Identification of Nonlinear LFR Systems starting from the Best Linear Approximation M. Schoukens and R. Tth EE EE Con ontrol Systems tems Nonlinear System Class 2 Outline Nonlinear System Class Initialization & Estimation Examples
SLIDE 2
SLIDE 3
Nonlinear System Class Initialization & Estimation Examples Conclusions
3
Outline
SLIDE 4
Nonlinear System Class Initialization & Estimation Examples Conclusions
4
Outline
SLIDE 5
5
Nonlinear System Class
SLIDE 6
6
Nonlinear System Class
SLIDE 7
7
Nonlinear LFR vs Nonlinear SS
Structured NL State-Space
SLIDE 8
8
Nonlinear LFR vs Nonlinear SS
Full NL State-Space πΆw = π½ππ¦ π·z = π½ππ¦ 0ππ£ πΈzu = 0ππ¦ π½ππ£ πΈyw = π½ππ§
SLIDE 9
9
Uniqueness of the Representation
SLIDE 10
10
Uniqueness of the Representation
All the problems of linear state-space representation
SLIDE 11
11
Uniqueness of the Representation
All the problems of linear state-space representation Additional exchange of a linear gain between the nonlinearity and the linear dynamics
SLIDE 12
Nonlinear System Class Initialization & Estimation Examples Conclusions
12
Outline
SLIDE 13
13
Initialization & Estimation
Step 1: Estimate the Best Linear Approximation
Initial estimate of:
Frequency Domain Nonparametric BLA Rational Transfer Function State-Space Realization
SLIDE 14
14
Initialization & Estimation
Step 1: Estimate the Best Linear Approximation
For a good initial estimate, all the states should be βvisibleβ for the best linear approximation of the system
SLIDE 15
15
Initialization & Estimation
Step 2: Nonlinear optimization of all the parameters together Initializing Nonlinearity, w and z Matrices Nonlinearity can be replaced in a 3rd step
SLIDE 16
16
Initialization & Estimation
Step 2: Nonlinear optimization of all the parameters together
Nonlinear Optimization Levenberg-Marquardt Optimization
simulation error
SLIDE 17
Nonlinear System Class Initialization & Estimation Examples Conclusions
17
Outline
SLIDE 18
18
Silverbox Benchmark
SLIDE 19
19
Silverbox Benchmark
Validation Estimation
SLIDE 20
20
Silverbox Benchmark
nx = 2 3rd degree polynomial nonlinearity
SLIDE 21
21
Silverbox Benchmark
nx = 2 3rd degree polynomial nonlinearity rms errors on estimation data linear model error: 6.62 mV NL-LFR error: 0.25 mV rms errors on validation data linear model error: 14.5 mV NL-LFR error: 0.38 mV
SLIDE 22
22
Silverbox Benchmark
Validation Estimation
SLIDE 23
23
Silverbox Benchmark
SLIDE 24
24
Silverbox Benchmark
SLIDE 25
25
Silverbox Benchmark
SLIDE 26
26
Wiener-Hammerstein Benchmark
SLIDE 27
27
Wiener-Hammerstein Benchmark
Validation Estimation
SLIDE 28
28
Wiener-Hammerstein Benchmark
nx = 6 5th degree polynomial nonlinearity Neural network 20 neurons β 1 hidden layer - tansig rms errors on estimation data linear model error: 55.8 mV NL-LFR error: 0.29 mV rms errors on validation data linear model error: 56.1 mV NL-LFR error: 0.30 mV
SLIDE 29
29
Wiener-Hammerstein Benchmark
Validation Estimation
SLIDE 30
30
Wiener-Hammerstein Benchmark
SLIDE 31
31
Wiener-Hammerstein Benchmark
SLIDE 32
32
Wiener-Hammerstein Benchmark
SLIDE 33
33
Wiener-Hammerstein Benchmark
SLIDE 34
Nonlinear System Class Initialization & Estimation Examples Conclusions
34
Outline
SLIDE 35
35
Conclusions
Structured model directly from the data Linear initial model followed by NL optimization Good results on simple benchmark examples Future work: MIMO NL, MIMO LTI
