ETE FOUNDATION SCHOOL MASTER PLAN ISALARO, SOUTH SUDAN 23 MAY 2016 ETE FOUNDATION SCHOOL REGIONAL CONTEXT/SITE MAP 02 ISALARO, SOUTH SUDAN 23 MAY 2016 TO TORIT 0423'30.48"N 3229'32.18"E 0423'30.05"N

slide-1
SLIDE 1

ETE FOUNDATION SCHOOL MASTER PLAN

ISALARO, SOUTH SUDAN

23 MAY 2016

slide-2
SLIDE 2

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

02

REGIONAL CONTEXT/SITE MAP

slide-3
SLIDE 3

04°23'30.48"N 32°29'32.18"E 04°23'13.77"N 32°29'32.18"E 04°23'13.77"N 32°30'37.04"E 04°23'30.05"N 32°30'37.03"E 4 2 1 Meters

N

04°23'13.77"N 32°29'32 18"E

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

03

CONTEXT/SITE MAP

ETE FOUNDATION SCHOOL SITE

100 HECTARES (999,657 m2) TORIT ROAD TO TORIT

2000 m 500 m

slide-4
SLIDE 4

MISSION STATEMENT

The Empowerment Through Education (ETE) Foundation exists to promote, support and provide educational opportunities for the children of South Sudan with a focus on girls and women.

VISION

The Empowerment Through Education (ETE) Foundation aims to empower individuals to be engines of change through education.

KEY CONCEPTS

  • Two entry/Gateways into the site from Torit Road
  • Infirmary and Library/Administration Buildings flank entry into Compound
  • Infirmary to provide basic medical care for students, staff members,

their families and the local population.

  • Potential opportunity to partner with a medical organization to run the

infirmary.

  • Library to serve as resource for school and teachers and local

residents

  • Administrative Office to include: Administrative Offices and Conference

Room

  • Multi-Purpose Building on Axis with entry into Compound
  • Cafeteria, auditorium with stage for performances, gym, restrooms and

kitchen

  • Foreground Plaza on west side of Building for morning gathering. Flag

pole.

  • Play area for small children on east side of Building
  • East-west axis to minimize morning and afternoon heat gain.
  • Phase 1 Lower Primary and Upper Primary Classroom Buildings beyond

Infirmary and Library on north-south axis with each other.

  • Lower Primary (K-4th Grades): 15 Classrooms, Teacher’s Lounge, 2

Bathrooms and Playground.

  • Upper Primary (5th-8th Grades): Teacher’s Lounge, 8 Classrooms,

Computer Lab, Science Lab, 2 Bathrooms

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

04

INTRODUCTION

KEY CONCEPTS CONTINUED

  • Phase 2 Lower Primary and Upper Primary Classroom Buildings provides

expansion opportunities

  • Principal’s House set internal to site between classrooms and Teacher/Staff

Housing and across from Multi-Purpose Building

  • Guest House located adjacent to the Councilor’s house facing the

Multi-Purpose Building.

  • Teacher/Staff Housing (25 homes) encircles the Multi-Purpose Building on north,

east and south sides.

  • Green Houses and Sustainable Agricultural Fields extend east from main school

compound and are easily accessible from perimeter driveway.

  • Solar Array Field located northeast of the campus or PV on rooftops.
  • Leech Field(s) for sewage for all buildings located northeast of the campus
  • Security Fencing for Property Boundary
  • Kei Apple Bush Hedges.
  • Water Well and Water Purification Building located northwest of the compound

adjacent to the Sports Fields

  • Power Plant Building located northwest of the compound adjacent to the Sports

Field.

  • All Purpose Sports Field
  • Located at north entry to School Compound
  • To be shared with future Secondary School to the north.
  • Fully sustainable school campus
  • Potential Police Building at Entrance (within Public ROW)
  • Place to hang out/ Outdoor seating/ Car Park/ Flagpole
  • Potential Inn along Torit Road (not within the scope of this project)
  • Provides opportunities for accommodations for travelers and visitors to the

School as it grows.

  • Potential Farmer’s Market with Restaurant(s)
  • Covered Market Building in semi-circle creates shady Market Plaza within

bosque of trees.

  • Provides retail outlet for Crafts and Crops.
  • Entrepreneurial opportunities for the Village and the School
slide-5
SLIDE 5

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

05

PROGRAM

PROGRAM CONTINUED

  • Teacher and Staff Housing
  • 2 bedrooms, bathroom, kitchen and great room
  • Principal’s House
  • 2 bedrooms, bathroom, kitchen, great room, office
  • Guest House
  • 4 bedrooms, 1 bathroom, kitchen, great room
  • Water Well and Purification Building
  • Power Plant Building
  • Solar Storage Batteries, backup Generator and Electronics
  • All Purpose Sports Field with tarmac for basketball
  • Sustainable Farming Field and Greenhouse
  • Solar Array Field
  • Leech field(s) for sewage for all buildings

PROGRAM

Students

  • Current Enrollment (“school under the tree”):

140

  • Projected Enrollment (Years 1-3):

200

  • Maximum Enrollment:

540 Optimal Number of Students/Classrooms

  • K-4th Grade: 20 students each classroom/3 classrooms per grade/60 students

per grade

  • 5th-8th Grade: 30 students each classroom/2 classrooms per grade/60

students per grade Campus Buildings

  • Lower Primary Building (K-4th Grades)
  • 15 Classrooms (20 students/classroom x 6 m2/student =

120 m2/classroom)

  • 1 Teachers Lounge
  • Bathrooms
  • Playground
  • Upper Primary Building (5th-8th Grades)
  • 8 Classrooms (30 students/classroom x 10 m2/student =

200 m2/classroom)

  • Computer Lab
  • Science Lab
  • Library
  • Bathrooms
  • Teacher’s Lounge
  • Multi-Purpose Building
  • Cafeteria, auditorium, gym, kitchen and storage
  • Infirmary
  • Provides basic medical care for students and local population.
  • Partnership with medical organization to run the infirmary
  • Administrative Offices and Library
  • Administrative Offices
  • Conference Room
  • Library
slide-6
SLIDE 6

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

06

SITE AND VICINITY IMAGES

slide-7
SLIDE 7

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

07

CONCEPTUAL MASTER PLAN

slide-8
SLIDE 8

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

08

PHASING DIAGRAM

slide-9
SLIDE 9

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

09

BIRD’S-EYE PERSPECTIVES

NE AERIAL OBLIQUE

slide-10
SLIDE 10

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

10

BIRD’S-EYE PERSPECTIVE

SE AERIAL OBLIQUE

slide-11
SLIDE 11

BIRD’S-EYE PERSPECTIVE

SW AERIAL OBLIQUE

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

11

slide-12
SLIDE 12

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

12

PRECEDENT IMAGES

CLASSROOM BUILDINGS

slide-13
SLIDE 13

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

13

PRECEDENT IMAGES

CLASSROOM BUILDINGS AND CAMPUS COMMON BUILDINGS

slide-14
SLIDE 14

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

14

PRECEDENT IMAGES

COURTYARDS AND ARCADES

slide-15
SLIDE 15

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

15

PRECEDENT IMAGES

STAFF/TEACHER HOUSING AND AGRICULTURE AND SPORTS

slide-16
SLIDE 16

ETE FOUNDATION SCHOOL ISALARO, SOUTH SUDAN

23 MAY 2016

16

SUSTAINABILITY OPPORTUNITIES

SUSTAINABILITY CONCEPTS AND NEXT STEPS

  • Building Siting/Orientation to maximize solar opportunities and natural ventilation.
  • Building Design: Wall materials/Roof Forms/Natural Lighting/Ventilation/Verandas/

Roof Top Solar

  • Sustainable Building Systems: Buildings incorporating natural lighting, natural v

entilation, constructed using local materials and hand-built construction techniques.

  • Incorporate Passive Energy Strategies into buildings, including; passive lighting de

sign, passive ventilation, thermal mass and shading.

  • Clerestory lighting allows for maximum ambient light to enter the classroom

without the harsh glare and heat caused by direct sunlight.

  • Situate windows in order to maximize natural ventilation, flushing the hot air
  • ut of the classroom with prevailing winds.
  • Design the ceilings to absorb radiant heat from the metal roof, eliminating

unwanted heat gain into the classrooms.

  • Thermal mass provided by the masonry walls also helps to keep the

building cool.

  • Integration of Sustainable Agricultural practices into the curriculum. Outdoor

learning gardens will teach sustainable agriculture and nutritional practices, providing

  • pportunities for collaborative interaction extending beyond the classroom walls.
  • Solar Array Field/Power Plant Building
  • Compost/Leech Field/Bio-digester
  • Water Recycling/Rooftop Rainwater Collection: Rainwater is to be collected from

the metal roofs of the buildings, directed into a cistern, to be used to irrigate the agricultural fields.

  • Social Sustainability/Community: Actively promote discovery, self-efficiency and

strong community relationships. Covered outdoor terraces and courtyards can serve as shaded outdoor classrooms or as play areas, abutting the proposed agricultural

  • fields. Classrooms will be organized around gathering spaces of various scales

maximizing flexibility and creating safe outdoor spaces for learning, play and community events.

  • Phasing will allow the school to grow over time as it adapts to the school’s future

needs.

  • Economic Sustainability

SUSTAINABILITY CONCEPTS CONTINUED

  • Safety and Security: Secure and welcoming entry will invite the community into a

learning environment where the building is designed to teach in partnership with the school and the village community. Community input drives the design process, ensuring a school that is deeply embedded in the local culture and continued growth

  • f the village. Security walls connect to adjacent buildings with 3 gateway entrances.

NEXT STEPS

  • FUND RAISING: June 2016 – June 2017
  • CONCEPTUAL DESIGN OF PHASE 1 BUILDINGS and INFRASTRUCTURE: July

2016 – December 2016

  • DESIGN (BUILDINGS AND INFRASTRUCTURE): January 2017 – June 2017
  • GROUND BREAKING: July 2017
  • CONSTRUCTION: July 2017 – February 2018
  • GRAND OPENING: February 2018
