FRA-71-17.46, PID 105453 MATCHMAKER EVENT DISTRICT 6- MITCH BLACKFORD, DEPUTY DIRECTOR JANUARY 6, 2020 ODOT S M ISSION To provide easy movement of people and goods from place to place, we will: __________________________________

slide-1
SLIDE 1

FRA-71-17.46, PID 105453 MATCHMAKER EVENT DISTRICT 6- MITCH BLACKFORD, DEPUTY DIRECTOR JANUARY 6, 2020

slide-2
SLIDE 2

2 |

To provide easy movement

  • f people and goods from

place to place, we will:

__________________________________

Take care of what we have;

_________________________________

Make our system work better;

_________________________________

Improve safety;

_________________________________

Enhance capacity.

ODOT’ S M ISSION

FRA-71-17.46

slide-3
SLIDE 3

3 |

DISTRICT 6

  • Eight Counties
  • 4,921 lane miles of

roads

  • 1,557 Bridges
  • 15 Garages/Outposts
  • Operating Budget
  • Approx. $55 million
  • Capital Program
  • Over 45 Construction Projects
  • Over 434 Million Dollars

FRA-71-17.46

slide-4
SLIDE 4

4 |

PROJECT MANAGER & ENGINEERS

FRA-71-17.46

Leslie Montgomery, P.E.,Project Manager Tom Lau, P.E., Construction Area Engineer Brian Gable, P.E., Construction Project Engineer Mike Taricska, P.E., Burgess and Niple, Designer’s Project Manager

slide-5
SLIDE 5

5 |

PROJECT LOCATION

  • Proj. No. 19-

FRA-71-17.46 PID 105453

FRA-71-17.46

slide-6
SLIDE 6

6 |

PROJECT SCHEMATIC

FRA-71-17.46

  • Proj. No. 19-0037

FRA-71-17.46 PID 105453

slide-7
SLIDE 7

7 |

PROJECT OVERVIEW

FRA-71-17.46

Purpose: Replacement of the Broad St bridge and construction of 1 block of Lester Drive and 1 block of Elijah Pierce Ave between Long St and Broad St.

ESTIMATED COST

$32 Million

slide-8
SLIDE 8

8 |

N I-71 Northbound Phase 3B (2020-2022)

  • From 70W to 71N requires a lane change
  • Unbalanced lane usage

Today

  • Dedicated lane 70W to 71N

After 3B

slide-9
SLIDE 9

9 |

PROJECT WORK

FRA-71-17.46

Work will include: Full-depth pavement replacement Transitional Roadways Construction of 1 Bridge and 2 Retaining Walls Replace and rehabilitate sewers Underground utility ducts Lighting and Traffic Signals Landscaping

slide-10
SLIDE 10

10 |

SCHEDULE

FRA-71-17.46

Sale Date: 2/20/2020 Award Date: 3/2/2020 Construction Start: 05/01/2019 Construction End: 07/31/2021

slide-11
SLIDE 11

11 |

ROADWAY PAVEMENT TYPES

FRA-71-17.46

Item 441 & 442 Flexible Pavement: 18,000 CY Item 452 Concrete Pavement 10,000 SY Item 254 Pavement Planing: 45,000 SY Roadway & Pavement Work

Estimated Cost $ 4.2 M

slide-12
SLIDE 12

12 |

LANDSCAPING

FRA-71-17.46

Decorative Fence - 200’ Trees – 170 Each Shrubs and Perennials -17,000 Each Knee wall with brick veneer – 1800 LF Granite Curbing: 6000 LF Brick Pavers: 20,000 SF Landscaping Work

Estimated Cost $ 2 M

slide-13
SLIDE 13

13 |

STRUCTURES WORK TYPES

FRA-71-17.46

FRA-70-1P – 2-span continuous composite steel. 2 Cantilevered Concrete Retaining Walls

Structures Work

Estimated Cost $10 M

slide-14
SLIDE 14

14 |

DRAINAGE & EROSION CONTROL TYPES

FRA-71-17.46

Item 611 & 690 Drainage (various conduits & drainage structures) ODOT & City of Columbus Items 659 & 832 Erosion Control and Storm Water Pollution Prevention Drainage & Erosion Control

Estimated Cost $3 M

slide-15
SLIDE 15

15 |

TRAFFIC CONTROL, TRAFFIC SIGNALS & LIGHTING WORK TYPES

FRA-71-17.46

Item 809 – ITS Building, ITS Camera, Permanent and Temporary ITS Routing. Item 644 Pavement Markings Item 630 Signs and Supports Item 625 Lighting & Signals Traffic Control, Traffic Signals & Lighting Work

Estimated Cost $4.3 M

slide-16
SLIDE 16

16 |

MAINTENANCE OF TRAFFIC WORK TYPES

FRA-71-17.46

Item 614 Maintaining Traffic Maintenance of Traffic Work

Estimated Cost $1.5 M

slide-17
SLIDE 17

17 |

ENGINEERING AND SURVEYING SERVICES Item 623 Construction Layout Item 878 Inspection & Compaction of Unbound Materials

FRA-71-17.46

Engineering and Surveying Services

Estimated Cost $1.4 M

slide-18
SLIDE 18

18 |

DISADVANTAGE BUSINESS ENTERPRISE (DBE)

FRA-71-17.46

DBE Goal 10%

Contains the Proposal Note 013 - Disadvantaged Business Enterprise (DBE) Utilization Plan and Good Faith Efforts, updated 04/20/2018 All bidders shall submit a DBE Utilization Plan at the time of bid setting forth specific information demonstrating how the bidder will achieve the DBE goal.

DBE Certified Firms:

slide-19
SLIDE 19

19 |

QUESTIONS

FRA-71-17.46

How to Find US: ODOT District 6 400 E. William St. Delaware, OH 43015 740-833-8009 Send Prebid Questions to: http://www.dot.state.oh.us/Divisions/ContractAdmin/Contracts/ Pages/PBQs.aspx

slide-20
SLIDE 20

20 |

QUESTIONS

FRA-71-17.46

THANK YOU FOR ATTENDING!
