CETO solutions in intra-logistic Customized & Engineered to Order PALLET HANDLING Antpoda Lda. Rua de Julieta Ubaldina Miranda 106, Lote 17 4470-441 Maia Portugal Phone: +351 229 535 437 Email: antipoda@antipoda.eu Website:
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
CATALOGUE – PALLET HANDLING V3.1 08/2016
Antípoda Lda. Rua de Julieta Ubaldina Miranda 106, Lote 17 4470-441 Maia – Portugal Phone: +351 229 535 437 Email: antipoda@antipoda.eu Website: www.antipoda.eu
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
2
Electrical I&D Innovation and Design Automation Mechanical Planning
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
3
RC T 10 N - Roller Conveyor, Tangential Chain, Pallet, Steel frame ............................................................................................................................................................................ 5 RC R 10 N - Roller Conveyor, Roller to Roller, Pallet, Steel frame ............................................................................................................................................................................... 9 SUPPORT LEGS – Steel and welded tube supports ................................................................................................................................................................................................... 13 ACESSORIES FOR ROLLER CONVEYORS ..................................................................................................................................................................................................................... 14 RC R 11 E - Roller Conveyor, Roller to Roller, “E” Shape, Pallet, Steel frame ............................................................................................................................................................ 16 RC R 11 N - Roller Conveyor, Roller to Roller, Steel frame ........................................................................................................................................................................................ 18 CC 2/3 - Chain Conveyor ............................................................................................................................................................................................................................................ 20 TR 3 8/1 – Pallet Transfer .......................................................................................................................................................................................................................................... 23 RTT 8/1 - Roller Turntable ......................................................................................................................................................................................................................................... 25 RGV 8/1 - Rail Guided Vehicle ................................................................................................................................................................................................................................... 27 PPD 8/1 10/15 – Pneumatic Pallet Destacker ........................................................................................................................................................................................................... 29 PSG 8/1 10/15– Pallet Stack Guide ........................................................................................................................................................................................................................... 31
