Lecture 17

Spatial Data and Cartography (Part 2)

Colin Rundel 03/22/2017

1

Plotting

2

Example Data - NC SIDS

nc = st_read(system.file(”shape/nc.shp”, package=”sf”), quiet = TRUE) %>% select(-(AREA:CNTY_ID), -(FIPS:CRESS_ID)) head(nc, n = 10) ## Simple feature collection with 10 features and 7 fields ## geometry type: MULTIPOLYGON ## dimension: XY ## bbox: xmin: -81.74107 ymin: 36.07282 xmax: -75.77316 ymax: 36.58965 ## epsg (SRID): 4267 ## proj4string: +proj=longlat +datum=NAD27 +no_defs ## NAME BIR74 SID74 NWBIR74 BIR79 SID79 NWBIR79 ## 1 Ashe 1091 1 10 1364 19 ## 2 Alleghany 487 10 542 3 12 ## 3 Surry 3188 5 208 3616 6 260 ## 4 Currituck 508 1 123 830 2 145 ## 5 Northampton 1421 9 1066 1606 3 1197 ## 6 Hertford 1452 7 954 1838 5 1237 ## 7 Camden 286 115 350 2 139 ## 8 Gates 420 254 594 2 371 ## 9 Warren 968 4 748 1190 2 844 ## 10 Stokes 1612 1 160 2038 5 176 ## geometry ## 1 MULTIPOLYGON(((-81.47275543... ## 2 MULTIPOLYGON(((-81.23989105... ## 3 MULTIPOLYGON(((-80.45634460... ## 4 MULTIPOLYGON(((-76.00897216... ## 5 MULTIPOLYGON(((-77.21766662... ## 6 MULTIPOLYGON(((-76.74506378... ## 7 MULTIPOLYGON(((-76.00897216... ## 8 MULTIPOLYGON(((-76.56250762... ## 9 MULTIPOLYGON(((-78.30876159... ## 10 MULTIPOLYGON(((-80.02567291... 3

Base Plots

plot(nc)

NAME BIR74 SID74 NWBIR74 BIR79 SID79 NWBIR79

4

Geometry Plot

plot(st_geometry(nc), axes=TRUE) 84°W 82°W 80°W 78°W 76°W 33.5°N34°N34.5°N35°N35.5°N36°N36.5°N37°N 5

Graticules

plot(nc[,”SID79”], graticule=st_crs(nc), axes=TRUE, las=1) 84°W 82°W 80°W 78°W 76°W 33.5°N 34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 37°N

SID79

6

Graticules (EPSG:3631)

plot(st_transform(nc[,”SID79”], 3631), graticule=st_crs(nc), axes=TRUE, las=1) 84°W 82°W 80°W 78°W 76°W 33.5°N 34°N 34.5°N 35°N 35.5°N 36°N 36.5°N

SID79

7

ggplot2 2.2.1.9 (dev)

ggplot(nc) + geom_sf(aes(fill=SID79 / BIR79))

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W 0.000 0.002 0.004 0.006

SID79/BIR79

8

ggplot2 + projections

ggplot(st_transform(nc, 3631)) + geom_sf(aes(fill=SID79 / BIR79))

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W 0.000 0.002 0.004 0.006

SID79/BIR79

9

Example Data - Meuse

data(meuse, meuse.riv, package=”sp”) meuse = st_as_sf(meuse, coords=c(”x”, ”y”), crs=28992) meuse_riv = st_polygon(list(meuse.riv)) %>% st_sfc() %>% st_set_crs(28992) meuse ## Simple feature collection with 155 features and 12 fields ## geometry type: POINT ## dimension: XY ## bbox: xmin: 178605 ymin: 329714 xmax: 181390 ymax: 333611 ## epsg (SRID): 28992 ## proj4string: +proj=sterea +lat_0=52.15616055555555 +lon_0=5.38763888888889 +k=0.9999079 +x_0=155000 +y_0=463000 +ellps=bessel +towgs84=565.4171,50.3319,465.5524,-0.398957,0.343988,-1.87740,4.0725 +units=m +no_defs ## First 20 features: ## cadmium copper lead zinc elev dist

