Introduction to Computer Security

David Brumley dbrumley@cmu.edu

Carnegie Mellon University

Today: Overview

• Course Staff
• Trusting Trust
• Course Overview
• Example Applications
• Course Mechanics
• CMU CTF Team

2

You will find at least one error

• n each set of slides. :)

3

4

David Brumley

• B.A. Math UNC 1998
• M.S. CS Stanford 2003
• Ph.D. CS CMU 2008
• Computer security
• fficer, Stanford

University, 1998-2002

• Assistant Professor,

CMU, Jan 2009

Current Research Thrusts

• Automatic Exploit Generation

– AEG and Mayhem

• Scalable Malware Analysis

– BitShred

• Binary code analysis

– Decompilation

• Vetting whole systems

5

Trust

Trusting

6

Do you trust his Software?

7

Photo from http://culturadigitalbau.wikispaces.com/ file/view/thompson.c1997.102634882.lg.jpg/212982274/thompson.c1997.102634882.lg.jpg

Ken Thompson Co-Creator of UNIX and C Turing Award: 1983

8

9

Compiler

011001001111010 FIX mak login.c

10

Compiler

011001001111010

... if(program == “login”) add-login-backdoor(); if(program == “compiler”) add-compiler-backdoor();

FIX mak login.c

Ken Thompson Co-Creator of UNIX and C Turing Award: 1983

11

Would you trust Mother Teresa’s software?

12

13

Would you trust Mother Teresa’s software?

14

Surely cryptographers code must be secure?

Ron Rivest Adi Shamir Len Adleman

Picture from http://www.usc.edu/dept/molecular-science/RSA-2003.htm

Perfect Cryptography Exists!

We’re no better off guessing what an encrypted message contains given the ciphertext.

• Claude Shannon

15

But implementations may still leak...

16

message decrypt(ciphertext c, private_key k){ plaintext m; if(k == 1) m = time t1 decryption ops; return m; if(k == 2) m = time t2 decryption ops; return m; if(k == 3) m = time t3 decryption ops; return m; .... }

17

Isn’t this networking?

Routers run an

• perating system,

which hackers now target

Even GPS systems run

• Webservers
• FTP servers
• Network time daemons

18

19

Security is many things

This Class: Introduction to the Four Research Cornerstones of Security

20

Software Security Network Security OS Security Cryptography

21

Course Topics

Intro to Computer Security

Software Security

Control Flow Hijack Execution Safety Information Flow

Cryptography

Goals

• f

Crypto Stream Ciphers Block Ciphers Asymmetric Crypto Authentication/Integrity

OS Security

Common Defenses Authorization Security Architectures

Network Security

Web Security Denial

• f

Service Protocols Intrusion Detection

Your job: become conversant in these topics

Software Security

22

Control Flow Hijacks

23

shellcode (aka payload) padding &buf computation + control

Allow attacker ability to run arbitrary code

– Install malware – Steal secrets – Send spam

24

25

26

Software Security

• Recognize and exploit vulnerabilities

– Format string – Buffer overflow – Gist of other control flow hijacks, e.g., heap overflow

• Understand defenses in theory and practice

– ASLR – DEP – Canaries – Know the limitations!

27

Cryptography

28

Everyday Cryptography

• ATM’s
• On-line banking
• SSH
• Kerberos

Alice Bob

M

Public Channel Adversary Eve: A very clever person

Alice Bob

M

Public Channel Adversary Eve: A very clever person

Cryptography’s Goals:

– Data Privacy – Data Integrity – Data Authenticity

Alice Bob

M

Public Channel Adversary Eve: A very clever person

Cryptonium Pipe

Alice Bob

M

Public Channel Adversary Eve: A very clever person

Cryptonium Pipe

Cryptography’s Goals:

– Privacy – Integrity – Authenticity

34

Goals

• Understand and believe you should never,

ever invent your own algorithm

• Basic construction
• Basic pitfalls

35

OS Security

36

37

Principal Reference Monitor Object Requested Operation Approved Operation

Source Guard Resource

Authentication Authorization

In security, we isolate reasoning about the guard

38

OS Security

Authentication

Principles

Authorization

Reference monitors Access control lists

Auditing Security Architectures

Virtual Machines Software Fault Isolation

OS Goals

• Know Lampson’s “gold” standard

– Authorization – Authentication – Audit

• Know currently used security architectures

39

Network Security

40

41

Network Security

Web Security

XSS

Stored XSS Reflected XSS

SQL Injection

Defense Sanitization Stored procedures Attacks Basic syntax Comments Probes

CSRF

Attack Defense Referer Validation Custom Header Token validation

Intrusion Detection

Stateful Stateless Base Rate

Protocols

Kerberos BGP

Denial

• f

Service

Bots CDN

42

Network Security

Web Security

XSS

Stored XSS Reflected XSS

SQL Injection

Defense Sanitization Stored procedures Attacks Basic syntax Comments Probes

CSRF

Attack Defense Referer Validation Custom Header Token validation

Intrusion Detection

Stateful Stateless Base Rate

Protocols

Kerberos BGP

Denial

• f

Service

Bots CDN

43

Network Security

Web Security

XSS

Stored XSS Reflected XSS

SQL Injection

Defense Sanitization Stored procedures Attacks Basic syntax Comments Probes

CSRF

Attack Defense Referer Validation Custom Header Token validation

Intrusion Detection

Stateful Stateless Base Rate

Protocols

Kerberos BGP

Denial

• f

Service

Bots CDN

Networking Goals

• Understand the base rate fallacy and it’s

application to IDS

• Be able to recognize and perform basic web

attacks

• State what a DDoS is, and how CDN’s

mitigate their effect

44

Course Mechanics

45

Basics

• Pre-req:

– Basic UNIX development (gcc, gdb, etc.) – 15-213 or similar is recommended

• Read all papers before lecture

– Read – Underline – Question – Review

• Course website:

http://www.ece.cmu.edu/~dbrumley/courses/18487-f13

46

Workload

• 3 homework assignments
• 3 exams, keep highest 2 grades
• The Coolest Bug day.

47

The Coolest Bug

• Describe a classic old bug, or a new zero-day
• Provide an 5 minute tutorial on the bug.
• Present to the class.
• Class votes (via a limited number of tokens) on

best.

• Encourage finding your own zero-days.

48

1996

49

#1 Song: The Macarena Spice Girls Play Olympics Windows 95 Reigned

50

Ping of Death!

51

ICMP and IP Packets

IP Packet Max IP packet size = 65535 octets (216 – 1) (RFC 791) 20 for typical header 8 for ICMP header 65507 for data (65535-20-8) To process ICMP, I need to handle up to 65507 octets

52

ICMP and IP Packets

IP Packet Max IP packet size = 65535 octets (216 – 1) (RFC 791) 20 for typical header 8 for ICMP header 65507 for data (65535-20-8) To process ICMP, I need to handle up to 65507 octets

IP Fragmentation

One 4000 byte packet with Maximum Transmission Unit (MTU) of 1500

53

... length 4000 ID x fragflag

• ffset

... ... length 1500 ID x fragflag 1

• ffset

... ... length 1040 ID x fragflag

• ffset

370 ... ... length 1500 ID x fragflag 1

• ffset

185 ... packet len < MTU 1480 octet data

• ffset = 1480/8

Gets fragmented in 3 packets

ping of death

54

Attacker Victim

• 2. Victim reassembles fragments

into one big packet

• 3. Victim copies large packet,

exceeds buffer bounds, crashes

“A few ICMPv6 packets with router advertisements requests can cause a denial-of-service vulnerability reminiscent of the famous "Ping of Death". It’s a good illustration of how much we still do not know about the stability of IPv6. We continue to recommend turning off IPv6 on workstations if your network is not engineered for its use.”

55

“A few ICMPv6 packets with router advertisements requests can cause a denial-of-service vulnerability reminiscent of the famous "Ping of Death". It’s a good illustration of how much we still do not know about the stability of IPv6. We continue to recommend turning off IPv6 on workstations if your network is not engineered for its use.”

56

Basic Mechanics

• Grading based on:

– 3 homeworks (35%) – Highest 2 out of 3 tests (30% each) – Participation and coolest bug (5%)

• No late days except under exceptional circumstances.
• I guarantee at least the following:

– 90-100%: A – 80-89%: B – 70-79%: C – 60-69%: D – < 59%: F

57

• Obey the law
• Do not be a nuisance
• Don’t cheat, copy others

work, let others copy, etc.

58

One note

My wife will have a baby boy sometime this

• semester. This may affect the course.

59

Image credits: http://onyx-ii.com/srcstore/scripts/store/item.cfm?Item_Number=BE-STXLW-CD

Capture the Flag

60

61

CMU Capture the Flag Team

62

Red Team

• Vulnerability Discovery
• Exploitation
• Network mapping
• Web security

Blue Team

• Intrusion detection
• Hot-patching
• Firewalls
• Work-arounds

63

64

10,000 Students in 2,000 teams

65

Size of circle proportional to number of teams

66

67

Example Network Forensics

68

PicoCTF

• 10,000 students
• 600 teams solving advanced problems

– ROP attacks – Breaking incorrect use of modern crypto

• Identified the best of the best

“I learned more in one week than the last two years in CS courses.”

69

If you get an A, you may be eligible to help with PicoCTF 2014

70

Questions?

END

Information Flow

72

Program High In Low In High Out Low Out

OK to mix NO mixing!

e.g., password e.g., dictionary

73

Information Flow

Data Dependence

Assignment

Control Dependence

if-then-else

Side Channel

Timing

Information Flow Goals

• What is safe and unsafe information flow?
• How is it calculated?
• Know the non-interference information flow

property.

74

Execution Safety

Trapped Errors

halts computation immediately ex:

• divide by zero
• dereference (R/W)

an illegal address

Untrapped Errors

can go unnoticed until (possibly much) later ex:

• buffer overflow
• writing an integer into

an array of strings

75

76

Safe Languages

Untrapped Errors

can go unnoticed until (possibly much) later ex:

• buffer overflow
• writing a string into an

integer

77

A safe language has no untrapped errors.

untyped typed statically checked dynamically checked

“typechecking”

Execution Safety Goals

• State what type safety means.
• Read typing inference rules.
• Give examples of differences between type

safety and security.

• State control flow integrity

– Give examples of vulnerabilities protected by CFI – Give examples of vulnerabilities not protected by CFI

78
