Energy Retrofit Strategy for Existing Buildings (Retrofit Strategy) June 25, 2014 Outline BACKGROUND ON RETROFITS STRATEGY PURPOSE STRATEGY FOCUS ON OPPORTUNITY SECTORS SUPPORT VOLUNTARY ACTION OTHER TOOLS SUMMARY 2 BACKGROUND ON

slide-1
SLIDE 1

Energy Retrofit Strategy for Existing Buildings

(Retrofit Strategy) June 25, 2014

slide-2
SLIDE 2

2

BACKGROUND ON RETROFITS STRATEGY SUMMARY OTHER TOOLS FOCUS ON OPPORTUNITY SECTORS

Outline

SUPPORT VOLUNTARY ACTION STRATEGY PURPOSE

slide-3
SLIDE 3

BACKGROUND ON RETROFITS

slide-4
SLIDE 4

We have a variety of building types in Vancouver. There are…

4

BACKGROUND ON RETROFITS

slide-5
SLIDE 5

77,000 houses and duplexes with 106,000 units…

5

BACKGROUND ON RETROFITS

slide-6
SLIDE 6

5,700 apartment and condominium buildings with 174,000 units…

6

BACKGROUND ON RETROFITS

slide-7
SLIDE 7

5,200 commercial and institutional buildings

7

with over 114 million square feet…

BACKGROUND ON RETROFITS

slide-8
SLIDE 8

8

And 250 industrial facilities.

BACKGROUND ON RETROFITS

slide-9
SLIDE 9

Collectively these buildings cost $550 million to heat and power each year ...

9

BACKGROUND ON RETROFITS

slide-10
SLIDE 10

producing 1.6 million tonnes of GHGs per year, which is just over 55% of the Vancouver community GHGs.

10

BACKGROUND ON RETROFITS

slide-11
SLIDE 11

The Green Building target in the Greenest City Action Plan calls for reducing these emissions by 20% by 2020; which if we succeed …

11

BACKGROUND ON RETROFITS

slide-12
SLIDE 12

… Vancouver residents and businesses could save over $90 million and 160,000 tonnes of GHGs per year by 2020.

12

BACKGROUND ON RETROFITS

slide-13
SLIDE 13

The purpose of this Retrofit Strategy is to outline the approach that the City will undertake to achieve this goal.

13

BACKGROUND ON RETROFITS

slide-14
SLIDE 14

STRATEGY PURPOSE

slide-15
SLIDE 15

Greenest City Action Plan The City is aiming to reduce city-wide GHG emissions by 33% and reduce GHG emissions in existing buildings by 20% by 2020.

STRATEGY PURPOSE

15

slide-16
SLIDE 16

16

55% of total GHG emissions are from buildings:

Nearly a quarter of planned GHG reductions* from building retrofits.

16

STRATEGY PURPOSE

* Excluding targeted reductions from Provincial legislation on vehicle fuel standards, vehicle efficiency and clean power.

Building Retrofits, 23% Waste, 7% Electric Vehicles, 5% Increased Walking, Bike & Transit, 32%

Neighbourhood Energy17%

New Building Energy Efficiency, 16%

The Greenest City Action Plan targets 160,000t of GHG reductions from existing building retrofits

slide-17
SLIDE 17

17

BACKGROUND ON RETROFITS

Barriers to Retrofitting Our Buildings:

  • Hard to access and compare energy use data
  • Low owner awareness of cost saving opportunities
  • Competing demands and lack of owner expertise
  • Low natural gas prices

Opportunities:

17

BACKGROUND ON RETROFITS

  • Improve housing affordability by reducing energy costs
  • Support green jobs
  • Pilot new approaches
  • Leverage and enhance existing incentives through

partnerships with BC Hydro, Fortis BC, and strong industry associations

slide-18
SLIDE 18

STRATEGY

slide-19
SLIDE 19

Building-related GHG emissions by building sector:

Heat Utilities, 7% Public Sector, 7% Small Commercial, 10% Industry, 20% Detached houses, 31% Multi-Unit Residential Buildings *, 18% Lrg Comm, 7% 19

