ → ✓P1A P1Bx2 ◆ yT A = 0 ⇔ yT B = 0

SLIDE 37

Equal Nullspaces #3

Let’s prove one of them
Proof
Conversely,

(replace A and B in proof)

(⇐) N(AT ) = N(BT ) ⇔ A

col

∼ B

A = BQ P2A = 0 ⇒ P2BQ = 0 ⇒ P2B = 0 ⇒ N(AT ) ⊆ N(BT ) N(BT ) ⊆ N(AT )

SLIDE 38

Summary #1

The four fundamental subspaces associated to

a matrix Am×n are

The range or column space
The row-space or left-hand range
The nullspace
The left-hand nullspace

N(A) = {x | Ax = 0} ⊆ Rn R(A) = {Ax} ⊆ Rm N(AT ) = {y | yA = 0} ⊆ Rm R(AT ) = {yA} ⊆ Rn

SLIDE 39

Summary #2

Let P be a nonsingular matrix such that

PA = U, where U is in echelon form and let rank(A) = r

Spanning sets for
R(A): Basic columns of A
R(AT): Non-zero rows in U (transposed)
N(A): The hi in the general solution of Ax = 0
N(AT): The last m – r rows in P (transposed)

SLIDE 40

Summary #3

If A and B are matrices of the same shape

A

col

∼ B ⇔ R(A) = R(B) ⇔ N(AT ) = N(BT ) A

row

∼ B ⇔ N(A) = N(B) ⇔ R(AT ) = R(BT )

SLIDE 41

LINEAR INDEPENDENCE, BASIS, AND DIMENSION

SLIDE 42

Linear independence

Matrix dimensions give an incomplete picture
f the true size of a linear system
The important number is the rank
Number of pivots
Number of non-zero rows in echelon form
Better interpretation
Number of genuinely independent rows in matrix
Other rows are redundant

SLIDE 43

Formally

Take a set of vectors
Look at linear combinations
Vectors vi are linearly independent (l.i.) iff the only

linear combination that produces 0 is trivial

Otherwise they are linearly dependent (l.d.)
One of them is a linear combination of the others

S = {v1, v2, . . . , vr} α1v1 + α2v2 + · · · + αrvr αi = 0

SLIDE 44

Easy to visualize in R3

2 vectors are dependent if they lie on a line
3 vectors are dependent if they lie on a plane
Or line
4 vectors are always dependent
3 random vectors should be independent

SLIDE 45

Example

Determine if the set of

vectors is l.i.

Look for a non-trivial

solution to

I.e., non-trivial solution

to the homogeneous linear system

From Gauss-Jordan
So, they are l.d. and e.g.

S =      1 2 1   ,   1 2   ,   5 6 7      α1   1 2 1   + α2   1 2   + α3   5 6 7   =       1 1 5 2 6 1 2 7     α1 α2 α3   =     EA =   1 3 1 2   α1 = −3 α2 = −2 α3 = 1

SLIDE 46

Linear independence and Matrices

Let A be an m × n matrix.
These are equivalent to saying the columns of A

form a linearly independent set

N(A) = {0} rank(A) = n
These are equivalent to saying the rows of A form

a linearly independent set

N(AT ) = {0} rank(A) = m
If A is square, these are equivalent to saying

matrix A is non-singular

Columns of A form a linearly independent set
Rows of A form a linearly independent set

SLIDE 47

Diagonal dominance

An n × n matrix A = [aij] is diagonally

dominant whenever

I.e., diagonal elements are larger in magnitude than

the sum of magnitudes of other row elements

These matrices appear frequently in practical
applications. Two important properties are
They are never singular
Don’t need to use partial pivoting

|akk| >

n

X

j=1 j6=k

|akj|, k ∈ {1, 2, . . . , n}

SLIDE 48

Diagonal dominance

Diagonally dominant matrices are non-singular
Proof by contradiction
Assume there is a non-zero vector in N(A)
Find a contradiction
Let Ax = 0, and let xk be the entry of largest

magnitude in x

⇒ akkxk = −

n

X

j=1 j6=k

akjxj [Ax]k = 0 =

n

X

j=1

akjxj ⇒ |akk||xk| =

n

X

j=1 j6=k

akjxj

≤

n

X

j=1 j6=k

|akj||xj| ≤ |xk|

n

X

j=1 j6=k

|akj| ⇒ |akk| ≤

n

X

j=1 j6=k

|akj|

SLIDE 49

Polynomial interpolation

Given a set of m points

where xi are distinct, there is a unique polynomial

f degree m–1 that goes through each point in S

S = {(x1, y1), . . . , (xm, ym)} ⇥(t) = 0 + 1t + · · · + m−1tm−1 0 + 1x1 + 2x2

1 + · · · m−1xm−1 1

= ⇥(x1) = y1 0 + 1x2 + 2x2

2 + · · · m−1xm−1 2

= ⇥(x2) = y2 . . . 0 + 1xm + 2x2

m + · · · m−1xm−1 m

= ⇥(xm) = ym

SLIDE 50

Polynomial interpolation

Same as saying the following system has a

unique solution for any right-hand side yi

Matrix is non-singular whenever xi are distinct?
Such matrices are called Vandermonde Matrices

