EARTHQUAKE ENGINEERING LESSONS FROM STRONG EARTHQUAKES RELATED TO ADVANCED WAYS FOR SEISMIC RISK MITIGATIONS G. Rodolfo Saragoni Universidad de Chile THE 2010 CHILE, Mw=8.8 EARTHQUAKE G. Rodolfo Saragoni Universidad de Chile CIRCUMPACIFIC

slide-1
SLIDE 1
  • G. Rodolfo Saragoni

Universidad de Chile

EARTHQUAKE ENGINEERING LESSONS FROM STRONG EARTHQUAKES RELATED TO ADVANCED WAYS FOR SEISMIC RISK MITIGATIONS

slide-2
SLIDE 2
  • G. Rodolfo Saragoni

Universidad de Chile

THE 2010 CHILE, Mw=8.8 EARTHQUAKE

slide-3
SLIDE 3

CIRCUMPACIFIC SEISMICITY

slide-4
SLIDE 4

CIRCUMPACIFIC SUBDUCTION

slide-5
SLIDE 5

Placa Sudamericana

Placa de Nazca

SUBDUCTION OF NAZCA PLATE UNDER SOUTH AMERICA PLATE

slide-6
SLIDE 6

SUBDUCTION PLATE INTERACTION

slide-7
SLIDE 7

TYPES OF EARTHQUAKES

  • INTERPLATE THRUST SUBDUCTION EARTHQUAKES

(CHILE 2010 EARTHQUAKE)

  • INTRAPLATE SUBDUCTION EARTHQUAKES
  • CORTICAL EARTHQUAKES (SUPERFICIAL RELATED

WITH FAULTS)

  • STRIKE SLIP FAULT DUE TO INTERPLATE

INTERACTION (MAGALLANES FAGNANO FAULT)

slide-8
SLIDE 8

LARGE SUBDUCTION EARTHQUAKES

slide-9
SLIDE 9

Mw = -0.089·T+0.134·V+7.96 TSUNAMIS

slide-10
SLIDE 10

COMPARISON WITH L’AQUILA EARTHQUAKE

CHILE 2010

L’AQUILA 2009

450 KM 200 KM 26 KM 11 KM

slide-11
SLIDE 11

THE STUDY OF THE EARTHQUAKE IS DIVIDED IN THREE STAGES:

  • PRESEISMIC
  • COSEISMIC
  • POSTSEISMIC
slide-12
SLIDE 12

PRESEISMIC STAGE

slide-13
SLIDE 13

THE SEISMIC GAP SOUTH OF MATANZAS

slide-14
SLIDE 14

THE EARTHQUAKE WILL BE MAGNITUDE 8.0 – 8.3 SIMILAR TO TALCA EARTHQUAKE OF 1928

slide-15
SLIDE 15

Talca Earthquake 1928 (Sanhueza y Astroza)

slide-16
SLIDE 16

THE EARTHQUAKE WOULD BE CHARACTERIZED BY:

  • TO BE THE ONE WHICH MORE AFFECT THE TALL

BUILDINGS IN SANTIAGO (CAPITAL OF CHILE)

  • TO PRODUCE THE COLLAPSE OF MOST OF

ADOBE STRUCTURES IN COLCHAGUA PROVINCE

  • A MODERATE TSUNAMI
  • A 500 Km RUPTURE
slide-17
SLIDE 17

STUDY OF PISCO EARTHQUAKE, PERU 2007, Mw=7.9 EFECTS ON HIGHRISE BUILDINGS

slide-18
SLIDE 18

EFFECTS ON HIGHRISE BUILDINGS

Miraflores Building 17 Story, Lima

slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22

EFFECT OF NEW TALCA EARTHQUAKE IN SANTIAGO

PERFORMANCE DESING

slide-23
SLIDE 23

ACELEROGRAFIC INSTRUMENTATION

slide-24
SLIDE 24

INSTRUMENTATION U. DE CHILE RENADIC

slide-25
SLIDE 25

COSEISMIC STAGE

slide-26
SLIDE 26

CHARACTERISTICS OF Mw =8.8 EARTHQUAKE

Epicenter Cobquecura 35.909ºS 73.733ºW Depth 35Km Deaths 430 Losses US 30.000.000.000 (U$10.000.000.000) Duration 2,5 minutes Maximun Mercalli Intensity IX (Low Constitución) Bilateral Rupture, Dominant to the North Important Tsunami Surface faulting was activated

slide-27
SLIDE 27

Rupture Length Similar to Concepcion 1835 Earthquake NO to Talca 1928 Earthquake

slide-28
SLIDE 28
slide-29
SLIDE 29

USGS

CHILE 2010 EARTHQUAKE

slide-30
SLIDE 30

Asperities

slide-31
SLIDE 31
slide-32
SLIDE 32

Asperity cartoon (Sholz, 1990)

