A Brief History of Astronomical A Brief History of Astronomical Imaging Systems Imaging Systems 1 Oldest Imaging Imaging Instruments Instruments Oldest circa 1000 CE 1600 CE Used to measure angles and positions

slide-1
SLIDE 1

1

A Brief History of Astronomical A Brief History of Astronomical Imaging Systems Imaging Systems

slide-2
SLIDE 2

2

Oldest Oldest “ “Imaging Imaging” ” Instruments Instruments

  • circa 1000 CE – 1600 CE
  • Used to measure angles and positions
  • Included No Optics

– Astrolabe – Octant, Sextant – Tycho Brahe’s Mural Quadrant (1576)

  • Star Catalog accurate to 1' (1 arcminute = 1/60° ≈ limit of

resolution of unaided human eye)

– Astronomical Observatories were built by church as part of European Cathedrals

  • (possible subject for course term paper)
slide-3
SLIDE 3

3

Early Early “ “Imaging Imaging” ” System System the Mural Quadrant the Mural Quadrant

  • Most accurate positions
  • f stars and planets

then available

  • Used by Johannes

Kepler to derive the three laws of planetary motion

– Laws 1,2 published in 1609 – Third Law in 1619

H.C. King, History of the Telescope

slide-4
SLIDE 4

4

Kepler Kepler’ ’s s Three Laws of Three Laws of Planetary Motion Planetary Motion

1. The orbits of planets are ellipses with the Sun at one focus. 2. The line joining the planet to the Sun sweeps

  • ut equal areas in equal times as the planet

travels around the ellipse, thus the planet travels faster when it is closer to the Sun. 3. The ratio of the squares of the periods (“years”) for two planets is equal to the ratio of the cubes

  • f their semimajor axes.
slide-5
SLIDE 5

5

Optical Instruments, (1609+) Optical Instruments, (1609+)

  • Refracting Telescope

– uses lenses to redirect light – Invented in 1608

  • Hans Lippershey (1570? – 1619)

– Early Use in Astronomy

  • 1609, by Galileo Galilei (1564 – 1642)
  • Johannes Hevelius (1611 – 1687)
  • Reflecting Telescope

– Invented ca. 1671

  • Isaac Newton (1642-1727)
  • Spectroscope

– Invented ca. 1669, also by Newton

slide-6
SLIDE 6

6

Galileo Galileo’ ’s Telescopes s Telescopes

  • Combination of Two

Lenses

– Objective

  • Two surfaces: flat and

convex

– Eye Lens (Ocular)

  • Two surfaces: flat and

concave

  • Magnified by 20×

Cracked Objective Lens

slide-7
SLIDE 7

7

Galilean Telescope Galilean Telescope

  • Ray incident “above” the optical axis

emerges “above” the axis

  • image is “upright”
  • Small Field of View

fobjective

slide-8
SLIDE 8

8

Galilean Telescope Galilean Telescope

Ray entering at angle θ emerges at angle θ′ > θ Larger ray angle ⇒ angular magnification θ′ θ

slide-9
SLIDE 9

9

Keplerian Keplerian Telescope Telescope

Ray incident “above” the optical axis emerges “below” the axis image is “inverted” fobjective feyelens

slide-10
SLIDE 10

10

Keplerian Keplerian Telescope Telescope

Ray entering at angle θ emerges at angle θ′ where |θ′ | > θ Larger ray angle ⇒ angular magnification θ′ θ

slide-11
SLIDE 11

11

“ “Refractive Index Refractive Index” ”

  • Denoted by n
  • Measure of ratio of velocity of light in

matter to that in vacuum

c = velocity in vacuum ≈ 3 ×108 meters/second v = velocity in medium measured in same units n ≥ 1.0

v c n =

slide-12
SLIDE 12

12

Sample Refractive Indices Sample Refractive Indices

  • Vacuum:

n = 1.0

  • Air:

n ≈ 1.00003 ≈ 1.0

  • Water

n ≈ 1.33

  • Glass:

1.71 ≤ n ≤ 1.46

slide-13
SLIDE 13

13

Lenses Redirect ( Lenses Redirect (“ “Bend Bend” ”) Light ) Light by Refraction due to Different by Refraction due to Different n n

  • θ1

θ2 θ1 n1 n2

Incident Ray Refracted Ray Reflected Ray

slide-14
SLIDE 14

14

Refracted Angles Determined Refracted Angles Determined by by “ “Snell Snell’ ’s Law s Law” ” n n n n

1 1 2 2 2 1 1 2 1

sin sin sin sin θ θ θ θ = ⇒ =

L N M O Q P

−

slide-15
SLIDE 15

15

Problem with Refracting Problem with Refracting Telescopes: Telescopes: “ “Optical Dispersion Optical Dispersion” ”

  • Refractive index n of glass is not constant
  • n of glass tends to DECREASE with increasing

wavelength λ

  • ⇒ Refracted angles change with wavelength λ
  • Focal length f of lens tends to INCREASE with

increasing wavelength λ

– Different colors “focus” at different distances – “Chromatic Aberration”

slide-16
SLIDE 16

16

Optical Dispersion Optical Dispersion

n

λ

Ultraviolet Infrared

slide-17
SLIDE 17

17

Chromatic Aberration Chromatic Aberration

slide-18
SLIDE 18

18

Minimize Chromatic Aberration Minimize Chromatic Aberration

  • Chromatic aberration is less noticeable for

lenses with long focal lengths f

slide-19
SLIDE 19

19

Hevelius Hevelius’ ’ Refractor, ca. 1650 Refractor, ca. 1650

H.C. King, History of the Telescope

Objective Lens Eye Lens

slide-20
SLIDE 20

20

Later Methods to Diminish Later Methods to Diminish Chromatic Aberration Chromatic Aberration

