GENERAL TECHNICAL PRESENTATION SEPTEMBER 2017 MF/UF INTRODUCTION PAGE 1 CHALLENGES PAGE 3 SOLUTION PAGE 5 CONTENT COMPARISON PAGE 8 DESIGN CONCEPTS PAGE 14 LATEST DEVELOPMENTS PAGE 19 MF/UF INTRODUCTION PAGE 1 CLASSIFICATION OF


  1. GENERAL TECHNICAL PRESENTATION SEPTEMBER 2017

  2. MF/UF INTRODUCTION PAGE 1 CHALLENGES PAGE 3 SOLUTION PAGE 5 CONTENT COMPARISON PAGE 8 DESIGN CONCEPTS PAGE 14 LATEST DEVELOPMENTS PAGE 19

  3. MF/UF INTRODUCTION PAGE 1

  4. CLASSIFICATION OF FILTRATION TECHNOLOGIES MF/UF pore size range Pollen Colloids Germs and Bacteria Transp. Exopolym. Part. (TEP) Dissolved Organic Compounds Particle Size Log Scale Dissolved Salts Measurement TEP 100 µ m 10 µ m 1 µ m 0.1 µ m 0.01 µ m 0.001 µ m Reverse Measurement SDI Nano Osmosis Precipitated Fe & Mn compounds and HMO Ultra Filtration Micro Filtration Sand Filtration Filtration Removal of suspended solids and disinfection Sand media; Cartridge filter Polymer flat sheet Ceramic flat sheet Polymer hollow Polymer or Polymer NF/RO elements; Gravity flow or in steel, polymer membrane; membrane; fibre membrane; ceramic tubular Pressurized operation pressurized operation or other materials; Submerged Submerged Submerged membrane; Pressurized suction pressure suction pressure suction pressure Pressurized operation operation operation operation operation Typically used as pre-filtration for NF and RO P A G MF/UF INTRODUCTION E 2

  5. CHALLENGES PAGE 3

  6. CURRENT WATER TREATMENT Extremely high operational expenses High maintenance & High chemical consumption High power consumption service efforts; Frequent replacement Sea water Moderate Less Freshwater quality quantity Large pore sizes Sensitive materials High pressure operation Limited suitabilty for direct use as drinking water or subsequent NF/RO treatment Suspended solids; or other re-use purposes Iron & Manganese; Temperature; pH; Typically more than 10% Oil & grease; generated waste; Additional waste recovery Biological contaminations; Turbidity systems needed for loss reduction Limited use Huge losses of dirty (wasted resource) water resources Sewage PAGE 4 CHALLENGES

  7. SOLUTION PAGE 5

  8. CERAFILTEC‘s INNOVATIVE FILTRATION SOLUTION Very low operational expenses Durable and reliable Less chemical consumption Less power consumption operation Sea water Use of any water resources Best Maximum Freshwater Low suction quality quantity UF 0.1 µ m small pore size Robust ceramic material pressure operation Free of suspended Ideally suited for solids; Real drinking water and disinfection - subsequent NF/RO Insensitive against high Physical barrier treatment or concentrations and variations in: Recovery rate of up to 99.5% for germs & other high quality Suspended solids; which requires no additional bacteria re-use purposes Iron & Manganese; waste recovery systems; Temperature; pH; Minimal size of waste storage, Oil & grease; e.g. evaporation ponds Biological contaminations; Turbidity Lowest losses (saving of precious water resource) Sewage PAGE 6 SOLUTION

  9. CERAFILTEC‘s PRODUCTS Technology package with innovative ceramic flatsheet membrane filtration UF single ceramic flatsheet membrane plate with 0.1 µ m pore size Module 6.0 S for up to 60°C Module 6.0 H for hot water applications of up to 99°C Tower-Rack Filtration Train Single towers equipped with modules; with installed racks and Smart Box location; Fully modular design - several towers can simply be The operator simply will connect a smart phone or tablet connected with common filtered water header to form a rack; to the technology online portal by holding the mobile device Possibility to change single plates; Integrated sprinkler and air-scouring piping; close to the Smart Box; Internal filtered water collector system; Rack design without surrounding frame; The access enables a review of installed equipment and 1,000+ LMH high flux design; Fully made in plastic - Free of steel parts and hoses suitable train performance (history records) and adding of new NFC tag system for performance monitoring and support for harsh applications, like ground and seawater or other performance values into the online train database industrial applications PAGE 7 SOLUTION