     1 x1 x2

1

· · · xm−1

1

1 x2 x2

2

· · · xm−1

2

. . . . . . . . . . . . 1 xm x2

m

· · · xm−1

m

          α0 α1 . . . αm−1      =      y1 y2 . . . ym     

SLIDE 51

Vandermonde Matrices

Vandermonde matrices have independent

columns whenever

Proof
So p(x) has m distinct roots and degree n – 1?
Fundamental theorem of of algebra implies

n ≤ m

p(xi) = α0 + α1xi + α2x2

i + · · · + αn−1xn−1 i

Example of interpolation

2 4 6 8 x 2 4 6 8 H L 2 4 6 8 x 5 10 15 20 25 H L 2 4 6 8 x 6

4
2

2 4 6 P4HxL 2 4 6 8 x 6

4
2

2 4 6 P5HxL

SLIDE 54

Maximal independent subsets #1

We know that if rank(Am×n) < n then the

columns of A must be a dependent set

In such cases, we often want to extract the

maximal independent subset of columns

An l.i. set with as many columns of A as possible
Such columns are sufficient to span R(A)

SLIDE 55

Maximal independent subsets #2

If rank(Am×n) = r, then the following hold
Any maximal independent subset of the columns
f A contain exactly r columns
Any maximal independent subset of rows from A

contain exactly r rows

In particular, the r basic columns in A constitute a

maximal independent subset of the columns of A

SLIDE 56

Maximal independent subsets #3

Any maximal independent subset of the

columns of A contain exactly r columns

Proof
Every column of matrix A can be written as a

linear combination of the basic columns in A

Pick k > r columns of A and show they are l.d.

A∗s1 A∗s2 · · · A∗sk

B

B B @ α1 α2 . . . αk 1 C C C A = 0 A∗b1 A∗b2 · · · A∗br

B

B B @ β11 β12 · · · β1k β21 β22 · · · β2k . . . . . . ... . . . βr1 βr2 · · · βrk 1 C C C A B B B @ α1 α2 . . . αk 1 C C C A = 0

SLIDE 57

Basic facts about Independence

The following hold about a set of vectors in V
If S contains an l.d. subset, then S itself must be l.d.
If S is l.i., then every subset of S is also l.i.
If S is l.i. and , then is l.i. iff
Proof ( )
If and n > m, then S is l.d.

S = {u1, u2, . . . , un}

v ∈ V S ∪ {v} v ⇥ span(S) S ⊆ Rm

⇐

α1u1 + α2u2 + · · · + αnun + αn+1v = 0 ⇒ αn+1 = 0 ⇒ α1u1 + α2u2 + · · · + αnun = 0 ⇒ α1 = α2 = · · · = αn = 0

SLIDE 58

BASIS AND DIMENSION

SLIDE 59

Bases

A basis for a vector space V is a set S that
Spans V
Is linearly independent
Spanning sets can contain redundant vectors
Bases, on the other hand, contain only

necessary and sufficient information

Every vector space V has a basis
General proof depends on the axiom of choice
Bases are not unique

SLIDE 60

Examples

The unit vectors in Rn are a

basis for Rn. The standard or canonic basis of Rn

If A is an n × n non-singular matrix, then the set
f rows and the set of columns of A each

constitute a basis of Rn

What about ?
The set is a basis for all

polynomials of degree n or less

What about the vector space of all polynomials?

S = {e1, e2, . . . , en} Z = {0}

S = {1, x, x2, . . . , xn}

SLIDE 61

Characterizations of a Basis

With V a subspace of Rm and

the following are equivalent

(1) B is a basis for V
(2) B is a minimal spanning set for V
(3) B is a maximal l.i. subset of V

B = {b1, b2, . . . , bn}

SLIDE 62

Proof #1

(basis) ⇒ (minimal spanning set)
Assume B is a basis and X is a smaller spanning set
(minimal spanning set) ⇒ (basis)
A minimal spanning set must be l.i.
Otherwise remove an l.d. vector and reduce size
So it wasn’t minimal (contradiction)

b1 b2 · · · bn

=

x1 x2 · · · xk

B

B B @ α11 α12 · · · α1n α21 α22 · · · α2n . . . . . . ... . . . αk1 αk2 · · · αkn 1 C C C A B = XA k < n rank(A) ≤ k < n ⇤y ⇥= 0 | Ay = 0 ⇒ By = 0 ⇒ B is l.d. (contradiction)

SLIDE 63

Proof #2

(maximal l.i. set) ⇒ (basis)
If a maximal l.i. set B of V is not a basis for V

then there is

So is l.i. and B is not maximal (contradiction)
(basis) ⇒ (maximal l.i. set)
If basis B is not maximal l.i., then take a

larger set Y that is maximal l.i.

