SLIDE 1

10.1

EE 109 Unit 10 – MIPS Instruction Set

10.2

MIPS INSTRUCTION OVERVIEW

10.3

Instruction Set Architecture (ISA)

• Defines the _________________ of the processor

and memory system

• Instruction set is the ____________ the HW can

understand and the SW is composed with

• 2 approaches

– _____ = ___________ instruction set computer

• Large, rich vocabulary
• More work per instruction but slower HW

– _____ = ___________ instruction set computer

• Small, basic, but sufficient vocabulary
• Less work per instruction but faster HW

10.4

MIPS Processor and Bus Interface

• The MIPS processor can execute software instructions that will

cause it to:

– Load (Read) and Store (Write) data to and from memory or I/O devices – Perform arithmetic and logic operations (add, sub, and, etc.) – Make decisions to move around in the code (loops, ifs, call a function, etc.)

MIPS Processor

Addr (32-bits) Data (32-bits) Control

Memory instruc data ALU

ADD, SUB, AND, OR

• p.

in1 in2

• ut

PC $0-$31 (32-bits each) (32-bits ALU)

SLIDE 2

10.5

Which Instructions

• In this class we'll focus on assembly to do the following

tasks (shown with the corresponding MIPS assembly mnemonics)

– Load variables (data) from memory (or I/O) [LW,LH,LB] – Perform arithmetic, logical, and shift instructions in the CPU [ADD,SUB,AND,OR,SLL,SRL,SRA] – Store variables (data) back to memory after computation is complete [SW, SH, SB] – Compare data [SLT] – "Branch" to other code (to implement if and loops) [BEQ,BNE,J] – Call subroutines/functions [JAL, JR]

10.6

MIPS Instruction Set

• __________-style
• ______________ internal / __________ external data size

– Registers and ALU are 32-bits wide – Memory bus is logically 32-bits wide (though may be physically wider)

• Registers

– ______ General Purpose Registers (GPR’s)

• For integer and address values
• A few are used for specific tasks/values
• Fixed size instructions

– All instructions encoded as a single ______-bit word – Three operand instruction format (dest, src1, src2) – Load/store architecture (all data operands must be in registers and thus loaded from and stored to memory explicitly)

10.7

MIPS GPR’s

Assembler Name

• Reg. Number

Description $zero $0 Constant 0 value $at $1 Assembler temporary $v0-$v1 $2-$3 Procedure return values or expression evaluation $a0-$a3 $4-$7 Arguments/parameters $t0-$t7 $8-$15 Temporaries $s0-$s7 $16-$23 Saved Temporaries $t8-$t9 $24-$25 Temporaries $k0-$k1 $26-$27 Reserved for OS kernel $gp $28 Global Pointer (Global and static variables/data) $sp $29 Stack Pointer $fp $30 Frame Pointer $ra $31 Return address for current procedure Avoid using the yellow (highlighted) registers for anything other than its stated use

10.8

MIPS Programmer-Visible Registers

• General Purpose Registers

(GPR’s)

– Hold data operands or addresses (pointers) to data stored in memory

• Special Purpose Registers

– ___: ____________ ___(32-bits)

• Holds the address of the next

instruction to be fetched from memory & executed

– HI: Hi-Half Reg. (32-bits)

• For MUL, holds 32 MSB’s of
• result. For DIV, holds 32-bit

remainder

– LO: Lo-Half Reg. (32-bits)

• For MUL, holds 32 LSB’s of
• result. For DIV, holds 32-bit

quotient

MIPS Core PC: $0 - $31 32-bits GPR’s Special Purpose Registers HI: LO:

Recall multiplying two 32-bit numbers yields a 64-bit result

SLIDE 3

10.9

IMPORTANT R-TYPE INSTRUCTIONS

Performing Arithmetic, Logic, and Shift Operations

10.10

R-Type Arithmetic/Logic Instructions

C operator Assembly Notes + ADD $d, $s, $t d=destination, s = src1, t = src2

• SUB $d, $s, $t

Order: $s – $t. SUBU for unsigned * MUL $d, $s, $t If multiply won’t overflow 32-bit result & AND $d, $s, $t | OR $d, $s, $t ^ XO$ $d, $s, $t ~( | ) NOR $d, $s, $t Can be used for bitwise-NOT (~) << SLL $d, $s, shamt SLLV $d, $s, $t Shifts $s left by shamt (shift amount)

• r $t bits

>> (signed) SRA $d, $s, shamt SRAV $d, $s, $t Shifts $s right by shamt or $t bits replicating sign bit to maintain sign >> (unsigned) SRL $d, $s, shamt SRLV $d, $s, $t Shifts $s left by shamt or $t bits shifting in 0’s <, >, <=, >= SLT $d, $s, $t SLTU $d, $s, $t

