Computational Studies About Stabilization in Column Generation

Antonio Frangioni 1 Hatem M.T. Ben Amor 2 Jacques Desrosiers 3

1Dipartimento di Informatica, Universit`

a di Pisa

2Ad-Opt Division, Kronos Canadian Systems 3HEC Montr´

eal

Column Generation 2008 Aussois, June 18, 2008

Outline

1

Column Generation

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 2 / 44

Outline

1

Column Generation

2

Stabilized Column Generation

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 2 / 44

Outline

1

Column Generation

2

Stabilized Column Generation

3

Computational results I: it works

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 2 / 44

Outline

1

Column Generation

2

Stabilized Column Generation

3

Computational results I: it works

4

Computational results II: choosing the stabilization

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 2 / 44

Outline

1

Column Generation

2

Stabilized Column Generation

3

Computational results I: it works

4

Computational results II: choosing the stabilization

5

Conclusions

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 2 / 44

Column Generation

A set of columns, a ∈ A ⊂ Rm, ca ∈ R, b ∈ Rm Large-scale primal and dual problems: (P) max

• a∈A caxa
• a∈A axa

= b xa ≥ 0 a ∈ A (D) min πb πa ≥ ca a ∈ A A too large: impossible (or impractical) to solve at once

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 3 / 44

Column Generation

A set of columns, a ∈ A ⊂ Rm, ca ∈ R, b ∈ Rm Large-scale primal and dual problems: (P) max

• a∈A caxa
• a∈A axa

= b xa ≥ 0 a ∈ A (D) min πb πa ≥ ca a ∈ A A too large: impossible (or impractical) to solve at once Column Generation (CG): select B ⊆ A, solve Master problems (PB) max

• a∈B caxa
• a∈B axa

= b xa ≥ 0 a ∈ B (DB) min πb πa ≥ ca a ∈ B ⇒ primal feasible x∗ and dual unfeasible π∗

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 3 / 44

Column Generation (2)

Then solve pricing (or separation) problem (Pπ∗) max{ ca − π∗a : a ∈ A } for some a ∈ A/B or optimality certificate π∗a ≥ ca ∀a ∈ A

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 4 / 44

Column Generation (2)

Then solve pricing (or separation) problem (Pπ∗) max{ ca − π∗a : a ∈ A } for some a ∈ A/B or optimality certificate π∗a ≥ ca ∀a ∈ A Very simple idea, very simple implementation (in principle)

Master Problem π* a Subproblem

. . . yet surprisingly effective in many applications . . . provided that (Pπ∗) can be efficiently solved

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 4 / 44

Column Generation (2)

Then solve pricing (or separation) problem (Pπ∗) max{ ca − π∗a : a ∈ A } for some a ∈ A/B or optimality certificate π∗a ≥ ca ∀a ∈ A Very simple idea, very simple implementation (in principle)

Master Problem π* a Subproblem

. . . yet surprisingly effective in many applications . . . provided that (Pπ∗) can be efficiently solved x∗ feasible ⇒ lower bound, but π∗ unfeasible ⇒ no upper bound

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 4 / 44

Structure in Column Generation

In many cases convexity constraint

a∈A xa = 1 ⇒

(D) min η + πb η ≥ ca − πa a ∈ A ⇒ min πb + φ(π)

• max{ ca − πa : a ∈ A }

φ convex, nondifferentiable (polyhedral)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 5 / 44

Structure in Column Generation

In many cases convexity constraint

a∈A xa = 1 ⇒

(D) min η + πb η ≥ ca − πa a ∈ A ⇒ min πb + φ(π)

• max{ ca − πa : a ∈ A }

φ convex, nondifferentiable (polyhedral) (DB) ⇒ φB(π) = max{ ca − πa : a ∈ B } (cutting plane model of φ) Each φ(π) provides a valid (Lagrangian) upper bound

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 5 / 44

Structure in Column Generation

In many cases convexity constraint

a∈A xa = 1 ⇒

(D) min η + πb η ≥ ca − πa a ∈ A ⇒ min πb + φ(π)

• max{ ca − πa : a ∈ A }

φ convex, nondifferentiable (polyhedral) (DB) ⇒ φB(π) = max{ ca − πa : a ∈ B } (cutting plane model of φ) Each φ(π) provides a valid (Lagrangian) upper bound General case: k disjoint convexity constraints, A = A0 ∪A1 ∪. . . ∪Ak min { πb + φ(π) : π ∈ Π } where Π = { π : πa ≥ ca , a ∈ A0 } φ(π) =

h

• φh(π) = max{ ca − πa : a ∈ Ah }
• . . . minimizing convex polyhedral function over convex polyhedral set
• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 5 / 44

Structure in Column Generation (2)

The (dual) Master problem (DB) min

• πb +

h φh B(π) : π ∈ ΠB

• φh

B cutting-plane model of φh

ΠB ⊇ Π outer approximation

1J.E. Kelley “The Cutting-Plane Method for Solving Convex Programs” J. of the SIAM 8, 1960

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 6 / 44

Structure in Column Generation (2)

The (dual) Master problem (DB) min

• πb +

h φh B(π) : π ∈ ΠB

• φh

B cutting-plane model of φh

ΠB ⊇ Π outer approximation

k + 1 pricing problems (sometimes only k)

φh(π∗) give optimality cuts (subgradients of φh) φ0(π∗) gives feasibility cuts (faces of Π)

(sometimes, faces are extreme rays of unbounded pricing problems) Something as old as Kelley’s cutting plane approach1

1J.E. Kelley “The Cutting-Plane Method for Solving Convex Programs” J. of the SIAM 8, 1960

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 6 / 44

Structure in Column Generation (2)

The (dual) Master problem (DB) min

• πb +

h φh B(π) : π ∈ ΠB

• φh

B cutting-plane model of φh

ΠB ⊇ Π outer approximation

k + 1 pricing problems (sometimes only k)

φh(π∗) give optimality cuts (subgradients of φh) φ0(π∗) gives feasibility cuts (faces of Π)

(sometimes, faces are extreme rays of unbounded pricing problems) Something as old as Kelley’s cutting plane approach1 A well-known drawback: instability

1J.E. Kelley “The Cutting-Plane Method for Solving Convex Programs” J. of the SIAM 8, 1960

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 6 / 44

Instability

(PB) empty ≡ (DB) unbounded ⇒ Phase 0 / Phase 1 approach

• 2O. Briant, C. Lemar´

echal, Ph. Meurdesoif, S. Michel, N. Perrot, F. Vanderbeck “Comparison of bundle and classical column generation” Math. Prog. 2006

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 7 / 44

Instability

(PB) empty ≡ (DB) unbounded ⇒ Phase 0 / Phase 1 approach More in general: the sequence {π∗} has no locality properties2

frequent oscillations of dual values

Upper bound (dual) Lower bound (primal)

“bad quality” of generated columns

• 2O. Briant, C. Lemar´

echal, Ph. Meurdesoif, S. Michel, N. Perrot, F. Vanderbeck “Comparison of bundle and classical column generation” Math. Prog. 2006

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 7 / 44

Instability

(PB) empty ≡ (DB) unbounded ⇒ Phase 0 / Phase 1 approach More in general: the sequence {π∗} has no locality properties2

frequent oscillations of dual values

Upper bound (dual) Lower bound (primal)

“bad quality” of generated columns

⇒ tailing off, slow convergence

• 2O. Briant, C. Lemar´

echal, Ph. Meurdesoif, S. Michel, N. Perrot, F. Vanderbeck “Comparison of bundle and classical column generation” Math. Prog. 2006

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 7 / 44

Instability (2)

In other words: a good estimate of dual optimum is useless!

