Energy Management Solu0on Through LED Retrofit Newton Technology - - PowerPoint PPT Presentation

Energy Management Solu0on Through LED Retrofit

Newton Technology Group

NTG LED Technologies

High power consumption High heat emission High electricity cost Frequent maintenance and high costs Short lifetime

Issues of Conven0onal lamps

Advantages of LED lamps

• Up to 90% over incandescent lamp
• At least 50% over fluorescent lamp

Energy saving

• Up to 20 times longer than incandescent lamp
• Reduce maintenance workload and replacement cost

Longer lifetime

• Reduce eyestrain

No UV and flicker

• More safe working environment
• More environmental friendly

Non-toxic material

• Reduce air conditioning cost

Reduce heat emission

Poor heat management Unsa7sfactory

• utcome of ligh7ng

requirement Poor light quality Incompa7ble with dimmer func7on Fail to achieve stated life7me

Common issues of LED light

Most of other LED manufacturers cannot provide !!!

NTG LED Packaging Technology High Color Rendering CRI >90 Super low CCT 2100K IntelliSENSE Occupancy Technology Mul7-Levels Gradual Dimming Touchpad Control Technology Integrated Thermal Management Design Compact Heat Sink Size

NTG’s LED Product and System

NTG’s LED Technologies’ Niches

Technology

produces high efficiency LED light source with perfect heat conduc7ve structure for heat management.

« High color rendering with CRI > 90, resul7ng the same light quality as halogen or incandescent lamps. Ideal for hospitality

industry applica7on (such as Hotels, Restaurant, Shopping Malls.)

« Color Temperature as low as 2100K to create candlelight color for genera7ng a relaxing atmosphere. « Brightness output dimmable by exis7ng intelligent ligh7ng control system with line dimming or IntelliSENSE technology « IntelliSENSE technology adopts A.I. and passive infrared sensor technology along with brightness switching to realize “light-up

when needed” for enormous energy saving.

« Single integrated LED light source with special op7cal designed reflector and diffuser generates good illuminance and glare

limited light.

« High power LED module technology with state-of-the-art heat management technology allows high brightness output at

compact size of lamp fixture. By the NTG’s state-of-the art self-developed LED technologies, such as CRI>90 and CCT as low as 2100K, NTG’s LED lamps deliver as good ligh0ng quality as conven0onal light source such as incandescent and halogen, while most other LED manufacturers cannot provide.

NTG’s Technologies’ Niches

Direct substitute for halogen Efficient heat management design True warm color lighting Compatible with conventional triac dimmer Able to achieve 30,000+ hours

Compara0ve advantages of NTG patented LED lamps

Correlated Colour Temperature (CCT) specifica7on of colour appearance of the light emi^ed by a lamp, measure in degrees Kelvin (K)

• 1. Customised LED Colour Temperature

u For hospitality applica7on such as shopping mall or hotel, requires warm ambiance to

generate relaxing atmosphere

u NTG has the ability to customise warm colour between 2,100 K – 2,700K for different

applica7ons

2000K, CRI>90! 2500K, CRI>90!

NTG LED Spot Lamp LED Spot Lamp in the market

!

Design to deliver true halogen compa0bility:

• Delivers true warm color and sparkling effect
• Subs0tu0on for halogen lamps to generate desired ambience.

! !

Compara0ve Advantages: Ambience

• 2. Customised dimming system- maximize the saving

u Mo0on Sensing Technology

• Radio frequency (RF) sensor of 360° degree up to range of 5 meter

e.g. commercial building, hotel, car park.

u Photometric (Light) sensor, adjust brightness output

based on environment

u Interface to building central dimming control

system

u Wireless remote control interface

• Built-in infra red (IR) sensor on LED tube e.g.

corridor, stair case, parking bay

LED Build-in Sensor tube- Bank of China, Macau

External sensor with dimmable tube at KLCC Car park

Heat management solu0on (Heat sink)

• Good material conductors are aluminum and copper
• Fin shape with air holes increase surface for heat transmission and

enhance air circula7on

• 3. LED Heat Management

Overheated LED chip will lead to decrease in efficiency and lumen output.

NTG’s R&D

• Design of heat sink
• Ac7ve thermal control
• Intelligent dimming

NTG LED Spot Lamp Common LED Spot Lamp Superior LED packaging and heat sink design: § Ensures LED reliability and delivers design lifetime § Reduces maintenance workload and cost LED Package - Heat Pipe - Active Control ~ 65° C Small heat sink with fan > 72° C

Reliability and long life0me

• LED driver compa7ble with triac dimming control system
• Easy installa7on. No re-wiring nor changing exis7ng dimming system
• Perfect subs7tute of dimmable halogen spot lamp

LED Tube Dimming control system

• 4. Compara0ve advantages: Compa0bility

LED Test Cer0fica0on

Malaysia Standard Suruhanjaya Tenaga (ST) Approval Interna7onal Standard Circuit Breaker (CB)/IEC Approval European Standard European Conformity (CE) Approval

Patents of technologies and Cer0ficates of product safety

NTG LED Solu0on – Indoor

ü Customise LED products to meet client’s ligh0ng requirements.

