High Performance Computing Systems (CMSC714) Lecture 7: Single Node Architectures Abhinav Bhatele, Department of Computer Science Summary of last lecture Task-based programming models and Charm++ Key principles: Over-decomposition,

slide-1
SLIDE 1

Lecture 7: Single Node Architectures

Abhinav Bhatele, Department of Computer Science

High Performance Computing Systems (CMSC714)

slide-2
SLIDE 2

Abhinav Bhatele, CMSC714

Summary of last lecture

  • Task-based programming models and Charm++
  • Key principles:
  • Over-decomposition, virtualization
  • Message-driven execution
  • Automatic load balancing, checkpointing, fault tolerance

2

slide-3
SLIDE 3

Abhinav Bhatele, CMSC714

von Neumann architecture

3

https://en.wikipedia.org/wiki/Von_Neumann_architecture

slide-4
SLIDE 4

Abhinav Bhatele, CMSC714

UMA vs. NUMA

4

Uniform Memory Access Non-uniform Memory Access

https://frankdenneman.nl/2016/07/07/numa-deep-dive-part-1-uma-numa/

slide-5
SLIDE 5

Abhinav Bhatele, CMSC714

UMA vs. NUMA

4

Uniform Memory Access Non-uniform Memory Access

https://frankdenneman.nl/2016/07/07/numa-deep-dive-part-1-uma-numa/

slide-6
SLIDE 6

Abhinav Bhatele, CMSC714

Fast vs. slow cores

  • Intel Core line (Nehalem, Sandy Bridge, Ivy Bridge, Haswell, Broadwell, …)
  • AMD processors
  • IBM Power line
  • Slower cores: Low frequency, low power
  • IBM PowerPC line (440, 450, A2, …)

5

slide-7
SLIDE 7

Abhinav Bhatele, CMSC714

Intel Haswell Chip

6

slide-8
SLIDE 8

Abhinav Bhatele, CMSC714

BQC Chip

  • A2 processor core
  • Runs at 1.6 GHz
  • Shared L2 cache
  • Peak performance per core:
  • 12.8 Gflop/s
  • Total performance per node:

204.8 Gflop/s

7

SerDes SerDes

slide-9
SLIDE 9

Abhinav Bhatele, CMSC714

GPUs

  • NVIDIA: Fermi, Kepler, Maxwell,

Pascal, Volta, …

  • AMD
  • Intel
  • Figure on the right shows a single

node of Summit @ ORNL

8

P9 P9 DRAM 256 GB HBM 16 GB GPU 7 TF HBM 16 GB GPU 7 TF HBM 16 GB GPU 7 TF DRAM 256 GB HBM 16 GB GPU 7 TF HBM 16 GB GPU 7 TF HBM 16 GB GPU 7 TF

TF 42 TF (6x7 TF) HBM 96 GB (6x16 GB) DRAM 512 GB (2x16x16 GB) NET 25 GB/s (2x12.5 GB/s) MMsg/s 83

NIC HBM/DRAM Bus (aggregate B/W) NVLINK X-Bus (SMP) PCIe Gen4 EDR IB

HBM & DRAM speeds are aggregate (Read+Write). All other speeds (X-Bus, NVLink, PCIe, IB) are bi-directional.

NVM 6.0 GB/s Read 2.2 GB/s Write 12.5 GB/s 12.5 GB/s 1 6 G B / s 1 6 G B / s 64 GB/s 135 GB/s 135 GB/s 50 GB/s 50 GB/s 50 GB/s 50 GB/s 50 GB/s 50 GB/s 50 GB/s 50 GB/s 50 GB/s 50 GB/s 900 GB/s 900 GB/s 900 GB/s 900 GB/s 900 GB/s 900 GB/s

slide-10
SLIDE 10

Abhinav Bhatele, CMSC714

Volta GV100

9

The World’s Most Advanced Data Center GPU

slide-11
SLIDE 11

Abhinav Bhatele, CMSC714

Volta GV100 SM

10

The World’s Most Advanced Data Center GPU

https://images.nvidia.com/content/volta-architecture/pdf/volta-architecture-whitepaper.pdf

  • Each

Volta Streaming Multiprocessor (SM) has:

  • 64 FP32 cores
  • 64 INT32 cores
  • 32 FP64 cores
  • 8 Tensor cores
slide-12
SLIDE 12

Abhinav Bhatele, CMSC714

Questions

  • Why are the L2 caches sitting on the center of the chip? Why not vise-versa? Is this a

standard design?

  • Why is this paper, Blue Gene/Q, or A2 processor, so important?
  • Are there new significant prefetching methods other than list and stream prefetching

in recent architectures?

  • Is "multiply add pipeline" a commonly used operation, or is the architecture just

trying to increase its FLOP count? What are other commonly used operations that get pipelined in other architectures?

11

The IBM Blue Gene/Q Compute Chip

slide-13
SLIDE 13

Abhinav Bhatele, CMSC714

Questions

  • The paper is from 2010 and this is rather old. It seems that GPUs have evolved a lot in the last decade. How

would it compare today?

  • The GPU in the first paper is 1.5 years older than the CPU, what would be the results if they were both from the same time? How does Moore's

law apply to the GPUs, do they get 2x faster every 2 years?

  • GPUs have several types of caches (shared buffer, constant cache, texture cache). How should these caches be

differentiated (chosen) for a purpose?

  • Where did the "myth" come from? Is the CPU more difficult to optimize?
  • Have the features, recommended by the author, become true in current CPUs/GPUs?
  • Why radix sort is chosen as a benchmark metric, while it's not used as the default algorithm in most

programming languages? (java has mergesort, python timsort, C++ implements quicksort) Is it used more in HPC?

  • The paper says they discarded the delays related to memory bandwidth because GPU have 5x faster b/w than
  • CPU. What would be the approximate real life speeds with the memory included? How important is that to
  • ptimize bandwidth?

12

Debunking the 100X GPU vs. CPU myth

slide-14
SLIDE 14

Abhinav Bhatele 5218 Brendan Iribe Center (IRB) / College Park, MD 20742 phone: 301.405.4507 / e-mail: bhatele@cs.umd.edu

Questions?