We know Y is a basis
But a basis is minimal and B is smaller
So B must also be maximal

v V | v ⇥ span(B) B ∪ {v}

SLIDE 64

Dimension

We have just proven that, although there are

many bases for V, each of them has the same number of vectors

The dimension of a space V, dim V, is the

number of vectors in

Any basis of V
Any minimal spanning set for V
Any maximal independent set for V

SLIDE 65

Examples

, then dim Z = 0
The basis is the empty set
L is a line through the origin in R3, dim L = 1
Any non-zero vector along L forms a basis for L
P is a plane through the origin in R3, dim P = 2
How would we find a basis?
dim Rn = n
The canonic vectors form a basis

Z = {0}

SLIDE 66

Further insights

Dimension measures the “amount of stuff”

in a subspace

Point < Line < Plane < R3
Also measures the number of degrees of

freedom in the subspace

Z: no freedom, Line: 1 degree, Plane: 2 etc
Do not confuse with number of components

in a vector! Related, but not equal!

SLIDE 67

Subspace dimension

Let M and N be vectors spaces and
(1) dim M ≤ dim N
(2) If dim M = dim N , then M = N
Proof
(1) Assume dim M > dim N
Basis of M (all l.i. elements of N ) would have more

vectors than the maximum independent set of N

(2) Assume
Augment basis of M with
Independent set with more than dim N vectors!

M ⊆ N

M ⊂ N

v ∈ N \ M

SLIDE 68

Four Fundamental Subspaces: Dimension

For an m × n matrix A with rank(A) = r
dim R(A) = r
dim N(A) = n – r
dim R(AT) = r
dim N(AT) = m – r

SLIDE 69

Rank Plus Nullity Theorem

For all m × n matrices A

dim R(A) + dim N(A) = n

As the “amount of stuff” in R(A) grows,

the “amount of stuff” in N(A) shrinks

(dim N(A) was traditionally known as nullity)

SLIDE 70

Completing a Basis

If is an l.i. subset of an

n-dimensional space V, where r < n, show how to extend Sr with so that forms a basis for V

Solution
Create a matrix A with Sr as columns
Augment to by the identity matrix
Reduce to echelon form to find basic columns
Return the n basic columns of

Sr = {v1, v2, . . . , vr} {vr+1, . . . , vn} Sn = {v1, . . . , vr, vr+1, . . . , vn}

(A|I) (A|I)

SLIDE 71

Example

Take two l.i. vectors in R4 and augment to a

complete basis for R4

Solution

(A|I) =     1 1 1 −1 1 1 2 −2 1     S2 =            1 −1 2     ,     1 −2            E(A|I) =     1 1 1 1 −1/2 1 1 1/2     S4 =            1 −1 2     ,     1 −2     ,     1     ,     1           

SLIDE 72

Graphs

A graph G is defined by is a pair (V, E), where

V is a set of vertices, and E a set of edges

Each edge connects two vertices
So E ⊆ V × V

e1 = (v2, v1) e2 = (v1, v4)

. . .

e1 e2 e3 e4 v1 v2 v3 v4 e5 e6

SLIDE 73

Incidence Matrices

For a graph G with m vertices and n edges
Associate an m × n matrix E such that

[E]ij =      1, ej = (∗, vi) −1, ej = (vi, ∗) 0,

therwise

e1 e2 e3 e4 v1 v2 v3 v4 e5 e6 E =     1 −1 −1 −1 −1 1 1 1 1 1 −1 −1     e1 e2 e3 e4 e5 e6 v1 v2 v3 v4

SLIDE 74

Rank and Connectivity

Each edge is associated to two vertices
Each column contains two entries (1, and –1)
All columns add up to zero
In other words, if eT = (1 1 … 1),

then eT E = 0 and therefore

So
Equality holds iff the graph is connected!
I.e., when there is a sequence of edges connecting

any pair of vertices

e ∈ N(ET )

rank(E) = rank(ET ) = m − dim N(ET ) ≤ m − 1

SLIDE 75

Proof of Rank and Connectivity #1

Proof
Assume G is connected, prove dim N(ET) = 1
I.e., prove e = (1 1 … 1)T spans N(ET)
Let and take any xi and xk from x
There is a path from vi to vk
Take the subset of vertices visited along the way
There is an edge q linking and

(⇒)

x ∈ N(ET ) {vj1 = vi, vj2, . . . , vjr = vk}

vjp vjp+1

SLIDE 76

Proof of Rank and Connectivity #2

There is an edge q linking and
So column q in E is -1 at row jp and 1 at row jp+1
But and so
Since this is true for all p, it turns out xi = xk
But i and k were arbitrary
And so finally we reach
So dim N(ET) = 1
Which leads to rank(E) = m – 1

vjp vjp+1

xT E = 0 xT E∗q = 0 = xjp+1 − xjp x = αe

SLIDE 77

Proof of Rank and Connectivity #3

Proof
If the graph is not connected, we can partition it

into two disconnected subgraphs G1 and G2

Reorder vertices so vertices/edges in G1 appear

before vertices/edges of G2 in E.

