INSTRUMENTATION & DETECTORS for HIGH ENERGY PHYSICS I 05-07.11.2014 Isabelle Wingerter-Seez (LAPP-CNRS) - AEPSHEP2014 - Puri (India) 1 WHAT IS A PARTICLE DETECTOR ? An apparatus able to detect the passage of a particle and/or

slide-1
SLIDE 1

05-07.11.2014 Isabelle Wingerter-Seez (LAPP-CNRS) - AEPSHEP2014 - Puri (India)

INSTRUMENTATION & DETECTORS for HIGH ENERGY PHYSICS I

1

slide-2
SLIDE 2

05-07.11.2014

WHAT IS A PARTICLE DETECTOR ?

An apparatus able to

detect the passage of a particle and/or localise it and/or measure its momentum or energy and/or identify its nature and/or measure its time of arrival …..

2

slide-3
SLIDE 3

05-07.11.2014

HOW ARE PARTICLES DETECTED ?

In order to detect a particle it must

interact with the material of the detector transfer energy in some recognisable way and leave a signal.

Detection of particles happens via their energy loss in the material they traverse.

3

slide-4
SLIDE 4

05-07.11.2014

FOUR STEPS

4

  • 1. Particles interact with matter

depends on particle and material

  • 2. Energy loss transfer to detectable signal

depends on the material

  • 3. Signal collection

depends on signal and type of detection

  • 4. BUILD a SYSTEM

depends on physics, experimental conditions,….

L e s s

  • n

1 L e s s

  • n

2 L e s s

  • n

3

slide-5
SLIDE 5

05-07.11.2014

ELEMENTARY PARTICLES and FORCES

5

slide-6
SLIDE 6

05-07.11.2014

PARTICLES

6

slide-7
SLIDE 7

05-07.11.2014 7

H, + the ones we have not yet observed

slide-8
SLIDE 8

H,

05-07.11.2014

KNOWN PARTICLES

HOW CAN A PARTICLE DETECTOR

DISTINGUISH THE PARTICLES WE KNOW MEASURE PROPERTIES of PHYSICS PROCESSES IDENTIFY THE EXISTENCE OF A NEW PARTICLE

?

8

+ the ones we have not yet observed

slide-9
SLIDE 9

05-07.11.2014

LIMITED SIZE DETECTOR

A m o n g t h e s e 1 8 0 l i s t e d particles, 27 have a long enough lifetime such that, for GeV energies, they travel more than one micrometer Among these 27, 14 have c.τ <0.5 mm and leave a very short track in the detector

9

slide-10
SLIDE 10

05-07.11.2014

THE 13 PARTICLES A DETECTOR MUST BE ABLE TO MEASURE AND IDENTIFY

10

slide-11
SLIDE 11

05-07.11.2014

EXAMPLES OF INTERACTIONS

11

slide-12
SLIDE 12

05-07.11.2014

HEP & SI UNITS

12

slide-13
SLIDE 13

05-07.11.2014

MEASURING PARTICLES

13

slide-14
SLIDE 14

05-07.11.2014

INTERACTION CROSS-SECTION

14

slide-15
SLIDE 15

05-07.11.2014

FERMI GOLDEN RULE

15

slide-16
SLIDE 16

05-07.11.2014

CROSS-SECTION: ORDER OF MAGNITUDE

16

slide-17
SLIDE 17

05-07.11.2014

PROTON-PROTON SCATTERING CROSS-SECTION

17

slide-18
SLIDE 18

05-07.11.2014

CROSS-SECTIONS AT THE LHC

18

TRIGGER !

slide-19
SLIDE 19

05-07.11.2014

ELECTROMAGNETIC INTERACTION PARTICLE - MATTER

19

Interaction with the atomic electrons. The incoming particle loses energy and the atoms are exited or ionised. Interaction with the atomic nucleus. The incoming particle is deflected causing multiple scattering of the particle in the material. During this scattering a Bremsstrahlung photon can be emitted In case the particle’s velocity is larger than the velocity of light in the medium, the resulting EM shockwave manifests itself as Cherenkov radiation. When the particle crosses the boundary between two media, there is a probability of 1% to produce an Xray photon called Transition radiation.

