Digitally Assisted Analog Circuits Boris Murmann Stanford University Department of Electrical Engineering murmann@stanford.edu Outline Motivation Progress in digital circuits has outpaced performance growth in analog circuits by a


slide-1
SLIDE 1

Digitally Assisted Analog Circuits

Boris Murmann Stanford University Department of Electrical Engineering murmann@stanford.edu

slide-2
SLIDE 2

Digitally Assisted Analog Circuits

  • B. Murmann 2

Outline

  • Motivation

– Progress in digital circuits has outpaced performance growth in analog circuits by a large margin

  • Digitally Assisted A/D Converters

– Using digital computing capabilities as a new driver to improve A/D converter energy efficiency – Examples

  • Experimental proof-of-concept result
  • Next generation designs
  • Conclusions
slide-3
SLIDE 3

Digitally Assisted Analog Circuits

  • B. Murmann 3

Modern Electronic Circuits

  • Trend towards ubiquitous sensing, communication

and computing

– "Ambient Intelligence"

  • Signal processing predominantly done in digital

domain

– Rapidly improving digital capabilities, fueled by "Moore's Law"

  • Irreplaceable "bottleneck" - analog circuits

– Analog-Digital Converters (ADCs) – Digital-Analog Converters (DACs) – Filters and amplifiers (Anti-aliasing, RF power amplification, …)

  • Focus of this talk: ADCs
slide-4
SLIDE 4

Digitally Assisted Analog Circuits

  • B. Murmann 4

Issue 1: Throughput

150x 15 years

1 10 100 1000 10000 1987 1995 2003 Relative Performance

ADC* (2x / 4.7 years) µP MIPS (2x / 1.5 years)

* Performance measure: Bandwidth x Number of quantization levels

slide-5
SLIDE 5

Digitally Assisted Analog Circuits

  • B. Murmann 5

Issue 2: Power and Energy

  • Example: Cell phone

– Battery has roughly 3Wh of Energy – For a talk time of 12 hours, can draw no more than 250mW – Only a fraction of that power available for ADC

  • In an increasing number of applications, key issue is

how much performance you can squeeze into a fraction of 0.1…1Watt

  • What is the trend in ADC versus digital power/energy

consumption?

slide-6
SLIDE 6

Digitally Assisted Analog Circuits

  • B. Murmann 6

ADC Energy versus Digital Energy

  • Interesting metric to look at

– How many digital gates can you toggle for the energy needed in

  • ne A/D conversion?
  • Example

– Standard digital gates (NAND2) in 0.13mm CMOS consume about 6nW/Gate/MHz

  • Energy/Gate = 6fJ

– State-of-the-art 10-bit ADC consumes 1mW/MSample/sec

  • Energy/Conversion = 1nJ

– Energy equivalent number of gates

  • 1nJ/6fJ= 166,666
slide-7
SLIDE 7

Digitally Assisted Analog Circuits

  • B. Murmann 7

Impact of Technology Scaling

100,000 200,000 300,000 400,000 500,000 0.0 0.2 0.4 0.6 0.8 Feature Size [ µm] Energy Equivalent # of Gates 6bits 8bits 10bits 12bits 14bits 16bits ADC Resolution:

slide-8
SLIDE 8

Digitally Assisted Analog Circuits

  • B. Murmann 8

Observations

  • Energy equivalent number of gates per A/D

conversion has gone through the roof

  • Reason

– Digital circuits have scaled well with technology – Analog doesn't benefit quite as much from smaller features

  • Issues: Low supply voltage, low device gain, …
  • Key idea

– Build "digitally assisted analog circuits" – Find a way to leverage digital processing capabilities to improve performance and lower power of analog circuits

slide-9
SLIDE 9

Digitally Assisted Analog Circuits

  • B. Murmann 9

Analog Circuit Challenges

Power Dissipation Speed Matching Linearity Noise Precision

Matching and linearity constraints are not fundamental

slide-10
SLIDE 10

Digitally Assisted Analog Circuits

  • B. Murmann 10

A New Generation of ADCs

  • Conventional ADC

– Precisely linear mapping from input to

  • utput

– Relies on highly linear and well matched analog components

  • Digitally assisted

ADC

– A "sloppy" one-to-one mapper – Digital postprocessor estimates ADC errors and applies corrections

