SLIDE 1
SR 699 (Gulf Boulevard) from Park Boulevard to Walsingham Road
FPID: 436697-1-52-01
ADDITION OF SEPARATE PEDESTRIAN WAY WITHIN THE TOWN OF INDIAN SHORES
Presentation to the Town
- f Indian Shores
OCTOBER 29, 2019
SR 699 (Gulf Boulevard) from Park Boulevard to Walsingham Road - - PowerPoint PPT Presentation
SR 699 (Gulf Boulevard) from Park Boulevard to Walsingham Road - - PowerPoint PPT Presentation
SR 699 (Gulf Boulevard) from Park Boulevard to Walsingham Road FPID: 436697-1-52-01 ADDITION OF SEPARATE PEDESTRIAN WAY WITHIN THE TOWN OF INDIAN SHORES Presentation to the Town of Indian Shores OCTOBER 29, 2019 Existing Project FDOT to
SLIDE 2
SLIDE 3
Existing Project
FDOT to construct drainage improvements
- Install drainage structures
- Reconstruct pervious pavement
SLIDE 4
Proposed Project Improvements
FDOT to construct separated pedestrian way on Gulf Boulevard within the Town limits Two typical sections
- Section 1 from 191st Avenue to 195th Avenue
- Section 2 from 195th Avenue to Whitehurst Avenue
SLIDE 5
Proposed Project Improvements
Section 1 from 191st Avenue to 195th Avenue
- Existing FDOT Right-of-Way width is 60 to 100 feet
- Allows for separated bicycle path and sidewalk
- Existing 5-foot asphalt bicycle path to remain
- Add six-foot wide sidewalk
- As far from the road as feasible
- Meandering alignment
- Landscape opportunity areas between bicycle path and sidewalk
- Original drainage improvements to be constructed
SLIDE 6
Proposed Improvements
Section 1 from 191st Avenue to 195th Avenue
- All proposed sidewalk improvements are within existing SR 699 (Gulf
Boulevard) right-of-way
- Where possible connections to existing sidewalks will be built
- Right-of-way encroachments conflict with the proposed sidewalk
- Signs, fences, parking areas, walls, etc.
SLIDE 7
Section 1 – Typical Section
Color for illustration purposes only
SLIDE 8
Section 1 – Typical Section BEFORE AFTER
Color for illustration purposes only
SLIDE 9
Section 1 – Typical Section
Color for illustration purposes only
BEFORE
6’ Varies 5’ 10’ 10’ 5’ 6’ Varies
Swk. Sod Sod Swk. Travel Lane Travel Lane Shldr.
Bicycle Path
Right of Way Right of Way
Shldr.
Bicycle Path
SLIDE 10
Section 1 – Sidewalk Layout
Color for illustration purposes only
SLIDE 11
Section 1 – Sidewalk Layout
Color for illustration purposes only
SLIDE 12
Section 1 – Sidewalk Layout
Color for illustration purposes only
SLIDE 13
Proposed Project Improvements
Section 2 from 195th Avenue to Whitehurst Avenue
- FDOT Right of Way width is 40 feet
- Cannot build separate bicycle path and sidewalk
- New six-inch high curb between existing travel lanes and sidewalk
- Drop curb at driveways
- Eight-foot wide concrete pervious sidewalk behind curb
- Slots in curb for drainage
- Original drainage improvements to be constructed
SLIDE 14
Section 2 – Typical Section
Color for illustration purposes only
SLIDE 15
Section 2 – Typical Section BEFORE AFTER
Color for illustration purposes only
SLIDE 16
Section 2 – Typical Section
Color for illustration purposes only
Right of Way 10’ 10’ 8’
Swk. Travel Lane Travel Lane
Right of Way 8’
Swk.
2’ 2’
SLIDE 17
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 18
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 19
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 20
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 21
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 22
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 23
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 24
Section 2 – Path and Sidewalk Layout
Color for illustration purposes only
SLIDE 25