slide-20
SLIDE 20

05-07.11.2014

ENERGY LOSS BY IONISATION: BETHE-BLOCH FORMULA

20

slide-21
SLIDE 21

05-07.11.2014

IONISATION & EXCITATION

21

While the charged particle is passing another charged particle the Coulomb force is acting, resulting in momentum transfer. The relativistic form of the transverse electric field does not change the momentum transfer. The transverse field is stronger, but the time of action is shorter.

slide-22
SLIDE 22

05-07.11.2014

IONISATION & EXCITATION

22

The transferred energy The incoming particle transfers energy mainly/only to the atomic electrons.

slide-23
SLIDE 23

05-07.11.2014

BETHE-BLOCH FORMULA - CLASSICAL DERIVATION

23

slide-24
SLIDE 24

05-07.11.2014

BETHE-BLOCH FORMULA - CLASSICAL DERIVATION

24

slide-25
SLIDE 25

05-07.11.2014

BETHE-BLOCH FORMULA

25

slide-26
SLIDE 26

05-07.11.2014

ENERGY LOSS of PIONS in Cu

26

slide-27
SLIDE 27

05-07.11.2014

UNDERSTANDING BETHE-BLOCH

27

slide-28
SLIDE 28

05-07.11.2014

UNDERSTANDING BETHE-BLOCH

28

slide-29
SLIDE 29

05-07.11.2014

CHARGED PARTICLE ENERGY LOSS in MATERIALS

Dependance on target element

Mass A Charge Z

Minimum Ionisation

  • dE/dx ~ 1-2 MeV g-1cm2

e.g. for Pb with ρ=11.35 g/cm3:

  • dE/dx ~ 13 MeV/cm

29

slide-30
SLIDE 30

05-07.11.2014

MATERIAL PROPERTIES

30

slide-31
SLIDE 31

05-07.11.2014 31

slide-32
SLIDE 32

05-07.11.2014

STOPPING POWER AT MINIMUM IONISATION

32

slide-33
SLIDE 33

05-07.11.2014

dE/dX and PARTICLE IDENTIFICATION

33

slide-34
SLIDE 34

05-07.11.2014

dE/dx FLUCTUATIONS

34

slide-35
SLIDE 35

05-07.11.2014

dE/dx FLUCTUATIONS - LANDAU DISTRIBUTION

35

slide-36
SLIDE 36

05-07.11.2014

MEAN PARTICLE RANGE

36

slide-37
SLIDE 37

05-07.11.2014

ENERGY LOSS of ELECTRONS

37

slide-38
SLIDE 38

05-07.11.2014

ELECTROMAGNETIC INTERACTION PARTICLE - MATTER

38

Interaction with the atomic electrons. The incoming particle loses energy and the atoms are exited or ionised. Interaction with the atomic nucleus. The incoming particle is deflected causing multiple scattering of the particle in the material. During this scattering a Bremsstrahlung photon can be emitted In case the particle’s velocity is larger than the velocity of light in the medium, the resulting EM shockwave manifests itself as Cherenkov radiation. When the particle crosses the boundary between two media, there is a probability of 1% to produce an Xray photon called Transition radiation.

slide-39
SLIDE 39

05-07.11.2014

BREMSSTRAHLUNG

39

Real photon emission in the electromagnetic field of the atomic nucleus

where y=k/E and

For a given E, the average energy lost by radiation, dE, is obtained by integrating over y.

Electric field of the nucleus + of the electrons Z(Z+1) At large radius, electrons screen the nucleus ln(183Z-1/3) [D.F.]

slide-40
SLIDE 40

05-07.11.2014

BREMSSTRAHLUNG & RADIATION LENGTH

40

slide-41
SLIDE 41

05-07.11.2014

RADIATION LENGTH

The radiation length is a “universal” distance, very useful to describe electromagnetic showers (electrons & photons) X0 is the distance after which the incident electron has radiated (1-1/e) 63% of its incident energy

41

Air Eau Al LAr Fe Pb PbWO4 LAr/Pb Z

  • 13

18 26 82

  • X0 (cm)

