  • P. Ewart

The science of light

slide-2
SLIDE 2
  • Lecture notes: On web site

NB outline notes!

  • Textbooks:

Hecht, Optics Klein and Furtak, Optics Lipson, Lipson and Lipson, Optical Physics Brooker, Modern Classical Optics

  • Problems: Material for four tutorials plus past

Finals papers A2

  • Practical Course: Manuscripts and Experience

Oxford Physics: Second Year, Optics

slide-3
SLIDE 3

Structure of the Course

1. Geometrical Optics 2. Physical Optics (Interference) Diffraction Theory (Scalar) Fourier Theory 3. Analysis of light (Interferometers) Diffraction Gratings Michelson (Fourier Transform) Fabry-Perot 4. Polarization of light (Vector)

Oxford Physics: Second Year, Optics

slide-4
SLIDE 4

Electronics Optics Quantum Electronics Quantum Optics Photonics

10-7 < T < 107 K; e- > 109 eV; superconductor Electromagnetism

slide-5
SLIDE 5

Oxford Physics: Second Year, Optics

Astronomical observatory, Hawaii, 4200m above sea level.

slide-6
SLIDE 6

Oxford Physics: Second Year, Optics

Multi-segment Objective mirror, Keck Obsevatory

slide-7
SLIDE 7

Oxford Physics: Second Year, Optics

Hubble Space Telescope, HST, In orbit

slide-8
SLIDE 8

Oxford Physics: Second Year, Optics

HST Deep Field Oldest objects in the Universe: 13 billion years

slide-9
SLIDE 9

Oxford Physics: Second Year, Optics

HST Image: Gravitational lensing

slide-10
SLIDE 10

Oxford Physics: Second Year, Optics

SEM Image: Insect head

slide-11
SLIDE 11

Oxford Physics: Second Year, Optics

Coherent Light: Laser physics: Holography, Telecommunications Quantum optics Quantum computing Ultra-cold atoms Laser nuclear ignition Medical applications Engineering Chemistry Environmental sensing Metrology ……etc.!

slide-12
SLIDE 12

Oxford Physics: Second Year, Optics

CD/DVD Player: optical tracking assembly

slide-13
SLIDE 13
  • Astronomy and Cosmology
  • Microscopy
  • Spectroscopy and Atomic Theory
  • Quantum Theory
  • Relativity Theory
  • Lasers

Oxford Physics: Second Year, Optics

Optics in Physics

slide-14
SLIDE 14

Geometrical Optics

  • Ignores wave nature of light
  • Basic technology for optical instruments
  • Fermat’s principle:

“Light propagating between two points follows a path, or paths, for which the time taken is an extremum”

Oxford Physics: Second Year, Optics

slide-15
SLIDE 15

Ray tracing - revision

axis Focal point Focal point

Oxford Physics: Second Year, Optics

slide-16
SLIDE 16

Simple magnifier

Object at near point a Virtual image at near point b Short focal length lens

Magnifier: angular magnification = b/a Eyepiece of Telescopes, Microscopes etc.

Oxford Physics: Second Year, Optics

slide-17
SLIDE 17

Oxford Physics: Second Year, Optics

P1 First Principal Plane Back Focal Plane

Location of equivalent thin lens

Thick lens or compound lens

slide-18
SLIDE 18

Oxford Physics: Second Year, Optics

P2 Second Principal Plane Front Focal Plane

Thick lens or compound lens

slide-19
SLIDE 19

Oxford Physics: Second Year, Optics

Principal Plane Focal Plane fT

Telephoto lens Equivalent thin lens

slide-20
SLIDE 20

Oxford Physics: Second Year, Optics

Principal Plane Focal Plane fW

Wide angle lens

slide-21
SLIDE 21

Oxford Physics: Second Year, Optics

fO fE

b

angular magnification = b/a Astronomical Telescope = fo/fE

slide-22
SLIDE 22

Oxford Physics: Second Year, Optics

angular magnification = b/a Galilean Telescope = fo/fE

slide-23
SLIDE 23

Oxford Physics: Second Year, Optics

b

fo fE

angular magnification = b/a Newtonian Telescope = fo/fE

slide-24
SLIDE 24

Oxford Physics: Second Year, Optics

The compound microscope

Objective magnification = v/u Eyepiece magnifies real image of object

slide-25
SLIDE 25

Oxford Physics: Second Year, Optics

Image of objective in eyepiece

Aperture stop

What size to make the lenses? Eye piece ~ pupil size Objective: Image in eye-piece ~ pupil size

slide-26
SLIDE 26

Oxford Physics: Second Year, Optics

(a) (b)