• 3H. Ben Amor, J. Desrosiers, F. Soumis “Recovering an optimal LP basis from an optimal dual solution” O.R. Lett. 2006
• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 8 / 44

Instability (2)

In other words: a good estimate of dual optimum is useless! . . . even a perfect one. Conceptual experiment on (MDVS)3: compute dual optimum, re-solve + dual box constraint of given width cpu(s) CG iter. SP cols. MP itrs. width % % % % ∞ 4178.4 509 37579 926161 200.0 835.5 20.0 119 23.4 9368 24.9 279155 30.1 20.0 117.9 2.8 35 6.9 2789 7.4 40599 4.4 2.0 52.0 1.2 20 3.9 1430 3.8 8744 0.9 0.2 47.5 1.1 19 3.7 1333 3.5 8630 0.9 Convergence speed does not improve near the optimum

• 3H. Ben Amor, J. Desrosiers, F. Soumis “Recovering an optimal LP basis from an optimal dual solution” O.R. Lett. 2006
• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 8 / 44

Instability (2)

In other words: a good estimate of dual optimum is useless! . . . even a perfect one. Conceptual experiment on (MDVS)3: compute dual optimum, re-solve + dual box constraint of given width cpu(s) CG iter. SP cols. MP itrs. width % % % % ∞ 4178.4 509 37579 926161 200.0 835.5 20.0 119 23.4 9368 24.9 279155 30.1 20.0 117.9 2.8 35 6.9 2789 7.4 40599 4.4 2.0 52.0 1.2 20 3.9 1430 3.8 8744 0.9 0.2 47.5 1.1 19 3.7 1333 3.5 8630 0.9 Convergence speed does not improve near the optimum Stabilization is useful

• 3H. Ben Amor, J. Desrosiers, F. Soumis “Recovering an optimal LP basis from an optimal dual solution” O.R. Lett. 2006
• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 8 / 44

1

Column Generation

2

Stabilized Column Generation

3

Computational results I: it works

4

Computational results II: choosing the stabilization

5

Conclusions

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 9 / 44

Stabilized Column Generation

CG ≡ CP algorithm ⇒ stabilization ≡ (generalized) bundle methods

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 10 / 44

Stabilized Column Generation

CG ≡ CP algorithm ⇒ stabilization ≡ (generalized) bundle methods Current center ¯ π, stabilizing term D : Rm → R ∪ {+∞}

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 10 / 44

Stabilized Column Generation

CG ≡ CP algorithm ⇒ stabilization ≡ (generalized) bundle methods Current center ¯ π, stabilizing term D : Rm → R ∪ {+∞} Stabilized dual master problem (DB,¯

π,D)

min{ φB(π) + D(π − ¯ π) : π ∈ ΠB }

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 10 / 44

Stabilized Column Generation

CG ≡ CP algorithm ⇒ stabilization ≡ (generalized) bundle methods Current center ¯ π, stabilizing term D : Rm → R ∪ {+∞} Stabilized dual master problem (DB,¯

π,D)

min{ φB(π) + D(π − ¯ π) : π ∈ ΠB }

φ

B

π π∗ φ

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 10 / 44

Stabilized Column Generation: Primal View

Stabilized primal master problem (k = 1) (PB,¯

π,D)

max

• a∈B caxa + ¯

π

• b −

a∈B axa

• − D∗

a∈B axa − b

• a∈B1 xa = 1

, xa ≥ 0 a ∈ B a (possibly nonquadratic) augmented Lagrangian of (PB)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 11 / 44

Stabilized Column Generation: Primal View

Stabilized primal master problem (k = 1) (PB,¯

π,D)

max

• a∈B caxa + ¯

π

• b −

a∈B axa

• − D∗

a∈B axa − b

• a∈B1 xa = 1

, xa ≥ 0 a ∈ B a (possibly nonquadratic) augmented Lagrangian of (PB) ¯ π = “first-order” Lagrangian term D∗ = Fenchel’s conjugate of D = “second-order” term A “distance-like” function with a (hard to tune) proximity weight 1 2t · 2

2

∗ = 1 2t · 2

2

• IB∞(t)

∗ = t · 1 1 t · 1 ∗ = IB∞(1/t)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 11 / 44

Stabilized Column Generation Algorithm

Initialize ¯ π and D solve P¯

π, initialize B with the resulting columns

repeat solve (DB,¯

π,D)/(PB,¯ π,D) for π∗ and x∗

if(

a∈B cax∗ a ≈ φ(¯

π) and

a∈B ax∗ a ≈ b )

then stop else solve Pπ∗, i.e., compute φ(π∗) possibly add some of the resulting columns to B possibly remove columns from B if( φ(π∗) is “substantially lower” than φ(¯ π) ) then ¯ π = π∗ /* Serious Step */ possibly update D while( not stop ) Generic SCG algorithm, allowing many variants General and flexible convergence theory

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 12 / 44

Convergence of Stabilized Column Generation

Conditions for convergence (not the most general ones)4:

i) D ≥ 0 convex, D(0) = 0, Sδ(D) compact and full-dimensional ∀δ > 0 (these hold for D if and only if they hold for D∗) ii) D differentiable in 0 ⇐ ⇒ D∗ strictly convex in 0 iii) D is “steep enough” ⇒ (DB,¯

π,D) is always bounded

iv) for some m ∈ (0, 1], φ(π∗) is “substantially lower” than φ(¯ π) if φ(π∗) − φ(¯ π) ≤ m( v(DB,¯

π,D) − φ(¯

π) ) but SS can be postponed finitely many times, e.g. to “flatten” D v) in a sequence of consecutive NS, D changes finitely many times vi) D ≤ ¯ D for some ¯ D as in i) vii) no two removals from B unless v(DB,¯

π,D) increases by ε > 0

Ensures finite termination If D∗ differentiable |B| can be kept bounded by aggregation Allows many variants (linesearch, scatter search, curved search . . . )