• Comparison. Order: $s – $t. Sets

$d=1 if $s < $t, $d=0 otherwise * MULT $s, $t MULTU $s, $t Result in HI/LO. Use mfhi and mflo instruction to move results / DIV $s, $t DIVU $s, $t $[s] / $[t]. Remainder in HI, quotient in LO

10.11

R-Type Instructions

C Code MIPS Assembly

F = X + Y – Z; G = F | Z;

LOAD* $4, X # Get X from mem. LOAD _____ # Get Y from mem. LOAD _____ # Get Z from mem. ADD _______ # Tmp = X+Y SUB _______ # Tmp = Tmp - Z STORE _______ # Store to F in mem OR _______ # Tmp2 = F | Z STORE $8, G # Store to G in mem * LOAD/STORE are not actual instructions. We will learn the actual syntax soon.

• To perform arithmetic or logic operations in many processors (MIPS

included) a copy of the operand MUST be loaded into a register first

• Consider the following operations

– F = X + Y – Z – G = F | Z

• Complete the assembly code

to perform these operations

– Remember to load/store your

• perands to/from registers

MIPS Processor

Addr (32-bits) Data (32-bits) Control

Memory

Load 00400000

ALU

ADD, SUB, AND, OR

• p.

in1 in2

• ut

PC $0-$31 (32-bits each) (32-bits ALU) Load … Store X (e.g. 12) Y (e.g. 7) Z (e.g. 3) F G $4 $5 $6 $7 $8 00400004 10010000 10010004 10.12

R-Type Instructions

• Format

– rs, rt, rd are 5-bit fields for register numbers – shamt = shift amount and is used for shift instructions indicating # of places to shift bits – opcode and func identify actual operation (e.g. ADD, SUB)

• Example:

– ADD $5, $24, $17

• pcode

rs (src1) 6-bits 5-bits rt (src2) 5-bits rd (dest) 5-bits shamt 5-bits function 6-bits 000000

• pcode

rs rt rd 00000 shamt 100000 func

• Arith. Inst.

$24 $17 $5 unused ADD

SLIDE 4

10.13

Logical Operations

• Should already be familiar with (sick of) these! ☺

☺ ☺ ☺

• Logic operations are usually performed on a pair of bits

AND – Output is true if both inputs are true OR – Output is true if any input is true XOR – Output is true if exactly one input is true

X1 X2 AND 1 1 1 1 1 X1 X2 OR 1 1 1 1 1 1 1 X1 X2 XOR 1 1 1 1 1 1 X1 NOT 1 1

NOT – Output is inverse of input 0 OR x = x 1 OR x = 1 x OR x = x 0 AND x = 0 1 AND x = x x AND x = x 0 XOR x = x 1 XOR x = NOT x x XOR x = 0

10.14

Logical Operations

• Logic operations on numbers means performing the
• peration on each pair of bits

Initial Conditions: $1 = 0xF0, $2 = 0x3C AND $2,$1,$2 R[2] = 0x30 0xF0 AND 0x3C 0x30 1111 0000 AND 0011 1100 0011 0000 OR $2,$1,$2 R[2] = 0xFC 0xF0 OR 0x3C 0xFC 1111 0000 OR 0011 1100 1111 1100 XOR $2,$1,$2 R[2] = 0xCC 0xF0 XOR 0x3C 0xCC 1111 0000 XOR 0011 1100 1100 1100 1 2 3 Tip: Unless you're very good w/ hex, convert to binary then perform these operations!

10.15

Logical Operations

• Logic operations on numbers means performing the
• peration on each pair of bits

Initial Conditions: $1= 0xF0, $2 = 0x3C NOR $2,$1,$2 R[2] = 0x03 0xF0 NOR 0x3C 0x03 1111 0000 NOR 0011 1100 0000 0011 4 NOR $2,$1,$1 R[2] = 0x0F 0xF0 NOR 0xF0 0x0F 1111 0000 NOR 1111 0000 0000 1111 Bitwise NOT operation can be performed by NOR’ing register with itself

10.16

Shift Operations

• Shifts data bits either left or right

– Bits shifted out and dropped on one side – Usually (but not always) 0’s are shifted in on the other side

• In addition to just moving bits around, shifting is a fast way to

multiply or divide a number by ____________(see next slides)

• 2 kinds of shifts

– Logical shifts (used for __________________ numbers) – Arithmetic shifts (used for _________________ numbers)

0 0 0 0 0 0 1 1 Right Shift by 2 bits:

Original Data Shifted by 2 bits

0 0 0 0 1 1 0 0 0 0 0 0 1 0 1 0 0 0 Left Shift by 2 bits:

Original Data Shifted by 2 bits

0 0 0 0 1 0 1 0 0 0

0’s shifted in… 0’s shifted in…

SLIDE 5

10.17

Logical Shift

• 0’s shifted in
• Only use for operations on unsigned data

– Right shift by n-bits = Dividing by 2n – Left shift by n-bits = Multiplying by 2n

Logical Right Shift by 2 bits: ... _____________ Logical Left Shift by 3 bits:

0’s shifted in… 0’s shifted in…

0 ... 0 1 1 0 0 = +12 = +3 = +96 0 x 0 0 0 0 0 0 0 C 0 x 0 0 0 0 0 0 0 3 0 x 0 0 0 0 0 0 6 0

10.18

Arithmetic Shift

• Use for operations on signed data
• Arithmetic Right Shift – replicate MSB

– Right shift by n-bits = Dividing by 2n

• Arithmetic Left Shift – shifts in 0’s

– Left shift by n-bits = Multiplying by 2n

_ _ 1 ... 1 1 1 Arithmetic Right Shift by 2 bits: 1 ... 1 0 0 0 0 Arithmetic Left Shift by 2 bits:

MSB replicated and shifted in… 0’s shifted in…

1 1 ... 1 1 0 0 = -4 = -1 = -16

Notice if we shifted in 0’s (like a logical right shift) our result would be a positive number and the division wouldn’t work

0 x F F F F F F F C 0 x _ _ _ _ _ _ _ _

Notice there is no difference between an arithmetic and logical left shift. We always shift in 0’s.

0 x _ _ _ _ _ _ _ _ _

10.19

Logical Shift vs. Arithmetic Shift

• Logical Shift

– Use for unsigned or non- numeric data – Will always shift in ______ whether it be a left or right shift

• Arithmetic Shift

– Use for signed data – Left shift will shift in ____ – Right shift will ____________ (__________ the sign bit) rather than shift in 0’s

• If negative number…stays

negative by shifting in _____

• If positive…stays positive by

shifting in ______

Right shift Left shift Right shift Left shift

__ __ ___

10.20

MIPS Logical Shift Instructions

• SRL instruction – Shift Right Logical
• SLL instruction – Shift Left Logical
• Format:

– SxL rd, rt, shamt (shamt = shift amount and is a constant; e.g. x << 7) – SxLV rd, rt, rs (rs is the shift amount and is variable; e.g. x << y)

• Notes:

– shamt limited to a 5-bit value (0-31) – SxLV shifts data in rt by number of places specified in rs

• Examples

– SRL $5, $12, 7 // Shifts data in reg. $12 right by 7 places – SLLV $5, $12, $20 // If $20=5, shift data in $12 left by 5 places

000000 00000

• pcode

rs 01100 rt 00101 rd 00111 shamt 000010 func

• Arith. Inst.

unused $12 $5 7 SRL 000000 10100 01100 00101 00000 000100

• Arith. Inst.

$20 $12 $5 unused SLLV

SLIDE 6

10.21

MIPS Arithmetic Shift Instruction

• SRA instruction – Shift Right Arithmetic
• No arithmetic left shift (use SLL for arithmetic left shift)
• Format:

– SRA rd, rt, shamt (shamt = shift amount and is a constant; e.g. x >> 7) – SRAV rd, rt, rs (rs is the shift amount and is variable; e.g. x >> y)

• Notes:

– shamt limited to a 5-bit value (0-31) – SRAV shifts data in rt by number of places specified in rs

• Examples

– SRA $5, $12, 7 – SRAV $5, $12, $20

000000 00000

• pcode

rs 01100 rt 00101 rd 00111 shamt 000011 func

• Arith. Inst.

unused $12 $5 7 SRA 000000 10100 01100 00101 00000 000111

• Arith. Inst.

$20 $12 $5 unused SRAV

10.22

Immediate Operands

• Most ALU instructions also have an immediate form to be used when one
• perand is a constant value
• Syntax: ADDI Rs, Rt, imm

– Because immediates are limited to 16-bits, they must be extended to a full 32- bits when used the by the processor – ___________ instructions always sign-extend to a full 32-bits even for unsigned instructions (addiu) – ___________ instructions always zero-extend to a full 32-bits

• Examples:

– ADDI $4, $5, -1 // R[4] = R[5] + 0xFFFFFFFF – ORI $10, $14, -4 // R[10] = R[14] | 0x0000FFFC

Arithmetic Logical ADDI ANDI SLTI ORI XORI Note: SUBI is unnecessary since we can use ADDI with a negative immediate value

10.23

Set If Less-Than

• SLT $rd, $rs, $rt

– Compares $rs value with $rt value and stores Boolean (1 = true, 0 = false) value into $rd – C code equivalent: _________________ – $rd can only be 0x0000001 or 0x00000000 after execution – Assumes signed integer comparison