Field stop

slide-27
SLIDE 27

Oxford Physics: Second Year, Optics

ILLUMINATION OF OPTICAL INSTRUMENTS

f/no. : focal length diameter

slide-28
SLIDE 28

Oxford Physics: Second Year, Optics

Lecture 2: Waves and Diffraction

  • Interference
  • Analytical method
  • Phasor method
  • Diffraction at 2-D apertures
slide-29
SLIDE 29

Oxford Physics: Second Year, Optics

u t, x T  Time

  • r distance

axis

t,z u

Phase change of 2p

slide-30
SLIDE 30

Oxford Physics: Second Year, Optics

dsinq d

q

r1 r2 P D

slide-31
SLIDE 31

Oxford Physics: Second Year, Optics

 Real Imaginary u

Phasor diagram

slide-32
SLIDE 32

Oxford Physics: Second Year, Optics

 / u /r

  • up

u /r

  • Phasor diagram for 2-slit interference

uo r uo r

slide-33
SLIDE 33

Oxford Physics: Second Year, Optics

ysinq +a/2

  • a/2

q

r r y + s i n q P D y dy

Diffraction from a single slit

slide-34
SLIDE 34

Oxford Physics: Second Year, Optics

  • 10
  • 5

5 10 0.0 0.2 0.4 0.6 0.8 1.0

p p p p p p

sinc

2(b)

b

Intensity pattern from diffraction at single slit

slide-35
SLIDE 35

Oxford Physics: Second Year, Optics

asinq +a/2

  • a/2

q

r P D

slide-36
SLIDE 36

Oxford Physics: Second Year, Optics

q0 q0

/

RO R R =

P P

Phasors and resultant at different angles q

slide-37
SLIDE 37

Oxford Physics: Second Year, Optics

R RP  /  

R sin /2 R

slide-38
SLIDE 38

Oxford Physics: Second Year, Optics

Phasor arc to first minimum Phasor arc to second minimum

slide-39
SLIDE 39

Oxford Physics: Second Year, Optics

y x z  q

slide-40
SLIDE 40

Diffraction from a rectangular aperture

slide-41
SLIDE 41

Oxford Physics: Second Year, Optics

Intensity y x

Diffraction pattern from circular aperture Point Spread Function

slide-42
SLIDE 42

Diffraction from a circular aperture

slide-43
SLIDE 43

Diffraction from circular apertures

slide-44
SLIDE 44

Oxford Physics: Second Year, Optics

Dust pattern Diffraction pattern Basis of particle sizing instruments

slide-45
SLIDE 45

Oxford Physics: Second Year, Optics

Lecture 3: Diffraction theory and wave propagation

  • Fraunhofer diffraction
  • Huygens-Fresnel theory of

wave propagation

  • Fresnel-Kirchoff diffraction

integral

slide-46
SLIDE 46

Oxford Physics: Second Year, Optics

y x z  q

slide-47
SLIDE 47

Diffraction from a circular aperture

slide-48
SLIDE 48

Oxford Physics: Second Year, Optics

Fraunhofer Diffraction How linear is linear?

A diffraction pattern for which the phase of the light at the

  • bservation point is a

linear function of the position for all points in the diffracting aperture is Fraunhofer diffraction

slide-49
SLIDE 49

Oxford Physics: Second Year, Optics

R R R R a a r r diffracting aperture source

  • bserving

point

r < /0

slide-50
SLIDE 50

Oxford Physics: Second Year, Optics

Fraunhofer Diffraction A diffraction pattern formed in the image plane of an optical system is Fraunhofer diffraction

slide-51
SLIDE 51

Oxford Physics: Second Year, Optics

O P A B C

f

slide-52
SLIDE 52

Oxford Physics: Second Year, Optics

u v

Equivalent lens system

Fraunhofer diffraction: in image plane of system

Diffracted waves imaged

slide-53
SLIDE 53

Oxford Physics: Second Year, Optics

(a) (b) O O P P

Equivalent lens system: Fraunhofer diffraction is independent of aperture position

