Experiment 21-Geometric Optics

slide-2
SLIDE 2

Part 1-Parallax (set up)

  • Draw one line down the

middle of the long side

  • f the paper
  • Draw a line

perpendicular to the first line along the short side of the paper

  • Place the mirror along

the short line

  • Place a pin anywhere

along the normal in front of the mirror

slide-3
SLIDE 3

Part 1-Parallax (perpendicular lines)

  • Line up horizontal

line at bottom of protractor with already drawn line

  • Perpendicular line

will be at 90o

slide-4
SLIDE 4

Part 1-Parallax (method)

  • Notice the reflection of

the first pin in the mirror. THIS IS OBJECT 1

  • Place a second pin on the

normal behind the mirror. THIS IS OBJECT 2

  • Look to the left (or right)
  • f the closer pin
  • At first the reflection and

the second pin you placed won’t line up

  • Move object 2 so that it

lines up with object 1 (but keep object 2 along the normal)

slide-5
SLIDE 5

Part 1-Parallax (method)

  • Notice that the reflection
  • f the front pin (object 1) is

lined up with the back pin (object 2)

  • Good job 
slide-6
SLIDE 6

Part 2-Reflection (set up)

  • Draw two

perpendicular lines and place mirror along the short line (like part 1)

  • Use the protractor

to draw a line between 25o-35o

  • Place two pins

along this line and label them P1 and P2

slide-7
SLIDE 7

Part 2-Reflection (method)

  • Move your head so that

the reflection of both pins in the mirror align with

  • ne another
slide-8
SLIDE 8

Part 2-Reflection (method)

  • Place down two pins so that they

line up with the reflections of P1 and P2

  • Label these pins P3 and P4
  • Draw a line connecting P3 and P4
slide-9
SLIDE 9

Part 2-Reflection (method)

  • Top down view of final result
slide-10
SLIDE 10

Part 3-Refraction (set up)

  • Place square plexiglass

in center of page

  • Trace its outline
slide-11
SLIDE 11

Part 3-Refraction (set up)

  • Draw a normal line from the top

left corner of the outline (2 cm)

  • Use the protractor to draw a line

between 25o-35o from the normal (like in part 3)

  • Place two pins along this line and

label them P1 and P2

slide-12
SLIDE 12

Part 3-Refraction (method)

  • Place the square lens on

top of its outline

  • Look through the bottom
  • f the lens to find the

image of P1 and P2* * You can place a blank sheet

  • f paper behind the lens to

make this easier for you

slide-13
SLIDE 13

Part 3-Refraction (method)

  • Move your head so

that the images of the two pins line up with one another

slide-14
SLIDE 14

Part 3-Refraction (method)

  • Place two pins down so

that they line up with the images of P1 and P2

  • Label these new pins P3

and P4

slide-15
SLIDE 15

Part 4-Total Internal Reflection (set up)

  • Place triangle plexiglass

lens on paper and trace its

  • utline
slide-16
SLIDE 16

Part 4-Total Internal Reflection (set up)

  • Draw a line perpendicular to

the left vertex of the long side on the lens (like in part 4) 1 cm from the vertex

  • Place two pins along this

line and label them P1 and P2

slide-17
SLIDE 17

Part 4-Total Internal Reflection (method)

  • Look through the bottom of

the lens and line up the images of P1 and P2 (like in part 4)* *You can place a blank sheet of paper behind the lens to make this easier for you

slide-18
SLIDE 18

Part 4-Total Internal Reflection (method)

  • Place down two pins so that

they align with the images of P1 and P2 (like part 4)

  • Label these two pins P3 and P4
slide-19
SLIDE 19

Part 4-Total Internal Reflection (method)

  • Draw a line connecting P3 and

P4 with the base of the lens

  • utline
  • Extend these lines through the

lens outline to the far side of the triangle

  • Draw a line across the triangle

connecting the extensions of P1P2 and P3P4

  • Top down view of the final

result
