Solving the 4-Year Flicker Problem Using PQube 3 Analog Channels as a Troubleshooting Tool Bruce Lonie PSL European Channel Partner Symposium Prague, Czech Republic June 7-9 2018 05/06/2018 Q 1 The Home of the Flicker Problem

slide-1
SLIDE 1

Solving the 4-Year Flicker Problem

Using PQube 3 Analog Channels as a Troubleshooting Tool

Bruce Lonie

PSL European Channel Partner Symposium

Prague, Czech Republic June 7-9 2018

05/06/2018 Q 1

slide-2
SLIDE 2

The “Home” of the Flicker Problem

05/06/2018 2

slide-3
SLIDE 3

Single Line of Electrical Distribution

05/06/2018 3

slide-4
SLIDE 4

PQube 3 Monitor Locations

3 each PQube 3 Pass-Thru / Residential Units / Voltage Only 2 each PQube 3 Rugged / Basement Electrical Room / V, I & Analog

05/06/2018 4

slide-5
SLIDE 5

Basement Electrical Room

05/06/2018 5

slide-6
SLIDE 6

PQube 3 / Pass-Thru & Rugged

Pass-Thru Rugged

05/06/2018 6

slide-7
SLIDE 7

PQube 3 Rugged’s Connected to Residential Metering Bay

05/06/2018 7

slide-8
SLIDE 8

Why PQube 3?

  • PQube 3’s equipped with cellular modems.
  • Automatic reporting
  • Data ready to view (gif files)

– Even non-technical individuals can understand the graphics.

  • No site visit required to gather recorded data
  • Daily / weekly / monthly trend information easily understood
  • Event detail as it occurs
  • PQube 3 can be reconfigured remotely

05/06/2018 8

slide-9
SLIDE 9

PQube 3 Pass-Thru Flicker Event

Residential Unit PQube 3 Pass-Thru

05/06/2018 9

slide-10
SLIDE 10

Unit 2H Flicker Trends

Daily Flicker Trend Weekly Flicker Trend

05/06/2018 10

slide-11
SLIDE 11

Unit 2H Flicker Event

Event RMS Plots Event Waveform Detail

05/06/2018 11

slide-12
SLIDE 12

Flicker Event Waveform Analysis

  • L-L voltage no

amplitude change

  • L-N voltage variations
  • N-E voltage variations

follow L-N variations

  • N-E voltage

adds/subtracts from L-N voltage amplitude

  • No corresponding

current changes

05/06/2018 12

slide-13
SLIDE 13

PQube Rugged in Basement on Residential Metering Bay Supply

  • L-L & L-N voltage

show no amplitude change.

  • PQ3R connected on

line side of loose connection.

  • AN1-2 left side of bus

splice.

  • AN3-4 right side of

bus splice.

05/06/2018 13

slide-14
SLIDE 14

Basement Electrical Room

05/06/2018 14

slide-15
SLIDE 15

PQube 3 Rugged AN1-2 & AN3-4

05/06/2018 15

slide-16
SLIDE 16

PQ3R Final Analog Channel Configuration

05/06/2018 16

slide-17
SLIDE 17

Bus Splice Showing Loose Connections at “C” (green)

05/06/2018 17

slide-18
SLIDE 18

Bus Splice Termination Lug

05/06/2018 18

slide-19
SLIDE 19

Using Analog Channels to Find Loose Connections / 1

05/06/2018 19

slide-20
SLIDE 20

Using Analog Channels to Find Loose Connections / 2

05/06/2018 20

slide-21
SLIDE 21

PQube 3 Rugged – new

  • pportunities
  • Portable 3-phase

– 8 current channels

  • Flexi or Split-Core

– 2 Environmental Sensors – Analog & Digital channels – Cellular modem – Outdoor rated

  • Unlimited Possibilities!

05/06/2018 21

slide-22
SLIDE 22

PQube 3 Rugged (PQ3R)

05/06/2018 22

slide-23
SLIDE 23

PQube 3 Pass-Thru (PQ3PT)

05/06/2018 23

slide-24
SLIDE 24

Lonie’s Laws of PQ Problem Solving

  • (1 of 2)

1. Do the simple things first. 2. There is always more than one problem. There are always more than one or two problems, keep looking and you will find them. 3. The problem investigation is like peeling the layers of an

  • nion. When you peel away the last layer the onion is

gone…and so is the problem. 4. Fix the problems as you find them…if you can. 5. The customer (aka client) NEVER tells you the whole

  • story. Every time you talk with them you learn another nugget
  • f knowledge.

6. Never believe someone else's measurements or test

  • results. Worst case, you verify the readings and test results

are correct.

05/06/2018 24

slide-25
SLIDE 25

Lonie’s Laws of PQ Problem Solving

  • (2 of 2)

7. Be nice to everyone, you never know who will provide you with an important clue. 8. If it is happening in the electrical environment you can figure

  • ut a way to measure it.

9. Substitute technology (multiple monitors) for time…it speeds up the investigative process and provides more and better quality data for analysis. Labor (time) is the most expensive cost component of an investigation, equipment (technology) is relatively inexpensive. Use equipment with remote communications capabilities to save labor.

  • 10. You are NOT allowed to repeal any of the basic laws of

physics.

  • 11. Ohm’s Law and Kirchhoff’s Law solve most problems...use

them wisely.

05/06/2018 25

slide-26
SLIDE 26

When Working in the Field…Keep it Simple & Keep it Safe!

05/06/2018 26
