Custom Engineered Odor Control Systems Flexible Reinforced Geo-membranes Table of Contents Main Contents Appendices Page Content Page Content 3 Application 10 Ap A Case Study 1 4 Value Proposition 11 Ap A Case Study 2 5 System

slide-1
SLIDE 1

Custom Engineered Odor Control Systems

Flexible Reinforced Geo-membranes

slide-2
SLIDE 2

Page Content

3 Application 4 Value Proposition 5 System Description 6 Specialty Filter 7 Installation Overview 8 Economics 9 Availability

Page Content

10 Ap A Case Study 1 11 Ap A Case Study 2 12 Ap A Case Study 3 13 Ap B Specs/ Compatibility 14 Ap B Resistance Props 15 Ap C Deployment 16 Ap C Design Fine Tune 17 Ap C Install & Hardware 18 Ap C Maintenance 19 Ap C Other applications 20 Ap C Fugitive Emmissions

Main Contents Appendices

Table of Contents

slide-3
SLIDE 3

Page 3

Diverse Application Universe

Anything Needing Odor Control

➢ Tanks ➢ Headworks ➢ Sludge Pits ➢ Open Channels ➢ Vessels

➢ Manhole Covers ➢ Truck Bays ➢ Vertical Vents ➢ Fugitive Emissions

Vent Covers

slide-4
SLIDE 4

Page 4

Exceptional Value Proposition

Quick Payback, Great Results

➢ Exceptional Broad

Spectrum Odor Control

➢ Eco Friendly – No Power ➢ Low CapEx and OpEx ➢ Made in North America ➢ Engineered to any shape,

size, dimension, application

➢ Simple, quick installation ➢ Can deal with any type odor ➢ Long lasting filters

Low Cost Custom Engineered

slide-5
SLIDE 5

Page 5

Geo-Membrane Description

Engineered Pockets Contain Filters

Filters are integrated into the Geo-membrane

➢ Filters easy to insert/maintain ➢ Pocket closes on 3 sides ➢ Designed to force gases through the filter ➢ Covered with mesh to protect from debris ➢ Reinforced bottom

slide-6
SLIDE 6

Page 6

Geo-Membrane Filter

Specialty Filter Components

➢ Filters are in a sponge- like medium (standard size 1 m2/10.8 ft2) ➢ Gas flows freely through filters ➢ Filters act as rain water drain into the basin ➢ Rain water does not wash away odor capturing ability ➢ General or Gas specific filters available (H2S & NH3)

slide-7
SLIDE 7

Page 7

Geo-Membrane Installation

Simple for Maintenance to Install

➢ Easily installed by maintenance staff ➢ High strength cable holds Geo-membrane ➢ Membrane perimeter sealed with batten bars ➢ Installation time 10 man hours/100 ft2 ➢ Easy to maintain and change filters ➢ Suspended structure - not affected by aeration, level changes, foam

slide-8
SLIDE 8

Page 8

Geo-Membrane Economics

Excellent Odor Control with Low Costs

 Overall cost is low compared to functional alternatives  Low CapEx and OpEx 

Please contact Anue for detailed cost information.

slide-9
SLIDE 9

Page 9

Proven Technology

Commercialized In 18 Countries….

… Now Available in the Americas through Anue Water Technology Channel Partners

slide-10
SLIDE 10

Page 10

Appendix A: Case Study 1

Bottling Safety and $$$ Saving

The Challenge: Major soft drink bottler receiving odor complaints

from nearby hotel. Problematic gas accumulation incident at plant site. Chemicals used but ineffective.

The Solution: Bottler buys custom Geo-Membrane solution Jan 2018.

Savings on chemicals >$240k/yr; 4 month payback. Additional savings on labor and maintenance.

slide-11
SLIDE 11

Page 11

Appendix A: Case Study 2

Dairy Odor Issue

The Challenge: Large Dairy receiving complaints of strong odors with complaints from neighbors and businesses, who pressured local government to act. Solutions first considered were rigid cover with extraction, and masking agents. Proposed cost too high. The Solution: Dairy purchased Geo-Membrane system. A support beam was provided by the manufacturer to ensure a perfect seal where pipes were obstructing. 3rd Party proves odor decrease >90%!

slide-12
SLIDE 12

Page 12

Appendix A: Case Study 3

Soft Drink Plant Odor Problem

The Challenge: 7 odor sources from major soft drink manufacturer drives pressure from Ministry of Environment. Problem is extreme odor from tall trickling filter/equalization tank with bridge & agitator. The Solution: First candidates were misting equipment, rigid cover; deemed too expensive. Installation of Geo-Membrane chosen and completed in 2 weeks. 3rd party testing show >90% odor reduction

  • achieved. Local government now recommends to other industries too!
slide-13
SLIDE 13

Page 13

Appendix B

Specifications and Compatibility

Membrane, filter & batten bar specifications

slide-14
SLIDE 14

Page 14

Heavy duty resistance to: UV-rays, Hot water (93oC/200oF), Hydrochloric/Phosphoric/Sulfuric acids Jet fuel (A, 4, 5, 8), Kerosene, Oils, Sea water. Extensive Data Available:

Appendix B

Resistance Properties

slide-15
SLIDE 15

Page 15

Appendix C: Additional Photos

Deployment

slide-16
SLIDE 16

Page 16

Appendix C: Additional Photos

Design Fine-tuning

Support beams & tight seal around pipes

Securely fixed and sealed with high visibility batten bars

slide-17
SLIDE 17

Page 17

Appendix C: Additional Photos

Installation Support hardware: Anchors, wires, brackets, bars

slide-18
SLIDE 18

Page 18

Appendix C: Additional Photos

Maintenance: Two Simple Steps

➢ Keep the filter areas free of major debris ➢ Change Filter every 6 to 12 months

slide-19
SLIDE 19

Page 19

Manhole/drain Container cover

Appendix C: Additional Photos

Other Applications

Vertical installation Engineered Sludge Pit Cover (above 3 pics)

slide-20
SLIDE 20

Page 20

Appendix C: Additional Photos

Fugitive emissions

Vents/grates can easily be fitted with the filters