Low Complexity “Sloppy” ADC Vin Daccurate Dsloppy Digital Postprocessor Vin Daccurate “Accurate” ADC

slide-11
SLIDE 11

Digitally Assisted Analog Circuits

  • B. Murmann 11

Examples

  • Digitally assisted pipeline ADC

– Murmann & Boser, ISSCC 2003

  • Minimum complexity, ultra low energy pipeline ADC

– Under development in my research group

  • ADC with embedded calibration for OFDM systems

– Under development in my research group

slide-12
SLIDE 12

Digitally Assisted Analog Circuits

  • B. Murmann 12

Pipeline ADC

  • Bottleneck: Highly linear gain element
  • A/D

D/A

  • D

Vres Vin STAGE 1 STAGE N-1 STAGE N S/H R bits Vin 2R D=0 D=1

  • V

res

Vin (e.g. R=1)

slide-13
SLIDE 13

Digitally Assisted Analog Circuits

  • B. Murmann 13

Open-Loop Gain Element

+ Lower Noise + Increased Signal Range + Lower Power + Faster – Nonlinear

  • Use DSP to

linearize!

Open-Loop Amplifier Conventional Precision Amplifier

slide-14
SLIDE 14

Digitally Assisted Analog Circuits

  • B. Murmann 14

Digital Nonlinearity Correction

System ID

Analog Nonlinearity Digital Inverse Modulation Dout,corr Vin Dout Parameters

  • Use digital system identification techniques to determine
  • ptimum post distortion function
  • Possible (and often necessary) to track correction parameters

without interrupting normal ADC operation

slide-15
SLIDE 15

Digitally Assisted Analog Circuits

  • B. Murmann 15

Experimental Verification

  • 12bit, 75MSamples/sec, 0.35µm, post-processor off chip
  • Based on commercial part (Analog Devices AD9235)

REFERENCE AND BIAS PIPELINE BACKEND STAGE1 SHA CLK LOGIC

slide-16
SLIDE 16

Digitally Assisted Analog Circuits

  • B. Murmann 16

Block Diagram

  • Proof of concept design

– Open-loop amplifier only in first, most critical stage

  • Judicious analog/digital co-design

– Only two corretion parameters (linear and cubic amplifier error)

~8400 Gates (0.042mm2 in 0.13µm)

slide-17
SLIDE 17

Digitally Assisted Analog Circuits

  • B. Murmann 17

Linearity Improvement

1000 2000 3000 4000

  • 20
  • 10

10 20 Post-Proc. OFF Post-Proc. ON

Code

slide-18
SLIDE 18

Digitally Assisted Analog Circuits

  • B. Murmann 18

Amplifier Power

10 20 30 40 50 60 Power [mW]

  • 62% (33mW)

Commercial Part (Precision Amplifier) This Work (Simple Amplifier)

slide-19
SLIDE 19

Digitally Assisted Analog Circuits

  • B. Murmann 19

Digital Post-Processor

Area=1.4mm2 (18%) Power=10.5mW (3.6%)

  • 8400 Gates, 64 bytes RAM, 64kBit ROM
  • Place & Route in 0.35µm technology

Pipelined ADC (7.9 mm2)

Post-Processor

10 20 30 40 Amplifier Savings Post- Processor Power [mW]

slide-20
SLIDE 20

Digitally Assisted Analog Circuits

  • B. Murmann 20

Going Beyond a Proof of Concept

  • Proof-of-concept design showed that the

idea of digital assistance works, but power savings were not "revolutionary"

  • As a more aggressive step, it is now

interesting to explore the question: How many "analog" transistors do we really need?

