CIAO RADIO MULTIMODE RECEIVER TEST SET By Sistel 24/10/05 1 - PowerPoint PPT Presentation

Oct 12, 2023 •194 likes •320 views

CIAO RADIO MULTIMODE RECEIVER TEST SET By Sistel 24/10/05 1 Introduction Ciao Radio is a Multimode HF Receiver and Test Set As Multimode HF Receivers it is a SDR ( Software Defined Radio ) with two antennas input .

  1. CIAO RADIO MULTIMODE RECEIVER TEST SET By Sistel 24/10/05 1

  2. Introduction  Ciao Radio is a Multimode HF Receiver and Test – Set  As Multimode HF Receivers it is a SDR ( Software Defined Radio ) with two antennas input .  Filtering and Demodulation of the signals is made from a PC connected to Ciao Radio trough an USB port  This allows any kind of demodulation , filtering and postprocessing via Software 24/10/05 2

  3. Ciao Radio as Test - Set  Spectrum and Spectrogram analysis  Generation of a CW carrier via DDS  Spectrum recording for surveing and postmodulation purposes  Audio Frequency analysis  Recording of the amplitude of the signals and statistical analysis for propagation studies  Measurements of the gain of antennas ( Line of Sight or even in Ionospheric Mode ) . 24/10/05 3

  4. CIAO RADIO Architecture 24/10/05 4

  5. Spectrum Analysis and Level Recording 24/10/05 5

  6. DSP 24/10/05 6

  7. Filtering shape easily changed by mouse 24/10/05 7

  8. Antenna comparison 24/10/05 8

  9. Advanced Automatic I-Q Balancing 24/10/05 9

  10. Multimode Demodulation 24/10/05 10

  11. Preselector Design 24/10/05 11

  12. Drawing 24/10/05 12
