Connecting Whats Next Economic Advantages of DAB+ Jens Stockmann, Product Specialist Transmission jens.stockmann@gatesair.com Proprietary and conf idential. | 1 Connecting Whats Next About Gates Air Gates Air is the largest

slide-1
SLIDE 1

Proprietary and conf idential. | 1

Connecting What’s Next Connecting What’s Next

Economic Advantages

  • f DAB+

Jens Stockmann, Product Specialist Transmission jens.stockmann@gatesair.com

slide-2
SLIDE 2

Proprietary and conf idential. | 2

Connecting What’s Next

About Gates Air

Gates Air is the largest transmitter manufacturer world wide

FM, DRM+, HD Radio Transmitter VHF DTV & DAB Transmitter VHF, UHF AM, DRM, HD Radio Transmitter Medium Wave

slide-3
SLIDE 3

Proprietary and conf idential. | 3

Connecting What’s Next

Main cost factors of Radio operation

Economical Advantages of DAB+

  • Equipment

Capital Expenses (CAPEX)

  • Distribution
  • Energy
  • Cooling
  • Floor space
  • Service & maintenance
  • License fee, spectrum costs
  • Simulcast period, operation of analog and digital Radio in parallel

Operational Expenses (OPEX)

slide-4
SLIDE 4

Proprietary and conf idential. | 4

Connecting What’s Next

Terrestrial digital Radio technologies

  • all using OFDM type of modulation
  • Differences in spectrum use and capacity
  • For optimized coverage Single Frequency Network (SFN) in DAB+ and

DRM+

slide-5
SLIDE 5

Proprietary and conf idential. | 5

Connecting What’s Next Connecting What’s Next

Transmission System FM, DAB+, DRM+

slide-6
SLIDE 6

Proprietary and conf idential. | 6

Connecting What’s Next

  • The comparison is for cost per service
  • The coverage area is the same for all radio types, DAB+, FM, DRM+
  • The area to be covered has at least 18 services
  • All services are good quality audio / music

The Assumptions used in following comparisons are:

slide-7
SLIDE 7

Proprietary and conf idential. | 7

Connecting What’s Next

FM - one complete network per program

  • each transmitter needs another frequency

Distribution Network Distribution Network Distribution Network

Freq1 Freq2 Freq3 Program 1 Program 2 Program 18 . . . Freq 54

slide-8
SLIDE 8

Proprietary and conf idential. | 8

Connecting What’s Next

  • ne network / one frequency for up to 18 Radio programs

Contribution Network

DAB+ Head-end

Freq1 Freq1 Freq1 Program 1 Program 2 Program 18 . . .

Notes: 18 programs assumes 64kbps each, DQPSK, FEC=0.5 24 programs could be included but at the lower bit rate of 48kbps

Distribution Network

slide-9
SLIDE 9

Proprietary and conf idential. | 9

Connecting What’s Next

+ one network / one frequency for up to 3 Radio programs

Program 1 Program 2

Notes: 3 programs assumes 62kbps each, 16QAM, FEC=0.62 4 programs could be included but at the lower bit rate of 46kbps

Program 3

Contribution Network

DRM+ Head-end

Distribution Network

Freq1 Freq1 Freq1

slide-10
SLIDE 10

Proprietary and conf idential. | 10

Connecting What’s Next

FM

DAB+

18x FM Transmitter 18x Frequencies 18x Frequency License fee 18x Studio-Transmitter Link (STL) 18x RDS encoder/ Data 18x Large antenna Tx 1, 2, 3 …….. 16, 17, 18 1x DAB+ Transmitter 1x Frequency 1x Frequency License fee 1x Studio-Transmitter Link (STL) 1x DAB+ Play-out 1x Medium antenna system Tx 1 carries 18 programs Tx 1, …….. 6 carries 18 programs 6x DRM+ Transmitter 6x Frequency 6x Frequency License fee 6x Studio-Transmitter Link (STL) 6x DRM+ Head-End 6x Large antenna system

DRM+

NOTE: DRM+ has a maximum capacity of 186kbps which is equivalent to 62kbps per service using 16QAM and FEC code rate 0.62

Example: 18 Radio Programs same coverage

Cost efficiency of FM, DAB+ and DRM+

NOTE: Antenna system aperture for DAB+ around 200MHz is approximately 1/2 that of FM and DRM+ around 100MHz for the same gain.

