1 Receiver -1 Receiver Field Preparation Field Preparation June - - PDF document

Topcon GRS Topcon GRS-

• 1 Receiver

1 Receiver Field Preparation Field Preparation

June 2009

June 2009

Topcon GRS-1 Receiver - Field Preparation

• What do you need to know to get started with your Topcon GRS-1?
• Which TopSURV modules do I buy?
• How does the Topcon GRS-1 Receiver connect to the Internet?
• How do I setup a cell phone plan for my new Topcon GRS-1?
• How do I manage cell phone connections within the GRS-1 receiver?
• How do I know if my GRS-1 is successfully connected to the Internet?
• How do I send / receive an e-mail (with attachment) using the GRS-1?
• Did you know that the GRS-1 can tether to a computer that is already on the Internet?
• How can I see my position within Google Maps, live in the field?
• How do I install Topcon Receiver Utility (TRU) software on a GRS-1 receiver?
• How do I configure Topcon Receiver Utility (TRU) software to connect to a GRS-1 receiver?
• How do I use Topcon Receiver Utility (TRU) software to check a GRS-1 receiver?
• How do I setup TopSURV to connect to my GRS-1 to a local real time network?
• How do I add a Photo Note with the GRS-1?
• What do the colored lights on the front of the GRS-1 indicate?
• How do I switch from using the internal antenna to an external?
• How do I power the GRS-1 receiver?
• What options are there for external memory with the GRS-1 receiver?
• What are some tips and tricks with the Topcon GRS-1 receiver?

Some Common Questions Some Common Questions… …

June 2009

Topcon GRS-1 Receiver - Field Preparation

Topcon GRS Topcon GRS-

• 1 Receiver

1 Receiver

The GRS-1 receiver is a dual-frequency, GPS + GLONASS L1, L2 receiver and hand-held controller built to be the most advanced, compact, and portable receiver for the GIS and surveying market. An integrated electronic compass and digital camera make the GRS-1 an all-purpose device that can also be utilized as a field collector. The GRS-1 can receive and process both L1 and L2 signals while using an external PG-A1 antenna. The GRS-1 provides the functionality, accuracy, availability, and integrity needed for fast and easy data collection.

June 2009

Topcon GRS-1 Receiver - Field Preparation

What are options for Topcon GRS What are options for Topcon GRS-

• 1 hardware

1 hardware configurations? configurations?

• Survey Grade / Precision Mapping - for use as a

member of a Real Time Network. The configuration for this would be a GRS-1 receiver on the pole connected to an external PG-A1 antenna on top.

• Sub-meter – field work done without an external PG-A1
• antenna. Configured within TopSURV to use Satellite

Based Augmentation System (SBAS). Excellent for GIS code and attribute data collection, recognaissance, or rough delineation.

• Hand-Held Controller – Integrated mini serial port,

Bluetooth, and Wi-Fi wireless LAN technology allows the GRS-1 to be easily connected to all Topcon hardware.

June 2009

Topcon GRS-1 Receiver - Field Preparation

What do you need to know to get started with What do you need to know to get started with your Topcon GRS your Topcon GRS-

• 1?

1?

• All GRS-1 receivers will ship with TopSURV data

collection software.

• If the intent is to use the GRS-1 as a rover within a

Real Time Network, then you will want to start the process of getting the modem activated and online first.

• Check that unit has the latest version of Windows

Mobile operating system and TopSURV data collection software.

• Using Topcon Receiver Utility (TRU) software,

check that unit has latest receiver firmware.

June 2009

Topcon GRS-1 Receiver - Field Preparation

Which Which TopSURV TopSURV modules do I buy? modules do I buy?

• To have TopSURV support

using a GRS-1 within a Real Time Network, ensure that the GPS+ module is activated.

• Once the GPS+ module is

activated, user has option of adding Roading module if applicable.

• Add the Total Station module to support the common scenario of using a

GRS-1 as a controller for conventional field work.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How does the Topcon GRS How does the Topcon GRS-

• 1 Receiver

1 Receiver connect to the Internet? connect to the Internet?

• The Topcon GRS-1 receiver is able to establish a connection to the

internet in multiple ways:

– With internal modem (GSM or CDMA) – With external Bluetooth enabled cell phone (Bluetooth tethering) – With Wi-Fi, also called Wireless LAN (WLAN) – With ActiveSync connection to a computer that is on the internet

June 2009

Topcon GRS-1 Receiver - Field Preparation

How does the Topcon GRS How does the Topcon GRS-

• 1 Receiver

1 Receiver connect to the Internet? connect to the Internet?

• The primary method to have the GRS-1 receiver connect to the internet is to

use the internal cellular modem.