• m ffreq soil lime

## 1 11.7 85 299 1022 7.909 0.00135803 13.6 1 1 1 ## 2 8.6 81 277 1141 6.983 0.01222430 14.0 1 1 1 ## 3 6.5 68 199 640 7.800 0.10302900 13.0 1 1 1 ## 4 2.6 81 116 257 7.655 0.19009400 8.0 1 2 ## 5 2.8 48 117 269 7.480 0.27709000 8.7 1 2 ## 6 3.0 61 137 281 7.791 0.36406700 7.8 1 2 ## 7 3.2 31 132 346 8.217 0.19009400 9.2 1 2 ## 8 2.8 29 150 406 8.490 0.09215160 9.5 1 1 ## 9 2.4 37 133 347 8.668 0.18461400 10.6 1 1 ## 10 1.6 24 80 183 9.049 0.30970200 6.3 1 2 ## 11 1.4 25 86 189 9.015 0.31511600 6.4 1 2 ## 12 1.8 25 97 251 9.073 0.22812300 9.0 1 1 ## 13 11.2 93 285 1096 7.320 0.00000000 15.4 1 1 1 ## 14 2.5 31 183 504 8.815 0.11393200 8.4 1 1 ## 15 2.0 27 130 326 8.937 0.16833600 9.1 1 1 ## 16 9.5 86 240 1032 7.702 0.00000000 16.2 1 1 1 ## 17 7.0 74 133 606 7.160 0.01222430 16.0 1 1 1 ## 18 7.1 69 148 711 7.100 0.01222430 16.0 1 1 1 ## 19 8.7 69 207 735 7.020 0.00000000 13.7 1 1 1 ## 20 12.9 95 284 1052 6.860 0.00000000 14.8 1 1 1 ## landuse dist.m geometry ## 1 Ah 50 POINT(181072 333611) ## 2 Ah 30 POINT(181025 333558) ## 3 Ah 150 POINT(181165 333537) ## 4 Ga 270 POINT(181298 333484) ## 5 Ah 380 POINT(181307 333330) ## 6 Ga 470 POINT(181390 333260) ## 7 Ah 240 POINT(181165 333370) ## 8 Ab 120 POINT(181027 333363) ## 9 Ab 240 POINT(181060 333231) ## 10 W 420 POINT(181232 333168) ## 11 Fh 400 POINT(181191 333115) ## 12 Ag 300 POINT(181032 333031) ## 13 W 20 POINT(180874 333339) ## 14 Ah 130 POINT(180969 333252) ## 15 Ah 220 POINT(181011 333161) ## 16 W 10 POINT(180830 333246) ## 17 W 10 POINT(180763 333104) ## 18 W 10 POINT(180694 332972) ## 19 W 10 POINT(180625 332847) ## 20 <NA> 10 POINT(180555 332707) 10

Meuse

plot(meuse, pch=16)

cadmium copper lead zinc elev dist

• m

ffreq soil lime

11

Layering plots

plot(meuse[,”lead”], pch=16, axes=TRUE) plot(meuse_riv, col=adjustcolor(”lightblue”, alpha.f=0.5), add=TRUE, border = NA) 176000 178000 180000 182000 184000 330000 331000 332000 333000

lead

12

Layering plots (oops)

plot(meuse, pch=16) plot(meuse_riv, col=adjustcolor(”lightblue”, alpha.f=0.5), add=TRUE, border = NA)

cadmium copper lead zinc elev dist

• m

ffreq soil lime

13

ggplot2

ggplot() + geom_sf(data=st_sf(meuse_riv), fill=”lightblue”, color=NA) + geom_sf(data=meuse, aes(color=lead), size=1)

50.92°N 50.94°N 50.96°N 50.98°N 51°N 51.02°N 5.72°E 5.73°E 5.74°E 5.75°E 5.76°E 5.77°E 200 400 600

lead

14

ggplot2 - axis limits

ggplot() + geom_sf(data=st_sf(meuse_riv), fill=”lightblue”, color=NA) + geom_sf(data=meuse, aes(color=lead), size=0.1) + ylim(329714, 333611)

50.955°N 50.96°N 50.965°N 50.97°N 50.975°N 50.98°N 50.985°N 50.99°N 5.72°E 5.73°E 5.74°E 5.75°E 5.76°E 5.77°E 200 400 600

lead

15

ggplot2 - bounding box

ggplot() + geom_sf(data=st_sf(meuse_riv), fill=”lightblue”, color=NA) + geom_sf(data=meuse, aes(color=lead), size=0.1) + ylim(st_bbox(meuse)[”ymin”], st_bbox(meuse)[”ymax”])

50.955°N 50.96°N 50.965°N 50.97°N 50.975°N 50.98°N 50.985°N 50.99°N 5.72°E 5.73°E 5.74°E 5.75°E 5.76°E 5.77°E 200 400 600

lead

16

Geometry Manipulation

17

Casting

nc_pts = st_cast(nc, ”MULTIPOINT”) nc_pts ## Simple feature collection with 100 features and 7 fields ## geometry type: MULTIPOINT ## dimension: XY ## bbox: xmin: -84.32385 ymin: 33.88199 xmax: -75.45698 ymax: 36.58965 ## epsg (SRID): 4267 ## proj4string: +proj=longlat +datum=NAD27 +no_defs ## First 20 features: ## NAME BIR74 SID74 NWBIR74 BIR79 SID79 NWBIR79 ## 1 Ashe 1091 1 10 1364 19 ## 2 Alleghany 487 10 542 3 12 ## 3 Surry 3188 5 208 3616 6 260 ## 4 Currituck 508 1 123 830 2 145 ## 5 Northampton 1421 9 1066 1606 3 1197 ## 6 Hertford 1452 7 954 1838 5 1237 ## 7 Camden 286 115 350 2 139 ## 8 Gates 420 254 594 2 371 ## 9 Warren 968 4 748 1190 2 844 ## 10 Stokes 1612 1 160 2038 5 176 ## 11 Caswell 1035 2 550 1253 2 597 ## 12 Rockingham 4449 16 1243 5386 5 1369 ## 13 Granville 1671 4 930 2074 4 1058 ## 14 Person 1556 4 613 1790 4 650 ## 15 Vance 2180 4 1179 2753 6 1492 ## 16 Halifax 3608 18 2365 4463 17 2980 ## 17 Pasquotank 1638 3 622 2275 4 933 ## 18 Wilkes 3146 4 200 3725 7 222 ## 19 Watauga 1323 1 17 1775 1 33 ## 20 Perquimans 484 1 230 676 310 ## geometry ## 1 MULTIPOINT(-81.472755432128... ## 2 MULTIPOINT(-81.239891052246... ## 3 MULTIPOINT(-80.456344604492... ## 4 MULTIPOINT(-76.008972167968... ## 5 MULTIPOINT(-77.217666625976... ## 6 MULTIPOINT(-76.745063781738... ## 7 MULTIPOINT(-76.008972167968... ## 8 MULTIPOINT(-76.562507629394... ## 9 MULTIPOINT(-78.308761596679... ## 10 MULTIPOINT(-80.025672912597... ## 11 MULTIPOINT(-79.530509948730... ## 12 MULTIPOINT(-79.530509948730... ## 13 MULTIPOINT(-78.749122619628... ## 14 MULTIPOINT(-78.806800842285... ## 15 MULTIPOINT(-78.492523193359... ## 16 MULTIPOINT(-77.332206726074... ## 17 MULTIPOINT(-76.298927307128... ## 18 MULTIPOINT(-81.020568847656... ## 19 MULTIPOINT(-81.806221008300... ## 20 MULTIPOINT(-76.480529785156... 18