slide-11
SLIDE 11

Proprietary and conf idential. | 11

Connecting What’s Next Connecting What’s Next

Equipment Costs

slide-12
SLIDE 12

Proprietary and conf idential. | 12

Connecting What’s Next

Transmitter investment costs FM, DRM+ and DAB+

Transmitter FM DRM+ DAB+ Power 10 kW peak 1 kW rms 2,5 kW rms Price per Transmitter 50.000 USD 45.000 USD 80.000 USD Transmitter 18 6 1 Price all Transmitter 900.000 USD 270.000 USD 80.000 USD

DAB Transmitter investment costs 11x lower compared to FM 3x lower compared to DRM+

Example: 18 Radio Programs same coverage

100 200 300 400 500 600 700 800 900 1,000

FM DRM+ DAB+

slide-13
SLIDE 13

Proprietary and conf idential. | 13

Connecting What’s Next Connecting What’s Next

Energy Costs

slide-14
SLIDE 14

Proprietary and conf idential. | 14

Connecting What’s Next

  • Electricity prices increased of 6.3% between

2010 & 2011

  • Continued to increase 6.6% between 2011

and 2012

  • Projected to continue to rise throughout the

world, increasing by as much as 60% by 2030

Issues Customers Are Facing

  • Some countries have imposed energy taxes

based partly on carbon content

  • In Australia the carbon tax in 2012 was at

$23 per tonne of CO2 emissions

  • Broadcast Australia estimated the first year
  • f the new tax cost them almost $3M

Rising Cost of Energy Carbon T axes

slide-15
SLIDE 15

Proprietary and conf idential. | 15

Connecting What’s Next

Energy consumption transmitter FM, DRM+ and DAB+

Transmitter FM DRM+ DAB+ Power 10 kW 1 kW rms 2,5 kW rms Efficiency 72% 40 % 40% Energy consumption per Transmitter 13,9 kW 2,5 kW 6,25 kW Transmitters 18 6 1 Energy all Transmitters 250 kW 15 kW 6,25 kW Annual cost

  • f energy

328.500 USD 20.000 USD 8.000 USD

DAB+ energy savings 41x lower compared to FM 2,5x lower compared to DRM+

Example: 18 Radio Programs same coverage

Assumes 0,15 USD per kWh 0.05 0.1 0.15 0.2 0.25 0.3 0.35

FM DRM+ DAB+

slide-16
SLIDE 16

Proprietary and conf idential. | 16

Connecting What’s Next

Energy costs FM, DRM+ and DAB+

Assumes 0,15 USD / kWh

Example: 18 Radio Programs same coverage

DAB+ energy savings over 10 years 3.207.000 USD compared to FM 120.000 USD compared to DRM+

0.5 1 1.5 2 2.5 3 3.5 1 2 3 4 5 6 7 8 9 10

FM DRM+ DAB+

  • Energy costs over 10 years of operation
slide-17
SLIDE 17

Proprietary and conf idential. | 17

Connecting What’s Next Connecting What’s Next

Cooling Effort

slide-18
SLIDE 18

Proprietary and conf idential. | 18

Connecting What’s Next

Energy saving for room cooling FM, DRM+ and DAB+

18 x FM Transmitter 1x DAB+ Transmitter 6 x DRM+ Transmitter

Example: 18 Radio Programs same coverage

slide-19
SLIDE 19

Proprietary and conf idential. | 19

Connecting What’s Next

Energy saving for room cooling FM, DRM+ and DAB+

Transmitter FM DRM+ DAB+ Power 10 kW 1 kW rms 2,5 kW rms Power consumption (rms) 13,9 kW 2,5 kW 6,25 kW Dissipated Power 3,9 kW 1,5 kW 3,75 kW Transmitter for 18 Radio programs 18 6 1 Dissipated power for 18 programs 70,2 kW 9 kW 3,75 kW Cost per annum 92.250 USD 11.800 USD 5.000 USD

Example: 18 Radio Programs same coverage

10,000 20,000 30,000 40,000 50,000 60,000 70,000 80,000 90,000 100,000

FM DRM+ DAB+

DAB+ heat dissipation 18x lower to FM 2x lower to DRM+

slide-20
SLIDE 20

Proprietary and conf idential. | 21

Connecting What’s Next Connecting What’s Next

Space in Equipment Room and on Towers

slide-21
SLIDE 21

Proprietary and conf idential. | 22

Connecting What’s Next

0,6 m2

Space savings on transmission site FM, DRM+ and DAB+

1 m

3,6 m2

1 m

18 x FM Transmitter 1x DAB+ Transmitter 6 x DRM+ Transmitter 9,0 m

10,8 m2

1 m

Example: 18 Radio Programs same coverage

slide-22
SLIDE 22

Proprietary and conf idential. | 23

Connecting What’s Next

Analoge FM, DRM+

  • Many towers
  • Interferences

Save tower & antenna space with DAB+

DAB+

  • Single Antenna
  • No interferences
slide-23
SLIDE 23

Proprietary and conf idential. | 25

Connecting What’s Next

The Cost of Space

Cost comparison for combined antenna aperture on the transmission tower and transmitter room space

