Clinical Digital Imaging Clinical Digital Imaging

NetCam

DP71 Advanced digital microimaging

• 12.5 megapixel cooled CCD camera
• Highest color reproducibility
• Custom monochrome mode
• 15 fps real-time display
• Extensive selection of image

processing filters and display tools

• Annotation capabilities

including arrows, text and highlighting

• Option of archiving images,

spreadsheets, graphs and diagrams to a database; Structured Archive (STAR)

• r Web-based

DP71+ MicroSuite = Telepathology Power

• NetCam is a feature of

MicroSuite™ FIVE, included in the “Basic” package and higher

• NetCam allows one or more

remote users to view a live or captured image from a DP71 camera placed on a microscope

• “Remote”: another physical or

geographical location

• Communication is through the

Internet via TCP/IP (static IP address)

NetCam

Digital Slide Scanner

• High throughput rapid scanning
• 210 slide loading capacity
• Whole Slide or Region of Interest (ROI)
• Easy to use software, 2 clicks and batch scanning begins 20x and 40x always available
• Three scanning modes: Manual, Semi Automatic & Automatic
• Scans each slide at 20x in less than 4 minutes, 40X scans in 8 mins (20mm x 20mm size

sample)

• Scans using 3 CCD 4096 x 64 pixel TDI sensors
• Each slide is available for viewing immediately after the scan is completed
• Uses Olympus 20x .75 NA Plan Apo Objective
• 1 x 3 glass slides only
• Barcode capable both 1D and 2D
• Fluorescence Upgrade
• 3 Filters available (FITC, TxRed, Triple)
• Z-Stack Capture now available
• OAI/BLI are exclusive distributor of NDP for US and Canada

Hamamatsu NanoZoomer

WebSlide Server Software

• WebSlide Server is a standard TCP/IP HTML server

designed specifically for the deployment of Virtual Slides and standard HTML content over the internet including Java and ActiveX.

• Operates as a service
• Very easy to use
• Reliable, no monitoring or IT support needed
• 24/7 log of WSS activity including IP address, viewer

used, and slides viewed

• Can be sold as a stand alone product or with a slide

scanner

• Deploys four viewer options- ActiveX, WebSlide Finder,

Java and WebSlide Browser

Virtual Slide Viewers

ActiveX

• Single Pane
• Works with Internet Explorer
• Interactive Thumbnail
• Many options for changing objectives

including right click, drop down menu, and the mouse wheel

• F8: Turn on/off thumbnail,

annotations, and view tracker

• Open multiple WebSlide windows

simultaneously

WebSlide Finder

• Our most powerful viewer!
• Utilizes all the benefits of ActiveX
• Two modes: Workflow and Education
• Open up to 16 windows at one time
• Synchronization of multiple WebSlides
• WebSlide Conferencing
• Detailed metadata and descriptions are

included or can be added using SlideTray

• Easy, simple, keyword and multiple keyword

searches

• Simple window navigation with F keys
• Save snapshots using CTRL+C

Virtual Slide Viewers

Java

• For our Mac/Linux users
• Cross Platform compatible
• Works with other common internet

browsers such as FireFox and Safari

• Right click to change magnification

(apple key + mouse click)

• Outline for high power only in

thumbnail

• Thumbnail is static

WebSlide Browser

• WebSlide Synchronization & Chat

Room

• Annotation Tools including arrows,

lines, boxes, and text

• Exporting feature for Area and Tape

measurements

• WebSlide Link Creator- for emailing

WebSlides

• ActiveX & Applet Creator for Web

Pages & PowerPoint Presentations
