Outline of EWBS Module

Chapter 1 Introduction of EWBS

1

Configuration of EWBS Signal

Emergency information is telecast in combination of TMCC signal and TS (Transport Stream).

Information Source Encoding Part Video Encoding Audio Encoding Data Encoding Video Audio Data Multiplexing Part TS Remulti plexing Data Encoding

・ ・ ・

EWBS Character Information Layer Processing Error Correction Modulation Interleave TMCC signal generating Frame Configuration Transmission Route Encoding Part OFDM Transmission wave Formation Information EWBS Area Information （PMT) EWBS Activation Flag (TMCC_B26)

2

What is TMCC Signal?

Parameters such as “in which mode should the signal be demodulated?” are described. EWBS Activation Flag is included for the purpose of power control.

SP S 1 2 3 4 5 6 7 8 9 10 11 12 Carrier Number S S S S S S S S S S SP S S S S S S S S S S S S SP SP S S S S S S S S S S S S SP S S S S S S S S S S S S SP S S S S S S S S S S S SP 1 2 3 OFDM Symbol Number TMCC 4 S S S S S SP S S S S S S S S S S S SP S S S S S S S S S S S S SP SP S S S S S S S S S S S S SP S S S S S S S S S S S S SP S S S S S S S S S S S SP 199 200 201 202 203 S S S S S

・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・・・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・

OFDM Segment Configuration

Frequency

TMCC

3

Transmission and Multiplexing Configuration Control

What is TS Signal?

Broadcasting contents such as video, audio, etc., as well as broadcasting information such as datacasting, emergency warning, etc. are multiplexed into the TS signal. In EWBS, emergency warning information is distributed by using PMT and character superimpose packets. TS is something like a ship container, carrying video, audio, program distribution information, etc. Compressed video, audio, contents for datacasting, etc. are divided into pieces; and they are transmitted serially in the TS packets of 188 byte each. An ID number, called PID, is allocated to each of the packets; in a way that what sort of information is included in each of the containers can be identified.

Video Audio PAT Video PMT DATA Video EIT Audio Video DATA TOT Video 188Byte Video Video

4

Transport Stream

5

PAT … Program Association Table (PID = 0 x 0000) PID of PMT is written in. The number of PMT is the same as that of services provided. PMT … Program Map Table (PID = Described in PAT.) PID of the name of program, video, audio, etc. as well as the format of video, audio, etc. are written in . Area code for EWBS and PID of character superimpose packets are also written into the PMT.

PMT(1) PID PMT(2) PID PMT(3) PID PAT PMT (1) Program name Video PID Video format Audio PID Audio format Data PID EWBS Area EWBS Text PID … PMT (2) VIDEO stream AUDIO stream DATA stream EWBS Text stream Video Audio Data EWBS Text EWBS Area

Composition of EWBS Receivers

TMCC signal is extracted from the Tuner. Once TMCC_B26 is changed to "1", TS Analyzing Part should be activated for TS analysis. Targeted area of emergency warning is detected from PMT in the TS packet. Contents of warning are extracted from the character superimpose packet of TSP.

Antenna RF -> IF FFT TMCC Carrier Demodulation

TMCC Emergency Information

TS Analyzing Part

TS

6

Chapter 2 Hardware of EWBS module

7

EWBS Module

Newly developed module for EWBS reception, to be incorporated into simplified EWBS receiver or TV receivers.

40mm 25mm

8

Features of EWBS Module

 Size: 40mm X 25mm SMD/DIP(2mm pitch)  Power 3.3V Single power supply Power consumption: 190mW in standby, 248mW when receiving EWBS  Applicable frequency: UHF 470MHz ～ 806MHz  Bandwidth: 6MHz/8MHz  1-seg Reception:

• Approx. 13dB higher than Full-seg reception

 When area code is set, emergency warning is received only in the pre-set areas. When area code is not set, emergency warning is emitted unconditionally.  Output of EWBS reception flag  Emergency information is emitted from serial port. Standard specification: UART I2C, SPI specifications also available.