Now compute the rank

(⇐)

E = ✓E1 E2 ◆

rank(E) = rank ✓E1 E2 ◆ = rank(E1) + rank(E2) = m − 2 ≤ (m1 − 1) + (m2 − 1)

SLIDE 78

Application of Rank and Connectivity

Nodes
Loops

A : I1R1 − I3R3 + I5R5 = E1 − E3 B : I2R2 − I5R5 + I6R6 = E2 C : I3R3 + I4R4 − I6R6 = E3 + E4 1 : I1 − I2 − I5 = 0 2 : −I1 − I3 + I4 = 0 3 : I3 + I5 + I6 = 0 4 : I2 − I4 − I6 = 0

SLIDE 79

Rank of a product

Equivalent matrices have the same rank
Recall the rank normal form
Multiplication by invertible matrices preserves rank
Multiplication by rectangular or singular

matrices can reduce the rank

If A is m × n and B is n × p then

rank(AB) = rank(B) − dim N(A) ∩ R(B)

SLIDE 80

Proof #1

Start with a basis for
Augment to form a basis for R(B)
Let us prove that dim R(AB) = t, so that
Sufficient to prove that

is a basis for R(AB) N(A) ∩ R(B)

S = {x1, x2, . . . , xs} Sext = {x1, . . . , xs, z1, . . . , zt} rank(AB) = rank(B) − dim N(A) ∩ R(B) T = {Az1, . . . , Azt}

SLIDE 81

Proof #2

T spans R(AB)
T is l.i.

b ∈ R(AB) ⇒ b = ABy By ∈ R(B) ⇒ By = X ξixi + X ηizi b = A X ξixi

+ A

X ηizi

=

X ηiAzi ⇒ X αizi ∈ N(A) ∩ R(B) X αiAzi = 0 ⇒ A X αizi

= 0

⇒ X αizi − X βixi = 0 ⇒ X αizi = X βixi ⇒ αi = βi = 0

SLIDE 82

Small perturbations can’t reduce rank

We already know that we can’t increase rank

by means of matrix product

We now show it is impossible to reduce rank

by adding a matrix that is “small enough”

“Small” in a sense that will be clarified later,

but for now here is some intuition

rank(AB) ≤ rank(B) rank(A + E) ≥ rank(A)

SLIDE 83

Proof

Suppose rank(A) = r and let P and Q reduce

A to rank normal form

Apply P and Q to A + E
But Ir + E11 is invertible. Keep eliminating
From which

P(A + E)Q = ✓Ir + E11 E12 E21 E22 ◆ PEQ = ✓E11 E12 E21 E22 ◆ P2P(A + E)QQ2 = ✓Ir + E11 S ◆

rank(A + E) = rank(A) + rank(S) ≥ rank(A)

PAQ = ✓Ir ◆

SLIDE 84

Pitfall solving singular systems

Due to floating-point precision,

we do not really solve Ax = b

We solve some perturbed system (A+E)x = b
If A is non-singular, so is A+E and we are fine
If A is singular, A+E may have higher rank!
All we need is for rank(S) > 0!
But
So fewer free variables than actual system
Significant loss of information

S = E22 − E21(I + E11)−1E12

SLIDE 85

Products ATA and AAT

For A in Rm×n, the following statements hold
rank(ATA) = rank(A) = rank(AAT )
R(ATA) = R(AT )

and R(AAT ) = R(A)

N(ATA) = N(A)

and N(AAT ) = N(AT )

For A in Cm×n, replace transposition by

conjugate transpose operation

SLIDE 86

Proof #1

rank(ATA) = rank(A)
We know that
So prove

rank(AT A) = rank(A) − dim N(AT ) ∩ R(A) N(AT ) ∩ R(A) = {0} x ∈ N(AT ) ∩ R(A) ⇒ AT x = 0 x = Ay ⇒ AT Ay = 0 ⇒ xT x = 0 ⇒ yT AT Ay = 0 ⇒ X x2

i = 0 ⇒ x = 0

SLIDE 87

Proof #2

R(ATA) = R(AT )
N(ATA) = N(A)

R(BC) ⊆ R(B) ⇒ R(AT A) ⊆ R(AT ) dim R(AT A) = rank(AT A) = rank(A) = rank(AT ) = dim R(AT ) N(B) ⊆ N(CB) ⇒ N(A) ⊆ N(AT A) dim N(A) = n − rank(A) = n − rank(AT A) = dim N(AT A)

SLIDE 88

Application for ATA

Consider an m×n system Ax = b that may or

may not be consistent

Multiply on the left by AT to reach

ATAx = AT b

This is known as the associated system of

normal equations

It has many nice properties

SLIDE 89

Application for ATA

ATAx = AT b is always consistent!
If Ax = b is consistent, then both systems

have the same solution set

Take a particular solution p for Ax = b
If Ap = b, then ATAp = AT b
General solution is p + N(A) = p + N(ATA)
If Ax = b has a unique solution, then it is
x = (ATA)-1AT b N(A) = 0 = N(ATA)

AT b ∈ R(AT ) = R(AT A)

(warning: A may not even be square, so not invertible!)