plot(st_geometry(nc), border=’grey’) plot(st_geometry(nc_pts), pch=16, cex=0.5, add=TRUE) 19

Casting - POINT

st_cast(nc, ”POINT”) ## Simple feature collection with 2529 features and 7 fields ## geometry type: POINT ## dimension: XY ## bbox: xmin: -84.32385 ymin: 33.88199 xmax: -75.45698 ymax: 36.58965 ## epsg (SRID): 4267 ## proj4string: +proj=longlat +datum=NAD27 +no_defs ## First 20 features: ## NAME BIR74 SID74 NWBIR74 BIR79 SID79 NWBIR79 ## 1 Ashe 1091 1 10 1364 19 ## 2 Ashe 1091 1 10 1364 19 ## 3 Ashe 1091 1 10 1364 19 ## 4 Ashe 1091 1 10 1364 19 ## 5 Ashe 1091 1 10 1364 19 ## 6 Ashe 1091 1 10 1364 19 ## 7 Ashe 1091 1 10 1364 19 ## 8 Ashe 1091 1 10 1364 19 ## 9 Ashe 1091 1 10 1364 19 ## 10 Ashe 1091 1 10 1364 19 ## 11 Ashe 1091 1 10 1364 19 ## 12 Ashe 1091 1 10 1364 19 ## 13 Ashe 1091 1 10 1364 19 ## 14 Ashe 1091 1 10 1364 19 ## 15 Ashe 1091 1 10 1364 19 ## 16 Ashe 1091 1 10 1364 19 ## 17 Ashe 1091 1 10 1364 19 ## 18 Ashe 1091 1 10 1364 19 ## 19 Ashe 1091 1 10 1364 19 ## 20 Ashe 1091 1 10 1364 19 ## geometry ## 1 POINT(-81.4727554321289 36.... ## 2 POINT(-81.5408401489258 36.... ## 3 POINT(-81.5619812011719 36.... ## 4 POINT(-81.6330642700195 36.... ## 5 POINT(-81.7410736083984 36.... ## 6 POINT(-81.6982803344727 36.... ## 7 POINT(-81.7027969360352 36.... ## 8 POINT(-81.6699981689453 36.... ## 9 POINT(-81.3452987670898 36.... ## 10 POINT(-81.347541809082 36.5... ## 11 POINT(-81.3247756958008 36.... ## 12 POINT(-81.3133239746094 36.... ## 13 POINT(-81.2662353515625 36.... ## 14 POINT(-81.2628402709961 36.... ## 15 POINT(-81.2406921386719 36.... ## 16 POINT(-81.2398910522461 36.... ## 17 POINT(-81.2642440795898 36.... ## 18 POINT(-81.3289947509766 36.... ## 19 POINT(-81.3613739013672 36.... ## 20 POINT(-81.3656921386719 36.... 20