9

Functional Flow of EWBS Module

10

Receiving program of preset channel Activate TS Analyzing Part TMCC(B26) = 1

No Yes

Check area code Make output of EWBS receiving flag Searching character packets Decoding character data Make output of character information

Wide Applications of EWBS Module

 Public Electronic Signage  Small Display for home use  Incorporation into wrist watches  TV Receivers, Set-top Boxes  Accessories measuring instrument of reception sensitivity

11

Chapter 3 Software of EWBS module

12

Commands of EWBS Module

115,200bps, 8bit, 1 stop bit, no parity, no flow control

Setting UART Command Format

Header Body Trailer STX 0x02 TYPE 0x1D Cmd code Chk SUM Data Size Data EXT 0x03 Command packet format (Host → Module) Header Body Trailer STX 0x02 ACK NAK Cmd code Chk SUM Data Size Data EXT 0x03 Response packet format (module -> host)

13

ChkSUM : (STX) + (TYPE) + (CMD) + (ChkSUM) + (DataSize) + (DATA1) + (DATA2) + ... + (EXT) = 0x****00

List of Commands

 CMD_GET_EWBS_INFO (0x11) Confirm the version of EWBS module  CMD_GET_EWBS_STATUS (0x26) Obtain broadcasting conditions of EWBS signal  CMD_GET_EWBS_RSSI (0x27) Obtain receiving conditions of EWBS signal  CMD_GET_EWBS_TXT (0x28) Obtain character data of EWBS  CMD_GET_AREA_CODE (0x24)

• btain channel and area code information being monitored

 CMD_SET_AREA_CODE (0x25) Set channel and area code of the channel to be monitored

14

CMD_GET_EWBS_INFO

Confirm the version of Module

Header Body Trailer STX 0x02 TYPE 0x1D Cmd 0x11 SUM 0xCD Size 0x00 Data None EXT 0x03 Command packet format (Host → Module) Header Body Trailer STX 0x02 ACK 0x06 Cmd 0x11 SUM 0xF5 Size 0x0B Data 0x45 0x57 0x42 0x53 0x5F 0x6D 0x6F 0x64 0x01 0x03 0x10 EXT 0x03 Response packet format (Module -> host) Data : EWBS_mod ver.1.3.16

15

CMD_GET_EWBS_STATUS

Obtain receiving conditions of EWBS signal

Header Body Trailer STX 0x02 TYPE 0x1D Cmd 0x26 SUM 0xB8 Size 0x00 Data None EXT 0x03 Command packet format (Host → Module) Header Body Trailer STX 0x02 ACK 0x06 Cmd 0x26 SUM 0xB4 Size 0x01 Data 0x03 EXT 0x03 Response packet format (Module -> host) Receiving “Data = 0x03 EWBS Signal”, and play out alert sound.

16

Flow of Emergency Signal Reception

EWBS Module [EWBS_out] → H Host CPU

No

CMD_GET_EWBS_STATUS (status) CMD_GET_EWBS_TEXT

status_bit0 == 1 Yes Completion of text reception No

(text_data_size=0) (text_data_size + Character_code)

Yes text_data_size=0 Yes EWBS Status Inquiry Obtain character information EWBS Reception Command Response No Display of character data End of EWBS

[EWBS_out] → L

End of Alarm Sound Switching off of character data indication 17

Chapter 3 Applied example of EWBS module

18

Public Electronic Signage

• Normally displaying information, ads, time, etc.
• Upon receiving EWBS, the display is switched to

warning information.

＋ Memory card LED display PC

insert LAN UART USB LAN

Control Unit Media for information, ads, etc.

HDMI

LCD Panel Speaker

19

Example of Control Circuit of Public Electronic Signage

Beagle Bone Black CPU Board uSD LAN USB HDMI EWBS module Antenna UART POWER

command (3.3V)

GPIO

EWBS_DET

GPIO

SIREN

PC LCD Panel LED Display USB Speaker LED Display RS-232C UART LED Display

20

21

List of Parts and Components

Item Reference Part Maker Quantity Comment 1 C1,C3,C7,C9,C10,C12,C13, C14,C15,C16 GRM188R71C104KA01D MURATA 10 0.1uF 2 C2,C8,C11 GRM188R61C105KA93D MURATA 3 1uF 3 C4,C5,C6 GRM188R61A106KE69D MURATA 3 10uF 4 FB2,FB1 BLM21PG221SN1D MURATA 2 BLM21PG221SN1D 5 FB3 BLM18KG601SN1D MURATA 1 BLM18KG601SN1D 6 J1 PJ-102A CUI Inc. 1 PWR JACK 7 J2 0731000258 Molex 1 731000258 8 J3 LD09P33E4GV00LF Amphenol FCI 1 DB9 9 R1 MCR03ERTJ104 Rohm 1 100k 10 R2,R3,R6,R7,R8 MCR03ERTJ220 Rohm 5 22 11 R4,R5,R9 MCR03ERTJ103 Rohm 3 10k 12 U1 LMS33460MG/NOPB TI 1 LMS33460MG/NOPB 13 U2 EWBSmodule Century 1 EWBSmodule 14 U3 ST3232CDR Stmicro 1 ST3232CDR 15 Z1 BeagleBoneBlack GHI Electronics 1 Beagle Bone Black