SLIDE 90

Normal equations

For an m×n system Ax = b, the associated system of

normal equations is the m×n system ATAx = AT b

ATAx = AT b is always consistent,

even when Ax = b is not

When both are consistent, the solution sets agree
Otherwise, ATAx = AT b gives the least-squares

solution to Ax = b

When Ax = b is consistent and has a unique solution,

so does ATAx = AT b and the solution x = (ATA)-1AT b

SLIDE 91

LEAST SQUARES

SLIDE 92

Motivating problem

Assume we observe a phenomenon that varies

with time and record observations

Want to be able to infer the value of an
bservation at an arbitrary point in time
Assume we have a sensible model for f
Find “good” values for and given D

f(ˆ t ) = ˆ b

α β

f(t) = α + βt e.g. D =

(t1, b1), (t2, b2), . . . , (tm, bm)

SLIDE 93

Proposed solution

Want to find “best”
Find values for and

that minimize

Turns out this reduces

to a linear problem

Let us express in vector

form and generalize α β

m

X

i=1

ε2

i = m

X

i=1

f(ti) − bi

2 f(t) = α + βt

SLIDE 94

Changing to vector form

In our example, define
Then and

A =      1 t1 1 t2 . . . . . . 1 tm      x = ✓α β ◆ b =      b1 b2 . . . bm      ε = Ax − b

[ε]i = α + βti − bi = εi

m

X

i=1

ε2

i = εT ε = (Ax − b)T (Ax − b)

= xT AT Ax − xT AT b − bT Ax + bT b = xT AT Ax − 2xT AT b + bT b

SLIDE 95

The minimization problem

Our goal is to find where the scalar

function

From calculus, at the minimum
Both Ax and xT AT can be seen as matrix

functions of each xi

We can use our rules for differentiation of

matrix functions

ε(x) = xT AT Ax − 2xT AT b + bT b

arg min

x

ε(x) rε(x) = 0

⇥ rε(x) ⇤

i = ∂ε(x)

∂xi

SLIDE 96

Finding the minimum

Differentiating

w.r.t. each component in x we get

Since and since
Equating to zero and grouping all rows

ATAx = AT b

⇥ rε(x) ⇤

i = ∂ε(x)

∂xi = ∂x ∂xi

T

AT Ax + xT AT A ∂x ∂xi − 2 ∂x ∂xi

T

AT b

ε(x) = xT AT Ax − 2xT AT b + bT b

⇥ rε(x) ⇤

i = eT i AT Ax + xT AT Aei 2eT i AT b

∂x ∂xi = ei eT

i AT =

⇥ AT ⇤

i∗

= 2eT

i AT Ax − 2eT i AT b

= 2 ⇥ AT Ax ⇤

i∗ − 2

⇥ AT b ⇤

i∗

SLIDE 97

Is there a favorite solution?

Calculus tells us that the minimum of

can only happen at some solution of the normal equations ATAx = AT b

Are all solutions equally good?
Take any two solutions z1 and z2 = z1 + u
Same argument proves no other vector can

produce a lower value for ε(x)

ε(x) = xT AT Ax − 2xT AT b + bT b

ε(x)

ε(z2) = ε(z1 + u) = ε(z1) + uT AT Au = ε(z1) ε(z1) = bT b − zT

1 AT b

SLIDE 98

General Least Squares

For A in Rm×n and b in Rm, let
The general least squares problem is to find

a vector x that minimizes the quantity

Any such vector is a least-squares solution
The solution set is the same as of ATAx = AT b
Unique only iff rank(A) = n, in which case

x = (ATA)-1AT b

If Ax = b is consistent, solution sets are the same

ε = Ax − b

m

X

i=1

ε2

i = εT ε = (Ax − b)T (Ax − b)

SLIDE 99

Example of Linear Regression

Predict amount of weight that a pint of ice-

cream loses when stored at low temperatures

Assume a linear model for phenomenon

t1 (time), t2 (temperature), (random noise)

Assume random noise “averages out”
Use measurements to find least-squares

solution for parameters in

y = α0 + α1t1 + α2t2 + ε

ε

E(t1, t2) = α0 + α1t1 + α2t2

SLIDE 100

Result of experiments

Assume the following measurements
In vector form, we get

Time (weeks)

1 1 1 2 2 2 3 3 3

Temp (oC)

10
5
10
5
10
5

Loss (grams)