• 4F. “Generalized Bundle Methods”, SIOPT, 2002
• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 13 / 44

The Proximal Point Case

No convexity constraint ⇒ only feasibility cuts ⇒ no upper bound . . . until “full” stabilized primal and dual problems solved (P¯

π,D)

max

• a∈A caxa + ¯

π

• b −

a∈A axa

• − D∗

a∈A axa − b

• xa ≥ 0

, a ∈ A (D¯

π,D)

min

• φ(π) + D(π − ¯

π) : π ∈ Π

• nly at this point ¯

π can be updated Something as old as a (nonquadratic5) Proximal Point approach6

• 5M. Teboulle “Convergence of Proximal-like Algorithms” SIAM J. on Opt. 7, 1997

6R.T. Rockafellar “Monotone Operators and the Proximal Point Algorithm” SIAM J. on Contr. and Opt., 1976

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 14 / 44

The Proximal Point Case

No convexity constraint ⇒ only feasibility cuts ⇒ no upper bound . . . until “full” stabilized primal and dual problems solved (P¯

π,D)

max

• a∈A caxa + ¯

π

• b −

a∈A axa

• − D∗

a∈A axa − b

• xa ≥ 0

, a ∈ A (D¯

π,D)

min

• φ(π) + D(π − ¯

π) : π ∈ Π

• nly at this point ¯

π can be updated Something as old as a (nonquadratic5) Proximal Point approach6 Large effort to solve (D¯

π,D) to optimality even for “bad” ¯

π SCG = Bundle method = proximal point with early stop rule Bundle method + m = 1 ⇒ proximal point method Introduce “artificial” convexity constraints if possible

• 5M. Teboulle “Convergence of Proximal-like Algorithms” SIAM J. on Opt. 7, 1997

6R.T. Rockafellar “Monotone Operators and the Proximal Point Algorithm” SIAM J. on Contr. and Opt., 1976

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 14 / 44

Choosing the Stabilizing Term

Reasonable choices: piecewise-linear functions ⇒ (PB,¯

π,D) is a LP

Something as old as the BoxStep method7 (D¯

π,M)

min

• φ(π) : π − ¯

π ≤ M , π ∈ Π

• 7R.E. Marsten, W.W. Hogan, J.W. Blankenship “The BOXSTEP Method for Large-scale Optimization” Op. Res. 1975
• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 15 / 44

Choosing the Stabilizing Term

Reasonable choices: piecewise-linear functions ⇒ (PB,¯

π,D) is a LP

Something as old as the BoxStep method7 (D¯

π,M)

min

• φ(π) : π − ¯

π ≤ M , π ∈ Π

• The stabilizing term must:

have at least one parameter controlling the stabilization make (PB,¯

π,D)/(DB,¯ π,D) easy to solve

provide a good rate of convergence in practice

7R.E. Marsten, W.W. Hogan, J.W. Blankenship “The BOXSTEP Method for Large-scale Optimization” Op. Res. 1975

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 15 / 44

Choosing the Stabilizing Term

Reasonable choices: piecewise-linear functions ⇒ (PB,¯

π,D) is a LP

Something as old as the BoxStep method7 (D¯

π,M)

min

• φ(π) : π − ¯

π ≤ M , π ∈ Π

• The stabilizing term must:

have at least one parameter controlling the stabilization make (PB,¯

π,D)/(DB,¯ π,D) easy to solve

provide a good rate of convergence in practice

Balancing master problem cost vs convergence speed is nontrivial:

master problem cost is often, but not always, predominant less iterations ⇒ smaller B ⇒ more efficient

7R.E. Marsten, W.W. Hogan, J.W. Blankenship “The BOXSTEP Method for Large-scale Optimization” Op. Res. 1975

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 15 / 44

Choosing the Stabilizing Term

Reasonable choices: piecewise-linear functions ⇒ (PB,¯

π,D) is a LP

Something as old as the BoxStep method7 (D¯

π,M)

min

• φ(π) : π − ¯

π ≤ M , π ∈ Π

• The stabilizing term must:

have at least one parameter controlling the stabilization make (PB,¯

π,D)/(DB,¯ π,D) easy to solve

provide a good rate of convergence in practice

Balancing master problem cost vs convergence speed is nontrivial:

master problem cost is often, but not always, predominant less iterations ⇒ smaller B ⇒ more efficient

Does BoxStep achieve all this? Not quite

7R.E. Marsten, W.W. Hogan, J.W. Blankenship “The BOXSTEP Method for Large-scale Optimization” Op. Res. 1975

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 15 / 44

Choosing the (Right) Stabilizing Term

Why BoxStep fails? Scylla / Charybdis situation (a.k.a. Catch 22):

M small ⇒ π∗

i = ¯

πi ± M, small and independent on problem’s data M large ⇒ no stabilization

• 8S. Kim, K.N. Chang, J.Y. Lee “A Descent Method with L.P. Subproblems for Nondiff. Convex Opt.” Math. Prog. 1995
• 9O. du Merle, D. Villeneuve, J. Desrosiers, P. Hansen “Stabilized Column Generation” Disc. Math. 1999
• 10C. Lemar´

echal “Bundle Methods in Nonsmooth Optimization” in Nonsmooth Optimization, 1978 11M.C. Pinar, S.A. Zenios “On Smoothing Exact Penalty Functions for Convex Constrained Optimization” SIOPT, 1994 12M.D. Grigoriadis, L.G. Kahchiyan “An exponential-function reduction method for block-angular convex programs” Networks, 1995

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 16 / 44

Choosing the (Right) Stabilizing Term

Why BoxStep fails? Scylla / Charybdis situation (a.k.a. Catch 22):

M small ⇒ π∗

i = ¯

πi ± M, small and independent on problem’s data M large ⇒ no stabilization

The theory allows a lot, in particular mixing penalty with trust region

• 8S. Kim, K.N. Chang, J.Y. Lee “A Descent Method with L.P. Subproblems for Nondiff. Convex Opt.” Math. Prog. 1995
• 9O. du Merle, D. Villeneuve, J. Desrosiers, P. Hansen “Stabilized Column Generation” Disc. Math. 1999
• 10C. Lemar´

echal “Bundle Methods in Nonsmooth Optimization” in Nonsmooth Optimization, 1978 11M.C. Pinar, S.A. Zenios “On Smoothing Exact Penalty Functions for Convex Constrained Optimization” SIOPT, 1994 12M.D. Grigoriadis, L.G. Kahchiyan “An exponential-function reduction method for block-angular convex programs” Networks, 1995

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 16 / 44

Choosing the (Right) Stabilizing Term

Why BoxStep fails? Scylla / Charybdis situation (a.k.a. Catch 22):

M small ⇒ π∗

i = ¯

πi ± M, small and independent on problem’s data M large ⇒ no stabilization

The theory allows a lot, in particular mixing penalty with trust region Thus, increase the number of pieces. But how many?