• SLTI $rd, $rs, immediate

– Same as above but now 2nd source is a constant

• SLTU $rd, $rs, $rt

– Same as SLT but interprets values as unsigned

SLT $4, $1, $2 $4 = 0x0000000_ Initial Conditions: $1= 0xffffffff, $2 = 0x00000000 $3 = 0x000000ff SLT $4, $3, $3 $4 = 0x0000000_ SLT $4, $3, $1 $4 = 0x0000000_ SLTI $4, $2, 35 $4 = 0x0000000_ SLTU $4, $1, $2 $4 = 0x0000000_

10.24

DATA TRANSFER AND MEMORY ACCESS INSTRUCTIONS

Loading (Reading) and Storing (Writing) Data From and To Memory

SLIDE 7

10.25

Physical Memory Organization

• Physical view of memory as large 2-D array of bytes (8K rows by 1KB

columns) per chip (and several chips)

• Address is broken into fields of bits that are used to identify where in the

array the desired 32-bit word is

– Processor always accesses memory chunks the size of the data bus, selecting

• nly the desired bytes as specified by the instruction

...

… Physical View of Memory

...

Proc.

32 32 A D

Rank/Bank Row Col

Sample Address Breakdown

... ...

XX

0x00000404 00000 0000000000001 00000001 00 0x0404 = 0x000000 0x000400 0x000800 Assume each unit is a word

10.26

MIPS Supported Data Sizes

Integer

• 3 Sizes Defined

– Byte (B)

• 8-bits

– Halfword (H)

• 16-bits = 2 bytes

– Word (W)

• 32-bits = 4 bytes

Floating Point

• 3 Sizes Defined

– Single (S)

• 32-bits = 4 bytes

– Double (D)

• 64-bits = 8 bytes
• (For a 32-bit data bus, a

double would be accessed from memory in 2 reads)

10.27

MIPS Memory Organization

• We can logically picture

memory in the units (sizes) that we actually access them

• Most processors are ________

__________________

– Every byte (8-bits) has a unique address – 32-bit address bus => 4 GB address space

• However, 32-bit logical data bus

allows us to access _______ of data at a time

• Logical view of memory

arranged in rows of 4-bytes

– Still with separate addresses for each byte

5A 0x000000 13 F8 … 0x000001 0x000002 Logical Byte-Oriented View of Mem.

Proc. Mem.

32 32 A D 5A 13 7C 29 33 … 0x000008 0x000004 0x000000 Logical Word-Oriented View F8 AD 8E int x,y=5;z=8; x = y+z;

Recall variables live in memory & need to be loaded into the processor to be used

10.28

Memory & Data Size

Byte operations only access the byte at the specified address

N N+1 N+2 N+3

(Assume start address = N)

Halfword operations access the 2-bytes starting at the specified address

N N+1 N+2 N+3

Word operations access the 4-bytes starting at the specified address

N N+1 N+2 N+3

• Little-endian memory can be thought of as right justified
• Always provide the LS-Byte address of the desired data
• Size is explicitly defined by the instruction used
• Memory Access Rules

– Halfword or Word access must start on an address that is a multiple of that data size (i.e. half = multiple of 2, word = multiple of 4)

Byte 31 Half 15 Word 31

LB LH LW

Registers: Memory

Used to load a 1- byte var. (char) Used to load a 4- byte variable (int)

SLIDE 8

10.29

Memory Read Instructions (Signed)

LB (Load Byte) Provide address of desired byte LH (Load Half) Provide address of starting byte LW (Load Word) Provide address of starting byte

Sign Extend 31 Byte 7

GPR

Sign Extend 31 Half 15 Word 31

If address = 0x02

• Reg. = 0x_____________

If address = 0x00

• Reg. = 0x_____________

If address = 0x00

• Reg. = 0x____________

5A 13 7C … 000004 000000 F8 5A 13 7C … 000004 000000 F8 5A 13 7C … 000004 000000 F8

Memory

10.30

Memory Read Instructions (Unsigned)

LBU (Load Byte) Provide address of desired byte LHU (Load Half) Provide address of starting byte LW (Load Word) Provide address of starting byte

Zero Extend 31 Byte 7

GPR

Zero Extend 31 Half 15 Word 31

If address = 0x01

• Reg. = 0x__________

If address = 0x00

• Reg. = 0x___________

If address = 0x00

• Reg. = 0x____________

Memory

5A 13 7C … 000004 000000 F8 5A 13 7C … 000004 000000 F8 5A 13 7C … 000004 000000 F8

10.31

Memory Write Instructions

SB (Store Byte) Provide address of desired byte SH (Store Half) Provide address of starting byte SW (Store Word) Provide address of starting byte if address = 0x02 if address = 0x02 if address = 0x00 Memory