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
4
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
5
Maximum Load: 900 kg/pallet for roller pitch 200 mm; 1200 kg/pallet for roller pitch 175 mm and 1500 kg/pallet for roller pitch 150 mm; Speed: 12m/min (50Hz); Structure: Main frame in powder coated steel, horizontal application, support height, 300-600 mm TOR (top-of-roller) with +- 25 mm adjustment (see
page 17);
Roller: Zinc plated rollers, Ø89 mm; Drive Medium: SEW gear motor positioned at the middle of the conveyor length. Rollers driven by 10B-1 tangential chain. Reversible; Roller wings: steel welded at the center or on both sides of the rollers upon request; Empty pallet indexer: Pneumatic empty pallet indexer upon request (see page 19); Stopper: Pneumatic Stopper and fixed stopper upon request (see page 19). H (TOR*) *TOR – Top of the roller L Pallet 800 x 1200: S = 1040 mm Pallet 1000 x 1200: S = 1240 mm S Pallet 800 x 1200: RL = 930 mm Pallet 1000 x 1200: RL = 1130 mm RL
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
6
800/1000 mm PALLET WIDE, PITCH 150 mm 800/1000 mm PALLET WIDE, PITCH 150 mm
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
1350 1 3 2 3900 3 9 4 1500 1 3 2 4050 3 10 4 1650 1 4 2 4200 3 10 4 1800 1 4 2 4350 3 10 4 1950 1 4 2 4500 3 11 4 2100 1 5 2 4650 3 11 4 2250 1 5 2 4800 3 11 4 2400 1 5 2 4950 4 12 4 2550 2 6 3 5100 4 12 5 2700 2 6 3 5250 4 13 5 2850 2 7 3 5400 4 13 5 3000 2 7 3 5550 4 13 5 3150 2 7 3 5700 4 14 5 3300 2 8 3 5850 4 14 5 3450 2 8 3 6000 4 14 5 3600 2 8 3 3750 3 9 3 PITCH 150 mm 800/1000 mm 1200 mm
TANGENTIAL CHAIN
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
7
800/1000 mm PALLET WIDE, PITCH 175 mm 800/1000 mm PALLET WIDE, PITCH 175 mm
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
1400 1 3 2 4375 3 10 4 1575 1 3 2 4550 3 11 4 1750 1 4 2 4725 3 11 4 1925 1 4 2 4900 4 12 4 2100 1 5 2 5075 4 12 5 2275 1 5 2 5250 4 13 5 2450 2 6 2 5425 4 13 5 2625 2 6 3 5600 4 13 5 2800 2 6 3 5775 4 14 5 2975 2 7 3 5950 4 14 5 3150 2 7 3 6125 4 15 5 3325 2 8 3 3500 2 8 3 3675 3 9 3 3850 3 9 4 4025 3 10 4 4200 3 10 4 PITCH 175 mm 800/1000 mm 1200 mm
TANGENTIAL CHAIN
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
8
800/1000 mm PALLET WIDE, PITCH 200 mm 800/1000 mm PALLET WIDE, PITCH 200 mm
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
1200 1 2 2 4600 3 11 4 1400 1 3 2 4800 3 11 4 1600 1 3 2 5000 4 12 4 1800 1 4 2 5200 4 12 5 2000 1 4 2 5400 4 13 5 2200 1 5 2 5600 4 13 5 2400 1 5 2 5800 4 14 5 2600 2 6 3 6000 4 14 5 2800 2 6 3 3000 2 7 3 3200 2 7 3 3400 2 8 3 3600 2 8 3 3800 3 9 4 4000 3 9 4 4200 3 10 4 4400 3 10 4 PITCH 200 mm 800/1000 mm 1200 mm
TANGENTIAL CHAIN
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
9
Maximum Load: 900 kg/pallet for roller pitch 198,44 mm; 1200 kg/pallet for roller pitch 174.63 mm and 1500 kg/pallet for roller pitch 150,81 mm; Speed: 12m/min (50Hz); Structure: Main frame in powder coated steel, horizontal application, support height, 300-600 mm TOR (top-of-roller) with ± 25 mm adjustment (see page
17);
Roller: Zinc plated rollers, Ø89 mm; Drive Medium: SEW gear motor positioned at the middle of the conveyor length. Rollers driven by 10B-1 chain roller to roller. Reversible; Roller wings: steel welded at the center or on both sides of the rollers upon request; Empty pallet indexer: Pneumatic empty pallet indexer upon request (see page 19); Stopper: Pneumatic Stopper and fixed stopper upon request (see page 19). *TOR – Top of the roller H (TOR*) L Pallet 800 x 1200: S = 1087 mm Pallet 1000 x 1200: S = 1287 mm S RL Pallet 800 x 1200: RL = 930 mm Pallet 1000 x 1200: RL = 1130 mm
