Crystal Crystal Ci City ty Bl Block ock Plan Plan # #CCBP CCBP-G-1 -G-1 Long Long R Rang ange e Planning Planning C Committee ommittee #2 February 22, 2018 0 Agenda 1 Site Plan: Plaza Existing 4 Site Plan: G1 - Existing 5

slide-1
SLIDE 1

Crystal Crystal Ci City ty Bl Block

  • ck Plan

Plan # #CCBP CCBP-G-1

  • G-1

Long Long R Rang ange e Planning Planning C Committee

  • mmittee

#2

February 22, 2018

slide-2
SLIDE 2

Agenda

1

slide-3
SLIDE 3

4

Site Plan: Plaza – Existing

slide-4
SLIDE 4

5

Site Plan: G1 - Existing

slide-5
SLIDE 5

6

Site Plan: Roof - Proposed

CURRENT 4.1 SUBMISSION

slide-6
SLIDE 6

7

Site Plan: G1 - Proposed

slide-7
SLIDE 7

Renderings

slide-8
SLIDE 8

8

slide-9
SLIDE 9

01_SHADOW STUDIES

LRPC PRESENTATION FEBRUARY 22, 2018 EXISTING BUILDING: 73% SUN EXPOSURE SEPTEMBER 22, 3PM EXISTING + 43 BULK ANGLE: 61% SUN EXPOSURE SEPTEMBER 22, 3PM CURRENT DESIGN: 59% SUN EXPOSURE SEPTEMBER 22, 3PM EXISTING BUILDING: 84% SUN EXPOSURE MAY 22, 3PM EXISTING + 43 BULK ANGLE: 82% SUN EXPOSURE MAY 22, 3PM CURRENT DESIGN: 80% SUN EXPOSURE MAY 22, 3PM

slide-10
SLIDE 10

Sun Exposure Studies - 18th and Crystal Drive

Autumnal Equinox Condition - September 22nd - 3:00 PM Mid- Equinox Condition - May 22nd - 3:00 PM Autumnal Equinox Condition - September 22nd - 3:00 PM Mid-Equinox Condition - May 22nd - 3:00 PM Existing Proposed Existing Proposed

slide-11
SLIDE 11

Metro Market Square Park

slide-12
SLIDE 12

Existing Conditions

PLANTING AREA PLANTING AREA PEDESTRIAN REALM PEDESTRIAN REALM VEHICULAR DRIVE & PARKING GARAGE ENTRY CRYSTAL DRIVE 18TH STREET Existing Vent & Metro Stair Existing Vent Existing Metro Elevator *Not accessible to pedestrians

slide-13
SLIDE 13

Existing Conditions

VEHICULAR DRIVE & PARKING PLANTING AREA PEDESTRIAN REALM PEDESTRIAN REALM PLANTING AREA PLANTING AREA 1 8 T H S T R E E T 1770 CRYSTAL DRIVE CRYSTAL DRIVE Existing Vent & Metro Stair Existing Vent Existing Metro Elevator GARAGE ENTRY *Not accessible to pedestrians

slide-14
SLIDE 14

Design Study Options

slide-15
SLIDE 15

Study Option A | Planted Slope

1 8 T H S T R E E T CRYSTAL DRIVE ADA ACCESSIBLE RAMP Existing Vent PLANTING AREA PEDESTRIAN REALM 30’ 10’ 8.33% ACTIVE OPEN SPACE GARAGE ENTRY New Metro Entry New Metro Elevator Accessible Crosswalk 1770 CRYSTAL DRIVE Existing Metro Elevator *Not accessible to pedestrians *Usable pedestrian access Retail frontage not feasible

slide-16
SLIDE 16

Study Option B | Gradual Staircase

New Metro Entry Accessible Crosswalk ACTIVE OPEN SPACE PLANTING AREA PEDESTRIAN REALM 1 8 T H S T R E E T CRYSTAL DRIVE Retaining Wall ADA Elevator 1770 CRYSTAL DRIVE Existing Vent New Metro Elevator GARAGE ENTRY Existing Metro Elevator *Not accessible to pedestrians

