Dielectric tuning of cavities D. Bowring 3rd Workshop on Cavities and Detectors for Axion Research August 21, 2018 On behalf of T. Connolly, M. Kang, M. Ortega, S. Priya, C. Salemi, M. Silezin, A. Sonnenschein, and A. Tollestrup. Headline: We

slide-1
SLIDE 1

Dielectric tuning of cavities

  • D. Bowring

3rd Workshop on Cavities and Detectors for Axion Research August 21, 2018

On behalf of T. Connolly, M. Kang, M. Ortega, S. Priya, C. Salemi,

  • M. Silezin, A. Sonnenschein, and A. Tollestrup.
slide-2
SLIDE 2

Headline: We can tune a 4.5 GHz cavity by a linewidth using an STO crystal.

2

  • D. Bowring

— Dielectric tuning of cavities

slide-3
SLIDE 3

Before we start, I want to brag about our students.

Chiara Salemi (MIT, Physics) Marlene Ortega (Brown, Physics) Michal Silezin (UIUC, Engineering) and Thomas Connolly (U.Mass-Amherst, Physics)

3

  • D. Bowring

— Dielectric tuning of cavities

slide-4
SLIDE 4

Overview

  • 1. Simultaneous tuning of many cavities is hard.
  • 2. Ferroelectric materials have variable ǫ, depending on

applied voltage.

  • 3. We can tune our prototype cavity via this method.
  • 4. Still some work to be done.

4

  • D. Bowring

— Dielectric tuning of cavities

slide-5
SLIDE 5

Concept: Coarse mechanical tuning + fine tuning via ferroelectrics

Tuning cartoon, showing cavity array, coarse-tuning rod assembly, and fine-tuning ferroelectric material.

5

  • D. Bowring

— Dielectric tuning of cavities

slide-6
SLIDE 6

Strontium titanate (STO) exhibits dǫ/dV = 0.

O.G. Vendik et al., J. Supercond 12, 2 (1999).

◮ tan δ 10−3 for single-crystal STO at 10 GHz ◮ Significant loss introduced w/ electrodes. We see

this too. (More later.)

6

  • D. Bowring

— Dielectric tuning of cavities

slide-7
SLIDE 7

Prior work on 2D resonators

  • S. Priya, M. Kang (Va

Tech)

◮ Prior work on 2D resonators. ◮ Possible to measure ǫ. ◮ Thin film process development

  • ngoing.

7

  • D. Bowring

— Dielectric tuning of cavities

slide-8
SLIDE 8

Prior work on 2D resonators

8

  • D. Bowring

— Dielectric tuning of cavities

slide-9
SLIDE 9

(Relatively) New Prototype Cavity

◮ f010 4.4 GHz for empty

cavity.

◮ Linear rod path; 25 mm

throw; 6.25 mm rod diameter

◮ TM010 mode has ∼300 MHz

  • f “clean” tuning range.

◮ Can be loaded with STO

samples.

9

  • D. Bowring

— Dielectric tuning of cavities

slide-10
SLIDE 10

(Relatively) New Prototype Cavity

10

  • D. Bowring

— Dielectric tuning of cavities

slide-11
SLIDE 11

For this work: remove tuning rod & insert crystal

3D-printed L-bracket + single-crystal STO sample. The tuning rod was not installed during the measurements described here.

11

  • D. Bowring

— Dielectric tuning of cavities

slide-12
SLIDE 12

Progressively lossy interventions

QL f010 at room temp. (GHz) Empty Cavity 11,000 4.36 Uncoated Sample 10,000 4.28 Ti Coated Sample 1,300 4.36 With Electrodes 900 TBD

◮ Currently large systematic errors. We need a screw

torque standard, e.g.

◮ 10x drop in Q when Ti coating applied. ◮ Straightforward explanation (see next slide). ◮ NB: No effort made to optimize cavity Q (polishing,

RF joint design, etc.)

12

  • D. Bowring

— Dielectric tuning of cavities

slide-13
SLIDE 13

Crystal modes hybridize with cavity modes.

◮ Coating w/ metal film turns this into a planar

resonator.

◮ Crystal is 20 x 10 x 0.3 mm (ripe for mode

crowding).