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
10
800/1000 mm PALLET WIDE, PITCH 150,81 mm 800/1000 mm PALLET WIDE, PITCH 150,81 mm
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
1350 1 3 2 3900 3 9 4 1500 1 3 2 4050 3 10 4 1650 1 4 2 4200 3 10 4 1800 1 4 2 4350 3 10 4 1950 1 4 2 4500 3 11 4 2100 1 5 2 4650 3 11 4 2250 1 5 2 4800 3 11 4 2400 1 5 2 4950 4 12 4 2550 2 6 3 5100 4 12 5 2700 2 6 3 5250 4 13 5 2850 2 7 3 5400 4 13 5 3000 2 7 3 5550 4 13 5 3150 2 7 3 5700 4 14 5 3300 2 8 3 5850 4 14 5 3450 2 8 3 6000 4 14 5 3600 2 8 3 3750 3 9 4 PITCH 150,81 mm 800/1000 mm 1200 mm
ROLLER TO ROLLER
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
11
800/1000 mm PALLET WIDE, PITCH 174,63 mm 800/1000 mm PALLET WIDE, PITCH 174,63 mm
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
1400 1 3 2 4375 3 10 4 1575 1 3 2 4550 3 11 4 1750 1 4 2 4725 3 11 4 1925 1 4 2 4900 4 12 4 2100 1 5 2 5075 4 12 5 2275 1 5 2 5250 4 13 5 2450 2 6 2 5425 4 13 5 2625 2 6 3 5600 4 13 5 2800 2 6 3 5775 4 14 5 2975 2 7 3 5950 4 14 5 3150 2 7 3 6125 4 15 5 3325 2 8 3 3500 2 8 3 3675 3 9 3 3850 3 9 4 4025 3 10 4 4200 3 10 4 PITCH 174,63 mm 800/1000 mm 1200 mm
ROLLER TO ROLLER
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
12
800/1000 mm PALLET WIDE, PITCH 198,44 mm 800/1000 mm PALLET WIDE, PITCH 198,44 mm
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS WINGS Nᵒ OF LEGS (see specs on
1200 1 2 2 4600 3 11 4 1400 1 3 2 4800 3 11 4 1600 1 3 2 5000 4 12 4 1800 1 4 2 5200 4 12 5 2000 1 4 2 5400 4 13 5 2200 1 5 2 5600 4 13 5 2400 1 5 2 5800 4 14 5 2600 2 6 3 6000 4 14 5 2800 2 6 3 3000 2 7 3 3200 2 7 3 3400 2 8 3 3600 2 8 3 3800 3 9 4 4000 3 9 4 4200 3 10 4 4400 3 10 4 PITCH 198,44 mm 800/1000 mm 1200 mm
ROLLER TO ROLLER
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
13
Supports with powder coated finish;
Steel legs: laser cutted steel thickness of 4 and 6 mm;
Welded tube legs: Vertical tube 80x40x2 and horizontal tube 40x40x2 mm.
SUPPORT LEGS - STEEL HEIGHT- TOR* (mm) 300 - 600 SUPPORT LEGS - STEEL HEIGHT- TOR* (mm) 300 - 600 *TOR – Top of the roller
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
14
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
15
Walkover plates: allow to pass over the conveyor when access is needed. Made in zinc plated steel with teardrop pattern; Fixed end stopper: final bumper for pallets fixed on the conveyor. Made in zinc plated steel or RAL 1021; Pneumatic stopper: allow to stop empty pallets with accuracy. To be use with robot cells. Pneumatic cylinder ISO 15552. Stopper
plate in zinc plated steel or RAL 1021;
Pneumatic indexer: allow index empty pallets with accuracy to one side of the conveyor. To be use with robot cells. Pneumatic
cylinder ISO 15552. Indexer shaft and side guide in zinc plated steel or RAL 1021;
Photocell and mirror support: Support bracket adjustable in height 150 mm. Support fixed to an aluminium profile guide to allow
easy positioning of the support in all conveyor length. Extra lateral protection as an optional;
Forklift bumper: UPN 120 main structure with adjustable front steel plate 6 mm thickness. Fixed to the ground.
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
16
Conveyor length: 1660 mm (L); Maximum Load: 1200 kg/pallet; Speed: 12 m/min (50Hz); Structure: Main frame in powder coated steel, horizontal application; Height: 110 mm TOR (top-of-roller) with + 25 mm adjustment; Roller: Zinc plated rollers, Ø80 mm. Standard pitch 166 mm; Drive Medium: SEW gear motor positioned at the top of the conveyor length. Rollers driven by 10B-1 chain roller to roller. L = 1660 mm S Pallet 800 x 1200: S = 1320 mm Pallet 1000 x 1200: S = 1520 mm Roller Pitch 166 mm Pallet 800 x 1200: RL = 930 mm Pallet 1000 x 1200: RL = 1130 mm RL