22

Example of Small Display for home use

EWBS module Antenna UART POWER

command (3.3V)

GPIO

EWBS_DET

GPIO

SIREN

CPU POWER I2C

TEXT

GIPO DAC

SOUND

Character Display Switch GPIO

23

24

List of Parts and Components

Item Reference Part Maker Quantity Comment 1CN1 10118192-0001LF Amphenol FCI 1 microUSB 2CN2 PRPC005SAAN-RC Sullins 1 CON5 3C1,C3,C8,C9,C10,C11,C12, C13,C14,C16,C17,C18,C19 GRM188R71C104KA01D MURATA 13 0.1uF 4C2 GRM188R61C105KA93D MURATA 1 1uF 5C4,C5,C6,C7,C15,C20,C21, C22 GRM188R61A106KE69D MURATA 8 10uF 6D1 GSE6V8UNX5F GLOBALTECH 1 GSE6V8UNX5F 7D2,D3 RB050L-40 Rohm 2 RB050L-40 8D4 RB521S-30TE61 Rohm 1 RB521S-30TE61 9FB2,FB1 BLM21PG221SN1D MURATA 2 BLM21PG221SN1D 10FB3,FB4,FB5,FB6 BLM18KG601SN1D MURATA 4 BLM18KG601SN1D 11J1 0731000258 Molex 1 731000258 12J2 PJ-102A CUI Inc. 1 PWR JACK 13J3 MJ-3536N CUI Inc. 1 PHONE JACK 14R1,R2,R5,R6,R7,R9,R10 MCR03ERTJ220 Rohm 7 22 15R3,R4,R8 MCR03ERTJ103 Rohm 3 10k 16R11,R17 MCR03ERTJ104 Rohm 2 100k 17R12,R13,R14,R15,R18,R19 MCR03ERTJ472 Rohm 6 4.7k 18R16 1 R* 19R20 MCR03ERTJ221 Rohm 1 220 20R21,R24 MCR03ERTJ102 Rohm 2 1k 21R22,R25 MCR03ERTJ151 Rohm 1 150 22R24,R23 MCR03ERTJ473 Rohm 2 47k 23SW1 OS102011MS2QN1 C&K 1 Slide Switch 24SW2,SW3,SW4 3-1825910-5 TE Connectivity 3 Tactile Switches 25U1 EWBS module Century 1 EWBSmodule 26U2 STM32F072C8T6 STmicro 1 STM32F072C8T6 27U3 GS1117Y33F GLOBALTECH 1 GS1117Y33F 28U4 LMS33460MG/NOPB TI 1 LMS33460MG/NOPB 29U5,U6 SN74LVC1G04DCKR TI 2 SN74LVC1G04DCKR 30U7 NJM2737V JRC 1 NJM2737V 31VR1 3314H-1-203 Bourns 1 20k(v) 32X1 CSTCE8M00G55-R0 MURATA 1 CSTCE8M00G55-R0 33Y1 PKM17EPP-2002-B0 MURATA 1 PKM17EPP-2002-B0 34ZD1 ACM1602NI Xiamen Zettler 1 LCD 16x2 Character Display

25

Evaluation of Reliability

 Standard of Capacitors Maximum Temperature: Rated maximum temperature minus 20 degrees Celsius

• r below. Consideration of self heating value and ambient temperature required.

Voltage: Rated voltage x 0.6 or below  Resistance Standard Power: Rated power x 0.6 or below Voltage: Rated voltage x 0.8 or below Rated Voltage = √(rated power x resistance value)  Inductor Standard Maximum Temperature: : Rated maximum temperature minus 20 degrees Celsius

• r below. Consideration of self heating value and ambient temperature required.

Derating evaluation of parts makes it possible to increase the reliability of the module.

26

 Semiconductors Power Voltage, Terminal Input Voltage: Within rated values Maximum Output Current: Rated Current x 0.8 or below Maximum junction temperature: Rating upper temperature minus 20 degrees Celsius or below. Consideration of self heating value and ambient temperature required.  Connectors Surface Temperature: Rated Maximum Temperature minus 20 degrees Celsius or

• below. Consideration of self heating value and ambient temperature required.

Maximum Voltage: Rated Voltage x 0.5 or below.

