SLIDE 1
1
Local Airports
2
- Civilian
- San Diego
International
- Montgomery
Field
- Brown Field
- Navy
- Naval Air Station
North Island
- Naval Outlying
Centennial 1917 - 2017 1 Local Airports Civilian San Diego - - PowerPoint PPT Presentation
Centennial 1917 - 2017 1 Local Airports Civilian San Diego - - PowerPoint PPT Presentation
Naval Air Station North Island Centennial 1917 - 2017 1 Local Airports Civilian San Diego International Montgomery Field Brown Field Navy Naval Air Station North Island Naval Outlying Landing Field Imperial Beach
SLIDE 2
SLIDE 3
3
San Diego Airspace
- Complex airspace
and air traffic control (ATC) structure
- San Diego airport
airspace and runway configuration influence aircraft
- perations
throughout San Diego County
SLIDE 4
- Naval Air Station North Island Units
- Commander Helicopter Sea Combat Wing/Commander
Helicopter Maritime Strike Wing
- Fleet Readiness Center Southwest
- Fleet Logistics Squadron (VRC) 30
- Fleet Logistics Support Squadron (VR) 57
- Flight International/L3/Windbreaker
- U. S. Customs and Border Protection
- Transient Aircraft
- Tactical
- Passenger/Cargo
Air Operations Overview
4
SLIDE 5
5 NAS North Island NOLF Imperial Beach Brown Field1 San Diego International1 Montgomery Field1
2010 102,482 235,581 89,730 190,137 191,868 2014 80,349 192,457 90,139 191,765 215,120 2015 81,148 199,819 92,676 193,712 213,848 20162 83,181 193,549 79,207 180,536 184,494
Airfield Operations
1 http://aspm.faa.gov/opsnet/sys/Main.asp?force=atads
201/2016 – 11/2016 3http://www.san.org/News/Air-Traffic-Reports
NAS North Island San Diego International3
2014 88,250 19,019,654 2015 82,978 20,322,360 2016 68,790 Not Available
Air Terminal/Passenger Operations
Annual Operations
SLIDE 6
- Airfield hours
- Runway Use
Program
6
Noise Abatement Procedures
SLIDE 7
- Aircraft Approaches Restrictions
- Transient Aircraft Restrictions
- Engine Run-up Operations
- Visual Flight Rule Helicopter Course Rules
- Navy imposed City Overflight Restrictions
7
Noise Abatement Procedures
SLIDE 8
Flight Rules
- Visual Meteorological
Condition (VMC) and Visual Flight Rules (VFR)
- Good weather
- Limited ATC Services
- Instrument
Meteorological Condition (IMC) and Instrument Flight Rules (IFR)
- Bad Weather
- Full ATC Services
8
SLIDE 9
Hotel Visual Approach RWY 29
- IFR procedure
- Way for a pilot operating
under IFR to proceed visually and clear of clouds to an airport
- Increased use would
burden a complex ATC system and increase flights along the beach
9
SLIDE 10
VFR Helicopter Routes
10
- Surf Arrival/departure
- Bay Arrival/Departure
- Channel
Arrival/Departure
SLIDE 11
Comparison
11
SLIDE 12
Precision Approach Radar
12
- Runway 29
- Centerline
- Off-set
- Box Pattern,
Air Traffic Control Radar Vector to final approach courses
SLIDE 13
Helicopter Flight Tracks
13
- Data provided by FAA
- Depicts 4,587 tracks
below 3,000 feet during month of August 2016
- Reflects efforts to
keep helicopters
- perations over water
SLIDE 14
Coronado Cays
14
SLIDE 15
Coronado Village
15
SLIDE 16
Concerns or comments may be submitted by an electronic feedback form at: http://www.cnic.navy.mil/regions/cnrsw/installations/nav base_coronado/about/CommunityConcerns.html
- r;
via the Naval Base Coronado Community Concerns Hot Line at (619)545-8847
Community Concerns Hot Line
16
SLIDE 17
17
BACKUP
SLIDE 18
AIRPORTS
18