  • Create lens systems from multiple lenses made

from different glasses

– “doublets” or “triplets” – Designed so that chromatic aberrations “cancel” for some wavelengths

  • Difficult to design and fabricate
  • Beyond capability of early optical technicians
slide-21
SLIDE 21

21

“ “Achromatic Achromatic” ” Lenses Lenses

  • “Achromatic” means

“no color”

  • Two (or more) lenses

with different glasses

– “Crown”, with smaller n – “Flint”, with larger n

slide-22
SLIDE 22

22

Easy Way to Eliminate Easy Way to Eliminate Chromatic Aberration Chromatic Aberration

  • Don’t use lenses!!

f All colors “focus” at same distance f

slide-23
SLIDE 23

23

Newton Newton’ ’s Reflector s Reflector

  • ca. 1671
  • 1"-diameter mirror
  • no chromatic

aberration

– mirrors reflect all wavelengths at the same angle!

H.C. King, History of the Telescope

slide-24
SLIDE 24

24

Large Historical Reflecting Large Historical Reflecting Telescope Telescope

H.C. King, History of the Telescope

Lord Rosse’s 1.8 m (6'-diameter) telescope metal mirror, 1845

slide-25
SLIDE 25

25

History of Imaging Sensors History of Imaging Sensors

  • Eye

– Limited sensitivity – Limited range of wavelengths – Images can be “stored” only “by hand” (drawings)

  • Image Recording Systems

– Chemical-based Photography

  • wet plates, 1850 +
  • dry plates, 1880+
  • Kodak plates, 1900+

– Physics-based Photography, 1970 +

  • Electronic Sensors, CCDs
slide-26
SLIDE 26

26

History of Imaging Sensors History of Imaging Sensors

  • Groundbased Infrared Imaging

– 1856: using thermocouples and telescopes (“one-pixel sensors”) – 1900+: IR measurements of planets – 1960s: IR survey of sky (Mt. Wilson, lead sulfide − PbS − detector)

  • Spacebased Infrared Imaging

– 1983: IRAS (Infrared Astronomical Satellite)

  • cooled Silicon and Germanium detectors

– 1989: COBE (Cosmic Background Explorer)

slide-27
SLIDE 27

27

History of Imaging Sensors History of Imaging Sensors

  • Airborne Infrared Observatories

– Galileo I (Convair 990), 1965 – 4/12/1973 (crashed) – Frank Low, 12"–diameter telescope on NASA Learjet, 1968 – Kuiper Airborne Observatory (KAO) (36"- diameter telescope)

slide-28
SLIDE 28

28

Galileo I ( Galileo I (Convair Convair 990) 990)

  • Started in 1965
  • Several “ports” available for cameras
  • Crashed 4/12/1973

– midair collision on landing at NAS Moffet

slide-29
SLIDE 29

29

NASA Learjet, 1968 NASA Learjet, 1968

  • 12"–diameter telescope, by Frank Low
slide-30
SLIDE 30

30

Kuiper Kuiper Airborne Observatory Airborne Observatory

  • Modified C-141

Starlifter

  • 2/1974 – 10/1995
  • ceiling of 41,000' is

above 99% of water vapor, which absorbs most infrared radiation

slide-31
SLIDE 31

31

Stratospheric Observatory for Stratospheric Observatory for Infrared Astronomy Infrared Astronomy − − SOFIA SOFIA

  • Boeing 747SP
  • 2.7-m Mirror (106")
slide-32
SLIDE 32

32

Spaceborne Spaceborne Observatories Observatories

  • “Orbiting Astronomical Observatory”

(OAO), 1960s

  • “Infrared Astronomical Satellite” (IRAS),

1980s

  • Hubble Space Telescope (HST), 1990
  • Chandra (Advanced X-ray Astrophysics

Facility= AXAF), 7/1999

slide-33
SLIDE 33

33

History of Imaging Systems for History of Imaging Systems for Radio Astronomy Radio Astronomy

  • Wavelengths λ are much longer than visible light

– millimeters (and longer) vs. hundreds of nanometers

  • History

– 1932: Karl Jansky (Bell Telephone Labs) investigated use of “short waves” for transatlantic telephone communication – 1950s: Plans for 600-foot “Dish” in Sugar Grove, WV (for receiving Russian telemetry reflected from Moon) – 1960s 305m Dish at Arecibo, Puerto Rico – 1963: Penzias and Wilson (Bell Telephone Labs), “Cosmic Microwave Background” – 1980: “Very Large Array” (= VLA) in New Mexico

slide-34
SLIDE 34

34

Jansky Jansky Radio Telescope Radio Telescope

Image courtesy of NRAO/AUI

1932

slide-35
SLIDE 35

35

Large Radio Telescopes Large Radio Telescopes

http://www.naic.edu/about/ao/telefact.htm

305m at Arecibo, Puerto Rico 100m at Green Bank, WV

Image courtesy of NRAO/AUI

slide-36
SLIDE 36

36

Very Large Array = VLA Very Large Array = VLA

Image courtesy of NRAO/AUI

  • 27 telescopes
  • 25m diameter
  • transportable on rails
  • separations up to 36

km (22 miles)