0.15 0.18 0.2 0.17 0.19 0.22 0.2 0.23 0.25

A =               1 1 −10 1 1 −5 1 1 1 2 −10 1 2 −5 1 2 1 3 −10 1 3 −5 1 3 −0               b =               0.15 0.18 0.2 0.17 0.19 0.22 0.2 0.23 0.25               x =   α0 α1 α2  

SLIDE 101

Solution

Certainly the system can’t be consistent?
Best we can do is solve normal equations

ATAx = AT b

Which leads to
So for example

Ax = b ⇒ εi = 0

  9 18 −45 18 42 −90 −45 −90 375     α0 α1 α2   =   1.79 3.73 −8.2  

E(t1, t2) = 1.74 + .025t1 + .005t2 E(9, −35) = 1.74 + .025(9) + .005(−35) = .224

SLIDE 102

Example of Curve Fitting

Interestingly, least squares can be used to fit

non-linear models to data

Model must be linear on the parameters we

are solving for

Does not need to be linear on the variables
I.e., linear on , maybe not on ti
For example, we can use least squares to fit a

polynomial to a set of points αi

SLIDE 103

Polynomial fitting problem

Find a polynomial
f a given degree that fits the data

as well as possible in the least squares sense

Assume ti are distinct and n ≤ m
Here we are more interested in n < m
Otherwise we can fit the data perfectly
With Lagrange interpolation
Fitting “perfectly” not always a good idea

p(t) = α0 + α1t + α2t2 + · · · + αn−1tn−1 D =

(t1, b1), (t2, b2), . . . , (tm, bm)

SLIDE 104

In matrix form

Analogous to earlier

derivation, since

This time with

m

X

i=1

ε2

i = m

X

i=1

p(ti) − bi

2 = (Ax − b)T (Ax − b) A =      1 t1 t2

1

· · · tn−1

1

1 t2 t2

2

· · · tn−1

2

. . . . . . . . . ... . . . 1 tm t2

m

· · · tn−1

m

     x =      α0 α1 . . . αn−1      b =      b1 b2 . . . bm     

SLIDE 105

Example of Polynomial Fitting

Use measurements of the height of a

projectile at different positions to find out where it will land

Sensible model for trajectory is a parabola
So we have
Assume we have more than three data points
Only need three data points
Don’t want to discard useful data
Improves results when measurements are noisy

p(t) = α0 + α1t + α2t2

SLIDE 106

Fitting the data

A =       1 1 0.25 0.0625 1 0.5 0.25 1 0.75 0.5625 1 1 1       AT A =   5. 2.5 1.875 2.5 1.875 1.5625 1.875 1.5625 1.38281   AT b =   62. 43.75 34.9375  

Distance from source (km)

.25 .50 .75 1

Height (m)

8 15 19 20 x =   −0.2286 39.83 −19.43   p(t) = −0.2286 + 39.83t − 19.43t2

Ê Ê Ê Ê Ê

0.2 0.4 0.6 0.8 1.0 5 10 15 20

p(t) = 0 ⇒ t ∈ {0.005755, 2.044}

Ê Ê Ê Ê Ê

0.2 0.4 0.6 0.8 1.0 5 10 15 20

SLIDE 107

Ê Ê Ê Ê Ê

0.0 0.5 1.0 1.5 2.0 10 20 30 40

Ê Ê Ê Ê Ê

0.0 0.5 1.0 1.5 2.0 10 20 30 40

What about Lagrange Interpolation?

Also uses all the data, as long as we increase

polynomial degree

Distance from source (km)

.25 .50 .75 1

Height (m)

8 15 19 20 (t) =

m

X

i=1

bi Qm

j6=i(t − tj)

Qm

j6=i(ti − tj)

! (t) = 1 3(88t + 62t2 − 160t3 + 64t4)

SLIDE 108

LINEAR TRANSFORMATIONS

SLIDE 109

Linear Transformations

Given two vectors spaces U and V over field F
A linear transformation from U to V is a linear

function T mapping U into V

A linear operator on U is a linear

transformation mapping U into itself

T(αx + y) = αT(x) + T(y)

SLIDE 110

Examples #1

The zero transformation, 0(x) = 0, maps any

vector in U to the zero vector in V

The identity operator I(x) = x, maps every

vector from U back into itself

For any m × n matrix A, the function

T(x) = Ax is a linear transformation from Rn to Rm

SLIDE 111

Geometric examples

The rotator Q in R2 by an angle
The projector P from R3 to the xy-plane
The reflector R about the xy-plane

θ

Q(u) = ✓cos θ − sin θ sin θ cos θ ◆ u P(u) =   1 1   u u P(u) R(u) =   1 1 −1   u u R(u) u Q(u) θ