Two8? (too few) Three9? (still too few) Infinitely many10,2? (perhaps too many?)

Piecewise-quadratic11 or exponential12 also possible (but why?)

• 8S. Kim, K.N. Chang, J.Y. Lee “A Descent Method with L.P. Subproblems for Nondiff. Convex Opt.” Math. Prog. 1995
• 9O. du Merle, D. Villeneuve, J. Desrosiers, P. Hansen “Stabilized Column Generation” Disc. Math. 1999
• 10C. Lemar´

echal “Bundle Methods in Nonsmooth Optimization” in Nonsmooth Optimization, 1978 11M.C. Pinar, S.A. Zenios “On Smoothing Exact Penalty Functions for Convex Constrained Optimization” SIOPT, 1994 12M.D. Grigoriadis, L.G. Kahchiyan “An exponential-function reduction method for block-angular convex programs” Networks, 1995

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 16 / 44

A 5-piecewise-linear Function

D(u) = m

i=1 Di(ui) where

Di(ui) =            −(ζ−

i + ε− i ) (ui + Γ− i ) − ζ− i ∆− i

−∞ ≤ ui ≤ −Γ−

i − ∆− i

−ε−

i ( ui − ∆− i )

−Γ−

i − ∆− i ≤ ui ≤ −∆− i

−∆−

i ≤ ui ≤ ∆+ i

+ε+

i ( ui − ∆+ i )

∆+

i ≤ ui ≤ ∆+ i + Γ+ i

+(ε+

i + ζ+ i ) (ui − Γ+ i ) − ζ+ i ∆+ i

∆+

i + Γ+ i ≤ ui ≤ +∞

∆i

+

∆i

• Γi
• Γi

+

εi

+

ζi

+

εi- ζi

• π

Trust region on ¯ π + small penalty close + much larger penalty far

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 17 / 44

Why A 5-piecewise-linear Function

Many parameters: interval widths Γ±/∆±, penalty costs ζ±/ε±

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 18 / 44

Why A 5-piecewise-linear Function

Many parameters: interval widths Γ±/∆±, penalty costs ζ±/ε± Different roles for small and large penalty costs:

large penalties ζ± to make (DB,¯

π,D) bounded ⇒ no Phase 0

small penalties ε± take into account problem’s data

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 18 / 44

Why A 5-piecewise-linear Function

Many parameters: interval widths Γ±/∆±, penalty costs ζ±/ε± Different roles for small and large penalty costs:

large penalties ζ± to make (DB,¯

π,D) bounded ⇒ no Phase 0

small penalties ε± take into account problem’s data

Its Fenchel’s conjugate: D∗(y) = m

i=1 D∗ i (yi) where

D∗

i (yi) =

               +∞ yi < −(ζ−

i + ε− i )

−(Γ−

i + ∆− i ) yi − Γ− i ε− i

−ζ−

i − ε− i ≤ yi ≤ −ε− i

−∆−

i

yi −ε−

i ≤ yi ≤ 0

+∆+

i

yi 0 ≤ yi ≤ ε−

i

+(Γ+

i + ∆+ i ) yi − Γ+ i ε+ i

ε+

i ≤ yi ≤ (ζ+ i + ε+ i )

+∞ yi > (ζ+

i + ε+ i )

4-piecewise-linear, outer box [−(Γ−

i + ∆− i ), −(Γ− i + ∆− i )],

interval widths ⇐ ⇒ penalties

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 18 / 44

The Corresponding Master Problems

Notation: γ± = ¯ π ± ∆± ± Γ±, δ± = ¯ π ± ∆±

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 19 / 44

The Corresponding Master Problems

Notation: γ± = ¯ π ± ∆± ± Γ±, δ± = ¯ π ± ∆± Stabilized dual master problem (case A = A0): (DB,¯

π,D)

min πb + ζ−v − + ε−u− + ε+u+ + ζ+v + −u− + δ− ≤ π ≤ δ+ + u+ −v − + γ− ≤ π ≤ γ+ + v + πa ≤ ca , a ∈ B v −, u−, u+, v + ≥ 0

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 19 / 44

The Corresponding Master Problems

Notation: γ± = ¯ π ± ∆± ± Γ±, δ± = ¯ π ± ∆± Stabilized dual master problem (case A = A0): (DB,¯

π,D)

min πb + ζ−v − + ε−u− + ε+u+ + ζ+v + −u− + δ− ≤ π ≤ δ+ + u+ −v − + γ− ≤ π ≤ γ+ + v + πa ≤ ca , a ∈ B v −, u−, u+, v + ≥ 0 Stabilized primal master problem: (PB,¯

π,D)

max

• a∈B caxa + γ−z− + δ−y − − δ+y + − γ+z+
• a∈B axa + z− + y − − y + − z+ = b

z− ≤ ζ− , y − ≤ ε− , y + ≤ ε+ , z+ ≤ ζ+ z−, y −, y +, z+ ≥ 0 xa ≥ 0 a ∈ B as many constraints as (PB), 4 variables for each stabilized constraint

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 19 / 44

A 5-to-3-pieces Variant

Large penalties inactive near optimum ⇒ dynamic 5-to-3-pieces CG PP-5 5-3 CG PP-5 5-3 CG PP-5 5-3 p1 p3 p5 time(s) 204 43 37 285 45 49 3562 306 256 mp(s) 126 14 12 181 20 18 2676 142 114 itr 149 52 48 196 53 58 422 80 72 p6 p7 p8 time(s) 4178 596 501 2883 1224 1068 1429 837 757 mp(s) 3149 216 166 1641 611 593 779 480 272 itr 509 196 160 380 178 145 259 145 134

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 20 / 44

A 5-to-3-pieces Variant

Large penalties inactive near optimum ⇒ dynamic 5-to-3-pieces CG PP-5 5-3 CG PP-5 5-3 CG PP-5 5-3 p1 p3 p5 time(s) 204 43 37 285 45 49 3562 306 256 mp(s) 126 14 12 181 20 18 2676 142 114 itr 149 52 48 196 53 58 422 80 72 p6 p7 p8 time(s) 4178 596 501 2883 1224 1068 1429 837 757 mp(s) 3149 216 166 1641 611 593 779 480 272 itr 509 196 160 380 178 145 259 145 134 Master problem cost decreases, iterations count does not increase Pure Proximal test, but extends to Bundle Per-constraint parameter handling (flexibility but complexity)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 20 / 44