Casting - LINESTRING

st_cast(nc, ”LINESTRING”) ## Simple feature collection with 100 features and 7 fields ## geometry type: LINESTRING ## dimension: XY ## bbox: xmin: -84.32385 ymin: 33.88199 xmax: -75.45698 ymax: 36.58965 ## epsg (SRID): 4267 ## proj4string: +proj=longlat +datum=NAD27 +no_defs ## First 20 features: ## NAME BIR74 SID74 NWBIR74 BIR79 SID79 NWBIR79 ## 1 Ashe 1091 1 10 1364 19 ## 2 Alleghany 487 10 542 3 12 ## 3 Surry 3188 5 208 3616 6 260 ## 4 Currituck 508 1 123 830 2 145 ## 5 Northampton 1421 9 1066 1606 3 1197 ## 6 Hertford 1452 7 954 1838 5 1237 ## 7 Camden 286 115 350 2 139 ## 8 Gates 420 254 594 2 371 ## 9 Warren 968 4 748 1190 2 844 ## 10 Stokes 1612 1 160 2038 5 176 ## 11 Caswell 1035 2 550 1253 2 597 ## 12 Rockingham 4449 16 1243 5386 5 1369 ## 13 Granville 1671 4 930 2074 4 1058 ## 14 Person 1556 4 613 1790 4 650 ## 15 Vance 2180 4 1179 2753 6 1492 ## 16 Halifax 3608 18 2365 4463 17 2980 ## 17 Pasquotank 1638 3 622 2275 4 933 ## 18 Wilkes 3146 4 200 3725 7 222 ## 19 Watauga 1323 1 17 1775 1 33 ## 20 Perquimans 484 1 230 676 310 ## geometry ## 1 LINESTRING(-81.472755432128... ## 2 LINESTRING(-81.239891052246... ## 3 LINESTRING(-80.456344604492... ## 4 LINESTRING(-76.008972167968... ## 5 LINESTRING(-77.217666625976... ## 6 LINESTRING(-76.745063781738... ## 7 LINESTRING(-76.008972167968... ## 8 LINESTRING(-76.562507629394... ## 9 LINESTRING(-78.308761596679... ## 10 LINESTRING(-80.025672912597... ## 11 LINESTRING(-79.530509948730... ## 12 LINESTRING(-79.530509948730... ## 13 LINESTRING(-78.749122619628... ## 14 LINESTRING(-78.806800842285... ## 15 LINESTRING(-78.492523193359... ## 16 LINESTRING(-77.332206726074... ## 17 LINESTRING(-76.298927307128... ## 18 LINESTRING(-81.020568847656... ## 19 LINESTRING(-81.806221008300... ## 20 LINESTRING(-76.480529785156... 21

st_cast(nc, ”LINESTRING”) %>% st_geometry() %>% plot() 22

Grouping Features

nc_state = st_union(nc) plot(nc_state) nc_state ## Geometry set for 1 feature ## geometry type: MULTIPOLYGON ## dimension: XY ## bbox: xmin: -84.32385 ymin: 33.88199 xmax: -75.45698 ymax: 36.58965 ## epsg (SRID): 4267 ## proj4string: +proj=longlat +datum=NAD27 +no_defs 23

More Grouping

nc_cut = nc %>% cbind(nc %>% st_centroid() %>% st_coordinates()) %>% mutate(region = cut(X, breaks = 5)) nc_cut ## Simple feature collection with 100 features and 10 fields ## geometry type: MULTIPOLYGON ## dimension: XY ## bbox: xmin: -84.32385 ymin: 33.88199 xmax: -75.45698 ymax: 36.58965 ## epsg (SRID): 4267 ## proj4string: +proj=longlat +datum=NAD27 +no_defs ## First 20 features: ## NAME BIR74 SID74 NWBIR74 BIR79 SID79 NWBIR79 X ## 1 Ashe 1091 1 10 1364 19 -81.49826 ## 2 Alleghany 487 10 542 3 12 -81.12515 ## 3 Surry 3188 5 208 3616 6 260 -80.68575 ## 4 Currituck 508 1 123 830 2 145 -76.02750 ## 5 Northampton 1421 9 1066 1606 3 1197 -77.41056 ## 6 Hertford 1452 7 954 1838 5 1237 -76.99478 ## 7 Camden 286 115 350 2 139 -76.23435 ## 8 Gates 420 254 594 2 371 -76.70448 ## 9 Warren 968 4 748 1190 2 844 -78.11043 ## 10 Stokes 1612 1 160 2038 5 176 -80.23428 ## 11 Caswell 1035 2 550 1253 2 597 -79.33477 ## 12 Rockingham 4449 16 1243 5386 5 1369 -79.77038 ## 13 Granville 1671 4 930 2074 4 1058 -78.65647 ## 14 Person 1556 4 613 1790 4 650 -78.97684 ## 15 Vance 2180 4 1179 2753 6 1492 -78.41127 ## 16 Halifax 3608 18 2365 4463 17 2980 -77.65628 ## 17 Pasquotank 1638 3 622 2275 4 933 -76.31460 ## 18 Wilkes 3146 4 200 3725 7 222 -81.15963 ## 19 Watauga 1323 1 17 1775 1 33 -81.69129 ## 20 Perquimans 484 1 230 676 310 -76.45461 ## Y region geometry ## 1 36.43140 (-82.4,-80.8] MULTIPOLYGON(((-81.47275543... ## 2 36.49101 (-82.4,-80.8] MULTIPOLYGON(((-81.23989105... ## 3 36.41252 (-80.8,-79.1] MULTIPOLYGON(((-80.45634460... ## 4 36.40728 (-77.5,-75.8] MULTIPOLYGON(((-76.00897216... ## 5 36.42228 (-77.5,-75.8] MULTIPOLYGON(((-77.21766662... ## 6 36.36145 (-77.5,-75.8] MULTIPOLYGON(((-76.74506378... ## 7 36.40120 (-77.5,-75.8] MULTIPOLYGON(((-76.00897216... ## 8 36.44423 (-77.5,-75.8] MULTIPOLYGON(((-76.56250762... ## 9 36.39697 (-79.1,-77.5] MULTIPOLYGON(((-78.30876159... ## 10 36.40034 (-80.8,-79.1] MULTIPOLYGON(((-80.02567291... ## 11 36.39347 (-80.8,-79.1] MULTIPOLYGON(((-79.53050994... ## 12 36.39600 (-80.8,-79.1] MULTIPOLYGON(((-79.53050994... ## 13 36.30013 (-79.1,-77.5] MULTIPOLYGON(((-78.74912261... ## 14 36.38870 (-79.1,-77.5] MULTIPOLYGON(((-78.80680084... ## 15 36.36234 (-79.1,-77.5] MULTIPOLYGON(((-78.49252319... ## 16 36.25305 (-79.1,-77.5] MULTIPOLYGON(((-77.33220672... ## 17 36.31237 (-77.5,-75.8] MULTIPOLYGON(((-76.29892730... ## 18 36.20160 (-82.4,-80.8] MULTIPOLYGON(((-81.02056884... ## 19 36.22480 (-82.4,-80.8] MULTIPOLYGON(((-81.80622100... ## 20 36.20488 (-77.5,-75.8] MULTIPOLYGON(((-76.48052978... 24

ggplot(nc_cut) + geom_sf(aes(fill=region))