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
17
RC R 11 E 8 - 800 mm PALLET WIDE RC R 11 E 1 - 1000 mm PALLET WIDE Dim. MAXIMUM Nᵒ OF PALLETS Dim. MAXIMUM Nᵒ OF PALLETS
L - CONVEYOR LENGTH (mm)
1660 1
L - CONVEYOR LENGTH (mm)
1660 1
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
18
Conveyor length: 1500 to 3000 mm (L); Low side frame: 105 mm Maximum Load: 1200 kg/pallet. Speed: 12 m/min (50Hz); Structure: Main frame in powder coated steel, horizontal application; Height: 110 mm TOR (top-of-roller) with + 25 mm adjustment; Roller: Zinc plated rollers, Ø80 mm. Standard pitch 166,69 mm; Drive Medium: SEW gear motor positioned at the middle of the conveyor length. Rollers driven by 10B-1 chain roller to roller. L Pallet 800 x 1200: S = 1300 mm Pallet 1000 x 1200: S = 1500 mm RL S Pallet 800 x 1200: RL = 930 mm Pallet 1000 x 1200: RL = 1130 mm
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
19
800/1000 mm PALLET WIDE, PITCH 166,69 mm
L - CONVEYOR LENGTH (mm)
MAXIMUM Nᵒ OF PALLETS Nᵒ OF LEGS 1500 1 3 1666 1 3 1832 1 3 1998 1 3 2164 1 3 2330 1 3 2496 1 4 2662 2 4 2828 2 4 2994 2 4 PITCH 166,69 mm 800/1000 mm 1200 mm
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
20
Conveyor length from 1300 up to 3600 mm (L); 2 and 3 Strand Chain 10B-2, center distance multiple of 350 or 440 mm; Maximum Load: 1000 kg/pallet for 2 strand and 1500 kg/pallet for 3 strand. Maximum of 2 pallets Chain Speed: 12 m/min (50Hz); Structure: Main frame in powder coated steel, horizontal application; Support height: 300-600 mm TOC (top-of-chain) with +- 25 mm adjustment (H); Drive Medium: SEW gear motor positioned on the side. Reversible; Side guides: Square 40x40 mm tube side guide, adjustable 140 mm horizontally. *TOR – Top of the roller H (TOR*) L
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
21
CC 2 - Chain Conveyor 2 Strand CC 3 - Chain Conveyor 3 Strand
L - CONVEYOR LENGTH (mm)
Maximum Weight on Conveyor (kg) Nº of Legs
L - CONVEYOR LENGTH (mm)
Maximum Weight on Conveyor (kg) Nº of Legs 1300 1000 2 1300 1500 2 1500 1000 2 1500 1500 2 1600 1000 2 1600 1500 2 1800 1000 2 1800 1500 2 2000 2000 2 2000 3000 2 2200 2000 2 2200 3000 2 2400 2000 2 2400 3000 2 2600 2000 3 2600 3000 3 2800 2000 3 2800 3000 3 3000 2000 3 3000 3000 3 3200 2000 3 3200 3000 3 3400 2000 3 3400 3000 3 3600 2000 3 3600 3000 3
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
22
Side guides: adjustable side guides. Made in square tube 40 mm. Finish in zinc plated or RAL 1023;
Fixed end stopper: final bumper for pallets fixed on the conveyor. Made in zinc plated steel or RAL 1023;
Forklift bumper: UPN 120 main structure with adjustable front steel plate 6 mm thickness. Fixed to the ground.
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
23
Pallet Transfer System for pallets dimensions of 800 x 1200 and 1000 x 1200 mm; Maximum Load: 1500 kg/pallet; Speed: Rollers/ chains speed 12 m/min (50Hz); Structure: Main frame in powder coated steel, horizontal application; Rollers: Zinc plated rollers, Ø89 mm. Standard pitch 180 mm; Chains: 10B-2 chains w/ straight plates. 540 mm between chains; Single level system: lift/lower of the chains/rollers at same time to allow product height never changes; Support height, 400-600 mm TOR/C (top-of-roller/chain) with +- 25 mm adjustment (H); Drive Medium: All SEW gear motors.