SLIDE 112

Infinite dimensional examples

Let V be the space of differentiable functions,

and W the space of all functions (from R to R). The mapping D(f) = df/dx

Let C be the set of all continuous functions

from R to R. The mapping T(f) = R x

0 f(t)dt

Z x

αf(t) + g(t)
dt = α

Z x f(t)dt + Z x g(t)dt ∂(αf + g) ∂x = α∂f ∂x + ∂g ∂x

SLIDE 113

Coordinates of a Vector

Let be a basis for U
Take a vector v in U
The coefficients in the expansion

are called the coordinates of v w.r.t B

To denote the column vector with these

coefficients, we write

Order is important!
When no basis is specified, canonic basis (in

standard order) is assumed

B = {b1, b2, . . . , bn}

αi

v = α1b1 + α1b1 + · · · + αnbn [v]B = α1 α2 · · · αn T

SLIDE 114

Change of basis as a linear system

Find the coordinates of vector

in basis

v =   8 7 4   B =      1 1 1   ,   1 2 2   ,   1 2 3     

SLIDE 115

Space of Linear Transformations

For each pair of vector spaces U and V over F,

the set of linear transformations L(U, V) from U to V is itself a vector space over F

Let and

be bases for U and V , find a basis for L(U, V)

The set with all Bji forms a basis for L(U, V)
dim L(U, V) = (dim U ) (dim V )

L(uj) =

m

X

i=1

αijvi L(u) =

n

X

j=1

ξjL(uj) L(u) =

n

X

j=1

ξj

m

X

i=1

αijvi =

n

X

j=1 m

X

i=1

αij(ξjvi) =

n

X

j=1 m

X

i=1

αijBji(u) Bji(u) = ξjvi

B = {u1, u2, . . . , un} B0 = {v1, v2, . . . , vm}

u = ξ1u1 + ξ2u2 + · · · + ξnun

SLIDE 116

Proof

That Bji spans L(U, V) should be clear
We started from an arbitrary transformation
To prove that the Bji are l.i., try writing

Coordinate Matrix Representation

Let and

be bases for U and V, respectively

The coordinate matrix of L in L(U, V) with

respect to the basis pair is

B = {u1, u2, . . . , un} B0 = {v1, v2, . . . , vm} (B, B0)

[L]BB0 = ⇣ ⇥ L(u1) ⇤

B0

⇥ L(u2) ⇤

B0

· · · ⇥ L(un) ⇤

B0

⌘ L(u) =

n

X

j=1 m

X

i=1

αijξjvi [L]BB0 =      α11 α12 · · · α1n α21 α22 · · · α2n . . . . . . ... . . . αm1 αm2 · · · αmn      L(uk) =

m

X

i=1

αikvi =           α1k α2k . . . αmk          

B0

SLIDE 118

Change of basis and similarities

Coordinate matrices depend on basis choice
Some bases may force coordinate matrix to

have desirable properties

Learn to choose basis that simplifies our work
Other properties do not change regardless of

basis are invariant to choice of basis

These properties are inherent to the

transformation itself and are worthy of study

SLIDE 119

Change of basis operator

Assume we have two bases for V
Let T be a linear operator on V such that

T(yi) = xi

T is the change of basis operator from to B
And we have

B = {x1, x2, . . . , xn} B0 = {y1, y2, . . . , yn}

B0

ld basis

new basis

[T]B = [T]B0 = [I]BB0

[T(yi)]B0 = [xi]B0 [T(xi)]B xi =

n

X

j=1

αjyj ⇒ T(xi) =

n

X

j=1

αjT(yj) =

n

X

j=1

αjxj = [xi]B0 [I(xi)]B0 = [xi]B0 not necessarily the identity matrix!

SLIDE 120

Change of basis matrix

Assume we have two bases for V
If T(yi) = xi is the change of basis operator
P is the change of basis matrix from B to
We have
for all v in V
P is nonsingular
P is unique

B0 P = [T]B = [T]B0 = [I]BB0

[v]B0 = P[v]B B = {x1, x2, . . . , xn} B0 = {y1, y2, . . . , yn}

ld basis

new basis

SLIDE 121

Example

Here are two different bases for the space of

polynomials of degree two or less

Find the coordinates of

relative to

Answer

B = {1, t, t2} B0 = {1, 1 + t, 1 + t + t2} q(t) = 3 + 2t + 4t2

B0

q(t) = 1(1) − 2(1 + t) + 4(1 + t + t2)

SLIDE 122

Changing Matrix Coordinates

Let A be a linear operator on V,

let B and be two bases for V

The coordinate matrices and

are related as follows

Conversely,

B0 [A]B [A]B0 P = [I]BB0 Q = [I]B0B = P−1 [A]B = P−1[A]B0P [A]B0 = Q−1[A]BQ

SLIDE 123

Similarity

Matrices Bn×n and Cn×n are said to be similar

matrices whenever there exists a nonsingular matrix Q such that

We write when B and C are similar
The linear operator

defined by is called a similarity transformation B = Q−1CQ B ' C f : Rn×n → Rn×n f(C) = Q−1CQ

