SLIDE 1
- To identify the incremental traffic impact of
the proposed development and to identify traffic improvements to address the traffic impact.
- The purpose is not to solve existing traffic
problems.
- Requires review by the Township and
Elementary Center Phoenixville Area School District Tra raffic ic - - PowerPoint PPT Presentation
Elementary Center Phoenixville Area School District Tra raffic ic - - PowerPoint PPT Presentation
Elementary Center Phoenixville Area School District Tra raffic ic Pre resentation entation Novembe ber r 19, 9, 2014 Purpose of the Traffic Impact Study (TIS) To identify the incremental traffic impact of the proposed development and
SLIDE 2
SLIDE 3
- 1. Existing Conditions Analysis
– What are the traffic operations today?
- 2. Future Conditions Analysis - With Background
Traffic Growth Only
– How will traffic operate in the future with normal traffic growth, but without the school traffic?
- 3. Future Conditions Analysis – With Traffic From
the Proposed School
– How will traffic operate in the future with the added traffic from the school?
Steps of a TIS
SLIDE 4
Scope reviewed and approved by PennDOT and the Township
- 8 Intersections
- 2 Peak Periods
– Weekday morning school arrival peak hour – Weekday afternoon school dismissal peak hour
- 3 Study Years
– Today – 2017 School Opening Year – 2022 Design Year
TIS Scope
SLIDE 5
Study Area Study Area
PennDOT Intersection
SLIDE 6
- Two peak hours
– Weekday morning peak hour – Weekday afternoon peak hour
- School traffic accounts for:
– Parents – Faculty/staff – Buses – Athletic fields
- No credit taken for
– existing school traffic on the roads today – existing sports traffic on the roads today – prior golf club traffic
School Traffic
SLIDE 7
Weekday Morning Peak Hour In Out 304 249 Weekday Afternoon Peak Hour In Out 235 189
Source: Institute of Transportation Engineers, Trip Generation, 9thEd. & PASD Data
School Traffic
SLIDE 8
Proposed Traffic Improvements Proposed Traffic Improvements
Pothouse Road Pothouse Road PA Route 29 Charlestown Road Bridge Street Site Access
SLIDE 9
Proposed Traffic Improvements Proposed Traffic Improvements
PA Route 29 Charlestown Road Bridge Street Site Access
Subject to PennDOT
Pothouse Road Pothouse Road
SLIDE 10
Proposed Traffic Improvements Proposed Traffic Improvements
Trotter’s Drive PA Route 29 Charlestown Road Bridge Street Site Access
Subject to PennDOT
Pothouse Road Pothouse Road
SLIDE 11
Proposed Traffic Improvements Proposed Traffic Improvements
Trotter’s Drive PA Route 29 Charlestown Road Bridge Street Site Access
Mitigation Improvements
Pothouse Road Pothouse Road
SLIDE 12
Proposed Traffic Improvements Proposed Traffic Improvements
Trotter’s Drive PA Route 29 Charlestown Road Bridge Street Site Access
Additional Improvements
Pothouse Road Pothouse Road
SLIDE 13
Proposed Traffic Improvements Proposed Traffic Improvements
Trotter’s Drive PA Route 29 Charlestown Road Bridge Street Site Access
ALL Proposed Improvements
Pothouse Road Pothouse Road
SLIDE 14
- Pothouse Road and Site Access
Proposed Traffic Improvements
SLIDE 15
SLIDE 16
Proposed Traffic Improvements
- Pothouse Road and State Road (PA Route 29)
SLIDE 17
- Pothouse Road and State Road (PA Route 29)
SLIDE 18
- PennDOT has expressed support for the
project and the proposed improvements
- The TIS has been reviewed by the Township
Traffic Engineer and PennDOT
- Last week design plans for the proposed
improvements were submitted for review to PennDOT and the Township
Current Status & Next Steps
SLIDE 19
Thank You