1

Column Generation

2

Stabilized Column Generation

3

Computational results I: it works

4

Computational results II: choosing the stabilization

5

Conclusions

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 21 / 44

Computational results: MDVS

Multiple-Depot Vehicle Scheduling:

two-components route costs: fixed vehicle cost + arc costs number of tasks m ∈ {400, 800, 1000, 1200} type T ∈ {A, B} (location of depots) number of depots d ∈ {4, 5}

m + d constraints in the master problem, d subproblems Initialization by MCF ⇒ initial solution and good initial ¯ π High fixed cost + initial solution ⇒ “artificial” convexity constraint p1 p2 p3 p4 p5 p6 p7 p8 p9 p10 T A A B B A B A B A B m 400 400 400 400 800 800 1000 1000 1200 1200 d 4 4 4 4 4 4 5 5 4 4 Arcs 2.1e5 2.1e5 2.1e5 2.0e5 7.9e5 8.2e5 1.3e6 9.7e5 1.5e6 1.1e6

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 22 / 44

Computational results: MDVS (2)

p1 p2 p3 p4 p5 p6 p7 p8 p9 p10 cpu CG 139 177 235 159 3138 3966 3704 1742 3685 3065 PP 31 36 38 28 482 335 946 572 1065 2037 BM 26 28 35 21 295 257 639 352 545 1505 mp CG 88 125 165 105 1679 2004 1955 925 1984 1743 PP 13 16 17 10 189 128 428 257 542 1326 BM 10 14 15 10 100 70 329 206 334 983 itr CG 117 149 200 165 408 524 296 186 246 247 PP 47 47 49 45 93 64 98 83 86 150 BM 37 43 44 36 57 53 59 49 51 101 both PP and BM improve upon CG both in iterations count and time BM better that PP on large instances where initial ¯ π is worse master problem time for BM slightly larger (more SSs)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 23 / 44

Computational results: VCS

Simultaneous Vehicle & Crew Scheduling: cover trips → segments → duties (with deadheading), set departure times from parkings

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 24 / 44

Computational results: VCS

Simultaneous Vehicle & Crew Scheduling: cover trips → segments → duties (with deadheading), set departure times from parkings Subproblems:

constrained shortest paths with up to 7 resources ⇒ expensive, or many subnetworks (one for each departure time) ⇒ less resources

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 24 / 44

Computational results: VCS

Simultaneous Vehicle & Crew Scheduling: cover trips → segments → duties (with deadheading), set departure times from parkings Subproblems:

constrained shortest paths with up to 7 resources ⇒ expensive, or many subnetworks (one for each departure time) ⇒ less resources

Solve only a small subset (10-20) of networks at all iterations . . . . . . but the last one for proving optimality

Problem

Cov Flow Net Nodes Arcs p199 199 897 822 1528 3653 p204 204 919 829 1577 3839 p206 206 928 835 1569 3861 p262 262 1180 973 1908 4980 p315 315 1419 1039 2180 6492 p344 344 1549 1090 2335 7210 p463 463 2084 1238 2887 9965

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 24 / 44

Computational results: VCS (2)

p199 p204 p206 p262 p315 p344 p463 cpu(min) CG 26 26 30 68 142 238 662 BM 12 13 14 40 73 163 511 mp(min) CG 13 9 14 35 43 90 273 BM 3 3 4 7 19 20 93 sp(min) CG 13 17 16 33 99 148 389 BM 9 10 10 33 54 143 418 itr CG 167 129 245 263 239 303 382 BM 116 119 173 160 213 201 333 Pure Proximal worse than CG: proving optimality too many times Bundle Method improves upon CG both in iterations and time . . . even if subproblem time sometimes increases “rough” BM with no “flattening” ever of D

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 25 / 44

1

Column Generation

2

Stabilized Column Generation

3

Computational results I: it works

4

Computational results II: choosing the stabilization

5

Conclusions

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 26 / 44

Guidelines for Choosing the Stabilizing Term

Study the (combined) impact of three factors:

“shape” of the stabilizing term “steepness” of the stabilizing term quality of initial dual estimate

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 27 / 44

Guidelines for Choosing the Stabilizing Term

Study the (combined) impact of three factors:

“shape” of the stabilizing term “steepness” of the stabilizing term quality of initial dual estimate

As few parameters as possible (symmetric, uniform, normalized):

Quadratic ST (Q): t = 10j for j ∈ T = {7, 5, 3, 2, 1} Boxstep ST (1P): ∆ ∈ {1000, 500, 100, 10, 1} 3-pieces ST (3P): ∆, tε = 2∆ (tangent to Q) 5-pieces linear ST (5P): for each (∆, ε) in 3P, two sub-intervals of width ∆/2, slopes 1 and ε − 1.0 (outer, inner)

5 Q, 5 1P algorithms, ≤ 25 3P and 5P (“useless” variants removed)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 27 / 44

Guidelines for Choosing the Stabilizing Term

Study the (combined) impact of three factors:

“shape” of the stabilizing term “steepness” of the stabilizing term quality of initial dual estimate

As few parameters as possible (symmetric, uniform, normalized):

Quadratic ST (Q): t = 10j for j ∈ T = {7, 5, 3, 2, 1} Boxstep ST (1P): ∆ ∈ {1000, 500, 100, 10, 1} 3-pieces ST (3P): ∆, tε = 2∆ (tangent to Q) 5-pieces linear ST (5P): for each (∆, ε) in 3P, two sub-intervals of width ∆/2, slopes 1 and ε − 1.0 (outer, inner)

5 Q, 5 1P algorithms, ≤ 25 3P and 5P (“useless” variants removed) No dynamic adjustment, favors “simple” approaches

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 27 / 44

Guidelines for . . .

Initial dual points: given dual optimal solution ˜ π

α-points: α˜ π for α ∈ {0.9, 0.75, 0.5, 0.25, 0.0} (feasible as 0 is) random points such that δ1 ≤ π − ˜ π∞ ≤ δ2 for (δ1, δ2) ∈ {(0, 0.5), (0, 1), (0.5, 1)}.

(α-points are better structured than random ones)

• 13H. Ben Amor, J. Desrosiers “A Proximal Trust Region Algorithm for Col. Gen. Stabilization” Comput. & O.R. 2006
• 14D. Carpaneto, M. Dall’Amico, M. Fischetti, P. Toth “A Branch and Bound Algorithm for the Multiple Depot Vehicle

Scheduling Problem” Networks 1989

• 15A. Oukil, H. Ben Amor, J. Desrosiers “Stabilized Column Generation for Highly Degenerate Multiple-Depot Vehicle

Scheduling Problems” Comput. & O.R. 2006

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 28 / 44

Guidelines for . . .

Initial dual points: given dual optimal solution ˜ π

α-points: α˜ π for α ∈ {0.9, 0.75, 0.5, 0.25, 0.0} (feasible as 0 is) random points such that δ1 ≤ π − ˜ π∞ ≤ δ2 for (δ1, δ2) ∈ {(0, 0.5), (0, 1), (0.5, 1)}.