30420 36 8,9 14 1,76 0.56 0.89 1.9

dE/dx=E/X0 dE/E=dx/X0 E=E0e-x/X0

E0

1X0

0,37 E0

1 3 2

slide-42
SLIDE 42

05-07.11.2014

RADIATION LENGTH

42

Approximation (X0 in cm: divide by ρ [g/cm3]) Energy loss by radiation γ Absorption (e+ e- pair creation) For compound material wj being the relative density

: 1/ X0 = " wj / Xj

slide-43
SLIDE 43

05-07.11.2014

CRITICAL ENERGY

43

slide-44
SLIDE 44

05-07.11.2014

TOTAL ENERGY LOSS FOR ELECTRONS

44

slide-45
SLIDE 45

05-07.11.2014

µ+ in COPPER

45

slide-46
SLIDE 46

05-07.11.2014

INTERACTION OF PHOTONS WITH MATTER

46

slide-47
SLIDE 47

05-07.11.2014

PHOTO-ELECTRIC EFFECT

47

slide-48
SLIDE 48

05-07.11.2014

PHOTO-ELECTRIC EFFECT

48

slide-49
SLIDE 49

05-07.11.2014

PAIR PRODUCTION

49

slide-50
SLIDE 50

05-07.11.2014

COMPTON SCATTERING

50

Process dominant at Eγ ≃ 100 keV - 5 GeV scattered e- Ee’=√me2c4+pe’2c2 Pe’=- pγ’ Atomic e- Ee=mec2 Pe~0

Incident Photon Eγ = h ν pγ =h ν/c Scattered photon Eγ’ = h ν’ pγ’=h ν’/c

θ φ

σcompton ∼ Z . ln(Eγ)/Eγ QED cross-section for γ-e scattering

slide-51
SLIDE 51

05-07.11.2014

ANGULAR DISTRIBUTION

51

slide-52
SLIDE 52

05-07.11.2014

INTERACTION OF PHOTONS WITH MATTER

52

Mass absorption coefficient λ = 1/(µ/ρ) [g.cm2] with µ=ΝΑ.σ/A

slide-53
SLIDE 53

05-07.11.2014

INTERACTION OF PHOTONS WITH MATTER

53

slide-54
SLIDE 54

05-07.11.2014

ELECTROMAGNETIC INTERACTION PARTICLE - MATTER

54

Interaction with the atomic electrons. The incoming particle loses energy and the atoms are exited or ionised. Interaction with the atomic nucleus. The incoming particle is deflected causing multiple scattering of the particle in the material. During this scattering a Bremsstrahlung photon can be emitted In case the particle’s velocity is larger than the velocity of light in the medium, the resulting EM shockwave manifests itself as Cherenkov radiation. When the particle crosses the boundary between two media, there is a probability of 1% to produce an Xray photon called Transition radiation.

slide-55
SLIDE 55

05-07.11.2014

CERENKOV RADIATION

Particles moving in a medium with speed larger than speed of light in that medium loose energy by emitting electromagnetic radiation

Charged particles polarise the medium generating an electrical dipole varying with time Every point in the trajectory emits a spherical EM wave; waves constructively interfere

55

slide-56
SLIDE 56

05-07.11.2014

CERENKOV RADIATION

56

slide-57
SLIDE 57

05-07.11.2014

IDENTIFYING PARTICLES with CERENKOV RADIATION

57

slide-58
SLIDE 58

05-07.11.2014

CERENKOV RADIATION: MOMENTUM DEPENDENCE

58

mπ = 0.1395 GeV mK = 0.4937 GeV mp = 1 .007 GeV

slide-59
SLIDE 59

05-07.11.2014

COSMIC RAYS

59

slide-60
SLIDE 60

05-07.11.2014

HESS EXPERIMENT

60

slide-61
SLIDE 61

05-07.11.2014

Transition radiation

Transition radiation occurs if a relativistic particle (large γ) passes the boundaries between two media with different refraction indices.