31 Byte 7

GPR

31 Half 15 Word 31

• Reg. = 0x12345678
• Reg. = 0x12345678
• Reg. = 0x12345678

… 000004 000000 … 000004 000000 … 000004 000000

10.32

MIPS Memory Alignment Limitations

• Bytes can start at any address
• Halfwords must start on an

even address

• Words must start on an

address that is a multiple of 4

• Examples:

– Word @ A18C – – Halfword @ FFE6 – – Word @ A18E – – Halfword @ FFE5 –

F8 7C … 00A18C Addr 00FFE4 C1 4B 29 EA 49 CF 5A 13 BD 52

SLIDE 9

10.33

Load Format (LW,LH,LB)

• Syntax: LW $rt, offset($rs)

– $rt = Destination register – offset($rs) = Address of desired data – Operation: $rt = Mem[ offset + $rs ] – offset limited to 16-bit signed number

• Examples

– LW $2, 0x40($3) // $2 = ________________ – LBU $2, -1($4) // $2 = ________________ – LH $2, 0xFFFC($4) // $2 = ________________

5A12C5B7 0x002048 134982FE F8BE97CD 0x002044 0x002040 00002000 $3 0000204C $4

• ld val.

$2 Memory

Address

Registers

10.34

More LOAD Examples

• Examples

– LB $2,0x45($3) // $2 = _____________ – LH $2,-6($4) // $2 = _____________ – LHU $2, -2($4) // $2 = _____________

5A12C5B7 0x002048 134982FE F8BE97CD 0x002044 0x002040 00002000 0000204C

• ld val.

$3 $4 $2 Memory

Address

Registers

10.35

Store Format (SW,SH,SB)

• SW $rt, offset($rs)

– $rt = Source register – offset($rs) = Address to store data – Operation: Mem[ offset + $rs ] = $rt – offset limited to 16-bit signed number

• Examples

– SW $2, 0x40($3) – SB $2, -5($4) – SH $2, 0xFFFE($4)

00002000 0000204C 123489AB $3 $4 $2 Memory

Address

Registers 0x002048

_ _ _ _ _ _ _ _

0x002044 0x002040

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

10.36

Loading an Immediate

• If immediate (constant) ___________________

– Use ______ or _________ instruction with _____ register – Examples

• ADDI $2, $0, 1

// $2 = 0 + 1 = 1 (Loads const. 1 into $2)

• ORI

$2, $0, 0xF110 // $2 = 0 | 0xF110 = 0xF110 (Loads 0xF110)

• If immediate more than 16-bits

– Immediates limited to 16-bits so we must load constant with a 2 instruction sequence using the special ___________________________ instruction – To load $2 with 0x12345678

• _______________________
• _______________________

$2 $2

SLIDE 10

10.37

I-Type Instructions

• I-Type (Immediate) Format

– rs, rt are 5-bit fields for register numbers – I = Immediate is a 16-bit constant – opcode identifies actual operation

• Example:

– ADDI $5, $24, 1 – LW $5, -8($3)

• pcode

rs (src1) 6-bits 5-bits rt (src/dst) 5-bits immediate 16-bits 001000 11000

• pcode

rs 00101 rt ADDI $24 $5 immediate 1 010111 00011 00101 LW $3 $5

• 8

LW is explained in the next section but is an example of an instruction using the I-type format Fill me in…

10.38

Translating to Machine Code

• 32-bit Fixed Size Instructions broken into 3 types (R-, I-, and J-)

based on __________…

• ___________

– Arithmetic/Logic instructions – 3 register operands

• r shift amount
• ___________

– Use for data transfer, branches, etc. – 2 registers + 16-bit const.

• _________

– 26-bit jump address – We'll cover this later

• pcode

rs (src1) 6-bits 5-bits rt (src2) 5-bits rd (dest) 5-bits shamt 5-bits function 6-bits

• pcode

rs (src1) 6-bits 5-bits rt (src/dst) 5-bits immediate 16-bits

• pcode

__-Type

Jump address 26-bits 6-bits

__-Type __-Type

add $5,$7,$8 000000 ______ ______ ______ ______ 100000 lw $18, -4($3) 100011 ______ ______ _____ _____ _____ _____ j 0x0400018 000010 0000 0100 0000 0000 0000 0001 10 Each type uses portions of the instruction to "code" certain aspects of the instruction. But they all start with an opcode that helps determine which type will be used.