ü Research & Development (R&D) capabili0es ü Provide comprehensive ligh0ng solu0on

What can NTG offer?

NTG offer Ligh0ng design and Effect Simula0on

Dialux simula0on of 3D Rendering and Lux level

Customise Energy Efficient Solu0on

Exis0ng Conven0onal Lights LED Light Solu0on Energy savings 11W PL-S 5W LED Down light 55% 13W PL-C 7W LED PL-C 55% 18W PL-C 7W LED PL-C 61% 26W PL-C 9W LED PL-C 65% 18W Fluorescent 2” 10W tube, 0.6m 44% 36W Fluorescent 2” 21W tube, 1.2m 42%

Exis0ng Conven0onal Lights LED replacement Energy savings 54W T5 Fluorescent 30W tube with T8 ba^en 44% 50W Halogen 6.5W spot lamp 87% 150W spotlight SON bulb 80W flood lamp 47% 70W MHL 40W flood lamp 43% 250W MHL 120W flood lamp 52% 250W HPS 120W flood lamp 52% 400W High mast (HPSI) 160W flood lamp 60%

LED ECO-Ceiling Series

Wacage Input voltage Average life0me Luminous Flux CCT 6W – 25W 100V -240V AC 35,000 hours 900 lm 2,700K – 3,000K * High CRI Dimmable ceiling lamp is available in 18W and 25W

LED ECO-Ceiling Series

Applica0on areas

• Shopping mall
• BouEque
• Show room and gallery
• Museum and art centres
• Hotel and restaurant

LED ECO-Spot Series

Wacage Average life0me CCT 4.5W – 10W 35,000 hours 2,500K – 2,700K * Available in dimmable series

LED ECO-Spot Series

Applica0on areas

• Shopping mall
• BouEque
• Show room and gallery
• Museum and art centres
• Consignment counter

4.5W – 6.5W LED spot lamp

• CRI: 90
• CCT: 2700K
• Replaces 20W - 50W Tungsten Halogen Lamps
• Saves up to 80% energy cost

LED reflector lamp

• CRI:80 - 90
• CCT: 2700K – 3000K
• Replace AR111 halogen reflector lamp
• Saves up to 80% energy cost

Application areas:

• Lobby, restaurant, shopping mall and retails shops

LED Ligh0ng Solu0ons AR111

LED ECO-Strip Series

Wacage Average life0me CCT 5W – 6W 35,000 hours 2,100K – 4,200K Applica0on areas

• Shopping mall
• BouEque
• Show room and gallery
• Hotel and restaurant
• Saves up to 80% energy cost

LED bulbs

• CRI: 80 - 90
• CCT: 2700K – 3000K
• Replaces incandescent bulb
• Saves up to 90% energy cost

Application areas:

• Lobby, restaurant

LED Ligh0ng Solu0ons

LED ECO-Tube Series

Wacage Average life0me CCT 10W – 30W 35,000 hours 3,000K – 6,000K

Applica0on areas

• Office
• Parking lots
• Supermarket and shop
• Saves up to 85% energy cost

Outdoor Ligh0ng

Wacage Average life0me CCT 40W – 240W 35,000 hours 2,100K – 6,000K Applica0on areas

• Landscape
• Billboard
• Signage

LED Canopy Ligh0ng

Wacage Average life0me CCT 120W & above 35,000 hours 5,000K – 6,000K

NTG LED Solu0on – Outdoor

Conven0onal Street light vs LED

470W 240W 49% Energy Saving

Conven0onal lights vs LED Becer uniformity of light distribu0on

Conven0onal lights vs LED

Better visibility Lower glare

Standard and cer0ficate of Newton G4

Business Model

available for NTG Client

WHY NTG

ü Premium quality products with advance technology ü Technical support all the way to R&D lab ü Customised solu7on delivering LED ligh7ng solu7on ü Professional support services ü Strong commitment to Client

Business Highlight

• Very strong marke7ng network in Malaysia and China
• Working on the projects in both public and private sec7on.
• Petronas KLCC , Sunway, Hektar group, AIA , Interna7onal Airport, 7-Eleven, BDRB group
• World class Casino hotel and luxury Hotel
• Worldwide clients base and Sales network in
• PRC China : Beijing, Inner Mongolia, Jilin, Hebei, Hong Kong , Macau
• South East Asia : Malaysia
• Europe : Turkey
• Government and NGO connec7on :
• Project working on the Street ligh7ng in Malaysia.
• Providing energy management service and ligh7ng design service to Interna7onal Airport and tailor made

products for Mass Rapid Transit in Malaysia

Strong Client base and connec0on

Advanced outdoor lighting

NTG Street Lamp have been approved and listed in the EMAL ( government approved product list )