slide-17
SLIDE 17

Study Option C | Retaining Wall & Crystal Drive Retail Opportunity

New Metro Entry Accessible Crosswalk New Metro Elevator Retaining Wall ACTIVE OPEN SPACE ACTIVE OPEN SPACE PLANTING AREA PEDESTRIAN REALM 1 8 T H S T R E E T CRYSTAL DRIVE Retaining Wall ADA Elevator Existing Vent 1770 CRYSTAL DRIVE GARAGE ENTRY A C T I V E R E T A I L Existing Metro Elevator

slide-18
SLIDE 18

Preferred Option | Maximize Usable Urban Open Space

ACTIVE OPEN SPACE PLANTING AREA PEDESTRIAN REALM New Metro Entry Accessible Crosswalk 1 8 T H S T R E E T CRYSTAL DRIVE ACTIVE RETAIL

A C T I V E R E T A I L A C T I V E R E T A I L

1770 CRYSTAL DRIVE GARAGE ENTRY Metro Elevator Existing Metro Elevator

slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22

Public Way Elevator Precedents - Sidewalk Oriented at Face of Building

slide-23
SLIDE 23

Public Way Elevator Precedents - Landscape Oriented

slide-24
SLIDE 24

Perspective from Below

Option A | Planted Slope Option C | Retaining Wall & Crystal Drive Retail Option B | Gradual Stair Preferred Option | Maximize Usable Urban Open Space

slide-25
SLIDE 25

Perspective from Above

Option A | Planted Slope Option C | Retaining Wall & Crystal Drive Retail Option B | Gradual Stair Preferred Option | Maximize Usable Urban Open Space

slide-26
SLIDE 26

Section Studies

slide-27
SLIDE 27

Preferred Option | Metro Market Square Park

PROPOSED CORNER BUILDING

N/S - A N/S - B N/S - C N/S - D E/W

slide-28
SLIDE 28

East/West Section | Existing Conditions

Metro Entry

  • S. Bell St.

Lawn Area Vehicular Drive & Parking Garage Entry Drive Drive Sloped Planting Area Sloped Planting Area Crystal Drive Metro Elevator Sidewalk Sidewalk Sidewalk

slide-29
SLIDE 29

East/West Section | Preferred Option Maximize Usable Urban Open Space

Future 18th Street Park Feature Wall & Stair Crystal Drive Retail Plaza Metro Entry

  • S. Bell St.

Sidewalk Sidewalk Sidewalk

slide-30
SLIDE 30

North/South Section A | Existing Conditions

18th Street Vehicular Drive Planting Parking Planting Area 1770 Crystal Drive Sidewalk

slide-31
SLIDE 31

North/South Section A | Preferred Option Maximize Usable Urban Open Space

18th Street Corner Building Retail Plaza Sidewalk 1770 Crystal Drive

slide-32
SLIDE 32

18th Street Sidewalk Sloped Planting Parking Parking Vehicular Drive 241 18th St. Sidewalk

North/South Section C | Existing Conditions

slide-33
SLIDE 33

North/South Section C | Proposed Condition

18th Street Sidewalk Sloped Planting and Garden Walks Future 18th Street Park 241 18th St.

slide-34
SLIDE 34

Connection to Center Park

slide-35
SLIDE 35

CONNECTION TO CENTER PARK

CENTER PARK (EXISTING)

DROP-OFF BIKE LANE

EXISTING WALL 251 18TH STREET 241 18TH STREET

slide-36
SLIDE 36

Hardscape / Softscape | Existing vs. Proposed Existing Proposed

Corner Building

Total Landscape ( Turf, Planting ) Hardscape ( Paved Surface ) Total Landscape ( Turf, Planting , DG) Hardscape ( Paved Surface ) Building Footprint ( + Greenroof ) Usable Open Space Usable Open Space 68,260 sqft 27,420 sqft 40,840 sqft 68,260 sqft 29,470 sqft 28,260 sqft 10,530 sqft 20,500 sqft 57,730 sqft

slide-37
SLIDE 37