OVERVIEW | 1. PRIORITIZE | 2. SECTOR SPECIFIC | 3. REGULATE

* Multi-unit Residential Buildings (MURBs) include both rental apartment and strata condominium type buildings

slide-20
SLIDE 20

20 20

20

OVERVIEW | 1. PRIORITIZE | 2. SECTOR SPECIFIC | 3. REGULATE

Vancouver’s Strategic Retrofit Approach

  • 1. Focus on Highest Opportunity Sectors
  • 2. Apply Sector Specific Approaches to

Support Voluntary Action

  • 3. Utilize the Vancouver Building Bylaw
slide-21
SLIDE 21
  • 1. FOCUS ON

LARGEST OPPORTUNITIES

slide-22
SLIDE 22

22

We are already working to reduce emissions as part of the

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

Neighbourhood Energy Strategy

Heat Utilities, 7% Public Sector, 7% Small Commercial, 10% Industry, 20% Detached houses, 31% Multi-Unit Residential Buildings, 18% Lrg Comm ercial 7%

slide-23
SLIDE 23

23

Local, provincial and federal governments are

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

already taking action on public sector buildings

Heat Utilities, 7% Public Sector, 7% Small Commercial, 10% Industry, 20% Detached houses, 31% Multi-Unit Residential Buildings, 18% Lrg Comm ercial 7%

slide-24
SLIDE 24

24

Small commercial, small industrial, and small multi-unit

  • Building stock, ownership

models and equipment are very diverse.

  • Large number of small owners

and operators, each with small GHG emissions.

  • Difficult to engage

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

residential (MURBs) are NOT an initial focus for new City action

Heat Utilities, 7% Public Sector, 7% Small Commercial, 10% Industry, 20% Detached houses, 31% Multi-Unit Residential Buildings, 18% Lrg Comm ercial 7%

slide-25
SLIDE 25

25

Focus on building sectors where additional City action

25

  • 1. Large commercial
  • 2. Multi-unit residential

buildings (MURBs)

  • 3. Detached houses
  • 4. Industry

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

Would have the biggest GHG reduction impact:

Heat Utilities, 7% Public Sector, 7% Small Commercial, 10% Industry, 20% Detached houses, 31% Multi-Unit Residential Buildings, 18% Lrg Comm ercial 7%

slide-26
SLIDE 26
  • 2. SECTOR

SPECIFIC APPROACHES

slide-27
SLIDE 27

27

INDUSTRIAL COMMERCIAL MURBs HOUSES

[insert pic of industrial building in Vancouver]

Sector specific strategies:

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

  • Focus on biggest industrial emitters
  • Support uptake of existing programs
slide-28
SLIDE 28

28

  • 1. Focus on largest industrial emitters

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

5 lrg plants 20% of Industrial GHG emissions 250 Industrial Facilities

  • 5 large industries

report GHG emissions to Metro

  • 245 highly diverse

and small impact industries not part of initial focus

slide-29
SLIDE 29

Promote participation in FortisBC facility audit, support retrofit business case development, and foster uptake of existing incentives Assess need for supplementary incentives and make recommendations to FortisBC and/or Council as required.

29

CITY ACTION CITY ACTION INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-30
SLIDE 30

30

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

Sector specific strategies:

  • Identify least efficient large

commercial buildings to catalyze voluntary action.

slide-31
SLIDE 31

31

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

  • 1. Focus on the largest commercial buildings

5,200 Commercial Buildings 422 Large Comm. Bld. 61% of Commercial floorspace

slide-32
SLIDE 32

32

INDUSTRIAL COMMERCIAL MURBs HOUSES

  • Strong leadership by BOMA
  • Well managed buildings within a competitive

industry with capacity to implement retrofits

  • Good existing incentive and support programs

from BC Hydro and Fortis

  • Primary gap in this sector is mechanism to

easily identify least efficient buildings to catalyze voluntary efficiency improvements

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

  • 1. Focus on the largest commercial buildings
slide-33
SLIDE 33

33

  • 2. Identify the least efficient of the large commercial

buildings by energy benchmarking INDUSTRIAL COMMERCIAL MURBs HOUSES Energy benchmarking for buildings: the collection, comparison, and sharing

  • f building energy use data and ratings.

