RIC-30-9.26 PROJECT 200121 , PID 93455 MATCHMAKER EVENT FEBRUARY 26, 2020 GENERAL PROJECT INFORMATION Kent A. Kapustar, P.E. ODOT Project Manager 2 | RIC-30-9.26, PID 93455 ODOT PROJECT TEAM o Kent Kapustar, P.E. Project Manager o

SLIDE 1

RIC-30-9.26

PROJECT 200121 , PID 93455 MATCHMAKER EVENT • FEBRUARY 26, 2020

SLIDE 2

2 |

GENERAL PROJECT INFORMATION

Kent A. Kapustar, P.E. ODOT Project Manager

RIC-30-9.26, PID 93455

SLIDE 3

3 |

ODOT PROJECT TEAM

Kent Kapustar, P.E. – Project Manager
Mike Fair, P.E. – District Construction Engineer
Ed Yetzer, P.E. – Construction Area Engineer
Jeff Labaki, P.E. – Construction Project

Engineer

Lisa Washington – Northwest Regional Outreach

Manager

RIC-30-9.26, PID 93455

SLIDE 4

4 |

PROJECT DESIGN TEAM

Fred Seling, P.E. – Prime Consultant Project Manager

RIC-30-9.26, PID 93455

Prime Consultant Subconsultants

SLIDE 5

5 |

PROJECT OVERVIEW Project Overview Maps – SR 309 to SR 13

RIC-30-9.26, PID 93455

SLIDE 6

6 |

PROJECT OVERVIEW Project Overview Maps – SR 13 to 5th Avenue

RIC-30-9.26, PID 93455

SLIDE 7

7 |

KEY PROJECT DATES

Sale Date: April 2, 2020
Award Date: April 13, 2020
Construction Year 1 – Phases 1 & 2
All Lanes Open by October 31, 2020
Construction Year 2 – Phases 3, 4, 5 & 5A
Begin Construction April 1, 2021
All Lanes Open by October 31, 2021

RIC-30-9.26, PID 93455

SLIDE 8

8 |

KEY PROJECT DATES

Construction Year 3 – Phases 6, 7 & 8
Begin Construction April 1, 2022
All Lanes Open by October 31, 2022
Construction Year 4 – Phase 9
Construction End Date: May 26, 2023

RIC-30-9.26, PID 93455

SLIDE 9

9 |

MAJOR WORK

RIC-30-9.26, PID 93455

SLIDE 10

10 |

PROJECT WORK

3.8 Miles of full-depth pavement reconstruction on US 30
Subgrade stabilization
Widened shoulders
Median Barrier
Cutting back vertical rock faces along US 30 east of SR 545
Interchanges
Reconfigure SR 39 interchange
Eliminate the closely spaced eastbound SR 13 and SR 545 off/on
ramps. Combine into a single off/on ramp
Minor improvements to the Trimble Road, SR 13 – westbound, SR

545 – westbound and Fifth Avenue ramps

RIC-30-9.26, PID 93455

SLIDE 11

11 |

PROJECT WORK

Structure Work
Replace 4 mainline bridges
Remove 1 existing mainline bridge
Minor repair to RIC-30-11.56 (17-span concrete I-beam bridge)
Decorative vandal protection fence with “MANSFIELD” lettering on 2

existing bridges

Highway Lighting
Drainage
Two Retaining Walls
Noise Barrier Wall

RIC-30-9.26, PID 93455

SLIDE 12

12 |

PROJECT WORK

Traffic Signal
Signing and Pavement Marking
ROW Fence Replacement
Side Roads
Construction of new cul-de-sac with moveable barrier gate on West

Longview Avenue

Realignment of West Longview Avenue at SR 39
Realignment of SR 545
Reconstruction of SR 39
Milling and Resurfacing of East Longview Avenue
Reconstruction of Wise Avenue

RIC-30-9.26, PID 93455

SLIDE 13

13 |

MATERIALS

RIC-30-9.26, PID 93455

SLIDE 14

14 |

ROADWAY PAVEMENT

Item 301 & 302 – Flexible Pavement: 36,000 CY
Item 441 & 442 Flexible Pavement: 25,000 CY
Item 452 Concrete Pavement: 19,000 SY
Item 254 Pavement Planing: 82,000 SY