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
24
Lateral side stopper: side stopper for incoming pallets from chains to rollers. Made in zinc plated steel or RAL 1021;
Fixed end stopper: final end stopper for incoming pallets from roller conveyor. Made in zinc plated steel or RAL 1021;
TR 3 8 - 800 mm PALLET WIDE TR 3 1 - 1000 mm PALLET WIDE Dim. MAXIMUM Nº OF PALLETS Dim. MAXIMUM Nº OF PALLETS
L - CONVEYOR LENGTH (mm)
1450 1
L - CONVEYOR LENGTH (mm)
1450 1 Pallet 800 x 1200: S = 1088 mm Pallet 1000 x 1200: S = 1288 mm L = 1450 S *TOR/C – Top of the roller/ Top of the chain H(TOR*)
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
25
Roller turntable for pallets 800 x 1200 and 1000 x 1200 mm; Maximum Load: 1200 kg/pallet; Roller Speed: 12 m/min (50Hz); Table speed: 5 r.p.m.; Structure: Main frame in powder coated steel, horizontal application. Main structure of the conveyor supported by roller bearing; Support height 400-600 mm TOR (top-of-roller) with 25 mm adjustment; Roller: Zinc plated rollers, Ø80 mm; Roller Drive Medium: SEW gear motor positioned at the top of the roller conveyor frame. Reversible; Rotation Drive Medium: SEW gear motor positioned on the side of the base frame. Stop position from -90ᵒ to + 90ᵒ; Pneumatic locking device (optional): Pneumatic locking device for applications where stop position accuracy is needed at -90ᵒ, 0ᵒ and + 90ᵒ positions.
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
26
RTT 8 - 800 mm PALLET WIDE RTT 1 - 1000 mm PALLET WIDE Dim. MAXIMUM PALLETS Dim. MAXIMUM PALLETS
L - CONVEYOR LENGTH (mm)
1617 1
L - CONVEYOR LENGTH (mm)
1617 1 ACESSORIES PN - PNEUMATIC LOCKING DEVICE FR - FREE ROLLERS *TOR – Top of the roller H(TOR*) L = 1617 mm Pallet 800 x 1200: S = 1556 mm Pallet 1000 x 1200: S = 1756 mm S
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
27
Roller conveyor for pallets 800 x 1200 and 1000 x 1200 mm; Maximum Load: 1500 kg/pallet; Roller Speed: 12 m/min (50Hz); Max. RGV speed: 30 m/min (50Hz); Max. acceleration/decelerating: 0,1 m/s2; Structure: Main frame in powder coated steel, horizontal application; Support height 400-600 mm TOR (top-of-roller) with 25 mm adjustment; Roller: Zinc plated rollers, Ø89 mm; Roller Drive Medium: All SEW gear motors.
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
28
800 mm PALLET WIDE 1000 mm PALLET WIDE Dim. MAXIMUM PALLETS Dim. MAXIMUM PALLETS
L - CONVEYOR LENGTH (mm)
1500 1
L - CONVEYOR LENGTH (mm)
1500 1 RGV ACESSORIES RGV BUMPER RAIL CABLE CARRIER + FIXATION TO RGB Pallet 800 x 1200: S = 1040 mm Pallet 1000 x 1200: S = 1240 mm S L *TOR – Top of the roller H (TOR*)
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
29
Destacker for 800 x 1200 or 1000 x 1200 mm pallets; Available in two sizes: max. number of pallets 10 and 15; Pallets infeed: transversal (1200 mm) or longitudinal (800 or 1000 mm); Pallet can be outfeed transversal or longitudinal way; For conveyors from 300 to 600 mm TOR (top-of-roller); Roller conveyor included; Forklift bumper as an optional.
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
30
800 mm PALLET WIDE 1000 mm PALLET WIDE MAXIMUM PALLETS MAXIMUM PALLETS 10 15 10 15
Infeed Outfeed LEGEND:
All drawings/ documents are owned by Antípoda. It is prohibited to reproduce, copy or use the content in any format, in part or in whole without Antípoda’s written authorization.
31
Guide for 800 x 1200 or 1000 x 1200 mm pallet stack; Used to guide a stack of pallets throw a conveyor. Can be used to aligned pallets to be destacked by a robot cell; Available in two sizes: max. number of pallets 10 and 15; Pallets infeed: longitudinal (800 or 1000 mm); For conveyors from 300 to 600 mm TOR (top-of-roller); Roller conveyor not included;