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-34
SLIDE 34

34

Buildings that participated in energy benchmarking

34

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

realized energy savings of 7% over 3 years (US EPA).

slide-35
SLIDE 35

35

Sample of U.S. cities that require energy benchmarking: INDUSTRIAL COMMERCIAL MURBs HOUSES

Disclosure City Commercial MURB To Gov't Via Website At time of Transaction Rating System Austin 10,000+ SF Y Buyer Energy Star Boston 35,000+ SF 35+ units 35,000+ SF Y Y Energy Star Chicago 50,000+ SF 50,000+ SF Y Y Energy Star New York 50,000+ SF 50,000+ SF Y Y Energy Star San Francisco 10,000+ SF Y Y Buyer Lessee Energy Star Seattle 20,000+ SF 20,000+ SF Y Buyer Lessee Energy Star

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-36
SLIDE 36

36

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

Additional important benefits of energy benchmarking:

  • provides data to inform development of

programs and policies

  • enables evaluation of programs and policies
  • Publicly available benchmark ratings support

market demand for improved energy performance

slide-37
SLIDE 37

Support voluntary benchmarking by large commercial and MURB portfolio owners by providing training, call centre guidance, etc.

CITY ACTION

37

INDUSTRIAL COMMERCIAL MURBs HOUSES

Consult with stakeholders and develop an approach to data sharing and ensuring benchmarking for all commercial buildings >50,000 ft2 .

CITY ACTION

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-38
SLIDE 38

38

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

Sector specific strategies:

  • Focus on largest and least efficient

Multi-unit Residential Buildings (MURBs).

  • Provide targeted support.
slide-39
SLIDE 39

39

39

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

5,700 MURBs 725 large MURBs 64% of MURB floorspace

  • 1. Focus on the largest MURBs
  • Nearly all large

condo buildings are managed by 8 property management firms.

  • 46 landlords own 60%
  • f market rental

units.

slide-40
SLIDE 40

40

40

INDUSTRIAL COMMERCIAL MURBs HOUSES

  • 2. Identify the least efficient MURBs using Energy

Benchmarking

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-41
SLIDE 41
  • 3. Additional City support for voluntary energy

efficiency action is required for MURBs

41

  • MURBs include both rental apartment and condominium

strata type buildings

  • Limited owner investment in building improvements and

limited capacity/expertise to implement energy improvements

  • Limited awareness of energy efficiency opportunities and

incentives

  • Current City “Green Landlord” pilot is proving to be

successful

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-42
SLIDE 42

City support for 21 Vancouver rental apartment buildings included:

  • energy and water efficiency audits
  • retrofit business cases that leverage Hydro/Fortis incentives
  • Average GHG reduction of 16% and payback on owner

investments of 2.5 years

  • low-flow toilet incentives (will reduce 23 million litres water

use/year)

  • LandlordBC emerged as a strong partner

Participating buildings have committed to undertaking identified energy efficiency improvements BC Hydro and FortisBC have now launched Green Landlord Programs

Green Landlord pilot:

42

INDUSTRIAL COMMERCIAL MURBs HOUSES

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-43
SLIDE 43

43

INDUSTRIAL COMMERCIAL MURBs HOUSES

Undertake additional research and program design for Condominium and Non-market Rental Housing retrofits

CITY ACTIONS

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

  • Support voluntary MURB energy benchmarking and seek

changes to Vancouver Charter to enable benchmarking regulation

CITY ACTIONS

Partner with BC Hydro, FortisBC, and LandlordBC to expand the Green Landlord program and evaluate its effectiveness; make recommendations for enhancement (including additional incentives) as required

CITY ACTION

slide-44
SLIDE 44

INDUSTRIAL COMMERCIAL MURBs HOUSES

44

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

Sector specific strategies:

  • Identify and focus on least efficient

homes

  • Promote existing incentives and

explore enhancements

  • Pilot new technologies
slide-45
SLIDE 45

45

INDUSTRIAL COMMERCIAL MURBs HOUSES

  • 1. Identify the least efficient houses and duplexes
  • Data from the recently terminated

Provincial LiveSmart and Federal ecoEnergy programs indicate that older houses are typically least efficient

  • Additional tools, such as thermal imaging,

need to be developed to better identify least efficient homes and to help catalyze incentive uptake

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-46
SLIDE 46

46

INDUSTRIAL COMMERCIAL MURBs HOUSES

  • 2. City support for voluntary energy efficiency action is

required for houses

  • Federal and Provincial incentives: terminated
  • BC Hydro and FortisBC recently launched Home Energy