SLIDE 124

Relevance of similarity

Any two coordinate matrices for a given linear
perator must be similar
We know how to transform one into the other
The process is a similarity
Conversely, any two similar matrices are

coordinates of the same linear operator

For different choices of bases
We use similarity transformations to study

linear operators in a basis that simplifies the associated coordinate matrix

SLIDE 125

Example of invariance to similarity

The trace of a square matrix C
It is similarity invariant
We can talk about the trace of a linear operator
Regardless of the particular coordinate matrix
Even though they are different for different bases
Rank is also similarity invariant
Why?

trace(AB) = trace(BA) trace

(QC)Q−1

= trace

Q−1QC
= trace(C)

SLIDE 126

INVARIANT SUBSPACES

SLIDE 127

Invariant Subspaces

Take a linear operator T on V and consider the

image T(X ) of under T

Certainly it is a subset of V, but in general not

related to X in any obvious way

If , we say that X is an invariant

subspace under T

We can now look at T as a linear operator on X

if we ignore the rest of V and restrict it to X

Denote the restriction of T to X by

X ⊆ V T(X) ⊆ X T/X

SLIDE 128

Relevance to coordinate matrices #1

Assume we have a basis for the invariant X
Augment it to a basis for V
Write the coordinate matrix of T with basis B
But

BX = {x1, x2, . . . , xr} B = {x1, x2, . . . , xr, y1, y2, . . . , yq}

T(xj) =

r

X

i=1

αijxi [T]B = ⇣ · · · ⇥ T(xj) ⇤

B

· · · ⇥ T(yj) ⇤

B

· · · ⌘ ⇥ T(xj) ⇤

B =

B B B B B B B B @ α1j . . . αrj . . . 1 C C C C C C C C A T(yj) =

r

X

i=1

βijxi +

q

X

i=1

γijyi ⇥ T(yj) ⇤

B =

B B B B B B B B @ β1j . . . βrj γ1j . . . γqj 1 C C C C C C C C A

SLIDE 129

Relevance to coordinate matrices #2

So
It is block triangular
What if was also

an invariant subspace?

Would be block diagonal

[T]B =           α11 · · · α1r β11 · · · β1q . . . ... . . . . . . ... . . . αr1 · · · αrr βr1 · · · βrq · · · γ11 · · · γ1q . . . ... . . . . . . ... . . . · · · γq1 · · · γrq          

Y = span{y1, y2, . . . , yq}

[T]B = ✓[T/X ]BX [T/Y]BY ◆ [T]B = ✓[T/X ]BX Br×q Cq×q ◆

SLIDE 130

Invariant subspaces and matrix representation

Let T be a linear operator on V
Let be bases for subspaces with

dimensions and a basis for V

Subspace X is invariant under T iff
Subspaces are all invariant under T iff

BX , BY, . . . , BZ X, Y, . . . , Z B = BX ∪ BY ∪ · · · ∪ BZ r1, r2, . . . , rk [T]B = ✓Ar1×r1 B C ◆ A = [T/X ]BX X, Y, . . . , Z A = [T/X ]BX B = [T/Y]BY . . . C = [T/Z]BZ [T]B =      Ar1×r1 · · · Br2×r2 · · · . . . . . . ... . . . · · · Crk×rk     

SLIDE 131

Triangular and diagonal block forms

When T is an n × n matrix,
Q is a nonsingular matrix such that

iff the first r columns of Q span an invariant subspace under T

Q is a nonsingular matrix such that

iff where each Qi is n × ri and the columns of each Qi span an invariant subspace under T

Q−1TQ = ✓Ar×r Br×q Cq×q ◆ Q−1TQ =      Ar1×r1 · · · Br2×r2 · · · . . . . . . ... . . . · · · Crk×rk     

Q =

Q1

Q2 · · · Qk

SLIDE 132

Example

Find all subspaces of R2 that are invariant under
Solution
Zero-dimensional and 2-dimensional are trivial
One-dimensional invariants M are trickier

A = ✓ 0 1 −2 3 ◆

x ∈ M ⇒ Ax ∈ M Ax = λx (A − λI)x = 0 x ∈ N(A − λI) N(A λI) ⇥= {0} ✓−λ 1 −2 3 − λ ◆ → ✓−2 3 − λ −λ 1 ◆ → ✓−2 3 − λ 1 + (λ2 − 3λ)/2 ◆ λ2 − 3λ + 2 = 0 λ1 = 1 λ2 = 2

SLIDE 133

Example (continued)

Find all subspaces of R2 that are invariant under
Solution
Notice that spans R2
The scalars are called eigenvalues of A and the

nonzero vectors in are the associated eigenvectors of A

A = ✓ 0 1 −2 3 ◆

λ1 = 1 λ2 = 2 M1 = N(A − I) M2 = N(A − 2I) = span ⇢✓1 1 ◆ = span ⇢✓1 2 ◆ B = ⇢✓1 1 ◆ , ✓1 2 ◆ Q = ✓1 1 1 2 ◆ [A]B = Q−1AQ = ✓1 2 ◆
