SLIDE 1
Computer Science and Computer Engineering
1
CSCE
2
GUI Programming
- Event-driven programming
- GUI event loop
- Event listeners
- Components can generate events
Graphical User Interfaces (GUIs) CS 144 John Goettsche Computer - - PowerPoint PPT Presentation
Graphical User Interfaces (GUIs) CS 144 John Goettsche Computer - - PowerPoint PPT Presentation
Graphical User Interfaces (GUIs) CS 144 John Goettsche Computer Science and Computer Engineering 1 GUI Programming Event-driven programming GUI event loop Event listeners Components can generate events 2 CSCE Event
SLIDE 2
SLIDE 3
CSCE
3
Event Driven Programming
Event loop Event Listener
Event
SLIDE 4
CSCE
4
Example: Push Counter
- Update counter when button is pushed.
- Components: JButton, JLabel
- Event: button push
- Listener: actionListener
After 6 clicks: Initial GUI:
SLIDE 5
CSCE
5
Push Counter Components
Panel (JPanel object) Button (JButton object) Label (JLabel object) Frame (JFrame object)
SLIDE 6
CSCE
6
Building the GUI: Setting up Components
panel.add( button ); panel.add( label ); frame.add( panel ); The panel
SLIDE 7
CSCE
7
Building the GUI: Event Listeners
public void actionPerformed(ActionEvent e) { ... } Code to be executed when event occurs This method is contained in a class. We use
- bjects of this class to serve as "listener" objects.
SLIDE 8
CSCE
8
Building the GUI: Connecting Events to Event Listeners
button.addActionListener( listenerObject ); Object containing code for listener. (The actionPerformed method from the previous slide.)
SLIDE 9
CSCE
9
public class MyGUI { private int x; public MyGUI() { ... } private class MyInnerClass { } } Class within a class.
Inner Classes
Available to both MyGUI and MyInnerClass Inner class has access to outer class's fields.
SLIDE 10
CSCE
10
public class PushCounter extends JFrame { // The "Push Me" button private JButton pushButton; public PushCounter() { ... pushButton = new JButton( "Push Me!"); pushButton.addActionListener(new PushCounterButtonListener()); ... } private class PushCounterButtonListener implements ActionListener { public void actionPerformed(ActionEvent e) { .... } } }
Code to execute when event occurs.
A GUI Framework
Inner class implements the ActionListener interface. Extend JFrame class. Connect button click event to listener object.
SLIDE 11
CSCE
11
Inheritance
- Gain all methods and fields from inherited class.
- PushCounter is-a JFrame
public class PushCounter extends JFrame { ... } All methods/fields that are in class JFrame are now available in class PushCounter.
SLIDE 12
CSCE
12
Implementation of Interfaces
- Require the creation of certain methods (depending on the interface)
- ActionListener requires that the actionPerformed method exist.
private class PushCounterButtonListener implements ActionListener { public void actionPerformed(ActionEvent e) { .... } }
Must create the actionPerformed method
- r this will not compile.
Interface
SLIDE 13
CSCE
13
Starting Things Up
- To start a GUI-based program we need only instantiate a JFrame object.
- Remember, PushCounter is-a JFrame.
- JVM will automatically enter the event loop.
- main method may exist anywhere you like.
public static void main( String[] args ) { PushCounter frame = new PushCounter(); } Instantiate PushCounter, which extends JFrame. In GUI programs, the main method is often quite short.
SLIDE 14
CSCE
14
Code: PushCounter.java
