Deep Learning

Barun Patra

Index

• Introduction to Neural Nets
• Activations

○ Sigmoid ○ Tanh ○ Relu (Derivatives)

• Gradients
• Initialization
• Regularization

○ Dropout ○ Batch Norm

• Convolutional Networks

○ Inspiration ○ Kernels ○ Idea ○ As used in NLP

• Paper Discussion

Introduction

Image from Stanford’s CS231n supplementary notes

Representational Power

• A single hidden layer NN can approximate any function
• http://neuralnetworksanddeeplearning.com/chap4.html

So why do we use deep neural networks ??

• Sometimes more intuitive (Images)
• Works well in practice

Commonly Used Activations : Sigmoid

• Historically used.
• Has a nice interpretation as neuron firing
• Tendency to saturate and kill gradient
• In regions where neuron is 1 or 0, gradient is 0

Commonly Used Activations: Tanh

• Still Saturates, killing gradient
• Gradient ≠ 0, when the function is 0

Commonly Used Activations: ReLU

• Does not saturate
• Faster to implement
• Can cause network to die
• Converges faster in practice

Commonly Used Activations: Leaky ReLU & Maxout

Generalizing Leaky ReLU (Maxout) Leaky ReLU

• Double the number of parameters

Backpropagation and Gradient Computation

• Let z(i) be the output of the i(th) layer, and s(i) be the input.
• Let f be the activation being applied.
• Let w(i)

jk be the weight connecting the jth and the kth unit in the ith

layer

• We have:

Backpropagation and Gradient Computation

Backpropagation and Gradient Computation

Backpropagation and Activation

• Why does sigmoid learn slowly ??

Taken from “Understanding the difficulty of training deep feedforward neural networks”, Glorot and Bengio

Babysitting your gradient:

• For few examples (4-5 in a batch), compute numerical gradient
• Compare gradient from backprop and the numerical gradient

○ Use relative error instead of absolute error

• Rule of thumb:

○ relative error > 1e-2 usually means the gradient is probably wrong ○ 1e-2 > relative error > 1e-4 should make you feel uncomfortable ○ 1e-4 > relative error is usually okay for objectives with kinks. But if there are no kinks (e.g. use of tanh nonlinearities and softmax), then 1e-4 is too high. ○ 1e-7 and less you should be happy.

Initialization : Glorot Uniform / Xavier

• Do not start with all 0’s (Nothing to break symmetry in a layer)
• Sample from above uniform distribution/ Gaussian distribution

• Consider a network with linear neurons.
• Let z(i) be the output of the i(th) layer, and s(i) be the input
• Let Input (x) be of uniform variance Var[x] and 0 mean
• Let all weights are i.i.d’s. Then:

Initialization : Kuch Bhi ??

Initialization : Kuch Bhi ??

• Similarly

Initialization : Kuch Bhi ??

• For Information to flow, we want
• And hence:

Initialization : Sigmoid and ReLU

• The linear assumption good enough for tanh
• For Sigmoid and ReLU, small modifications needed
• The modification for ReLU + Some other stuff:

○ By He, Zang and Reng : https://arxiv.org/pdf/1502.01852.pdf ○ Surpassed human level performance on ImageNet Classification

Regularization (Motivation):

Strong tendency of a Neural Net to overfit

Regularization (Motivation):

Effect of L2 Regularization

Regularization (Methodology):

• L1 Regularization
• L2 Regularization
• Introducing Noise
• Max norm of weights
• Early stopping using validation set
• Dropouts
• Batch Normalization

Dropouts:

• Each hidden unit in a neural network trained with dropout must learn to work with a

randomly chosen sample of other units. This should make each hidden unit more robust and drive it towards creating useful features on its own without relying on other hidden units to correct its mistakes.

• http://www.jmlr.org/papers/volume15/srivastava14a.old/source/srivastava14a.pdf

Batch Normalization:

• Normalizing the input helps in training.
• What if we could normalize the input to every layer of the network ?
• For each layer with d dim input (x1 … xd), we want
• But normalizing like this may change what the layer represents
• To overcome that, the transformation inserted in the network can

represent the identity transform

Batch Normalization:

• Leads to faster training
• Less dependance on initializations

Some practical advice:

• Gradient check on small data
• Overfit without regularization on

small data.