Roadway and Pavement Estimated Cost: $24.7 Million

RIC-30-9.26, PID 93455

SLIDE 15

15 |

STRUCTURE WORK

Replace 4 mainline bridges with 3-span continuous steel

beam bridges on semi-integral abutments

Remove 3-span continuous steel beam bridge and replace

with embankment

Partial deck overlay, bearing resets, replace strip seals on

RIC-30-1156 L/R major bridge

Decorative fencing with lettering on two bridges
Two retaining walls and one noise wall

Structure Work Estimated Cost: $21.5 Million

RIC-30-9.26, PID 93455

SLIDE 16

16 |

DRAINAGE AND EROSION CONTROL WORK

Item 611 Drainage – 6” to 78” Conduit
Item 659 and 832 Erosion Control and Storm Water Pollution

Prevention Drainage and Erosion Control Work Estimated Cost: $5.9 Million

RIC-30-9.26, PID 93455

SLIDE 17

17 |

TRAFFIC CONTROL, TRAFFIC SIGNAL & LIGHTING WORK

Item 642 Pavement Markings
Item 630 Signs and Supports
Item 625 Highway Lighting
Item 625, 632, 633 and 809 Traffic Signal

Traffic Control, Signal and Lighting Work Estimated Cost: $3.3 Million

RIC-30-9.26, PID 93455

SLIDE 18

18 |

MAINTAINING TRAFFIC

Item 614 Maintaining Traffic
Includes $750,000 for maintaining existing bridge decks and

pavement patching on the existing roadway throughout the project

Item 615 Pavement for Maintaining Traffic, Class A: 77,000SY
Item 622 Portable Barrier: 306,000 FT

Maintenance of Traffic Work Estimated Cost: $11.7 Million *************************************************************************** Opinion of Probable Construction Cost Total $72.9 Million

RIC-30-9.26, PID 93455

SLIDE 19

19 |

MAINTENANCE OF TRAFFIC

RIC-30-9.26, PID 93455

SLIDE 20

20 |

MAINTENANCE OF TRAFFIC

CY 2020
Phases 1 & 2
Construct outside portion of EB Bowman St Bridge
Mainline pavement for maintaining traffic
Longview Ave. relocation
Median and shoulder reconstruction east of SR 545
Ramp I
Drainage and pavement on SR 39 and SR 545.
Construct Median Crossovers

RIC-30-9.26, PID 93455

SLIDE 21

21 |

MAINTENANCE OF TRAFFIC

CY 2021
Phase 3

RIC-30-9.26, PID 93455

SLIDE 22

22 |

MAINTENANCE OF TRAFFIC

CY 2021
Phase 4

RIC-30-9.26, PID 93455

SLIDE 23

23 |

MAINTENANCE OF TRAFFIC

CY 2021
Phase 5 / 5A – Median / Bridge Construction

RIC-30-9.26, PID 93455

SLIDE 24

24 |

MAINTENANCE OF TRAFFIC

CY 2022
Phase 6

RIC-30-9.26, PID 93455

SLIDE 25

25 |

MAINTENANCE OF TRAFFIC

CY 2022
Phase 7

RIC-30-9.26, PID 93455

SLIDE 26

26 |

MAINTENANCE OF TRAFFIC

CY 2022
Phase 8
Asphalt Surface Course
Pavement markings, RPMs, shoulder rumble strips
CY 2023
Phase 9
Pavement markings, RPMs, shoulder rumble strips not

completed due to temperature restrictions

Punch list items

RIC-30-9.26, PID 93455

SLIDE 27

27 |

DISADVANTAGED BUSINESS ENTERPRISE (DBE)

DBE Goal –10%

Contains the Proposal Note 013-Disadvantaged

Business Enterprise (DBE) Utilization Plan and Good Faith Efforts updated 04/20/2018

All bidders shall submit a DBE Utilization Plan at the time of

bid.

RIC-30-9.26, PID 93455

SLIDE 28

28 |

DISADVANTAGED BUSINESS ENTERPRISE (DBE)

The DBE Utilization Plan should set forth specific information

demonstrating how bidder will achieve DBE Goal

DBE Certified Firms:
http://www.dot.state.oh.us/Divisions/ODI/SDBE/Pages/DBE-

Directory.aspx

RIC-30-9.26, PID 93455

SLIDE 29

29 |

?

QUESTIONS

Last updated 2/27/2020

RIC-30-9.26, PID 93455

Please state your Name and Company prior to asking your question

SLIDE 30

30 |

THANK YOU FOR ATTENDING

RIC-30-9.26, PID 93455