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W

region

(−84.1,−82.4] (−82.4,−80.8] (−80.8,−79.1] (−79.1,−77.5] (−77.5,−75.8]

25

dplyr and sf - BFFs

nc_cut %>% group_by(region) %>% summarize(geometry = st_union(geometry)) %>% ggplot() + geom_sf(aes(fill=region))

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W

region

(−84.1,−82.4] (−82.4,−80.8] (−80.8,−79.1] (−79.1,−77.5] (−77.5,−75.8]

26

Affine Transfomations

rotate = function(a) matrix(c(cos(a), sin(a), -sin(a), cos(a)), 2, 2) ctrd = st_centroid(nc_state) state_rotate = (nc_state - ctrd) * rotate(-pi/4) + ctrd plot(state_rotate, axes=TRUE) −85 −80 −75 32 33 34 35 36 37 38 39 27

Scaling Size

ctrd = st_geometry(st_centroid(nc)) area = st_area(nc) %>% strip_attrs() nc_scaled = nc for(i in 1:nrow(nc)) nc_scaled$geometry[[i]] = ((st_geometry(nc[i,]) - ctrd[i]) * sqrt(min(area)/area[i]) + ctrd[i])[[1]] plot(nc_scaled[,”SID79”])

SID79

28

Back to the highways

hwy = st_read(”../../data/gis/us_interstates/”, quiet=TRUE, stringsAsFactors=FALSE) %>% st_transform(st_crs(nc)) ggplot() + geom_sf(data=nc) + geom_sf(data=hwy, col=’red’)

20°N 30°N 40°N 50°N 60°N

29

NC Interstate Highways

hwy_nc = st_intersection(hwy, nc) ggplot() + geom_sf(data=nc) + geom_sf(data=hwy_nc, col=’red’)

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W

hwy_nc ## Simple feature collection with 56 features and 10 fields ## geometry type: GEOMETRY ## dimension: XY ## bbox: xmin: -83.09008 ymin: 34.2791 xmax: -77.57348 ymax: 36.56092 ## epsg (SRID): 4267 ## proj4string: +proj=longlat +datum=NAD27 +no_defs ## First 20 features: ## ROUTE_NUM DIST_MILES DIST_KM NAME BIR74 SID74 NWBIR74 BIR79 ## 1 I77 546.83 880.05 Surry 3188 5 208 3616 ## 2 I95 1829.69 2944.61 Northampton 1421 9 1066 1606 ## 3 I85 610.51 982.53 Warren 968 4 748 1190 ## 4 I85 610.51 982.53 Granville 1671 4 930 2074 ## 5 I85 610.51 982.53 Vance 2180 4 1179 2753 ## 6 I95 1829.69 2944.61 Halifax 3608 18 2365 4463 ## 7 I77 546.83 880.05 Yadkin 1269 1 65 1568 ## 8 I40 2480.59 3992.14 Forsyth 11858 10 3919 15704 ## 9 I40 F 18.33 29.49 Forsyth 11858 10 3919 15704 ## 10 I40 2480.59 3992.14 Guilford 16184 23 5483 20543 ## 11 I40 F 18.33 29.49 Guilford 16184 23 5483 20543 ## 12 I73 54.84 88.25 Guilford 16184 23 5483 20543 ## 13 I85 610.51 982.53 Guilford 16184 23 5483 20543 ## 14 I40 2480.59 3992.14 Alamance 4672 13 1243 5767 ## 15 I85 610.51 982.53 Alamance 4672 13 1243 5767 ## 16 I40 2480.59 3992.14 Orange 3164 4 776 4478 ## 17 I85 610.51 982.53 Orange 3164 4 776 4478 ## 18 I40 2480.59 3992.14 Durham 7970 16 3732 10432 ## 19 I85 610.51 982.53 Durham 7970 16 3732 10432 ## 20 I95 1829.69 2944.61 Nash 4021 8 1851 5189 ## SID79 NWBIR79 geoms ## 1 6 260 LINESTRING(-80.745014063930... ## 2 3 1197 LINESTRING(-77.57347527372 ... ## 3 2 844 LINESTRING(-78.303117397331... ## 4 4 1058 LINESTRING(-78.788842681252... ## 5 6 1492 LINESTRING(-78.515924528417... ## 6 17 2980 LINESTRING(-77.629052087089... ## 7 1 76 LINESTRING(-80.819025924954... ## 8 18 5031 LINESTRING(-80.425019190468... ## 9 18 5031 LINESTRING(-80.325561526296... ## 10 38 7089 LINESTRING(-80.007026428880... ## 11 38 7089 LINESTRING(-80.033752259421... ## 12 38 7089 LINESTRING(-79.826140362816... ## 13 38 7089 LINESTRING(-79.804892355469... ## 14 11 1397 MULTILINESTRING((-79.259665... ## 15 11 1397 LINESTRING(-79.261130125158... ## 16 6 1086 LINESTRING(-79.259586126259... ## 17 6 1086 LINESTRING(-79.125632056119... ## 18 22 4948 LINESTRING(-79.001499734474... ## 19 22 4948 LINESTRING(-78.986039485815... ## 20 7 2274 LINESTRING(-77.786676909027... 30

