Henway Technologies Custom Circuit Board Design

HUDSON, OHIO

Schematic design PCB layout Firmware PCB assembly Production

HUDSON, OHIO

HENWAY HAS 10 YEARS OF EXPERIENCE

helping customers through the custom circuit development process.

www.henwaytech.com 3

No experience needed for engagement We create electronics requirements docs Host weekly teleconferences Internal design reviews Produce and debug prototypes Deliver documented samples

OUR HISTORY WITH BLUETOOTH

www.henwaytech.com 4

We started in the early days of Bluetooth Classic (SPP and A2DP) Over 7 years experience with Bluetooth Low Energy (4.0, 4.2 and 5)

IN 2020

alone we’ve worked on over 12 unique Bluetooth projects. 3 more starting soon

5

⦿ Automotive rack tracking (Est. sales volume 300k Bluetooth radios per year) ⦿ LR Bluetooth radios powered by Hydrogen Fuel Cell technology for military use ⦿ Bluetooth apps for medical grade sanitation devices ⦿ Putting Bluetooth radios on K-9 units for next generation emergency response teams ⦿ and many more

www.henwaytech.com EXAMPLE

BLUETOOTH DATA LOGGING

www.henwaytech.com 6

We can do anything involving reading from sensors, storing the data, and transmitting logged data via Bluetooth

Designed a battery powered device that resides near a motor shaft that counts the revolutions of the motor and its speed and sends this information over bluetooth

EXAMPLE

BLUETOOTH DATA LOGGING

www.henwaytech.com 7

Compact wearable Bluetooth designs in printed ink sensor application

Designed a battery powered device that auto-calibrates and auto-zeroes a conductive ink force sensor and sends this information over Bluetooth to a mobile app. The mobile app is able to keep connection with 2 devices simultaneously.

EXAMPLE

BLUETOOTH DATA LOGGING

www.henwaytech.com 8

Using Bluetooth to quantify machine performance and assist those responsible for preventative maintenance

A device that captures, analyzes in real-time, and buffers large amounts of data from a special motion sensor. Special algorithms are used to determine if motor vibrations are within tolerance. Operators can view this information on a mobile app in real time

• r download buffered data for in-depth analysis.

UP & COMING PROJECT

HIGH RELIABILITY

www.henwaytech.com 9

Transfer data safely without corruption

Designed battery powered device that took commands from a gateway and streamed accelerometer readings to the gateway via bluetooth. Imagine 6 devices and a hub that communicates with sensors one by one in a high vibration, harsh

• environment. Anything can happen

EXAMPLE

HIGH RELIABILITY

www.henwaytech.com 10 EXAMPLE

⦿ Made sure data was sent and received without corruption ⦿ Sensor values were stored until data was received ⦿ The system detected if the data was corrupted ⦿ Self recovery ⦿ Performed self-diagnostics ⦿ Sealed design non-user replaceable batteries

LONG BATTERY LIFE

www.henwaytech.com 11

We choose the best settings for the longest battery life. And we verify our results using SiLabs tools

EXAMPLE

Designed a sensor data-logging device where we needed to use advanced methods for optimizing the duration of data transfer and frequency.

LONG BATTERY LIFE

www.henwaytech.com 12

ADVERTISING TX DETAILS ADVERTISING TX DETAILS

Make power assumptions Build Prototype Verify the results

HIGH SECURITY

www.henwaytech.com 13

We’ve implemented all three levels of Bluetooth built-in security and we’ve developed our own security and encryption

Designed a device that stores secret info that sends and receives sensitive information over Bluetooth to a mobile device or PC. We have also implemented our own security on top of the existing security

EXAMPLE

HIGH SECURITY

www.henwaytech.com 14 EXAMPLE

⦿ All the Bluetooth communication for this project, even the advertising data, was encrypted using AES-128 key ⦿ Implementation of a Diffie–Hellman 3072 bit key-exchange for pairing on an 8-bit device. ⦿ Secure OTA update (download encrypted firmware image, decrypt and update in real time)

BLUETOOTH AUDIO

www.henwaytech.com 15

We’ve used Bluetooth audio profiles for non-audio data transfer

Designed a battery powered medical device for contact-less heart rate monitoring

EXAMPLE

BLUETOOTH AUDIO

www.henwaytech.com 16 EXAMPLE

⦿ Analog circuitry captures the patient's heartbeats ⦿ Used a Bluetooth classic module running A2DP profile to send the heartbeat information encoded as audio signal to a mobile app ⦿ Mobile app records the information and shows it in real time ⦿ Low cost: there was no processor on the board,

• nly analog circuitry and Bluetooth classic

module.

APP-LESS WAY TO USE THE BLUETOOTH PROTOCOLS FOR IOS AND ANDROID

www.henwaytech.com 17 EXAMPLE

Designed a small, 3-Button device that fit on your finger for the adrenaline seeking selfie market

Control Android and iOS devices without installing any app

APP-LESS WAY TO USE THE BLUETOOTH PROTOCOLS FOR IOS AND ANDROID

www.henwaytech.com 18 EXAMPLE

Using 3 buttons and SIG standard profiles, the user can control their phone, in this way:

Play / Pause music. Play next / prev track Control phone volume Answer phone calls Switch apps Open camera app Take pictures / Capture video