slide-54
SLIDE 54

Oxford Physics: Second Year, Optics

Fresnel’s Theory of wave propagation

slide-55
SLIDE 55

Oxford Physics: Second Year, Optics

dS n r P z

  • z

Plane wave surface

Huygens secondary sources on wavefront at -z radiate to point P on new wavefront at z = 0

unobstructed

slide-56
SLIDE 56

Oxford Physics: Second Year, Optics

rn q rn P

Construction of elements of equal area on wavefront

rn q rn

slide-57
SLIDE 57

Oxford Physics: Second Year, Optics

(q+ /2)  q rp Rp

First Half Period Zone

(q+/2) q rp Rp

Resultant, Rp, represents amplitude from 1st HPZ

slide-58
SLIDE 58

Oxford Physics: Second Year, Optics

rp /2 q q P O

Phase difference of /2 at edge of 1st HPZ

slide-59
SLIDE 59

Oxford Physics: Second Year, Optics

As n a infinity resultant a ½ diameter of 1st HPZ Rp

slide-60
SLIDE 60

Oxford Physics: Second Year, Optics

Fresnel-Kirchoff diffraction integral

ikr

  • p

e r S u i u ) r n, ( d     

slide-61
SLIDE 61

Oxford Physics: Second Year, Optics

Babinet’s Principle

slide-62
SLIDE 62

Oxford Physics: Second Year, Optics

Lectures 1 - 3: The story so far

  • Geometrical optics

No wave effects

  • Scalar diffraction theory:

Analytical methods Phasor methods

  • Fresnel-Kirchoff diffraction integral:

propagation of plane waves

slide-63
SLIDE 63

Oxford Physics: Second Year, Optics

Gustav Robert Kirchhoff (1824 –1887) Joseph Fraunhofer (1787 - 1826) Augustin Fresnel (1788 - 1827) Fresnel-Kirchoff Diffraction Integral

ikr

  • p

e r S u i u ) r n, ( d     

Phase at observation is linear function of position in aperture:  = k sinq y

slide-64
SLIDE 64

Oxford Physics: Second Year, Optics

Lecture 4: Fourier methods

  • Fraunhofer diffraction as a

Fourier transform

  • Convolution theorem –

solving difficult diffraction problems

  • Useful Fourier transforms

and convolutions

slide-65
SLIDE 65

Oxford Physics: Second Year, Optics

ikr

  • p

e r n r u i u ) . ( dS     x e x u A u

x i p

d ) ( ) (

b

a b

  

 

Fresnel-Kirchoff diffraction integral: Simplifies to: where b = ksinq

Note: A(b) is the Fourier transform of u(x)

The Fraunhofer diffraction pattern is the Fourier transform

  • f the amplitude function in the diffracting aperture
slide-66
SLIDE 66

Oxford Physics: Second Year, Optics

' d ). ' ( ). ' ( ) ( ) ( ) ( x x x g x f x g x f x h

  

   

The Convolution function: The Convolution Theorem:

The Fourier transform, F.T., of f(x) is F(b) F.T., of g(x) is G(b) F.T., of h(x) is H(b) H(b) = F(b).G(b) The Fourier transform of a convolution of f and g is the product of the Fourier transforms of f and g

slide-67
SLIDE 67

Oxford Physics: Second Year, Optics

b Monochromatic Wave Fourier Transform T

.bo  p/T

slide-68
SLIDE 68

Oxford Physics: Second Year, Optics

xo x b V(x) V( ) b

-function Fourier transform Power spectrum V(b)V(b)* = V2 = constant V

b

slide-69
SLIDE 69

Oxford Physics: Second Year, Optics

xS x b V(x) V( ) b

Comb of -functions Fourier transform

slide-70
SLIDE 70

g(x-x’) f(x) h(x)

Constructing a double slit function by convolution

Oxford Physics: Second Year, Optics

slide-71
SLIDE 71

g(x-x’) f(x) h(x)

Triangle as a convolution of two “top-hat” functions This is a self-convolution or Autocorrelation function

Oxford Physics: Second Year, Optics

slide-72
SLIDE 72

Joseph Fourier (1768 –1830)

Oxford Physics: Second Year, Optics

  • Heat transfer theory:
  • greenhouse effect
  • Fourier series
  • Fourier synthesis and analysis
  • Fourier transform as analysis
slide-73
SLIDE 73