Counties near the interstate (Projection)

nc_utm = st_transform(nc, ”+proj=utm +zone=17 +datum=NAD83 +units=m +no_defs”) hwy_utm = st_transform(hwy, ”+proj=utm +zone=17 +datum=NAD83 +units=m +no_defs”) hwy_nc_utm = st_intersection(nc_utm, hwy_utm) ggplot() + geom_sf(data=nc_utm) + geom_sf(data=hwy_nc_utm, col=’red’)

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W

31

Counties near the interstate (Buffering)

hwy_nc_buffer = st_buffer(hwy_nc_utm, 10000) ggplot() + geom_sf(data=nc_utm) + geom_sf(data=hwy_nc_utm, color=’red’) + geom_sf(data=hwy_nc_buffer, fill=’red’, alpha=0.3)

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W

32

Counties near the interstate (Buffering + Union)

hwy_nc_buffer = st_buffer(hwy_nc_utm, 10000) %>% st_union() %>% st_sf() ggplot() + geom_sf(data=nc_utm) + geom_sf(data=hwy_nc_utm, color=’red’) + geom_sf(data=hwy_nc_buffer, fill=’red’, alpha=0.3)

34°N 34.5°N 35°N 35.5°N 36°N 36.5°N 84°W 82°W 80°W 78°W 76°W

33

Exercise 1

How many counties in North Carolina are within 5, 10, 20, or 50 km of an interstate highway?

34

Raster Data

35

Example data - Meuse

meuse_rast = raster(system.file(”external/test.grd”, package=”raster”)) meuse_rast ## class : RasterLayer ## dimensions : 115, 80, 9200 (nrow, ncol, ncell) ## resolution : 40, 40 (x, y) ## extent : 178400, 181600, 329400, 334000 (xmin, xmax, ymin, ymax) ## coord. ref. : +init=epsg:28992 +towgs84=565.237,50.0087,465.658,-0.406857,0.350733,-1.87035,4.0812 +proj=sterea +lat_0=52.15616055555555 +lon_0=5.38763888888889 +k=0.9999079 +x_0=155000 +y_0=463000 +ellps=bessel +units=m +no_defs ## data source : /usr/local/lib/R/3.3/site-library/raster/external/test.grd ## names : test ## values : 128.434, 1805.78 (min, max) 36

plot(meuse_rast) plot(meuse_riv, add=TRUE, col=adjustcolor(”lightblue”,alpha.f = 0.5), border=NA) 176000 178000 180000 182000 184000 330000 332000 334000 500 1000 1500 37

raster class

str(meuse_rast) ## Formal class ’RasterLayer’ [package ”raster”] with 12 slots ## ..@ file :Formal class ’.RasterFile’ [package ”raster”] with 13 slots ## .. .. ..@ name : chr ”/usr/local/lib/R/3.3/site-library/raster/external/test.grd” ## .. .. ..@ datanotation: chr ”FLT4S” ## .. .. ..@ byteorder : Named chr ”little” ## .. .. .. ..- attr(*, ”names”)= chr ”value” ## .. .. ..@ nodatavalue : num -3.4e+38 ## .. .. ..@ NAchanged : logi FALSE ## .. .. ..@ nbands : int 1 ## .. .. ..@ bandorder : Named chr ”BIL” ## .. .. .. ..- attr(*, ”names”)= chr ”value” ## .. .. ..@ offset : int 0 ## .. .. ..@ toptobottom : logi TRUE ## .. .. ..@ blockrows : int 0 ## .. .. ..@ blockcols : int 0 ## .. .. ..@ driver : chr ”raster” ## .. .. ..@ open : logi FALSE ## ..@ data :Formal class ’.SingleLayerData’ [package ”raster”] with 13 slots ## .. .. ..@ values : logi(0) ## .. .. ..@ offset : num 0 ## .. .. ..@ gain : num 1 ## .. .. ..@ inmemory : logi FALSE ## .. .. ..@ fromdisk : logi TRUE ## .. .. ..@ isfactor : logi FALSE ## .. .. ..@ attributes: list() ## .. .. ..@ haveminmax: logi TRUE ## .. .. ..@ min : num 128 ## .. .. ..@ max : num 1806 ## .. .. ..@ band : int 1 ## .. .. ..@ unit : chr ”” ## .. .. ..@ names : chr ”test” ## ..@ legend :Formal class ’.RasterLegend’ [package ”raster”] with 5 slots ## .. .. ..@ type : chr(0) ## .. .. ..@ values : logi(0) ## .. .. ..@ color : logi(0) ## .. .. ..@ names : logi(0) ## .. .. ..@ colortable: logi(0) ## ..@ title : chr(0) ## ..@ extent :Formal class ’Extent’ [package ”raster”] with 4 slots ## .. .. ..@ xmin: num 178400 ## .. .. ..@ xmax: num 181600 ## .. .. ..@ ymin: num 329400 ## .. .. ..@ ymax: num 334000 ## ..@ rotated : logi FALSE ## ..@ rotation:Formal class ’.Rotation’ [package ”raster”] with 2 slots ## .. .. ..@ geotrans: num(0) ## .. .. ..@ transfun:function () ## ..@ ncols : int 80 ## ..@ nrows : int 115 ## ..@ crs :Formal class ’CRS’ [package ”sp”] with 1 slot ## .. .. ..@ projargs: chr ”+init=epsg:28992 +towgs84=565.237,50.0087,465.658,-0.406857,0.350733,-1.87035,4.0812 +proj=sterea +lat_0=52.15616055555555 +lon”| __truncated__ ## ..@ history : list() ## ..@ z : list()