• There are two types of cellular modems available for the GRS-1 receiver:

– GSM (Global System for Mobile Communications) – CDMA (Code Division Multiple Access)

• The GRS-1 network receiver is also able to establish a wireless Bluetooth

connection to an external cell phone.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup a cell phone plan for my new How do I setup a cell phone plan for my new Topcon GRS Topcon GRS-

• 1?

1?

• The most important factor in deciding between the two types of internal

modems (GSM or CDMA) is coverage. Look at the coverage maps for the provider that you are considering.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup a cell phone plan for my new How do I setup a cell phone plan for my new Topcon GRS Topcon GRS-

• 1?

1?

• Topcon GRS-1 receivers are available with either an internal GSM or

CDMA modem. Only GSM modems use SIM (Subscriber Identity Module) cards. CDMA modems do not have SIM cards.

• Using either modem type, it is common to describe to the cellular

provider that you need a, “No Obligation / Unlimited data plan (no voice).” Tell the sales representative that you have your own hardware.

Common CDMA Providers Common GSM Providers

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I manage cell phone connections How do I manage cell phone connections within the GRS within the GRS-

• 1 receiver?

1 receiver?

• The Topcon GRS-1 receiver has Windows Mobile 6.1 Classic operating
• system. Within this operating system, Topcon has introduced the TPS

Connection Manager.

• TPS Connection Manager is a utility software that ships standard within

every GRS-1 receiver.

TPS Connection Manager

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I manage cell phone connections How do I manage cell phone connections within the GRS within the GRS-

• 1 receiver?

1 receiver?

• Within the TPS Connection Manager, select Create New Connection
• Entry. Work your way down the screen.
• For the Connection Name, ensure not to use any special characters such

as an “&” ampersand.

• Select a Modem type of Cinterion HC25. Tap Create when done.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I know if my GRS How do I know if my GRS-

• 1 is successfully

1 is successfully connected to the Internet? connected to the Internet?

• At top center of the desktop screen, there are two arrows that

indicate whether the GRS-1 receiver has a successful internet connection.

• When the arrows are facing left to right (shown above) then a

connection to the internet is made.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I send / receive an e How do I send / receive an e-

• mail (with

mail (with attachment) using the GRS attachment) using the GRS-

• 1?

1?

• Using the TPS Connection Manager within the GRS-1 receiver’s Windows

Mobile 6.1 desktop screen, you are able to establish a connection to the internet prior to launching TopSURV data collection software.

• This connection allows unlimited number of options for transferring data

such as File Transfer Protocol (FTP) software, using an e-mail account to send / receive attachments, Microsoft Live Mesh, etc.

June 2009

Topcon GRS-1 Receiver - Field Preparation

Did you know that the GRS Did you know that the GRS-

• 1 can tether to a

1 can tether to a computer that is already on the Internet? computer that is already on the Internet?

• Since the Topcon GRS-1 receiver has Windows Mobile operating system,

it is able to share an internet connection when tethered to a laptop / computer that is already on the internet.

• Tethering is using some type of device (laptop / computer) to gain internet

access for another mobile device (GRS-1 receiver).

June 2009

Topcon GRS-1 Receiver - Field Preparation

Did you know that the GRS Did you know that the GRS-

• 1 can tether to a

1 can tether to a computer that is already on the Internet? computer that is already on the Internet?

• If the laptop / computer that you are using is on the internet, once you

make an ActiveSync connection between it and a Topcon GRS-1 receiver, the GRS-1 is then also on the internet.

• This is ideal when performing maintenance and internet software installs in

the office.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How can I see my position within Google How can I see my position within Google Maps, live in the field? Maps, live in the field?

• To install the free software of Google Maps on your Topcon GRS-1

receiver, open Internet Explorer and go to:

http://m.google.com/maps

• To type the address, tap on the keyboard icon at bottom center.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How can I see my position within Google How can I see my position within Google Maps, live in the field? Maps, live in the field?

• Click the Install Now link.
• Ensure to check on the option of Open File After Download. Tap Yes.
• It is common to have the GRS-1 receiver on charge during this process.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How can I see my position within Google How can I see my position within Google Maps, live in the field? Maps, live in the field?

• Tap the Accept button at lower left to proceed.
• Tap the OK button to launch Google Maps on the Topcon GRS-1 receiver.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How can I see my position within Google How can I see my position within Google Maps, live in the field? Maps, live in the field?

• Within Google Maps software on the GRS-1 receiver, tap the Menu button

at lower right.

• Select the Use GPS option to have Google Maps read in the position of the

GRS-1 receiver.