Oxford Physics: Second Year, Optics

Lecture 6: Theory of imaging

  • Fourier methods in optics
  • Abbé theory of imaging
  • Resolution of microscopes
  • Optical image processing
  • Diffraction limited imaging
slide-74
SLIDE 74

Oxford Physics: Second Year, Optics

ikr

  • p

e r n r u i u ) . ( dS     x e x u A u

x i p

d ) ( ) (

b

a b

  

 

Fresnel-Kirchoff diffraction integral: Simplifies to: where b = ksinq

Note: A(b) is the Fourier transform of u(x)

The Fraunhofer diffraction pattern is the Fourier transform

  • f the amplitude function in the diffracting aperture
slide-75
SLIDE 75

Ernst Abbé (1840 -1905)

slide-76
SLIDE 76

Oxford Physics: Second Year, Optics

a d d’ f D u v u(x) v(x)

Fourier plane

q

slide-77
SLIDE 77

Oxford Physics: Second Year, Optics

The compound microscope

Objective magnification = v/u Eyepiece magnifies real image of object

slide-78
SLIDE 78

Diffracted orders from high spatial frequencies miss the objective lens

So high spatial frequencies are missing from the image.

qmax defines the numerical aperture… and resolution

slide-79
SLIDE 79

Oxford Physics: Second Year, Optics

Fourier plane Image plane Image processing

slide-80
SLIDE 80

Oxford Physics: Second Year, Optics

Optical simulation of “X-Ray diffraction”

a b a’ b’

(a) and (b) show objects: double helix at different angle of view Diffraction patterns of (a) and (b) observed in Fourier plane Computer performs Inverse Fourier transform To find object “shape”

slide-81
SLIDE 81

PIV particle image velocimetry

Oxford Physics: Second Year, Optics

  • Two images recorded

in short time interval

  • Each moving particle gives

two point images

  • Coherent illumination
  • f small area produces

“Young’s” fringes in Fourier plane of a lens

  • CCD camera records

fringe system – input to computer to calculate velocity vector

slide-82
SLIDE 82

PIV particle image velocimetry

Oxford Physics: Second Year, Optics

slide-83
SLIDE 83

Oxford Physics: Second Year, Optics

a d d’ f D u v u(x) v(x)

Fourier plane

q

phase object amplitude object

slide-84
SLIDE 84

Oxford Physics: Second Year, Optics

Schlieren photography

Source Collimating Lens Imaging Lens Knife Edge Image Plane Refractive index variation

Fourier Plane

slide-85
SLIDE 85

Schleiren photography in i.c.engine

Schlieren film of autoignition Courtesy of Prof CWG Sheppard University of Leeds

Spark plug

slide-86
SLIDE 86

Oxford Physics: Second Year, Optics

Intensity y x

Diffraction pattern from circular aperture

Point Spread Function, PSF

slide-87
SLIDE 87

Oxford Physics: Second Year, Optics

Lecture 7: Optical instruments and Fringe localisation

  • Interference fringes
  • What types of fringe?
  • Where are fringes located?
  • Interferometers
slide-88
SLIDE 88

Oxford Physics: Second Year, Optics

non-localised fringes

Plane waves

Young’s slits

slide-89
SLIDE 89

Z

Oxford Physics: Second Year, Optics

Diffraction grating

q q to 8 f

Plane waves

Fringes localised at infinity: Fraunhofer

slide-90
SLIDE 90

Oxford Physics: Second Year, Optics

P’ P O

Wedged reflecting surfaces Point source

slide-91
SLIDE 91

Oxford Physics: Second Year, Optics

O P P’ q q’

Parallel reflecting surfaces Point source

slide-92
SLIDE 92

Oxford Physics: Second Year, Optics

P’ P R O S R’

Wedged Reflecting surfaces Extended source

slide-93
SLIDE 93

Oxford Physics: Second Year, Optics

t 2t=x source images 2t=x a path difference cos x a circular fringe constant a

Parallel reflecting surfaces Extended source

slide-94
SLIDE 94

Oxford Physics: Second Year, Optics

Wedged Parallel Point Source Non-localised Equal thickness Non-localised Equal inclination Extended Source Localised in plane

  • f Wedge

Equal thickness Localised at infinity Equal inclination

Summary: fringe type and localisation