◮ Highlighted mode couples strongly to cavity TM010. ◮ Remediation: spoil crystal mode Qs via thin,

patterned, resistive films.

13

  • D. Bowring

— Dielectric tuning of cavities

slide-14
SLIDE 14

Simulate hybridization & effect on C010.

HFSS simulation. Effect on C010 translated into integration time penalty.

14

  • D. Bowring

— Dielectric tuning of cavities

slide-15
SLIDE 15

We can demonstrate tuning via temperature control.

O.G. Vendik et al., J. Supercond 12, 2 (1999). Cavity loaded with single-crystal STO sample at wall.

15

  • D. Bowring

— Dielectric tuning of cavities

slide-16
SLIDE 16

Qualitatively, simulated and observed mode mixing agree.

∼ 40-50 dB of difference between dark red (high) and green (low).

16

  • D. Bowring

— Dielectric tuning of cavities

slide-17
SLIDE 17

Attach electrodes to Ti-coated crystal, tune with voltage.

17

  • D. Bowring

— Dielectric tuning of cavities

slide-18
SLIDE 18

Q ∼ 900 means the spectrum colorplot is not as clean.

Leakage current 1 µA below 600 V.

18

  • D. Bowring

— Dielectric tuning of cavities

slide-19
SLIDE 19

∆f010 (MHz) vs Voltage

Low-voltage structure probably due to charging. Monotonic above ∼75 V. Approximately one linewidth of voltage-based tuning!

19

  • D. Bowring

— Dielectric tuning of cavities

slide-20
SLIDE 20

Still lots of work to be done, of course.

Bandstop

  • n DC

probe “port”

◮ Bandstop filter reduces coupling

losses by 200x.

◮ Patterned electrodes (c.f. A. Dixit)

reduce crystal/cavity hybridization.

◮ Crystal position/size optimization. ◮ Understanding systematics,

improving DAQ &

  • instrumentation. . .

20

  • D. Bowring

— Dielectric tuning of cavities

slide-21
SLIDE 21

We have a conceptual design that integrates this into a multi-cavity array.

◮ Via Michal Silezin, summer engineering undergrad ◮ Assume a magnet with a 1-meter bore, 50 cm long. ◮ How many 50-mm dia. cavities can we fit in this

space? How should they be tuned? How cooled? What this design is/is not:

◮ This is not an engineering design ready for review. ◮ First-pass attempt to show various subsystems ◮ Hypothetical fridge scaled from ADMX ◮ Much thermal & electrical design work remains.

21

  • D. Bowring

— Dielectric tuning of cavities

slide-22
SLIDE 22

Multi-cavity array: 241 50-mm cavities

22

  • D. Bowring

— Dielectric tuning of cavities

slide-23
SLIDE 23

Multi-cavity array: 241 50-mm cavities

“Honeycomb” closed by lid with holes for tuning rods, cabling.

23

  • D. Bowring

— Dielectric tuning of cavities

slide-24
SLIDE 24

Coarse tuning via simultaneous motion of all rods

Tuning rods move together as part of a single piece.

24

  • D. Bowring

— Dielectric tuning of cavities

slide-25
SLIDE 25

Coarse tuning via simultaneous motion of all rods

Rod assembly moves on linear bearings. One piezo actuator can push the entire rod assembly.

25

  • D. Bowring

— Dielectric tuning of cavities

slide-26
SLIDE 26

Single-cell closeups

26

  • D. Bowring

— Dielectric tuning of cavities

slide-27
SLIDE 27

Each cell can be loaded with a crystal.

http://www.preperm.com sells stock with 2.5 < ǫ/ǫ0 25.

27

  • D. Bowring

— Dielectric tuning of cavities

slide-28
SLIDE 28

Doubling the array preserves L ∼ 5R and maximizes volume.

28

  • D. Bowring

— Dielectric tuning of cavities

slide-29
SLIDE 29

Thermal straps and insulations direct heat flow to correct temp. stages.

29

  • D. Bowring

— Dielectric tuning of cavities

slide-30
SLIDE 30

Thermal straps and insulations direct heat flow to correct temp. stages.

30

  • D. Bowring

— Dielectric tuning of cavities

slide-31
SLIDE 31

Thanks for your attention!