38

raster features

extent(meuse_rast) ## class : Extent ## xmin : 178400 ## xmax : 181600 ## ymin : 329400 ## ymax : 334000 dim(meuse_rast) ## [1] 115 80 1 res(meuse_rast) ## [1] 40 40 projection(meuse_rast) ## [1] ”+init=epsg:28992 +towgs84=565.237,50.0087,465.658,-0.406857,0.350733,-1.87035,4.0812 +proj=sterea +lat_0=52.15616055555555 +lon_0=5.38763888888889 +k=0.9999079 +x_0=155000 +y_0=463000 +ellps=bessel +units=m +no_defs” meuse_rast[20,] ## [1] NA NA NA NA NA NA NA NA ## [9] NA NA NA NA NA NA NA NA ## [17] NA NA NA NA NA NA NA NA ## [25] NA NA NA NA NA NA NA NA ## [33] NA NA NA NA NA NA NA NA ## [41] NA NA NA NA NA NA NA NA ## [49] NA NA NA NA NA NA NA NA ## [57] NA NA NA 749.536 895.292 791.145 607.186 511.044 ## [65] 468.404 399.325 350.362 306.180 300.483 310.082 283.940 285.771 ## [73] 304.709 309.690 301.799 308.753 328.357 345.611 NA NA 39

Rasters and Projections

meuse_rast_ll = projectRaster(meuse_rast, crs=”+proj=longlat +datum=NAD27 +no_defs”) par(mfrow=c(1,2)) plot(meuse_rast) plot(meuse_rast_ll) 178500 180000 181500 330000 332000 334000 500 1000 1500 5.72 5.74 5.76 50.96 50.97 50.98 50.99 500 1000 1500 40

meuse_rast ## class : RasterLayer ## dimensions : 115, 80, 9200 (nrow, ncol, ncell) ## resolution : 40, 40 (x, y) ## extent : 178400, 181600, 329400, 334000 (xmin, xmax, ymin, ymax) ## coord. ref. : +init=epsg:28992 +towgs84=565.237,50.0087,465.658,-0.406857,0.350733,-1.87035,4.0812 +proj=sterea +lat_0=52.15616055555555 +lon_0=5.38763888888889 +k=0.9999079 +x_0=155000 +y_0=463000 +ellps=bessel +units=m +no_defs ## data source : /usr/local/lib/R/3.3/site-library/raster/external/test.grd ## names : test ## values : 128.434, 1805.78 (min, max) meuse_rast_ll ## class : RasterLayer ## dimensions : 131, 91, 11921 (nrow, ncol, ncell) ## resolution : 0.000569, 0.00036 (x, y) ## extent : 5.717362, 5.769141, 50.95089, 50.99805 (xmin, xmax, ymin, ymax) ## coord. ref. : +proj=longlat +datum=NAD27 +no_defs +ellps=clrk66 +nadgrids=@conus,@alaska,@ntv2_0.gsb,@ntv1_can.dat ## data source : in memory ## names : test ## values : 135.647, 1693.578 (min, max) 41

Simple Features ←

→ Rasters

meuse_riv_rast = rasterize(meuse_riv, meuse_rast) ## Error in (function (classes, fdef, mtable) : unable to find an inherited method for function ’rasterize’ for signature ’”sfc_POLYGON”, ”RasterLayer”’ meuse_riv_rast = rasterize(as(meuse_riv, ”Spatial”), meuse_rast) plot(meuse_riv_rast) 176000 178000 180000 182000 184000 330000 332000 334000 0.9990 0.9995 1.0000 1.0005 1.0010 42

