ITU Mission

(from Y. Henri presentation - 18/09/14)

slide-3
SLIDE 3

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 3

Satellite Communication Use Cases

Satellite Communication Regulation Cases

14/10/2014

slide-4
SLIDE 4

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 4

Satellite Communication Use Cases

Satellite Communication Regulation Cases

14/10/2014

Transmission Verification

  • RF Parameters
  • Spectrum regulation

enforcement

  • Carrier ID Verification

(when applicable)

slide-5
SLIDE 5

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 5

Satellite Communication Use Cases

Satellite Communication Regulation Cases

14/10/2014

Enforcement of ITU regulation on Station Keeping (Article 22 Section III)

slide-6
SLIDE 6

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 6

Satellite Communication Use Cases

Satellite Communication Regulation Cases

14/10/2014

Harmful Interference Legal Mitigation

slide-7
SLIDE 7

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 7

Satellite Communication Use Cases

Satellite Communication Regulation Cases

14/10/2014

Verification of Proper Transmission Registration from national areas (depending on national regulation)

slide-8
SLIDE 8

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 8

Satellite Communication Use Cases

Harmful Interference Mitigation

14/10/2014

slide-9
SLIDE 9

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 9

Satellite Communication Use Cases

Harmful Interference Mitigation

14/10/2014

slide-10
SLIDE 10

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 10

Satellite Communication Use Cases

Satellite Communication Regulation Cases

14/10/2014

slide-11
SLIDE 11

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 11

Satellite Communication Use Cases

Harmful Interference Mitigation – Carrier ID

Carrier ID Demodulation Example on SES and Eutelsat Satellites

14/10/2014

slide-12
SLIDE 12

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 12

Satellite Communication Use Cases

Harmful Interference Mitigation – Carrier ID

Transmitter Coordinates Carrier ID Global Unique Identifier (GUID) Operator Defined Message

14/10/2014

slide-13
SLIDE 13

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 13

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation

slide-14
SLIDE 14

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 14

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation

slide-15
SLIDE 15

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 15

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation - Geolocation

Extract of Geolocation report (Draft example of golocation result by ZDS system)

slide-16
SLIDE 16

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 16

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation

slide-17
SLIDE 17

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 17

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation

slide-18
SLIDE 18

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 18

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation

slide-19
SLIDE 19

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 19

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation - Geolocation

Extract of Geolocation report (Draft example of golocation result by ZDS system)

slide-20
SLIDE 20

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 20

14/10/2014

Satellite Communication Use Cases

Harmful Interference Mitigation

slide-21
SLIDE 21

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 21

Satellite Communication Use Cases

Transmission Registration Check

14/10/2014

slide-22
SLIDE 22

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 22

Satellite Communication Use Cases

Transmission Registration Check

14/10/2014

slide-23
SLIDE 23

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 23

Satellite Communication Use Cases

Transmission Registration Check

14/10/2014

Local Regulation may require:

  • Regular monitoring of all satellites with local uplink
  • Check transmitting locations vs officially registered transmitters
slide-24
SLIDE 24

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 24

Satellite Communication Use Cases

Transmission Registration Check

14/10/2014

This requires full satellite (multiple transponders) systematic geolocation operations in order to retrieve transmitting location in a planned, regular and unsupervised fashion. Local Regulation may require:

  • Regular monitoring of all satellites with local uplink
  • Check transmitting locations vs officially registered transmitters
slide-25
SLIDE 25

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 25

Satellite Communication Use Cases

Transmission Registration Check

Transmitting location check requires VSAT Networking capabilities in order to identify remote stations transmitting from the national ground. Efficient Multiple Location per carrier capabilities is critical for that matter

TDMA Network (Carrier 1) Example on BADR-4

14/10/2014

slide-26
SLIDE 26

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 26

Satellite Communication Use Cases

Transmission Registration Check

Transmitting location check requires VSAT Networking capabilities in order to identify remote stations transmitting from the national ground. Efficient Multiple Location per carrier capabilities is critical for that matter

TDMA Network (Carrier 2) Example on BADR-4

14/10/2014

slide-27
SLIDE 27

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 27

Satellite Communication Use Cases

Transmission Registration Check

Transmitting location check requires VSAT Networking capabilities in order to identify remote stations transmitting from the national ground. Efficient Multiple Location per carrier capabilities is critical for that matter

TDMA Network (Carrier 3) Example on BADR-4

14/10/2014

slide-28
SLIDE 28

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 28

Satellite Communication Use Cases

Transmission Registration Check

Transmitting location check requires VSAT Networking capabilities in order to identify remote stations transmitting from the national ground. Efficient Multiple Location per carrier capabilities is critical for that matter

TDMA Network geolocation Example on BADR-4

14/10/2014

slide-29
SLIDE 29

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 29

Satellite Communication Use Cases

Station Keeping Verification

14/10/2014

Satellites must be maintained within an orbital slot according to dedicated ITU regulation. Countries are responsible for the enforcement of the regulation on their assigned orbital slots.

slide-30
SLIDE 30

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 30

Satellite Communication Use Cases

Station Keeping Verification

14/10/2014

How is it possible to check it ? Satellites must be maintained within an orbital slot according to dedicated ITU regulation. Countries are responsible for the enforcement of the regulation on their assigned orbital slots.

slide-31
SLIDE 31

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 31

Satellite Communication Use Cases

Station Keeping Verification

14/10/2014

Existing orbit determination techniques rely on active methods  Basically, the main source of accurate data comes the satellite operator

slide-32
SLIDE 32

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 32

Satellite Communication Use Cases

Station Keeping Verification

14/10/2014

Existing orbit determination techniques rely on active methods  Basically, the main source of accurate data comes the satellite operator  Need for third party control with passive measurements (Regulatory bodies and / or Independent service provider)

slide-33
SLIDE 33

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 33

Satellite Communication Use Cases

Station Keeping Verification

14/10/2014

 Passive Ranging System solely rely on downlink signals of the satellite of interest.  High performance synchronization algorithms make possible systems at the scale of a single country (500km x500km span)

slide-34
SLIDE 34

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 34

Inclined satellite Co-located satellites

Satellite Communication Use Cases

Station Keeping Verification

Example of 3D representation of satellite orbits (using ephemeris data generated by ZODIAC DATA SYSTEMS SEE)

14/10/2014

slide-35
SLIDE 35

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 35
  • 35

SEE Terminal #1 SEE Terminal #3 SEE Terminal #3

14/10/2014

Satellite Communication Use Cases

Station Keeping Verification

Satellite Ephemeris Estimation system & Geolocation system (in use for ephemeris data & geolocation service by ZDS)

SEE Terminal #2

slide-36
SLIDE 36

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 36

Satellite Communication Use Cases

ZODIAC DATA SYSTEMS QoS solutions

14/10/2014

slide-37
SLIDE 37

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

  • 37

Satellite Communication Use Cases

ZODIAC DATA SYSTEMS QoS solutions

14/10/2014

  • One Common HW High-performance Front-

End (IFoIP digitizer board)

  • Full Software Defined Radio Approach with

decentralized acquisition management

  • Scalable Architecture
  • Integrated Solution with easy upgrade for

managed cost of ownership

slide-38
SLIDE 38

ZODIAC AIRCRAFT SYSTEMS

This document is the property of ZODIAC DATA SYSTEMS. It cannot be duplicated or distributed without expressed written consent

Thank you for your attention

  • 38

ZDS locations

14/10/2014