Intensity of radiation is logarithmically proportional to γ

61

slide-62
SLIDE 62

05-07.11.2014

IDENTIFYING PARTICLES WITH TRANSITION RADIATION

62

slide-63
SLIDE 63

05-07.11.2014

ATLAS TRANSITION RADIATION TRACKER

63

slide-64
SLIDE 64

05-07.11.2014

IDENTIFYING PARTICLES WITH TRANSITION RADIATION

64

slide-65
SLIDE 65

05-07.11.2014

MULTIPLE SCATTERING

65

Example p=1 GeV, x=300µm, Si X0=9.4 cm ➝ θ0=0.8 mrad For a distance of 10 cm this corresponds to 80 µm, which is significantly larger than typical resolution of Si-strip detector. Scattering of charged particles off the atoms in the mdium causes a change of direction The statistical sum of many such small angle scattering results in a gaussian angular distribution with a width given by

slide-66
SLIDE 66

05-07.11.2014

ELECTROMAGNETIC SHOWERS

66

slide-67
SLIDE 67

05-07.11.2014

HADRONIC SHOWERS

67

slide-68
SLIDE 68

05-07.11.2014

HADRONIC SHOWERS

68

slide-69
SLIDE 69

05-07.11.2014

HADRONIC INTERACTION LENGTH

69

For high energies incoming hadrons, the hedronic cross-section is ~constant as function of energy ~independant of the hadron type The material dependance of the total cross-sectionis given by σinel ≈ σ0A0.7, σ0 = 35 mb Characterize hadronic interactions by hadronic interaction length in g/cm2 (or in [cm] by normalising to the material density).

slide-70
SLIDE 70

05-07.11.2014

INTERACTIONS OF PARTICLES WITH MATTER

70

IONISATION AND EXCITATION Charged particles traversing material and exciting and ionising atoms. The average energy loss of the incoming particle by the process, is to a good approximation, described by the Bethe- Block formula. MULTIPLE SCATTERING AND BREMSSTRAHLUNG Incoming particles are scattering off the atomic nuclei which are partially shielded by the atomic electrons. This scattering imposes a lower level on the momentum resolution of the spectrometer, when measuring the particle momentum by deflection of the particle trajectory in the magnetic field. The deflection of the particle on the nucleus results in an acceleration that causes the emission of Bremsstrahlung photons. The photons in turn produce e+e- pairs in the vicinity of the nucleus, which causes the EM cascade. This effect depends on m-2: only relevant for electrons. CHERENKOV RADIATION If a particle propagates in a material with velocity > speed of light in this material, C radiation is emitted at a characteristic angle that depends on the particle velocity and the refractive index of the medium TRANSITION RADIATION If a charged particle is crossing the boundary between two materials of different dielectric permittivity, there is a certain probability for emission of an X- ray photon. HADRONIC INTERACTION Incoming hadrons on a material will interact with the nucleus and create a shower composed of hadrons, electrons, photon. A fraction of the energy is lost in the form of binding energy or neutrinos.

INTERACTIONS DETECTORS

slide-71
SLIDE 71

05-07.11.2014

ELECTROMAGNETIC INTERACTIONS OF PARTICLES WITH MATTER

71

Interaction with the atomic electrons. The incoming particle loses energy and the atoms are exited or ionised. Interaction with the atomic nucleus. The incoming particle is deflected causing multiple scattering of the particle in the material. During this scattering a Bremsstrahlung photon can be emitted In case the particle’s velocity is larger than the velocity of light in the medium, the resulting EM shockwave manifests itself as Cherenkov radiation. When the particle crosses the boundary between two media, there is a probability of 1% to produce an Xray photon called Transition radiation.

INTERACTIONS DETECTORS

slide-72
SLIDE 72

05-07.11.2014

PARTICLE DETECTION: schematic

72

INTERACTIONS DETECTORS

slide-73
SLIDE 73

05-07.11.2014

PARTICLE DETECTION: schematic

73

slide-74
SLIDE 74

05-07.11.2014 74

slide-75
SLIDE 75

05-07.11.2014

CREDIT and BIBLIOGRAPHY

A lot of material in these lectures are from:

Daniel Fournier @ EDIT2011 Marco Delmastro @ ESIPAP 2014 Weiner Raigler @ AEPSHEP2013 Hans Christian Schultz-Coulon’s lectures Carsten Niebuhr’s lectures [1][2][3] Georg Streinbrueck’s lecture Pippa Wells @ EDIT2011 Jérôme Baudot @ ESIPAP2014