Transmitter FM DRM+ DAB+ Situation Owned Region site Metro site Owned Region site Metro site Owned Region site Metro site Cost per annum ,000s USD 5 35 75 5 35 75 5 35 75 Number of transmitters 18 18 18 6 6 6 1 1 1 Cost per annum ,000 USD 90 630 1,350 30 210 450 5 35 75

The cost of DAB+ transmitter tower and hall space is 18x lower compared to FM 6x lower compared to DRM+

slide-24
SLIDE 24

Proprietary and conf idential. | 26

Connecting What’s Next Connecting What’s Next

Service & Maintenance

slide-25
SLIDE 25

Proprietary and conf idential. | 27

Connecting What’s Next

Reduced Service & Maintenance Cost FM, DRM+ and DAB+

18 x FM Transmitter 1x DAB+ Transmitter 6 x DRM+ Transmitter

Drastic Service cost reductions using DAB+

  • reduced spare part stock
  • reduced part diversity
  • reduced maintenance effort
slide-26
SLIDE 26

Proprietary and conf idential. | 28

Connecting What’s Next

There are a number of options for operations and maintenance including

  • Broadcaster provides internal staff to conduct the work, often the case for commercial broadcasters
  • A managed service is used, often the case for multiplexes which have multiple broadcasters, e.g. DAB+
  • A mixture where the operations aspects are conducted by the broadcaster but maintenance is done by a

contract organization, this occurs in large metro transmission sites as well as remote sites

Reduced Service & Maintenance Cost FM, DRM+ and DAB+

Example: 18 Radio Programs same coverage

Transmitter FM DRM+ DAB+ Situation Owned Regional site Metro site Owned Regional site Metro site Owne d Regional site Metro site Weeks of effort per annum 2 4 12 Cost per annum ,000s USD 5 5 5 10 10 10 50 50 50 Number of transmitters 18 6 1 Cost per annum ,000 USD 90 90 90 60 60 60 50 50 50

The cost of DAB+ maintenance is approximately the same as DRM+ and 1/2 of FM

slide-27
SLIDE 27

Proprietary and conf idential. | 29

Connecting What’s Next Connecting What’s Next

Summary

slide-28
SLIDE 28

Proprietary and conf idential. | 30

Connecting What’s Next

Summary economical advantages of DAB+

Drastic cost reductions (CAPEX & OPEX) using DAB+ compared to FM for: 1. Equipment 2. Distribution 3. Energy 4. Cooling 5. Space 6. Service & Maintenance 7. RF transmission License Fees

slide-29
SLIDE 29

Proprietary and conf idential. | 31

Connecting What’s Next

  • Transition period from analog to digital for Radio is longer than for TV
  • Additional costs of transmission during the simulcast period will be approximately

10% -15% more relative to FM operation for each program provider.

  • Broadcaster may not be able to compensate all additional costs of simulcast
  • peration by more revenue

1. Simulcast costs are critical for acceptance & motivation of broadcaster 2. Clear road map of analog to digital transition helps to secure planning 3. Cost compensations for broadcaster during simulcast period Simulcast period most costly for program provider

Simulcast period

slide-30
SLIDE 30

Proprietary and conf idential. | 32

Connecting What’s Next

  • Standard PC for DAB Head-End (Audio live encoding, Multiplexing)
  • Open source software (CRC mmb tools)
  • Broadband internet access
  • First local licenses in Switzerland

Cost effective Soft Defined DAB+ solution based on Open Code Software

DAB+ for local Broadcaster

Contact: coinchon@ebu. More information on www.opendigitalradio.org wiki.digris.ch mmbtools.crc.ca

Laptop

Stream Audio Player Audio Encoder DAB+ MUX

Tx Internet Transmission site Studios

Mask Filter

EDI Head-End

slide-31
SLIDE 31

Proprietary and conf idential. | 33

Connecting What’s Next

It’s time for DAB+ !