Rebate Offer (HERO) program includes incentives (25% lower than peak historic levels)

  • BC Hydro and FortisBC programs not fully taking

advantage of emerging “smart” technologies (e.g. learning thermostats) for energy conservation in houses

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-47
SLIDE 47

47

Year Van Audits Van Renovations % of buildings retrofit after the audit 2007 396 285 72% 2008 1286 937 73% 2009 2852 2276 80% (COV promotion begins) 2010 3221 2601 81% 2011 2989 2360 79% 2012 1842 1380 75% (end of federal incentives) 2013 495 212 43% TOTAL 12,586 10,051

Program = 13,000t GHG reduction

City marketing of provincial and federal incentives resulted and significant GHG reductions.

47

INDUSTRIAL COMMERCIAL MURBs HOUSES in over double the provincial uptake rate in Vancouver

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-48
SLIDE 48

48

48

INSPIRE & SUPPORT/ WHAT CAN WE DO?

48

INDUSTRIAL COMMERCIAL MURBs HOUSES

Develop new tools to identify least efficient homes Work with BC Hydro, FortisBC, and Heritage Vancouver to promote HERO incentives and pilot additional incentive approaches if required.

CITY ACTION CITY ACTION

Pilot programs that leverage “smart” technologies such as learning thermostats to catalyze new utility incentive

  • fferings

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

CITY ACTION

slide-49
SLIDE 49

PROTECT / WHAT CAN WE DO ?

49

  • 3. Other Tools
slide-50
SLIDE 50

50

Value of Permit Action Typical Cost HERO Incentive Typcial Annual Savings > $5,000 EnerGuide assessment $300 $0 $0 >$25,000 Assessment & weather sealing

$300 + $800

$1,100 $500 $300 > $50,000 Assessment, weather sealing, & attic insulation

$300 + $800 + $1400

$2,500

$500 + $600

$1,100 $600

In 2014, energy retrofit requirements were included in the Vancouver Building By-Law (VBBL). 2014 VBBL Requirements for 1 and 2 Family Houses

50

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-51
SLIDE 51

51

Value of Permit Requirement > $5,000 EnerGuide assessment >$25,000 Assessment & weather sealing > $50,000 Assessment, weather sealing, & attic insulation

In 2014, energy retrofit requirements were included in the Vancouver Building By-Law (VBBL). 2014 VBBL Requirements for 1 and 2 Family Houses

51

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-52
SLIDE 52

2014 VBBL Requirements for MURBs and Commercial Buildings

52

Regular updates to the VBBL energy retrofit requirements

  • Complex diversity in types of buildings

and potential improvements

  • Tables of energy efficiency options

enable applicants to align required efficiency improvements with planned work

52

52

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

could reduce GHG emissions from existing buildings by 50,000 tonnes by 2020.

slide-53
SLIDE 53

53

Research, consult industry, and propose improved energy efficiency requirements to incorporate into the VBBL in 2016 and for subsequent updates Monitor the impact of VBBL requirements and propose additional regulatory approaches if necessary.

CITY ACTION CITY ACTION

OVERVIEW | 1. FOCUS | 2. SECTOR SPECIFIC | 3. REGULATE

slide-54
SLIDE 54

SUMMARY

slide-55
SLIDE 55

Key strategies and impacts by sector

55

Inst. Houses MURBs Comm. Industry

TARGET REDUCTION

(tonnes GHG per year by 2020)

Government Commitments

11,000

Benchmarking

 

19,000

Support Voluntary Improvements

   

80,000

Regulations

    

50,000 TARGET REDUCTION (tonnes

GHG per year by 2020)

27,000 31,000 29,000 40,000 33,000

= 160,000

55

55

SUMMARY

slide-56
SLIDE 56

56 56

56

SUMMARY

Summary

  • Targeted reduction of 160,000 t of GHG emissions/year

by 2020 is challenging and important

  • Residents and businesses could save over $90

million/year by 2020 if target is achieved

  • Focus support for voluntary action on highest
  • pportunity building sectors
  • Leverage existing incentives
  • Pilot new approaches and incentives as required
  • Partner with utility and industry associations
  • Continue to evolve the Vancouver Building Bylaw