slide-21
SLIDE 21

Digitally Assisted Analog Circuits

  • B. Murmann 21

Minimalistic Pipeline ADC Stage

  • Use a single active device, operated like a charge

pump to implement gain element

  • Highly energy efficient, low noise, …
  • Gain is imprecise and nonlinear, but post-processor

can take care of that

Vin

CL (next stage) Vres 1 1 1 2 CDAC VDAC VREFN,P

slide-22
SLIDE 22

Digitally Assisted Analog Circuits

  • B. Murmann 22

Simulated Energy/Conversion

  • 9-bit, "minimalistic" pipeline ADC prototype in 90nm technology

– Roughly 20,000 gates used for digital post-processing – Only 7pJ per conversion, ~50x below state-of the art

1.E+00 1.E+01 1.E+02 1.E+03 1.E+04 1.E+05 1.E+06 30 40 50 60 70 80 90 100 110 SN(D)R [dB] Energy/Conversion [pJ] Minimalistic Pipeline I SSCC 1998-2005

  • Expon. (I

SSCC 1998-2005)

slide-23
SLIDE 23

Digitally Assisted Analog Circuits

  • B. Murmann 23

Attributes (1)

  • At 10MSamples/s (~video-rate), this ADC consumes
  • nly 70µW
  • Can be powered from a 1cm3 size battery for more

than 1 year!

– A state-of the art ADC will drain the battery within a few days…

slide-24
SLIDE 24

Digitally Assisted Analog Circuits

  • B. Murmann 24

Attributes (2)

  • Energy/conversion is dominated by digital post-

processing

  • Great news!

– Energy efficiency will improve further when design is scaled to 65nm, 45nm, …

29

✪ ✼1 ✪

An

❛ ❧og O ♣er ❛tions ✭2 ♣J ✮ ❉igit ❛ ❧ Post ♣rocessing ✭ ✺ ♣J ✮
slide-25
SLIDE 25

Digitally Assisted Analog Circuits

  • B. Murmann 25

The Calibration Problem

  • The "sloppier" we make the analog portion of the

ADC, the more parameters we need to estimate and track

– Can become quite complex or even impossible without disturbing normal ADC operation

  • Idea: "System Embedded" postprocessing and

calibration of ADC

– Leverage redundancy and knowledge of certain input signal properties to estimate ADC errors – Re-use existing system resources for ADC calibration

  • Example: ADC for OFDM receivers
slide-26
SLIDE 26

Digitally Assisted Analog Circuits

  • B. Murmann 26

Embedded ADC Calibration for OFDM

  • Communications protocol uses "pilot tones" to

measure and equalize RF channel nonidealities

  • Why not use these pilots to "equalize" ADC?

– Errors in pilot signals can be used to estimate correction parameters for sloppy ADC

IFFT

DAC

FFT

f pilot f pilot ADC

Channel

DSP error

slide-27
SLIDE 27

Digitally Assisted Analog Circuits

  • B. Murmann 27

Typical Learning Curve

~100ms

slide-28
SLIDE 28

Digitally Assisted Analog Circuits

  • B. Murmann 28

Conclusions (1)

  • Analog circuit improvements lag progress of digital

functions

– Technology scaling only conditionally benefits analog circuit performance

  • Digitally assisted analog circuits offload accuracy

constraints to digital processor

  • ADCs are obvious candidates for "digital assistance"

– The benefits of digital pre/postprocessing are also being investigated for several other analog circuit blocks

  • Signal pre-distortion in RF power amplifiers
  • Signal pre-distortion in DACs
  • High-speed wireline interfaces
slide-29
SLIDE 29

Digitally Assisted Analog Circuits

  • B. Murmann 29

Conclusions (2)

  • Key benefits

– Lower power and potentially higher speed

  • Up to 100x reduction in ADC energy/conversion

– Digitally assisted ADCs will benefit from future technology scaling

  • "Sloppy" circuits will be compatible with low voltage, low gain,

ultimately scaled CMOS

  • Key challenges

– Interdisciplinary nature of design problem

  • Device modeling, circuit design
  • Math, signal processing algorithms
  • Inclusion of application layer

– Design complexity and turnaround time