10.39

COMPILING HIGH-LEVEL CODE

"Be the Compiler"

10.40

Tips for Translating to Assembly

• We will now translate C code to assembly
• A few things to remember:

– Data variables live in memory – Data must be brought into registers before being processed – You must have an address/pointer in a register to load/store data to/from memory

• Generally, you will need 4 steps to translate C to assembly:

– ________________ in a register (LUI + ORI) – _______ data from memory to a register (___________) – ___________ data (ADD, SUB, AND, OR, etc.) – ________ data back to memory (____________)

SLIDE 11

10.41

Translating HLL to Assembly

• HLL variables are simply locations in memory

– A variable name really translates to an address in assembly

C operator Assembly Notes int x,y,z; … x = y + z; LUI $8, 0x1000 ORI $8, $8, 0x0004 Assume x @ 0x10000004 & y @ 0x10000008 & z @ 0x1000000C char a[100]; … a[1]--; Assume array ‘a’ starts @ 0x1000000C

10.42

Translating HLL to Assembly

C operator Assembly Notes int dat[4],x; … x = dat[0]; x += dat[1]; LUI $8, 0x1000 ORI $8, $8, 0x0010 LW $9, 0($8) Assume dat @ 0x10000010 & x @ 0x10000020 unsigned int y; short z; y = y / 4; z = z << 3; LUI $8, 0x1000 ORI $8, $8, 0x0010 LW $9, 0($8) _________________ SW $9, 0($8) LH $9, 4($8) _________________ SH $9, 4($8) Assume y @ 0x10000010 & z @ 0x10000014

10.43

ASSEMBLERS

Directives Pseudo-instructions

10.44

Writing Assembly

• Code written at the assembly level needs

some additional help for specifying certain things

– _______________________ – Where ________ and _________ should be placed in memory – Easy ways to reference memory locations

• To help us do this assemblers provide some

additional statements that we can use

SLIDE 12

10.45

Our Simulator - MARS

Download at: http://courses.missouristate.edu/KenVollmar/MARS/

10.46

Assembler Syntax

• In MARS and most assemblers each line of the

assembly program may be one of three possible options

– Comment – Instruction / Pseudo-instruction – _________________________

10.47

Comments

• In MARS an entire line can be marked as a comment

by starting it with a pound (#) character:

• Example:

# This line will be ignored by the assembler LW $2,8($3) ADDI $2,$2,1 ...

10.48

Instructions

• In MARS each instruction is written on a

separate line and has the following syntax:

(Label:)

• Instruc. Op.

Operands Comment

• Example:

START: ADD $2,$3,$4 # R[2]=R[3] + R[4]

• Notes:

– Label is optional and is a text identifier for the address where the instruction is placed in memory. (These are normally used to identify the target of a branch

• r jump instruction.)

– In MARS, a comment can be inserted after an instruction by using a ‘#’ sign – A label can be on a line by itself in which case it refers to the address of the first instruction listed after it

SLIDE 13

10.49

Labels and Instructions

• The optional label in front of an instruction

evaluates to the ____________ where the instruction or data starts in memory and can be used in other instructions

.text START: LW $4,8($10) L1: ADDI $4,$4,-1 BNE $4,$0,L1 J START LW ADDI BNE J 0x400000 = START 0x400004 = L1 0x400008 0x40000C Assembly Source File …and replaces the labels with their corresponding address Assembler finds what address each instruction starts at… Note: The BNE instruc. causes the program to branch (jump) to the instruction at the specified address if the two operands are Not Equal. The J(ump) instruction causes program execution to jump to the specified label (address). .text LW $4,8($10) ADDI $4,$4,-1 BNE $4,$0,0x400004 J 0x400000 10.50

Assembler Directives

• Similar to pre-processor statements (#include,

#define, etc.) and global variable declarations in C/C++

– Text and data segments – Reserving & initializing global variables and constants – Compiler and linker status

• Direct the assembler in how to assemble the actual

instructions and how to initialize memory when the program is loaded

10.51

An Example

• This is output from an

actual MIPS gcc/g++ compiler

• Actual instructions are at

the bottom (addiu, srl, etc.)

• Directives are the things

starting with .

• Labels are names ending

with :

• Let's learn about some of

the directives

x: .word 5 .globl nums .section .bss .align 2 .type nums, @object .size nums, 40 nums: .space 40 .text .align 2 .globl _Z6calleei $LFB2: .ent _Z6calleei _Z6calleei: .frame $sp,0,$31 .mask 0x00000000,0 .fmask 0x00000000,0 addiu $2,$4,3 srl $3,$2,31 addu $2,$2,$3

10.52

Text and Static Data Segments

• .text directive indicates the

following instructions should be placed in the program area of memory

• .data directive indicates the

following data declarations will be placed in the data memory segment

Unused 0x0040_0000 Text Segment Static Data Segment Dynamic Data Segment Stack I/O Space 0x1000_0000 0x8000_0000 0xFFFF_FFFC 0x1000_8000 0x7FFF_FFFC 0x0000_0000

SLIDE 14

10.53

Static Data Directives

• Fills memory with specified data when program is

loaded

• Format:

(Label:) .type_id val_0,val_1,…,val_n

• type_id = {.byte, .half, .word, .float, .double}
• Each value in the comma separated list will be

stored using the indicated size

– Example: myval: .word 1, 2, 0x0003

• Each value 1, 2, 3 is stored as a word (i.e. 32-bits)
• Label “myval” evaluates to the start address of the first

word (i.e. of the value 1)

10.54

More Static Data Directives

• Can be used to initialize ASCII strings
• Format:

(Label:) .ascii “string” (Label:) .asciiz “string”

• .asciiz adds a null-termination character (0) at

the end of the string while .ascii does not

– Example: myval: .asciiz “Hello world\n”

• C-strings are just character arrays terminated with a null

character ('\0' ASCII = 00 decimal)

• Each character stored as a byte (including '\n' = Line Feed)
• Label “myval” evaluates to the start address of the first byte of

the string

10.55

Reserving Memory

• Reserves space in memory but leaves the contents

unchanged

• Format:

(Label:) .space num_bytes

.data dat1: .word 0x12345678 array: .space 4 dat2: .word 0xFEDCBA98 00 00 00 00 FE DC BA 98 0x1000000C 00 00 00 00 0x10000008 = dat2 0x10000004 = array 12 34 56 78 0x10000000 = dat1 Skipped 10.56

Alignment Directive

• Used to skip to the next, correctly-aligned address

for the given data size

• Format:
• 0 = byte-, 1 = half-, 2 = word-, 3 = double-alignment

.align 0,1,2, or 3

.data dat1: .byte 1, 2, 3 .align 1 dat2: .half 0x4567 .align 2 dat3: .word 0x89ABCDEF 00 00 00 00 89 AB CD EF 0x1000000C 00 00 45 67 0x10000008 = dat3 0x10000004 = dat2 00 03 02 01 0x10000000 = dat1 Skipped Skipped Note: The number after .align is not how many bytes to skip, it indicates what type of data will come next and thus the size to be aligned

SLIDE 15

10.57

.data example Examples

• C1 evaluates to ________________________
• MSG evaluates to ________________ (Note: \n = Line Feed char. = 0x0A)
• DAT evaluates to _________________
• VAR evaluates to _________________

.data C1: .byte 0xFE,0x05 MSG: .asciiz “SC\n” DAT: .half 1,2 .align 2 VAR: .word 0x12345678 0x10010000 0x10010004 0x10010008 0x1001000C 10.58

C/C++ and Directives

• Directives are used to initialize or reserve

space for global variables in C

short int count = 7; char message[16]; int table[8] = {0,1,2,3,4,5,6,7}; void main() { ... } .data count: message: .align ______ table: .word ________________ .text .globl main main: ...

C/C++ style global declarations Assembly equivalent 10.59

Summary & Notes

• Assembler Directives:

– Tell the assembler how to build the program memory image

• Where instructions and data should be placed in memory when

the program is loaded

• How to initialize certain global variables
• Recall, a compiler/assembler simply outputs a

memory IMAGE of the program. It must then be loaded into memory by the OS to be executed.

• Key: Directives are NOT instructions!

– They are used by the assembler to create the memory image and then removed – The MIPS processor never sees these directives!

10.60

Directives in the Software Flow

1110 0010 0101 1001 0110 1011 0000 1100 0100 1101 0111 1111 1010 1100 0010 1011 0001 0110 0011 1000 MOVE.W X,D0 CMPI.W #0,D0 BLE SKIP ADD Y,D0 SUB Z,D0 SKIP MUL …

High Level Language Description Assembly (.asm/.s files) Executable Binary Image int n = 0xC259; void main(){ if (x > 0) x = x + y - z; a = b*x;

.data n: .word 0xC259 .text SLT $4,$2,$0 BNE SKIP … SKIP: MUL … 1110 0010 0101 1001 0110 1011 0000 1100 0100 1101 0111 1111 1010 1100 0010 1011 0001 0110 0011 1000

.c/.cpp files

1110 0010 0101 1001 0110 1011 0000 1100 0100 1101 0111 1111 1010 1100 0010 1011 0001 0110 0011 1000

Object/Machine Code (.o files) Compiler Assembler Linker Loader / OS Program Executing Assembler Directives are used to create the

• bject code (executable)

image… …the processor NEVER sees/executes these directives PC SLT BNE

SLIDE 16

10.61

Pseudo-instructions

• “Macros” translated by the assembler to

instructions actually supported by the HW

• Simplifies writing code in assembly
• Example – LI (Load-immediate) pseudo-

instruction translated by assembler to 2 instruction sequence (LUI & ORI)

... lui $2, 0x1234

• ri $2, $2, 0x5678

... ... li $2, 0x12345678 ...