June 2009

Topcon GRS-1 Receiver - Field Preparation

Questions? Questions?

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I install Topcon Receiver Utility (TRU) How do I install Topcon Receiver Utility (TRU) software on a GRS software on a GRS-

• 1 receiver?

1 receiver?

• All Topcon software is available for download from the Secure Site. To

access, go to:

http://www.topconsupport.com/secure_site/main.php

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I install Topcon Receiver Utility (TRU) How do I install Topcon Receiver Utility (TRU) software on a GRS software on a GRS-

• 1 receiver?

1 receiver?

• All Topcon software is available for download from the Secure Site. To

access, go to:

http://www.topconsupport.com/secure_site/main.php

• Within the Software and

Firmware section, click on Software Utilities.

• Then click on TRU link to

jump to download section.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I install Topcon Receiver Utility (TRU) How do I install Topcon Receiver Utility (TRU) software on a GRS software on a GRS-

• 1 receiver?

1 receiver?

• For the Topcon GRS-1 receiver, use TRU for Field Computers (10.9 Mb).
• You can then either click Run to install directly to a GRS-1 that has an

ActiveSync connection to your computer / laptop or Save to install later.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I install Topcon Receiver Utility (TRU) How do I install Topcon Receiver Utility (TRU) software on a GRS software on a GRS-

• 1 receiver?

1 receiver?

• This will launch the Topcon Receiver Utility –

InstallShield Wizard.

• When prompted, click Next to proceed.
• On your computer / laptop, click the OK button on

the Application Downloading Complete message.

• On the GRS-1 receiver, tap the OK button on the message screen (shown at

top right) to continue the software installation process.

• Done. Topcon Receiver Utility (TRU) software is now installed on your

Topcon GRS-1 receiver.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I install Topcon Receiver Utility (TRU) How do I install Topcon Receiver Utility (TRU) software on a GRS software on a GRS-

• 1 receiver?

1 receiver?

• To launch From the Windows Mobile desktop screen, tap the Start button.
• Go to Programs to see a listing of all software that is currently installed on

your GRS-1 receiver.

• For the initial launch of TRU software, scroll down and tap the Topcon

Receiver Utility icon.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I configure Topcon Receiver Utility (TRU) How do I configure Topcon Receiver Utility (TRU) software to connect to a GRS software to connect to a GRS-

• 1 receiver?

1 receiver?

• For the initial launch of TRU software, you will need to declare connection

settings for the GRS-1 receiver. This will only need to be done once and it will recalled for future connections.

• Tap the triple dot button below Port Name.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I configure Topcon Receiver Utility (TRU) How do I configure Topcon Receiver Utility (TRU) software to connect to a GRS software to connect to a GRS-

• 1 receiver?

1 receiver?

• Select the Friendly Name of GNSS Port B with Physical Name of COM6

as shown above.

• This will only have to be declared once within TRU software on your GRS-1
• receiver. Afterwards, tap the OK button.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I configure Topcon Receiver Utility (TRU) How do I configure Topcon Receiver Utility (TRU) software to connect to a GRS software to connect to a GRS-

• 1 receiver?

1 receiver?

• Lastly, tap the Connect button to establish a connection to your GRS-1

receiver with TRU software.

• Done. Once the background changes to a solid white color, you are actively

communicating to the GRS-1 receiver with TRU software.

June 2009

Topcon GRS-1 Receiver - Field Preparation

Questions? Questions?

June 2009

Topcon GRS-1 Receiver - Field Preparation

• With a connection made to the GRS-1 receiver with TRU software, tap the

Information icon to see a listing of the receiver firmware currently installed.

• Ensure that the GRS-1 receiver has Receiver Firmware Version 3.4 (build

date, 13 May 2009) or higher.

• All receiver firmware is available from the Topcon Secure Site.

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• There multiple ways to do this. The common method is to establish an

internet connection prior to opening TopSURV using TPS Connection Manager utility.

• Check Cellular Power first, then check Data Connection. Once the GRS-1

is connected to the Internet, launch TopSURV data collection software.

TPS Connection Manager

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• From the TopSURV main menu, go to CONFIG / SURVEY to see a listing of

Survey Styles. Tap the triple dot button to the right of GPS+ Config.

• Select the Configuration template of My Network RTK and tap Edit.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• You can rename or use default name of My Network RTK. Either way,

ensure Type is Network RTK and Corrections is VRS.

• Declare a rover Antenna Type of PG-A1.
• The Post Process method is an optional check box dependant on the type
• f field work about to be performed.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• Since you have established an internet connection with TPS Connection

Manager prior to opening TopSURV, ensure to select the Modem Connect

• ption of Controller and a Network Type of Existing Network

Connection.