sub = !is.na(meuse_riv_rast[]) & !is.na(meuse_rast[]) river_obs = meuse_rast river_obs[!sub] = NA plot(river_obs) 176000 178000 180000 182000 184000 330000 332000 334000 400 600 800 1000 1200 1400 xyFromCell(river_obs, which(sub)) ## x y ## [1,] 180420 332540 ## [2,] 180380 332500 ## [3,] 180340 332460 ## [4,] 180300 332420 ## [5,] 180260 332380 ## [6,] 180140 332340 ## [7,] 180180 332340 ## [8,] 180220 332340 ## [9,] 180020 332300 ## [10,] 180060 332300 ## [11,] 180100 332300 ## [12,] 179860 332260 ## [13,] 179900 332260 ## [14,] 179940 332260 ## [15,] 179700 332220 ## [16,] 179740 332220 ## [17,] 179780 332220 ## [18,] 179820 332220 ## [19,] 179660 332180 ## [20,] 179700 332180 ## [21,] 179740 332180 ## [22,] 179620 332140 ## [23,] 179660 332140 ## [24,] 179700 332140 ## [25,] 179580 332100 ## [26,] 179620 332100 ## [27,] 179660 332100 ## [28,] 179580 332060 ## [29,] 179540 332020 ## [30,] 179540 331980 ## [31,] 179500 331900 ## [32,] 179460 331740 ## [33,] 179420 331580 ## [34,] 179380 331500 ## [35,] 179340 331420 ## [36,] 179300 331380 ## [37,] 179260 331340 ## [38,] 179220 331300 ## [39,] 179260 331300 ## [40,] 179180 331260 ## [41,] 179220 331260 ## [42,] 179140 331220 ## [43,] 179180 331220 ## [44,] 179140 331180 ## [45,] 179100 331140 ## [46,] 178900 330940 ## [47,] 178860 330900 ## [48,] 178820 330860 ## [49,] 178580 330540 ## [50,] 178540 330500 ## [51,] 178540 330460 ## [52,] 178500 330420 ## [53,] 178500 330380 ## [54,] 180180 330300 ## [55,] 180220 330300 ## [56,] 180020 330260 ## [57,] 180060 330260 ## [58,] 180100 330260 ## [59,] 180300 330260 ## [60,] 180340 330260 ## [61,] 180380 330260 ## [62,] 179940 330220 ## [63,] 179980 330220 ## [64,] 178460 330180 ## [65,] 179900 330180 ## [66,] 179940 330180 ## [67,] 178460 330140 ## [68,] 179860 330140 ## [69,] 179900 330140 ## [70,] 179860 330100 ## [71,] 179820 330060 ## [72,] 179780 330020 ## [73,] 179740 329980 ## [74,] 179700 329940 ## [75,] 179740 329940 ## [76,] 179660 329900 ## [77,] 179700 329900 ## [78,] 178540 329860 ## [79,] 179620 329860 ## [80,] 179660 329860 ## [81,] 178580 329820 ## [82,] 179580 329820 ## [83,] 179620 329820 ## [84,] 178620 329780 ## [85,] 179540 329780 ## [86,] 179580 329780 ## [87,] 178660 329740 ## [88,] 179500 329740 ## [89,] 179540 329740 ## [90,] 179420 329700 ## [91,] 179460 329700 ## [92,] 178780 329660 ## [93,] 179340 329660 ## [94,] 179380 329660 43

Rasters and Spatial Models

head(meuse) ## Simple feature collection with 6 features and 12 fields ## geometry type: POINT ## dimension: XY ## bbox: xmin: 181025 ymin: 333260 xmax: 181390 ymax: 333611 ## epsg (SRID): 28992 ## proj4string: +proj=sterea +lat_0=52.15616055555555 +lon_0=5.38763888888889 +k=0.9999079 +x_0=155000 +y_0=463000 +ellps=bessel +towgs84=565.4171,50.3319,465.5524,-0.398957,0.343988,-1.87740,4.0725 +units=m +no_defs ## cadmium copper lead zinc elev dist

• m ffreq soil lime

## 1 11.7 85 299 1022 7.909 0.00135803 13.6 1 1 1 ## 2 8.6 81 277 1141 6.983 0.01222430 14.0 1 1 1 ## 3 6.5 68 199 640 7.800 0.10302900 13.0 1 1 1 ## 4 2.6 81 116 257 7.655 0.19009400 8.0 1 2 ## 5 2.8 48 117 269 7.480 0.27709000 8.7 1 2 ## 6 3.0 61 137 281 7.791 0.36406700 7.8 1 2 ## landuse dist.m geometry ## 1 Ah 50 POINT(181072 333611) ## 2 Ah 30 POINT(181025 333558) ## 3 Ah 150 POINT(181165 333537) ## 4 Ga 270 POINT(181298 333484) ## 5 Ah 380 POINT(181307 333330) ## 6 Ga 470 POINT(181390 333260) head(st_coordinates(meuse)) ## X Y ## 1 181072 333611 ## 2 181025 333558 ## 3 181165 333537 ## 4 181298 333484 ## 5 181307 333330 ## 6 181390 333260 44

library(fields) tps = Tps(x = st_coordinates(meuse), Y=meuse$elev) pred_grid = xyFromCell(meuse_rast, seq_along(meuse_rast)) meuse_elev_pred = meuse_rast meuse_elev_pred[] = predict(tps, pred_grid) plot(meuse_elev_pred) 176000 178000 180000 182000 184000 330000 332000 334000 3 4 5 6 7 8 9 45

Hacky Crap

p = rasterToPolygons(meuse_elev_pred) %>% st_as_sf() grid.arrange( ggplot() + geom_sf(data=meuse, aes(color=elev), size=0.1), ggplot() + geom_sf(data=p, aes(fill=test), color=NA), ncol=2 )

50.955°N 50.96°N 50.965°N 50.97°N 50.975°N 50.98°N 50.985°N 50.99°N 5.73°E 5.74°E 5.75°E 5.76°E 6 7 8 9 10

elev

50.96°N 50.97°N 50.98°N 50.99°N 5.72°E 5.73°E 5.74°E 5.75°E 5.76°E 4 6 8

test

46