With pseudo-instruction After assembler… 10.62

Pseudo-instructions

Pseudo-instruction Actual Assembly NOT Rd,Rs NOR Rd,Rs,$0 NEG Rd,Rs SUB Rd,$0,Rs LI Rt, immed. # Load Immediate LUI Rt, {immediate[31:16], 16’b0} ORI Rt, {16’b0, immediate[15:0]} LA Rt, label # Load Address LUI Rt, {immediate[31:16], 16’b0} ORI Rt, {16’b0, immediate[15:0]} BLT Rs,Rt,Label SLT $1,Rs,Rt BNE $1,$0,Label

Note: Pseudoinstructions are assembler-dependent. See MARS Help for more details. 10.63

Support for Pseudo-instructions

• Pseudo-instructions often expand to several

instructions and there is a need for usage of a temporary register

• Assembler reserves register $1

– In the assembler, $1 = $at (assembler temp.)

• You can use $1 but it will be overwritten when

you use certain pseudo-instructions

10.64

Coding Exercise with MARS

• int x = 7, y = 5, z = 3;

z = x * z + (x – y++)

• # #DEFINE MASK 0xe0;

# PORTD &= ~(MASK) # PORTD |= ((x << 5) & MASK);

SLIDE 17

10.65

INSTRUCTION SET ARCHITECTURE

What are the common features of all processor instruction sets?

10.66

Components of an ISA

• 1. ________ and Address Size

– 8-, 16-, 32-, 64-bit

• 2. Which instructions does the processor support

– SUBtract instruc. vs. NEGate + ADD instrucs.

• 3. ________________________ of instructions

– How is the operation and operands represented with 1’s and 0’s

• 4. __________ accessible to the instructions

– Faster than accessing data from memory

• 5. Addressing Modes

– How instructions can specify location of data operands

10.67

Historic Progression of Data Size & Registers

Processor Year Trans. Count Data Size GPRs 8088 1979 29K 8 8 80286 1982 134K 16 8 80386/486 ’85/’89 275K/1.1 8M 32 8 Pentium 1993 3.1M 32 >8 Pentium 4 2000 42M 32 >= 128 Core 2 Duo 2006 291M 64 >= 128 6-core Core i7 2011 2.27B 64 >= 128 MIPS 1999 var. 32 32

10.68

General Instruction Format Issues

• Instructions must specify three things:

– ______________________________________ – Source operands

• Usually 2 source operands (e.g. X+Y)

– ______________________________________

• Example: ADD $8, $9, $10 ($8 = $9 + $10 where $ = Register)
• Binary (machine-code) representation broken into

fields of bits for each part

000000 00000 Arith. Unused OpCode 100000 Add Function Shift Amount 01001 01010 $9 $10

• Src. 1
• Src. 2

Dest. 01000 $8

SLIDE 18

10.69

Historical Instruction Formats

• Different instruction sets specify these differently

– 3 operand instruction set (MIPS, PPC, ARM)

• Similar to example on previous page
• Format: ADD DST, SRC1, SRC2 (DST = SRC1 + SRC2)

– 2 operand instructions (Intel / Motorola 68K)

• Second operand doubles as source and destination
• Format: ADD SRC1, S2/D

(S2/D = SRC1 + S2/D)

– 1 operand instructions (Old Intel FP, Low-End Embedded)

• Implicit operand to every instruction usually known as the

Accumulator (or ACC) register

• Format: ADD SRC1

(ACC = ACC + SRC1)

10.70

Historical Instruction Format Examples

Single-Operand Two-Operand Three-Operand

LOAD X ADD Y SUB Z STORE F LOAD A ADD B STORE G MOVE F,X ADD F,Y SUB F,Z MOVE G,A ADD G,B ADD F,X,Y SUB F,F,Z ADD G,A,B

(+) Smaller size to encode each instruction (-) Higher instruction count to load and store ACC value Compromise of two extremes (+) More natural program style (+) Smaller instruction count (-) Larger size to encode each instruction

• Consider the pros and cons of each format when performing the set of
• perations

– F = X + Y – Z – G = A + B

• Simple embedded computers often use single operand format

– Smaller data size (8-bit or 16-bit machines) means limited instruc. size

• Modern, high performance processors use 2- and 3-operand formats

10.71

MIPS Instruction Format

• _______________ operand format

– Most ALU instructions use 3 registers as their operands – All operations are performed on entire 32- bits (no size distinction) – Example: ADD $t0, $t1, $t2

• ______________ architecture

– Load (read) data values from memory into a register – Perform operations on registers – Store (write) data values back to memory – Different load/store instructions for different operand sizes (i.e. byte, half, word)

Proc.

1.) Load operands to proc. registers

Mem. Proc.

2.) Proc. Performs operation using register values

Mem. Proc.

3.) Store results back to memory

Mem. Load/Store Architecture