• Decay learning rate with time
• Regularize
• Always check learning curves

Introduction to Convolutional networks

• What are these convolutions and kernels ??
• https://docs.gimp.org/en/plug-in-convmatrix.html

Introduction to Convolutional Networks

• Animation at http://cs231n.github.io/convolutional-networks/

Kind of features learnt :

Convolutional Networks in NLP

• Gives a good generalization of unigram, bigram etc. features in embedding space
• With more layers, the receptor field increases

Taken from Hierarchical Question Answering using Co Attention

Relation Extraction with Conv Networks:

• Assumption : Every sentence between two entities express the relation
• Issue : Too Strong

Issue 1 with the Previous task (Mintz et al., 2009):

• Solution: Use Multi Instance Multi Label Model

Taken from (Zeng et. al, 2015)

Issue 2 with the Previous Task :

• Used hand crafted features + other NLP tools like dependency parsers

○ Have poor performance with increased sentence length ○ Long sentences form nearly 50% of the corpus being used to extract the relations

• Solution : Use Deep Learning !

○ Enter Convolutional Networks

The Model (Overview) :

Taken from (Zeng et. al, 2015)

The Model (Embedding):

• Train word2vec (skip gram model) [Why not CBOW ?]
• Use positional embeddings ( distance from the two entities) :

○ Capture the notion of distance of the word from the entities ○ The same word, at different locations at the sentence, might have different semantics ○ A proxy to LSTM embeddings

• Final dimension for one word : R(embed_dim + 2*embed_position)
• Final dimension of the embedding layer : R|Sentence| * ( embed_dim +

2*embed_position)

The Model (Convolution):

• Convolution with kernel width W
• W ∈ R W * ( n_dim_vector)
• N filters (Hyper parameter)
• Zero padding to ensure every word

gets convolved

• Final Layer Dimension: R|N| * (|S| + |W| -

1)

The Model (Pooling + Softmax):

• Pooling done in piecewise manner
• Idea from three parts of sentence

○ Remember ReVerb ??

• Less coarse than a single softmax
• The final dimension is R|num_filters| * 3
• Tanh
• Softmax to get probability over all

relations

The Data :

• A bag is labeled r if there is at least one sentence which contains r
• A bag contains all sentences between a pair of entities
• Potentially multiple same bags with different labels [ Unclear ]

The Objective Function And Training :

• Trained with mini batches of bags, with Ada Delta

Inference :

• Given a bag and a relation r
• The bag is marked to contain r if there exists one sentence in bag with

predicted r

Experiment Setup:

• Dataset: Aligning Freebase relations with NYT corpus
• Training: Sentence from 2005-06
• Testing : Sentences from 2007
• Held out evaluation : Extracted Relations against Freebase
• Manual evaluation : Evaluation by human
• Word2Vec trained on the NYT corpus. Entity tokens concatenated with ##
• Grid search over hyper parameters

Results (Held out evaluation) :

• Half of the Freebase relations used for testing [ Doubt ]
• Relations extracted from test articles compared against the Freebase Relations
• Results compared against Mintz, MultiR and Multi Instance Multi Label Learning

Results (Manual Evaluation)

• Chose Entity pairs where at least one was not present in Freebase as

candidate (To avoid overlap with the held out set)

• Top N relations extracted, and precision computed
• Since not all relations are known, recall not given (Pseudo Recall ??)

Results (Ablation Study):

Problems :

• Analysis of where PCNN improves over MultiR/MIML lacking [Surag]
• No coreference resolution [Rishab]
• No alternatives to 3 segment piecewise convolution [Haroun]
• Suffers from incomplete Freebase [Daraksha]
• Does not consider overlapping relations [Daraksha]
• A lot of training examples not being used [Shantanu]
• No comparison with other architectures [Akg]

Extensions :

• LSTM’s [A lot of people]/ More convolutional layers
• Bootstrapping along with Multi R
• Use other lexical features:

○ A comparison with handcrafted features and kernel based approach could be done to see what the architecture fails to capture [Anshul] ○ Consequently, kernel features could be added [Haroun, Dinesh Raghu] ○ Critiquing the critics [Arindam]

• Recursive auto encoders [Dinesh R.] (?)
• Better embeddings [Gagan, Happy]
• Using alternative Knowledge Bases for evaluation [Happy]
• Taking all the sentences which show the relation instead of the one with

the max probability [Shantanu]

Extensions (Contd.) :

• Binning according to length (But how many weights to train?) [Anshul]
• Adding Logic based constraints while learning (Confidence(y1) =>

Confidence(y2)) [Prachi]

• Instead of at least 1, at least k paradigm [Yashoteja]
• Attention based LSTM, CNN [Prachi] (?)
• A probability distribution over the sentences in a bag, with every sentence

predicting a relation, or NONE [Yashoteja]