(α-points are better structured than random ones) The Test Instances:

MDVS13 (easy) resource-constrained Urban Bus Scheduling14 (hard) Long-Horizon (weekly) MDVS15 (harder)

Stop: ≤ 10−4/1500 iterations (≤ 10−7/700 iterations for MDVS)

• 13H. Ben Amor, J. Desrosiers “A Proximal Trust Region Algorithm for Col. Gen. Stabilization” Comput. & O.R. 2006
• 14D. Carpaneto, M. Dall’Amico, M. Fischetti, P. Toth “A Branch and Bound Algorithm for the Multiple Depot Vehicle

Scheduling Problem” Networks 1989

• 15A. Oukil, H. Ben Amor, J. Desrosiers “Stabilized Column Generation for Highly Degenerate Multiple-Depot Vehicle

Scheduling Problems” Comput. & O.R. 2006

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 28 / 44

MDVS: Comparing kP, Using Initial Dual α-points

∆ 1000 500 100 alg CG 1P 3P 5P 1P 3P 5P 1P 3P 5P t 105 103 105 103 105 103 105 103 103 102 103 102 p1 134 85 110 79 110 72 80 118 72 120 65 122 74 58 75 58 p2 151 92 117 92 114 84 84 115 83 111 77 119 84 81 80 83 p3 183 117 162 114 161 99 109 163 96 158 89 129 103 80 94 81 p4 137 83 124 83 115 80 79 123 76 120 76 115 81 75 78 74 p5 592 343 481 256 468 222 260 498 223 493 194 200 274 241 278 279 p6 505 195 394 177 384 150 158 423 149 422 126 151 177 125 181 121 p7 287 152 271 125 275 110 125 284 110 281 107 181 164 141 160 159 p8 192 126 172 108 178 96 107 190 97 187 94 184 139 115 142 118 p9 258 161 224 127 215 109 140 225 110 223 101 179 130 140 130 170 p10 298 214 244 144 238 120 177 242 128 257 120 254 146 163 147 207 0.9 274 139 227 133 226 113 112 236 113 238 91 68 122 84 119 83 0.75 274 157 228 130 224 109 130 236 111 236 99 100 128 100 132 112 0.5 274 167 231 126 225 115 132 240 115 232 105 174 137 125 141 149 0.25 274 161 227 131 225 118 142 237 116 240 109 229 144 147 146 161 274 159 236 133 230 117 145 242 118 240 120 247 155 155 146 170

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 29 / 44

MDVS: Comparing kP, Using Initial Dual α-points (2)

∆ 100 10 1 alg CG 1P 3P 5P 1P 3P 5P 1P 3P 5P t 103 102 103 102 103 102 10 103 102 10 102 10 102 10 p1 134 122 74 58 75 58 408 115 73 110 113 73 111 255 123 96 126 97 p2 151 119 84 81 80 83 387 118 88 130 112 104 145 306 133 110 126 107 p3 183 129 103 80 94 81 473 156 97 122 150 106 150 442 168 122 166 125 p4 137 115 81 75 78 74 396 122 79 99 128 81 111 271 131 101 127 100 p5 592 200 274 241 278 279 544 474 346 388 475 332 406 620 481 336 489 335 p6 505 151 177 125 181 121 556 368 192 205 369 194 239 599 386 203 377 205 p7 287 181 164 141 160 159 554 289 185 244 275 183 286 601 286 204 282 193 p8 192 184 139 115 142 118 466 183 150 174 181 152 179 508 189 156 188 154 p9 258 179 130 140 130 170 505 222 178 235 219 179 233 531 242 178 232 183 p10 298 254 146 163 147 207 566 232 160 302 231 151 329 655 244 176 246 176 0.9 274 68 122 84 119 83 214 218 139 155 215 139 179 541 231 155 235 156 0.75 274 100 128 100 132 112 380 221 148 187 222 147 205 305 237 160 231 161 0.5 274 174 137 125 141 149 561 225 154 217 230 163 223 516 239 167 232 168 0.25 274 229 144 147 146 161 650 230 160 215 228 166 240 518 237 175 238 171 274 247 155 155 146 170 623 245 173 232 233 163 248 514 248 185 245 181

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 30 / 44

Comments

First half: average on α, instance-wise (robustness to initial point) Second half: average on instance, α-wise (dependence to initial point)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 31 / 44

Comments

First half: average on α, instance-wise (robustness to initial point) Second half: average on instance, α-wise (dependence to initial point) “Weak” penalties already better than CG (is +∞ weak?)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 31 / 44

Comments

First half: average on α, instance-wise (robustness to initial point) Second half: average on instance, α-wise (dependence to initial point) “Weak” penalties already better than CG (is +∞ weak?) An “intermediate” stabilization is better:

intermediate ∆ values are best (not too large or too small) something similar happens for t (better seen next)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 31 / 44

Comments

First half: average on α, instance-wise (robustness to initial point) Second half: average on instance, α-wise (dependence to initial point) “Weak” penalties already better than CG (is +∞ weak?) An “intermediate” stabilization is better:

intermediate ∆ values are best (not too large or too small) something similar happens for t (better seen next)

1P has best overall performance for α = 0.9 and ∆ = 100 however performance quickly degrades farther from ˜ π 3P and 5P are much more robust, both on α and “extreme” ∆, t

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 31 / 44

Comments

First half: average on α, instance-wise (robustness to initial point) Second half: average on instance, α-wise (dependence to initial point) “Weak” penalties already better than CG (is +∞ weak?) An “intermediate” stabilization is better:

intermediate ∆ values are best (not too large or too small) something similar happens for t (better seen next)

1P has best overall performance for α = 0.9 and ∆ = 100 however performance quickly degrades farther from ˜ π 3P and 5P are much more robust, both on α and “extreme” ∆, t For each ∆ either 3P or 5P outperforms 1P for at least one t Most often 5P better than 3P despite the very “rigid” shape

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 31 / 44

MDVS: Comparing Q, Using Initial Dual α-points

t 107 105 103 alg CG 1P Q 1P 3P 5P Q 1P 3P 5P Q ∆ 1000 500 1000 1000 100 1000 500 100 1000 500 100 p1 134 85 100 80 110 110 88 122 79 72 74 72 65 75 63 p2 151 92 112 84 117 114 103 119 92 83 84 84 77 80 86 p3 183 117 146 109 162 161 125 129 114 96 103 99 89 94 103 p4 137 83 115 79 124 115 98 115 83 76 81 80 76 78 73 p5 592 343 422 260 481 468 288 200 256 223 274 222 194 278 213 p6 505 195 318 158 394 384 199 151 177 149 177 150 126 181 109 p7 287 152 223 125 271 275 155 181 125 110 164 110 107 160 118 p8 192 126 162 107 172 178 126 184 108 97 139 96 94 142 112 p9 258 161 213 140 224 215 152 179 127 110 130 109 101 130 132 p10 298 214 204 177 244 238 148 254 144 128 146 120 120 147 153 0.9 274 139 200 112 227 226 149 68 133 113 122 113 91 119 84 0.75 274 157 200 130 228 224 148 100 130 111 128 109 99 132 94 0.5 274 167 203 132 231 225 147 174 126 115 137 115 105 141 114 0.25 274 161 202 142 227 225 149 229 131 116 144 118 109 146 139 0.0 274 159 203 145 236 230 149 247 133 118 155 117 120 146 151