• Next, Add the public IP Address and Port Number of your real time network.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• Enter the NTRIP (Networked Transport of RTCM via Internet Protocol) User

Identification and Password issued to you from your real time network manager.

• For the GRS-1 receiver, the Virtual Radio Port is D.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• From this point forward within the TopSURV configuration screens, all
• ptions are user definable.
• Shown here are commonly used settings.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• Within the Advanced screen, it is common to check on the option of

Multipath Reduction.

• The Satellite System selection is dependant on whether the real time

network that you are joining tracks and uses GLONASS satellites.

• Click Finish and OK to return to the TopSURV main menu.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• With the TopSURV Survey Configuration now made, a convenient Network

Connection dialog will appear and automatically begin the process of connecting to your real time network.

• The Mount Point listing will populate and you will see a message showing

Network Connection Started. Tap Close.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I setup How do I setup TopSURV TopSURV to connect to my to connect to my GRS GRS-

• 1 to a local real time network?

1 to a local real time network?

• The Network Connection screen is made

available to you one last time to perhaps change from the Mount Point that you commonly use.

• If you are going change from your usual

Mount Point, tap Disconnect, select a different Mount Point, and tap Connect.

• Otherwise, to use the same Mount Point from

a previous field survey (common), simply tap the OK button.

June 2009

Topcon GRS-1 Receiver - Field Preparation

Questions? Questions?

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I add a Photo Note with the GRS How do I add a Photo Note with the GRS-

• 1?

1?

• The GRS-1 receiver has an integrated 2 megapixel camera.
• Within TopSURV,

simply tap the Attribute button

• Tap the Photo Note

tab, and the Add

• button. Select Capture.
• Aim at the target and tap the

camera button. The photo is automatically associated with that point.

June 2009

Topcon GRS-1 Receiver - Field Preparation

What do the colored lights on the front of the What do the colored lights on the front of the GRS GRS-

• 1 indicate?

1 indicate?

June 2009

Topcon GRS-1 Receiver - Field Preparation

What do the colored lights on the front of the What do the colored lights on the front of the GRS GRS-

• 1 indicate?

1 indicate?

• The Bluetooth / Wireless LAN

– Blue blink: Internal Bluetooth device is powered on and ready – Red blink: Wireless LAN is powered on and ready – Violet blink: Notification from Windows – No light: The module is currently powered off

• The Recharging LED indicates the level of charge of the onboard battery

– Green: Internal battery has a full charge – Red: Internal battery is charging – Red blink: Charging error (disconnect charging cable and reconnect)

• The Cell Phone LED indicates the receiving status in the cell phone

modem

– No light: Internal cellular modem is currently powered off – Green: Internal cellular modem is available – Red: Internal cellular modem is does not have signal from cell network

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I switch from using the internal How do I switch from using the internal antenna to an external? antenna to an external?

• Two steps:

– Physically connect external PG-A1 antenna to GRS-1 receiver with custom cable. – Select TopSURV configuration to support hardware change.

June 2009

Topcon GRS-1 Receiver - Field Preparation

How do I power the GRS How do I power the GRS-

• 1 receiver?

1 receiver?

• The GRS-1 uses a BT-66Q battery for it’s primary power source. When

using the GRS-1 for static surveys, the battery will last up to four hours.

• A backup coin battery and rechargeable battery back up the GPS and clock

settings.

June 2009

Topcon GRS-1 Receiver - Field Preparation

What options are there for external memory What options are there for external memory with the GRS with the GRS-

• 1 receiver?

1 receiver?

• Removable Secure Digital (SD) memory cards can be used with the GRS-1

receiver to provide additional data storage, as well as data transfer.

• The GRS-1 supports SD cards with up to a 2 GB capacity. This device does

not currently support Secure Digital High Capacity (SDHC) memory cards.

June 2009

Topcon GRS-1 Receiver - Field Preparation

What are some tips and tricks with the What are some tips and tricks with the Topcon GRS Topcon GRS-

• 1 receiver?

1 receiver?

• If you are trying to make a connection to a GRS-1 using either Topcon

Receiver Utility (TRU) or PC-CDU, make sure that you power the GPS receiver on first.

• To turn the GPS Receiver Power on / off, use TPS Connection Manager

from the Windows Mobile desktop (bottom right corner).

• Without the external PG-A1 antenna, the onboard antenna of the GRS-1

receiver is L1 signal only. Only while using an external PG-A1 antenna will you be able to track and use more than L1 single frequency.

Topcon GRS Topcon GRS-

• 1 Receiver

1 Receiver Field Preparation Field Preparation

June 2009