27

*The evaluation standards here are for reference only. Standards of acceptance, as well as items to be checked are to be determined by the party concerned.

Reference Type Part Number Manufacturer Voltage Temperature Judgment Voltage-Rated Derating rate Derating Voltage Operating Voltage Temperature-Rated Derating Temperature Operating Maximum Temperature V ％ V V ℃ ℃ ℃ C1 Ceramic(chip) GRM188R71C104KA01D MURATA 16.0 60 9.6 5.3 125 105 45 OK C2 Ceramic(chip) GRM188R61C105KA93D MURATA 16.0 60 9.6 5.3 125 105 45 OK C3 Ceramic(chip) GRM188R71C104KA01D MURATA 16.0 60 9.6 5.3 125 105 45 OK C4 Ceramic(chip) GRM188R61A106KE69D MURATA 10.0 60 6.0 5.3 125 105 45 OK C5 Ceramic(chip) GRM188R61A106KE69D MURATA 10.0 60 6.0 5.3 125 105 45 OK

Capacitors

• Capacitor Standard

Maximum Temperature: Rated Maximum Temperature minus 20 degrees Celsius or

• below. Consideration of self heating value and ambient temperature required.

Voltage: Rated Voltage x 0.6 or below

28

Resistors

• Resistor Standard

Power: Rated Power x 0.6 or below Voltage: Rated Voltage ＝ √(Rated Power x Resistance Value)

Reference Type Part Number Manufacturer Resistance Power Voltage Condition Power Derating Power Operating Voltage Operating Current Operating Power Calculated Rating Voltage Voltage-Rated Derating Voltage Operating Voltage Ω W W V ｍA W Ｖ Ｖ V Ｖ R1 Thick Film MCR03ERTJ220 Rohm 22.0 0.100 0.060 0.900 40.909 0.037 1.5 50 1.2 0.9 OK R3 Thick Film MCR03ERTJ103 Rohm 10,000.0 0.100 0.060 3.450 0.345 0.001 31.6 50 25.3 3.5 OK R12 Thick Film MCR03ERTJ472 Rohm 4,700.0 0.100 0.060 3.450 0.734 0.003 21.7 50 17.3 3.5 OK R20 Thick Film MCR03ERTJ103 Rohm 220.0 0.100 0.060 3.450 15.682 0.054 4.7 50 3.8 3.5 OK R25 Thick Film MCR03ERTJ103 Rohm 1,500.0 0.100 0.060 2.200 1.467 0.003 12.2 50 9.8 2.2 OK

29

Inductors, Coils, Ferrite Beads

• Inductor Standard

Maximum Temperature: Rated Maximum Temperature minus 20 degrees Celsius or

• below. Consideration of self heating value and ambient temperature required.

Reference Type Part Number Manufacturer Temperature Voltage Condition Temperature-Rated Derating Temperature Operating Ambient Temperature Temperature Rise Current-Rated Operating Current

• perating temperature rise

Operating temperature Voltage - Rated Derating Voltage Operating Voltage ℃ ℃ ℃ ℃ mA mA ℃ ℃ V V V FB1 FERRITE BEAD BLM21PG221SN1D MURATA 125 105 45 40.0 2000.0 500.0 2.5 47.5 100.0 50.00 5.25 OK FB2 FERRITE BEAD BLM21PG221SN1D MURATA 125 105 45 40.0 2000.0 500.0 2.5 47.5 100.0 50.00 5.25 OK FB3 FERRITE BEAD BLM18KG601SN1D MURATA 125 105 45 40.0 1300.0 500.0 5.9 50.9 100.0 50.00 5.25 OK FB4 FERRITE BEAD BLM18KG601SN1D MURATA 125 105 45 40.0 1300.0 500.0 5.9 50.9 100.0 50.00 5.25 OK FB5 FERRITE BEAD BLM18KG601SN1D MURATA 125 105 45 40.0 1300.0 75.0 0.1 45.1 100.0 50.00 3.45 OK

30

Incorporation into STB

Character information can be superimposed regardless of video receiving channel.

HDMI

Character information of power control is displayed by HDMI CEC function. Alert sound activated via STB.

Antenna Distributor EWBS module Tuner Module Screen controller HDMI I/F character information TV Power control HDMI

• ut

Siren

31

Incorporation into TV receivers

Antenna Distributor EWBS module Tuner Module Screen controller LCD controller character information PS control Power Supply Display Panel (EWBS_out)

Character information can be superimposed for automatic start-up, regardless video receiving channel.

32