slide-33
SLIDE 33

L’AQUILA 2009 Mw=6.3

slide-34
SLIDE 34

TOCOPILLA 2007, M=7.7

slide-35
SLIDE 35

Coseismic Displacement

slide-36
SLIDE 36

INTENSITIES MSK, CHILE 2010 EARTHQUAKE

slide-37
SLIDE 37

COLAPSO DEL ADOBE

slide-38
SLIDE 38

TSUNAMI

slide-39
SLIDE 39

JUAN FERNANDEZ ISLAND

slide-40
SLIDE 40

TALCAHUANO

slide-41
SLIDE 41

TSUNAMI HEIGTS

slide-42
SLIDE 42

INSTRUMENTATION

slide-43
SLIDE 43

RECORDED ACCELEROGRAMS

  • MANY ACCELEROGRAMS RECORDED

IN SANTIAGO AT GROUND LEVEL, HIGH RISE BUILDINGS, BRIDGES, ISOLATED BUILDINGS and METRO.

  • RECORDED ACCELEROGRAMS AT

GROUND LEVEL IN THE MOST DAMAGE CITIES

slide-44
SLIDE 44

RECORDED ACCELEROGRAMS

slide-45
SLIDE 45

RECORDED ACCELEROGRAMS

slide-46
SLIDE 46
slide-47
SLIDE 47
slide-48
SLIDE 48
slide-49
SLIDE 49

DAMAGE TO BUILDINGS

  • THREE BUILDINGS COLLAPSED:

ONE IN CONCEPCION TWO IN SANTIAGO

slide-50
SLIDE 50

Alto Río - Concepción

slide-51
SLIDE 51

DAMAGE TO BUILDINGS

slide-52
SLIDE 52

DAMAGE TO BUILDINGS

slide-53
SLIDE 53

DAMAGE TO BUILDINGS

slide-54
SLIDE 54

DAMAGE TO BUILDINGS

  • MOST BUILDINGS DESIGNED

ACCORDING TO SEISMIC CHILEAN CODE Nch 433 “SEISMIC DESIGN OF BUILDINGS” PERFORMED WELL WITHOUT COLLAPSE

slide-55
SLIDE 55

DAMAGE TO BUILDINGS

  • THERE ARE SOME HIGH RISE

BUILDINGS WITH STRUCTURAL DAMAGE

slide-56
SLIDE 56

CHARACTERISTICS OF THE FAILURE OF THE HIGHRISE BUILDINGS

slide-57
SLIDE 57

HORIZONTAL FAILURE STRIPE IN BASEMENT WALLS

slide-58
SLIDE 58

HORIZONTAL FAILURE STRIPE IN BASEMENT WALLS

slide-59
SLIDE 59

HORIZONTAL FAILURE STRIPE IN BASEMENT WALLS

slide-60
SLIDE 60

HORIZONTAL FAILURE STRIPE IN BASEMENT WALLS

slide-61
SLIDE 61

HEAD OF THE WALL IN THE ZONE OF HORIZONTAL FAILURE STRIPE

slide-62
SLIDE 62

HEAD OF THE WALL IN THE ZONE OF HORIZONTAL FAILURE STRIPE

slide-63
SLIDE 63

HEAD OF THE WALL IN THE ZONE OF HORIZONTAL FAILURE STRIPE

slide-64
SLIDE 64

CABEZAL DE MURO FALLADO INCEPIENTEMENTE: CON FALLA HORIZONTAL INCIPIENTE, MOSTRANDO GRIETA HORIZONTAL ,DESCASCARAMIENTO EN EL CABEZAL Y PANDEO DE BARRAS VERTICALES (EDIFICIO DECLARADO INHABITABLE)

slide-65
SLIDE 65

FAILURE WITHOUT COMPRESION WITHOUT COVER SPOILING

slide-66
SLIDE 66

FAILURE IN UPPER SLABS

slide-67
SLIDE 67

EFFECT OF VERTICAL ACCELEROGRAMS PULSE ON WALL FAILURE

slide-68
SLIDE 68
slide-69
SLIDE 69
slide-70
SLIDE 70
slide-71
SLIDE 71

DAMAGE TO BRIDGES

  • MOST OF THE BRIDGES DESIGNED

ACCORDING TO CHILEAN CODE FOR BRIDGES PERFORMED WELL

slide-72
SLIDE 72
slide-73
SLIDE 73
slide-74
SLIDE 74
slide-75
SLIDE 75

DAMAGE TO BRIDGES

  • FEW BRIDGES DO NOT DESIGN

ACCORDING TO CHILEAN CODE COLLAPSE

slide-76
SLIDE 76
slide-77
SLIDE 77

SEISMIC PERFORMANCE OF RESEARCH NUCLEAR REACTOR

  • CHILE HAS TWO RESEARCH NUCLEAR

REACTORS IN SANTIAGO, BOTH PERFORMED WELL DURING THE EARTHQUAKE.