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 32 / 44

MDVS: Comparing Q, Using Initial Dual α-points (2)

t 102 10 alg CG 1P 3P 5P Q 1P 3P 5P Q ∆ 10 100 10 100 10 1 10 1 10 1 p1 134 408 58 73 58 73 188 255 110 96 111 97 423 p2 151 387 81 88 83 104 243 306 130 110 145 107 385 p3 183 473 80 97 81 106 261 442 122 122 150 125 494 p4 137 396 75 79 74 81 235 271 99 101 111 100 499 p5 592 544 241 346 279 332 336 620 388 336 406 335 583 p6 505 556 125 192 121 194 300 599 205 203 239 205 610 p7 287 554 141 185 159 183 316 601 244 204 286 193 568 p8 192 466 115 150 118 152 212 508 174 156 179 154 513 p9 258 505 140 178 170 179 263 531 235 178 233 183 539 p10 298 566 163 160 207 151 339 655 302 176 329 176 594 0.9 274 214 84 139 83 139 134 541 155 155 179 156 269 0.75 274 380 100 148 112 147 199 305 187 160 205 161 431 0.5 274 561 125 154 149 163 286 516 217 167 223 168 585 0.25 274 650 147 160 161 166 338 518 215 175 240 171 662 0.0 274 623 155 173 170 163 390 514 232 185 248 181 658

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 33 / 44

Comments (2)

Weak penalties: 1P better than Q, Q better than 3P and 5P (Q has no +∞ ⇒ too weak, 3P and 5P weaker than Q)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 34 / 44

Comments (2)

Weak penalties: 1P better than Q, Q better than 3P and 5P (Q has no +∞ ⇒ too weak, 3P and 5P weaker than Q) Mid penalties: Q better than 1P, often outperforms 3P and 5P Q more competitive w.r.t. 1P as α decreases 3P and 5P more competitive w.r.t. Q as α decreases, better for low α

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 34 / 44

Comments (2)

Weak penalties: 1P better than Q, Q better than 3P and 5P (Q has no +∞ ⇒ too weak, 3P and 5P weaker than Q) Mid penalties: Q better than 1P, often outperforms 3P and 5P Q more competitive w.r.t. 1P as α decreases 3P and 5P more competitive w.r.t. Q as α decreases, better for low α Strong penalties: 3P and 5P better than Q, all the more if α low

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 34 / 44

Comments (2)

Weak penalties: 1P better than Q, Q better than 3P and 5P (Q has no +∞ ⇒ too weak, 3P and 5P weaker than Q) Mid penalties: Q better than 1P, often outperforms 3P and 5P Q more competitive w.r.t. 1P as α decreases 3P and 5P more competitive w.r.t. Q as α decreases, better for low α Strong penalties: 3P and 5P better than Q, all the more if α low Summing up:

for very good dual estimate and good ∆, 1P wins Q much more robust w.r.t. dual estimate, very good for proper t 3P and 5P even better for proper ∆ (same t), even more robust

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 34 / 44

Comments (2)

Weak penalties: 1P better than Q, Q better than 3P and 5P (Q has no +∞ ⇒ too weak, 3P and 5P weaker than Q) Mid penalties: Q better than 1P, often outperforms 3P and 5P Q more competitive w.r.t. 1P as α decreases 3P and 5P more competitive w.r.t. Q as α decreases, better for low α Strong penalties: 3P and 5P better than Q, all the more if α low Summing up:

for very good dual estimate and good ∆, 1P wins Q much more robust w.r.t. dual estimate, very good for proper t 3P and 5P even better for proper ∆ (same t), even more robust

Morale: more parameters help

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 34 / 44

MDVS: Random Initial Dual Points

δ1—δ2 0.0—0.5 0.0—1.0 0.5—1.0 t alg ∆ md1 md2 md3 md1 md2 md3 md1 md2 md3 CG 151 549 259 151 549 259 151 549 259 107 1P 1000 632 700 700 611 700 700 529 600 514 Q 115 367 207 114 376 198 114 361 200 105 1P 500 414 527 543 520 421 393 550 627 345 3P 500 126 447 222 131 434 226 126 437 221 5P 500 127 437 218 125 434 225 122 440 230 Q 101 240 144 101 246 145 104 259 143 103 1P 100 212 255 176 331 274 285 293 337 261 3P 1000 96 232 123 94 216 121 94 221 121 500 83 189 103 85 182 107 80 185 107 100 85 203 130 85 201 123 85 206 132 5P 1000 84 181 107 87 182 109 84 184 110 500 74 156 99 74 155 97 74 156 95 100 82 193 130 86 199 137 84 203 139 Q 54 118 71 87 157 111 111 141 113

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 35 / 44

MDVS: Random Initial Dual Points (2)

δ1—δ2 0.0—0.5 0.0—1.0 0.5—1.0 t alg ∆ md1 md2 md3 md1 md2 md3 md1 md2 md3 CG 151 549 259 151 549 259 151 549 259 102 1P 10 300 464 468 312 471 503 300 517 544 3P 100 63 129 92 71 137 94 65 147 93 10 80 211 142 82 207 138 82 221 146 5P 100 58 122 97 72 123 94 60 136 97 10 79 203 140 82 218 149 86 215 155 Q 184 190 193 369 386 447 352 396 468 10 1P 1 320 651 509 363 683 487 294 700 508 3P 10 96 226 198 118 213 174 97 213 192 1 91 221 160 89 224 161 88 237 167 5P 10 122 364 214 117 256 190 117 254 202 1 92 235 156 84 225 163 92 248 161 Q 456 673 618 531 700 675 491 700 688

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 36 / 44

Comments (3)

1P strongly dependent on good initial estimate (much worse here) Q much better than 1P everywhere except for very strong penalties 3P and especially 5P better than Q with proper choice of ∆ 3P and 5P even more insensitive to dual estimate than Q

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 37 / 44

LH-MDVS (Random Initial Dual Points)

