Messaging & Directory Servers Directory Replication: from Gigabit LAN to HF Radio Steve Kille CEO October 2011 LDAPCon, Heidelberg, 2011 Messaging & Directory Servers Some Thoughts on Replication One Slide for each section of


slide-1
SLIDE 1

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Directory Replication: from Gigabit LAN to HF Radio

Steve Kille – CEO

October 2011

slide-2
SLIDE 2

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Some Thoughts on Replication

  • One Slide for each section of the paper
  • Key conclusions/points
  • More detail in the paper and URLs
  • Leave time to show how it works in practice
  • And a few retrospective slides at the end
slide-3
SLIDE 3

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

LDAP & Replication

  • LDAP is generally used to share information based on standard

schema (people; accounts; PKI etc)

  • (High) Replication of this data is often very important
  • For reasons we all understand (performance; locality; reliability)
  • There are wide range of approaches
slide-4
SLIDE 4

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

X.500 DISP

  • X.500 DISP (Directory Information Shadowing Protocol)
  • The only open standard for directory replication
  • Good functionality
  • A protocol that deserves to be used much more than it is
slide-5
SLIDE 5

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Strong Authentication for Replication

  • Strong Authentication (X.509 PKI) is sometimes sensible for

client authentication (e.g., with smart cards)

  • It should always be used for server to server authentication
  • Good security and administration characteristics
  • Too many organizations avoid it, because it is seen as “scary

technology”

slide-6
SLIDE 6

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Single Master vs Multi-Master

  • Pros and Cons
  • Single Master is best for many directory deployments
slide-7
SLIDE 7

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Disaster Recovery

  • Off site disaster recovery is key for some mission critical

directory deployments

  • Straightforward with multi-master (no special product support

needed)

  • Straightforward with single master (but you need product

support)

slide-8
SLIDE 8

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

LDAP Synchronization

  • Replication can be achieved between LDAP servers without any

special protocol support

  • And enhanced easily (e.g., Changelog)
  • Isode’s Sodium Sync product gives server independent replication
  • Plus flexible transformation and filtering

LDAP (Read) LDAP (Read and Write) Directory Server (Supplier) Directory Server (Consumer) Sodium Sync

slide-9
SLIDE 9

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Filtered Replication & Security Labels

  • Filtered Replication good for sharing selected information
  • Security Labels (military and intelligence) are a good way to

control replication

  • For example labelling an item “UK Top Secret, Releasable to NATO

Countries” vs “UK Top Secret, Releasable to US and Germany” can give flexible data oriented control

slide-10
SLIDE 10

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Directory Replication by Email

  • Seems a crazy idea, but useful for:
  • Messaging-only organizational boundaries
  • Where there are no special or optimized directory protocols:
  • Data Diode
  • HF Radio and other Constrained Networks
slide-11
SLIDE 11

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

“Show Me” Time

  • X.500 DISP Replication (and how it can be easy to set up)
  • Strong Authentication (for replication): it’s easy and there is no

excuse not to use it

  • Failover for Disaster Recovery
  • Sodium Sync for LDAP replication (and briefly replication by

email)

  • Security Label based access control (if there is time)
slide-12
SLIDE 12

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Hindsight on X.500 and LDAP

  • The goal was a global directory
  • This role has been taken by DNS
  • Which I don’t think is the best outcome
  • Things could have been different if two things had been done

early on with LDAP and X.500

slide-13
SLIDE 13

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Change 1: Use Domain/Email Names

  • Typed attributes are great for data and search
  • They suck for naming: awkward for real users
  • DC= was too little and too late
slide-14
SLIDE 14

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Change 2: Sort Top Level Replication

  • Today’s talk has been all about “leaf” replication
  • Top level replication is key to a very large distributed directory
  • getEDB should have been the start, not a dead-end
slide-15
SLIDE 15

LDAPCon, Heidelberg, 2011 Messaging & Directory Servers

Questions?

  • LDAP has a nice niche, but it could have been much much more
