Harbor Boulevard Enhancement Project US 41 to Olean Boulevard Board of County Commissioners Workshop April 15, 2014 Client: Charlotte County Consultants: Johnson Engineering Kimley-Horn & Associates Banks Engineering Southwest

SLIDE 1

US 41 to Olean Boulevard

Board of County Commissioners Workshop April 15, 2014

Client: Charlotte County Consultants: Johnson Engineering Kimley-Horn & Associates Banks Engineering Southwest Engineering & Design

Harbor Boulevard Enhancement Project

SLIDE 2

1. Lighting
2. Gateway Feature
3. Landscape, Wayfinding & Amenities
4. Preliminary Access Management
5. FPL
Questions

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

Agenda

SLIDE 3

Lighting: Option 1

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop Furnish & install Costs (per pole) Yearly O&M Costs (per pole) $10,700 $630

SLIDE 4

Lighting: Option 2

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

Bollard Lighting

Furnish & install Costs (per pole) Yearly O&M Costs (per pole) $7,700 (lights) +$4,800 (bollards) $12,500 (Total) $470

SLIDE 5

Lighting Option #3

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop Furnish & install Costs (per pole) Yearly O&M Costs (per pole) $6,700 $380

SLIDE 6

Lighting

Option Description Furnish & install Costs (per pole) Yearly O&M Costs (per pole) 1 Decorative enhanced & Low level pathway lighting (2nd Light Arm) $10,700 $630 2 Decorative enhanced w/outlets, banner arms; also bollard pathway lighting $7,700 (lights) +$4,800 (bollards) $12,500 (Total) $470 3 Decorative lighting; no enhancement, no pedestrian lighting $6,700 $380 Bollard Pathway Lighting where needed (for Safety & Supplemental Lights) $4,800 $125

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 7

Gateway Feature: Option #1

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop Cost Estimate $125,000 (Both Islands & Both Corners)

SLIDE 8

Gateway Feature: Option #1

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

*Materials TBD (brick, field stone, stucco) Column

Cost Estimate $125,000 (Both Islands & Both Corners)

SLIDE 9

Gateway Feature: Option #2

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop Cost Estimate $175,000 (Both Corners & One Median)

SLIDE 10

Gateway Feature: Option #2

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

*Materials TBD (brick, field stone, stucco) Column

Cost Estimate $175,000 (Both Corners & One Median)

SLIDE 11

Gateway Feature: Option #3

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop Cost Estimate $1,250,000

SLIDE 12

Gateway Features

Opt. Location Type of Feature Cost Estimate Notes:

1 Access Road Islands & Corners Island: Columns Corners: Large Sign/Wall $125,000 (Both Islands & Both Corners)

Duplicate on Olean No acquisition Medical sign Drainage Impacts Property sight issues Closest to US 41

2 Access Road Corners & Harbor Blvd Median Corners: Columns Median: Smaller Sign/Wall $175,000 (Both Corners & One Median)

Acquisition needed Drainage impacts Duplicate on Olean Farthest from US41

3 US 41 Grande Entrance as shown in the Citizen’s Master Plan $1,250,000

Acquisition FDOT Coordination Major Road Work Utility Re-Work

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop *All options have O&M Costs considerations not expressed in table.

SLIDE 13

Landscape, Wayfinding & Amenities

Pedestrian Nodes

Benches
Trash Receptacles
Bike Racks
Oasis

Wayfinding

Signs & Banners
Logo features
Inlaid Logo

Landscape

Canopy Trees
Decorative Trees (Right Tree-

Right Place)

Median landscaping
Florida Friendly

Hardscape Opportunity

Pavers
Concrete stamped
Porous

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 14

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

Landscape, Wayfinding & Amenities

SLIDE 15

Landscape, Wayfinding & Amenities

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop ENHANCED WAYFINDING WITH CUSTOM SHAPES SIGN ENHANCEMENTS

SLIDE 16

Landscape, Wayfinding & Amenities

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

POSSIBLE PEDESTRIAN NODE DETAIL

SLIDE 17

Preliminary Access Management

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 18

Preliminary Access Management

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 19

Preliminary Access Management

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 20

Preliminary Access Management

Day Video: Day Video Night Video: Night Video Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 21

Preliminary Access Management

Stakeholder Meeting

April 9th 5-7PM

Cultural Center - Room A

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 22

FPL: Overhead v. Underground

(Seeking BCC Direction)

East Side
Existing east side is service lines & street lights
Proposed to underground new lighting (street & pedestrian)
West Side
Existing 3 Phase Distribution trunk lines
Estimate of $500,000 to put underground in R/W
Property owners responsible to connection fees, FPL states:
Residential: $1,200-$7,500
Commercial: Depending on Load analysis by FPL
Easements would be required
Estimate of 9 months of construction, FPL Contractor

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop

SLIDE 23

QUESTIONS ?

Harbor Boulevard Improvements

Harbor Boulevard Enhancement Project

April 15, 2014 Board of County Commissioners Workshop