  • THE REACTORS ARE:
  • LA REINA IN OPERATION
  • LO AGUIRRE DISCONTINUED
slide-78
SLIDE 78

RESEARCH NUCLEAR REACTOR LA REINA UNDAMAGED (PGA = 0.2 – 0.3 g)

slide-79
SLIDE 79

RESEARCH NUCLEAR REACTOR LO AGUIRRE - SANTIAGO UNDAMAGED (PGA = 0.3 g).

slide-80
SLIDE 80

RESEARCH NUCLEAR REACTOR LA REINA UNDAMAGED (PGA = 0.2 – 0.3 g)

slide-81
SLIDE 81

RESEARCH NUCLEAR REACTOR LA REINA UNDAMAGED (PGA = 0.2 – 0.3 g)

slide-82
SLIDE 82

RESEARCH NUCLEAR REACTOR LA REINA UNDAMAGED (PGA = 0.2 – 0.3 g). REACTOR BARS

slide-83
SLIDE 83

RESEARCH NUCLEAR REACTOR LA REINA UNDAMAGED (PGA = 0.2 – 0.3 g). REACTOR BARS

slide-84
SLIDE 84

RESEARCH NUCLEAR REACTOR LO AGUIRRE - SANTIAGO UNDAMAGED (PGA = 0.3 g).

CONNECTIONS BETWEEN MAIN AND SECONDARY BUILDINGS

slide-85
SLIDE 85

RESEARCH NUCLEAR REACTOR LO AGUIRRE - SANTIAGO UNDAMAGED (PGA = 0.3 g). CONNECTIONS BETWEEN MAIN AND SECONDARY BUILDINGS LOOSE CONCRETE IN ANCHOR BOLTS

slide-86
SLIDE 86

CONVERSION LAB.

slide-87
SLIDE 87

FUEL ELEMENTS

slide-88
SLIDE 88

SAND LICUEFACTION

slide-89
SLIDE 89

¿IS THE 2010 EARTHQUAKE THE LARGEST THAT AFFECTS SANTIAGO OR IS THE 1730 EARTHQUAKE?

slide-90
SLIDE 90

PERFORMANCE OF HISTORICAL BUILDINGS

slide-91
SLIDE 91

SAN FRANCISCO CHURCH

slide-92
SLIDE 92

SAN FRANCISCO CHURCH

slide-93
SLIDE 93

SAN FRANCISCO CHURCH

slide-94
SLIDE 94

WOULD NOT BE THE LARGEST EARTHQUAKE

slide-95
SLIDE 95

CONCEPT OF FULLY OPERATIONAL AFTER EARTHQUAKE

slide-96
SLIDE 96

METRO DE SANTIAGO

slide-97
SLIDE 97

METRO DE SANTIAGO

slide-98
SLIDE 98

AEROPORT

slide-99
SLIDE 99

CAMARA CHILENA DE LA CONSTRUCCION BUILDING

slide-100
SLIDE 100

POSTSEISMIC STAGE

slide-101
SLIDE 101

CONCLUSIONS

  • IN GENERAL THE CHILEAN SEISMIC CODE

NCh 433 OF. 96 “SEISMIC DESIGN OF BUILDINGS” PERFORMED WELL IN REGARD OF LIVE PROTECTION CRITERIA. ONLY 3 BUILDINGS COLLAPSED

  • LOW BUILDINGS AND CONFINED MASONRY

HOUSES PERFORMED EXCELLENT

  • A LITTLE NUMBER BUT IMPORTANT OF

HIGH RISE BUILDINGS COULD COLLAPSE IF THE EARTHQUAKE RUPTURE WOULD BE TO THE SOUTH DUE TO DOPPLER EFFECT

  • ADOBE HOUSES HAD POOR PERFORMANCE

MOST OF THEM COLLAPSED

slide-102
SLIDE 102
  • THE BRIDGES DESIGNED ACCORDING TO CHILEAN

SEISMIC GUIDE HAD AN EXCELLENT PERFORMANCE

  • THE FEW BRIDGES AND PEDESTRIAN

OVERPASSES THAT COLLAPSED WERE NOT DESIGNED ACCORDING TO THE SEISMIC GUIDE

  • ACCELEROGRAMS FOR Mw=8.8 EARTHQUAKE

WERE OBTAINED FOR FIRST TIME AT WORLD

  • LEVEL. THESE RECORDS WILL BE MATTER OF

FUTURE STUDIES

  • POSSIBLE CHANGE OF THE PARADIGM FOR

BUILDING DESIGN FROM “LIVE PROTECTION” TO “CONTINUITY OF OPERATION”

  • LIQUEFACTION WAS OBSERVED IN MOST OF THE

AFFECTED AREA

  • MANY SURFACE FAULTS WERE ACTIVETED BY THE

EARTHQUAKE

slide-103
SLIDE 103
  • IMPORTANT DAMAGE AND NUMBER OF

VICTIMS WAS MAINLY DUE TO TSUNAMI AND ADOBE HOUSE COLLAPSES

  • THE TWO RESEARCH NUCLEAR REACTORS

IN SANTIAGO PERFORMED UNCRACKED FOR THE Mw=8.8 CHILEAN EARTHQUAKE.

  • THE PGA MEASURED IN SANTIAGO IN STIFF

SOIL WAS 0.2-0.3g