  10. COMPARISON PAGE 8

  11. WHY CERAFILTEC Sand filtration vs. CERAFILTEC About 100 times smaller pore size - Best filtered water quality, free of suspended solids Real disinfection - Physical barrier for germs & bacteria About 15 times lower flow through velocity - Extremely slow filtration with less than 0.2 mm/s leads to maximum removal efficiency Reliable filtered water quality - Insensitive against feed water quality variations Maximum filtered water output - Lowest backwash waste means highest recovery rate Most compact design - Up to 5 times smaller footprint Sand media; UF membrane with 0.1 µ m pore size; Simple single-storey filtration basin without nozzle bottom Large pore size; Out-to-In surface filtration process Depth filtration - whole media body is used for separation process Due to the very compact design of CERAFILTEC existing sand filter plants can be easily rehabilitated using existing civil work structure but highly increasing filtered water quality and quantity PAGE 9 COMPARISON

  12. WHY CERAFILTEC Submerged polymer membranes vs. CERAFILTEC Insensitive against chemicals and temperature Reliable filtered water quality without decline (no material ageing) Capability of high-pressure backwash leads to efficient membrane performance recovery without use of chemicals (no process stop) Highest flux rates - Up to 15 time less filter area Insensitive against high Fe, Mn concentration and turbidity Maximum filtered water output - Lowest backwash waste means highest recovery rate Very long life time - Less maintenance, service and Polymer hollow fibre and flat sheet Ceramic flat sheet membrane; replacement efforts membranes made of PVDF, PS, PES, Out-to-In filtration; PESM and other organic materials; Submerged suction pressure operation Out-to-In filtration; Submerged suction pressure operation The fully modular and highly compact design of CERAFILTEC enables a direct replacement of polymer membrane systems using existing filtered water tank and achieving at least same filtered water output PAGE 10 COMPARISON

  13. WHY CERAFILTEC Pressurized membranes vs. CERAFILTEC Insensitive against high Fe, Mn concentration and turbidity - No risks of membrane module clogging No compaction of formed cake layers - Up to 10 times higher flux rate Very low transmembrane pressure - Especially deformable/ jelly-like particles cannot be forced into the membrane pores or even pass the filter Very long filtration duration without need of backwash - Highest recovery rate means maximum filtered water output (Semi) dead end filtration - Save on feed pump capacity Low suction pressure operation - High energy savings Tubular ceramic and polymer membranes; Ceramic flat sheet membrane; Easy maintenance options, e.g. use of high-pressure In-to-Out filtration; Out-to-In filtration; High pressure operation Submerged suction pressure operation water jet In any emergency case CERAFILTEC‘s single plate module concept enables to simply change separate flatsheet membranes with lowest efforts in maintenance, service and replacement costs PAGE 11 COMPARISON

  14. WHY CERAFILTEC Other ceramic flatsheet membranes vs. CERAFILTEC Maximum flexibility due to fully modular concept with free selection of modules per tower and towers per rack No corrosion of rack equipment - Suitable for harsh applications, like ground and seawater or other challenging industrial applications Simple maintenance and service due to lift option of single towers (remaining towers stay in operation) Hydraulic design of up to 1,500 LMH - Up to 3 times higher module flow NFC tags on each module, tower, rack and train with Source: Meiden; meidensha.co.jp Source: ItN Water Filtration; itn-nanovation.com access to mobile service portal for simplifying Ceramic flat sheet membranes; Ceramic flat sheet membrane; operation, maintenance and permanent performance Two different rack sizes from each supplier with fixed number of modules; Modular design made in plastic without hoses; monitoring Surrounding stainless steel frame Rack design without surrounding frame Cost efficient replacement of single ceramic plates Most compact, flexible and highest performing design in the market PAGE 12 COMPARISON

  15. WHY CERAFILTEC Ceramic Alumina (Al 2 O 3 ) membranes vs. CERAFILTEC (SiC) +60 SiC Gamma-Al 2 O 3 Alpha-Al 2 O 3 Highly negatively charged membrane surface SiO 2 (Sand) +40 Always negative Zeta potential for complete Typical pH operating pH range range with FeCl 3 Zeta potential [mV] Ensured anti clogging effect - Highest and stable flux dosage +20 operation at pH below 7 Ideal operation conditions - Ferric Chloride dosage below pH 6 for maximum coagulation and removal 1 2 3 4 5 6 7 8 9 10 11 of DOC and TEP and still negatively charged membrane 0 surface of -25 to -30 mV No additional requirements of extended pre-treatment steps, like ozonation - Easy removal of all negatively charged -20 water contents, like bacteria, algae, TEP or oil -40 pH [-] CERAFILTEC‘s SiC membrane is the ideal ceramic material choice for surface water, seawater and other applications with pH operation below 7 PAGE 13 COMPARISON