δ1—δ2 0.0—0.5 0.0—1.0 0.5—1.0 t alg ∆ lh1 lh2 lh3 slv lh1 lh2 lh3 slv lh1 lh2 lh3 slv CG 629 1866 3588 6 629 1866 3588 6 629 1866 3588 6 107 1P 1000 1500 1500 1500 0 1500 1500 1500 0 1500 1500 1500 Q 448 1283 1500 9 446 1247 1500 8 458 1249 1500 9 105 1P 500 1208 1500 1500 1 1500 1500 1500 0 1224 1500 1500 1 3P 500 494 1265 1500 8 494 1283 1500 8 510 1306 1500 8 5P 500 483 1231 1484 9 483 1251 1486 9 489 1227 1498 9 Q 331 880 1314 12 343 882 1316 12 330 878 1331 12 103 1P 100 624 1500 1500 4 476 1374 1500 7 452 1382 1500 8 3P 1000 370 1443 1500 6 384 1394 1500 7 382 1442 1500 6 500 298 1161 1500 9 314 1186 1487 9 315 1183 1500 8 100 245 651 1155 13 249 696 1189 13 258 688 1209 13 5P 1000 298 1203 1484 9 293 1172 1450 9 314 1166 1473 10 500 240 882 1377 11 246 900 1362 11 253 885 1347 11 100 233 528 867 14 244 559 948 14 239 566 931 14 Q 136 283 396 14 155 323 457 14 152 317 460 14

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 38 / 44

LH-MDVS (2)

δ1—δ2 0.0—0.5 0.0—1.0 0.5—1.0 t alg ∆ lh1 lh2 lh3 slv lh1 lh2 lh3 slv lh1 lh2 lh3 slv CG 629 1866 3588 6 629 1866 3588 6 629 1866 3588 6 102 1P 10 505 1284 1500 8 611 1484 1500 5 546 1435 1500 5 3P 100 191 578 1085 13 199 755 915 10 200 626 1131 13 10 216 418 573 14 222 469 717 14 226 466 713 14 5P 100 164 436 793 14 170 519 822 14 175 481 797 14 10 217 396 518 14 220 447 685 14 225 444 641 14 Q 282 293 676 14 617 864 1249 10 608 777 1362 12 10 1P 1 969 1500 1500 4 1133 1500 1500 2 1106 1500 1500 3 3P 10 205 308 448 14 248 571 610 14 232 575 540 14 1 224 434 526 14 247 529 757 14 297 501 702 14 5P 10 234 303 614 14 270 636 651 14 250 618 491 14 1 249 442 532 14 257 608 880 14 263 485 682 14 Q 838 1486 1500 5 1233 1500 1500 2 1163 1500 1500 3

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 39 / 44

Comments (4)

1P never solves all, only occasionally better than pure CG 3P better than CG, quite good most of the time 5P remarkably better than 3P (much more so than in MDVS) Q even better than 5P (except for very large penalty) More difficult problem ⇒ more pieces?

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 40 / 44

UBS

t alg ∆ u5s0 u5s1 u7s0 u7s1 u10s0 u10s1 u12s0 u12s1 u15s0 u15s1 u20s0 u20s1 CG 106 132 158 169 321 300 371 506 858 785 1004 989 107 1P 1000 1500 285 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 Q 98 97 143 152 331 304 361 471 681 694 871 1105 105 1P 500 1373 209 1500 1020 1500 1500 1500 1500 1500 664 231 729 3P 500 99 125 169 181 458 321 394 590 944 1012 1251 1375 5P 500 111 113 164 193 404 362 441 602 920 816 1230 1490 Q 81 92 111 110 188 166 206 220 339 271 298 357 103 1P 100 336 167 350 328 675 417 953 315 690 286 260 391 3P 1000 75 85 107 98 169 149 181 188 277 243 233 335 500 72 75 90 88 141 133 155 167 243 191 181 230 100 77 80 101 102 171 156 178 203 342 270 279 399 5P 1000 71 74 97 87 154 131 150 159 248 191 194 239 500 62 68 82 78 122 107 130 129 199 139 158 186 100 77 76 99 99 166 155 175 196 317 304 297 412 Q 107 55 108 80 171 171 119 93 195 163 106 108

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 41 / 44

UBS (2)

t alg ∆ u5s0 u5s1 u7s0 u7s1 u10s0 u10s1 u12s0 u12s1 u15s0 u15s1 u20s0 u20s1 CG 106 132 158 169 321 300 371 506 858 785 1004 989 102 1P 10 259 458 349 461 645 534 698 725 811 787 763 950 3P 100 55 60 77 69 107 95 114 116 199 124 150 245 10 106 125 99 131 167 154 176 274 309 336 391 448 5P 100 52 59 70 83 109 89 104 209 187 118 159 227 10 107 80 102 140 171 154 178 268 388 380 372 499 Q 364 261 384 327 427 451 452 337 529 388 296 404 10 1P 1 361 391 559 462 729 748 879 1098 1397 1472 1500 1500 3P 10 134 140 183 172 198 297 213 320 278 270 362 370 1 111 119 128 143 182 171 210 254 407 372 368 516 5P 10 147 136 199 186 250 328 265 305 301 370 393 389 1 104 113 103 131 192 189 194 291 371 361 355 501 Q 506 486 634 877 1352 1273 1485 1125 1500 1276 995 1276

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 42 / 44

Comments (5)

Again, 1P not much (if any) better than pure CG 3P and 5P significantly better than 1P 5P most often better than 3P (more than in MDVS, less than in LH-MDVS) Q often the best, except for large penalty (more than in MDVS, less than in LH-MDVS)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 43 / 44

Comments (5)

Again, 1P not much (if any) better than pure CG 3P and 5P significantly better than 1P 5P most often better than 3P (more than in MDVS, less than in LH-MDVS) Q often the best, except for large penalty (more than in MDVS, less than in LH-MDVS) Trend confirmed: the more difficult problem, the more pieces needed

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 43 / 44

Comments (5)

Again, 1P not much (if any) better than pure CG 3P and 5P significantly better than 1P 5P most often better than 3P (more than in MDVS, less than in LH-MDVS) Q often the best, except for large penalty (more than in MDVS, less than in LH-MDVS) Trend confirmed: the more difficult problem, the more pieces needed Reminder: very “rigid” 3P and 5P, not exploiting all their parameters Reminder: static parameters, less important for Q (infinitely-sloped)

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 43 / 44

Conclusions

Generic framework for column generation stabilization Various piecewise-linear and quadratic stabilizing terms

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 44 / 44

Conclusions

Generic framework for column generation stabilization Various piecewise-linear and quadratic stabilizing terms Pure Proximal versus (rough) Bundle variants

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 44 / 44

Conclusions

Generic framework for column generation stabilization Various piecewise-linear and quadratic stabilizing terms Pure Proximal versus (rough) Bundle variants Tests on large-scale real-world problems Lessons:

stabilization adds complexity, but not unmanageable performances significantly improve having upper bound to follow is important best shape/stiffness of stabilization depends on several parameters general guidelines seem to exist ⇒ applicable in practice

• A. Frangioni (UNIPI)

Stabilized CG ColGen 2008 44 / 44