• f Malaysia 2014

Business Focus - 2

Approval from the Malaysia government for the G4 street lamp pilot. (June -2014)

Only very few companies can fulfill all the Gov. requirement and can conduct pilot in Malaysia

Exis0ng Projects: Shopping Malls

LED Solu0on: Energy Savings 60%

• Dimmable LED tubes
• LED ceiling lamps
• LED spot lamps

Special feature:

• True warm white 2700K
• Intelligent dimming

Bangsar Shopping Centre (BSC), Malaysia

LED Solu0on: Energy Savings 60%

• Dimmable LED tubes
• LED ceiling lamps

Special feature:

• True warm white 2700K
• Intelligent dimming

Qubicon Erzurum Shopping Centre, Turkey

Anatolium Shopping Centre (Cario), Turkey

LED Solu0on: Energy Savings 60%

• Dimmable LED tubes
• LED ceiling lamps

Special feature:

• True warm white 2700K
• Intelligent dimming

Area of 84,000 sq.m with further business opportuni7es of 5 other malls in Turkey and 85 malls in Europe.

The Link REIT Shopping Mall 1, Hong Kong

LED Solu0on:

• LED bulbs
• LED flood lamps
• LED spot lamps
• LED tubes
• LED ceiling lamps

The Link REIT Shopping Mall 2, Hong Kong

LED Solu0on:

• LED flood lamps
• LED spot lamps
• LED tubes
• LED ceiling lamps

Existing Projects: Office Buildings

Bank of China Building, Macau

LED Solu0on: Energy Savings 60%

• Dimmable LED tubes
• LED spot lamps

Special feature:

• True warm white 2700K
• Intelligent dimming

Goldlion Holdings Centre, Hong Kong

LED Solu0on: Energy Savings 60%

• Dimmable LED tubes
• LED ceiling lamps
• LED spot lamps

Special feature:

• True warm white 2700K
• Intelligent dimming

Citi bank Plaza, Hong Kong

LED Solu0on:

• LED bulbs
• LED spot lamps
• LED tubes
• LED ceiling lamps

Office of Jebsen Group, Hong Kong

LED Solu0on: Energy Savings 80%

• LED spot lamps

Special feature:

• True warm white 2700K
• Intelligent dimming

Office of Itochu, Hong Kong

LED Solu0on: Energy Savings 80%

• Dimmable LED tubes
• LED spot lamps

Special feature:

• True warm white 2700K
• Intelligent dimming

Government Building (Jiangsu), China

LED Solu0on:

• LED bulbs
• LED flood lamps
• LED spot lamps
• LED tubes
• LED ceiling

lamps

Applica7ons:

• Offices
• Corridors
• Conference

rooms

• Staircases
• Lobby

Energy saving:

• 208,000 kWh

per year

Jiangsu Industrial Park, Jiangsu, China

LED Solu0on: Energy Savings 50%

• LED Street lamp

Sunway Group

LED Solution for common areas both indoor and outdoor lighting

Existing Projects: Hotels

Sunway Group

LED Solution for common areas both indoor and outdoor lighting

Venetian Macau, Macau

LED Solu0on: Energy Savings 60%

• Dimmable LED tubes

Applica7ons:

• Back of house (Staff area)
• Staircase

LED Solu0on:

• LED bulbs
• LED flood lamps
• LED spot lamps
• LED dimmable tubes
• LED ceiling lamps

Galaxy Macau, Macau

Shangri La Hotel, China

LED Solu0on: Energy Savings 60%

• Dimmable LED tubes
• LED spot lamps

Applica7on:

• Hotel Lobby
• Restaurants
• Guest rooms and floor corridors
• Back of House (Staff area)

Projects: Others

Mass Rapid Transit for 24 Stations (Sungai Buloh to Kajang)

Design, Build and Install LED Package

• New product development
• LED light design drawings
• Ligh7ng configura7on and layout
• Product tes7ng and commissioning

International Airport

LED Solu0on: Energy Savings 50%

• LED tube
• LED ceiling lamp
• LED spot lamp
• LED high bay lamp
• LED PL-C tube

• LED Solu0on: Energy Savings 60%
• Dimmable LED tubes
• LED tube
• LED flood lamp

Semiconductor Factory Guangdong, China

LED Solu0on:

• LED flood lamps
• LED spot lamps
• LED ceiling lamps

Kawasaki Motor, Hong Kong

Other Existing Projects

CNPC Hong Kong Office Hong Kong Secondary School Hong Kong Scout Associa7on of Hong Kong
