Retrofit Challenges NW Ports Introduction to Retrofit Technology - - PowerPoint PPT Presentation

Jan 30, 2024 35 likes •138 views

Retrofit Challenges NW Ports Introduction to Retrofit Technology Level 2 Partial Flow Filter Low operating temperature Requires Exhaust Modification Level 1 No Maintenance Required DOC (Fit and Forget???) Replace existing muffler

slide-1
SLIDE 1

Retrofit Challenges

slide-2
SLIDE 2

NW Ports Introduction to Retrofit Technology

Level 1 DOC Replace existing muffler Level 3 Trial Projects Diesel Particulate Filter Higher operating temperature Requires exhaust modification Requires Annual Cleaning Level 2 Partial Flow Filter Low operating temperature Requires Exhaust Modification No Maintenance Required (Fit – and – Forget???) Level 3 – Diesel Particulate Filter Equipment Verification Equipment Pre-screening Duty Cycle Considerations Proper Equipment Placement Routine Cleaning Proactive Equipment Maintenance

2005 2008 2009 2010

slide-3
SLIDE 3

Building Collaboration

Create Advocates Understand Stakeholders Learn to Communicate Provide Support

slide-4
SLIDE 4

NW Ports Introduction to Retrofit Technology

Four critical steps for DPF success

  • 1. Pre-retrofit evaluation of equipment
  • 2. Ongoing training of operators and mechanics
  • 3. Regular equipment maintenance
  • 4. Support for troubleshooting, filter cleaning, &

maintenance

slide-5
SLIDE 5

NW Ports Introduction to Retrofit Technology

Pre-retrofit evaluation of equipment

  • 1. Equipment survey
  • 2. Temperature profiling during typical operation
  • 3. Initial opacity testing
  • 4. Follow-up opacity testing after any engine repairs
slide-6
SLIDE 6

NW Ports Introduction to Retrofit Technology

Ongoing training of operators and mechanics

  • 1. Pre-installation training

(low-ash oil, ULSD, no fuel additives, how it works)

  • 2. Post-installation training
  • 3. Refresher training

(checking monitor daily, cleaning intervals,

  • pacity testing)
slide-7
SLIDE 7

NW Ports Introduction to Retrofit Technology

Regular equipment maintenance

  • 1. Annual opacity tests
  • 2. Proactive maintenance
slide-8
SLIDE 8

NW Ports Introduction to Retrofit Technology

Support for troubleshooting

  • 1. Respond to issues promptly! Avoid rumors!

A. Terminals need to notify contractors as soon as an issue is identified B. Funding agencies and contractors need to follow up

  • 2. Don’t point fingers. Fix the problem.
slide-9
SLIDE 9

NW Ports Introduction to Retrofit Technology

Support for filter cleaning & maintenance

  • 1. Make sure the right procedures are in place

A. Cleaning contractor should:

1) Provide pre-cleaning inspections 2) Know who to notify if there is a problem

B. Contractors and manufacturers need be able to respond promptly to cracked cores and other issues

  • 2. Encourage good maintenance

A. Funding agencies should perform audits B. Contractors should encourage and support periodic training

slide-10
SLIDE 10

Thank You
