KINGFIELD CENTENNIAL BRIDGE #5852 WEARING SURFACE REPLACEM ENT Public Meeting 6:00 pm February 12, 2019 Kingfield, Maine TEAM NORTH Integrity Competence Service Location Map Centennial Bridge ( Rt. 16 over Carrabasset River ) TEAM NORTH

slide-1
SLIDE 1

Integrity • Competence • Service

TEAM NORTH KINGFIELD CENTENNIAL BRIDGE #5852 WEARING SURFACE REPLACEMENT

Public Meeting 6:00 pm February 12, 2019 Kingfield, Maine

slide-2
SLIDE 2

Integrity • Competence • Service

TEAM NORTH

Location Map

Centennial Bridge ( Rt. 16 over Carrabasset River)

slide-3
SLIDE 3

Integrity • Competence • Service

TEAM NORTH

Bridge Facts

  • Length-176’
  • Width

– 26’ curb to curb – 5’ sidewalk (upstream side) – 3’ safety walk (downstream side)

  • Year Built-1916
  • Bridge widened in 1961
  • Age 102 years
  • Historic structure
slide-4
SLIDE 4

Integrity • Competence • Service

TEAM NORTH

Bridge Condition

  • Deck – Fair Condition (5)
  • Superstructure - Fair Condition (5)
  • Substructure – Satisfactory Condition (6)
slide-5
SLIDE 5

Integrity • Competence • Service

TEAM NORTH

Traffic Information (Average Annual Daily Traffic)

  • Centennial Bridge – 2790
  • Route 27 north of bridge-5440
  • Route 27 south of bridge-2844
  • Maple Street-490
  • Stanley Avenue – 50 (estimated)
  • Island Road- 80 (estimated)
slide-6
SLIDE 6

Integrity • Competence • Service

TEAM NORTH

Proposed Scope of work

  • Remove concrete wearing surface
  • Install membrane waterproofing
  • Install asphalt wearing surface
  • Repair concrete curbs and sidewalks
  • Fill cracks in concrete
  • Fill in joints in sidewalk
  • Construct short approach slab on north

abutment

  • Pave 50’+/- of approaches on west end of bridge
slide-7
SLIDE 7

Integrity • Competence • Service

TEAM NORTH

Wearing Surface

slide-8
SLIDE 8

Integrity • Competence • Service

TEAM NORTH

Project Limits

slide-9
SLIDE 9

Integrity • Competence • Service

TEAM NORTH

Maintenance of Traffic

  • Staged Construction

– Repair half of bridge with traffic/pedestrians on other half – Use temporary traffic signals

  • 11’ travel lane on bridge during construction
  • Temporary concrete barrier down the middle of

the bridge

  • Sidewalk and/or the safety walk will be open

during construction

slide-10
SLIDE 10

Integrity • Competence • Service

TEAM NORTH

Route 27/16 Intersection

slide-11
SLIDE 11

Integrity • Competence • Service

TEAM NORTH

Temporary Traffic Control-Stage 1

slide-12
SLIDE 12

Integrity • Competence • Service

TEAM NORTH

Temporary Traffic Control-Stage 2

slide-13
SLIDE 13

Integrity • Competence • Service

TEAM NORTH

Temporary Changes at Anni’s Market

Entrance

  • n Route

16 – In

  • nly, no

exit On Route 27- Angle parking changed to 2 parallel parking spaces

slide-14
SLIDE 14

Integrity • Competence • Service

TEAM NORTH

Temporary Parking Impacts

Lose of 6 parking spots in front of the Herbert Grant Hotel Lose of 4 parking spaces in front of Longfellow’s Restaurant Lose of 1 parking space in front of Anni’s Market

slide-15
SLIDE 15

Integrity • Competence • Service

TEAM NORTH

Changes to Maple Street

slide-16
SLIDE 16

Integrity • Competence • Service

TEAM NORTH

North end of bridge Very Sharp Corner!

  • Trucks need both sides of the

road to make the corner

slide-17
SLIDE 17

Integrity • Competence • Service

TEAM NORTH

Proposed Truck Detour (Rt. 27 & 234)

Abutment to abutment distance using Route 234 - 37.3 miles Extra distance to Anson using Rt. 234

  • vs. Rt. 16 – 5.1 miles
slide-18
SLIDE 18

Integrity • Competence • Service

TEAM NORTH

Level of Service (LOS)

Level of Service Delay (sec/veh) Description A < 10 Free Flow B 10-20 Stable Flow (slight delays) C 20-35 Stable Flow (acceptable delays) D 35-55 Approaching unstable flow (tolerable delay,

  • ccasionally wait through more than one

signal cycle before proceeding) E 55-80 Unstable flow F >80 Forced Flow ( jammed)

slide-19
SLIDE 19

Integrity • Competence • Service

TEAM NORTH

Traffic Signal Analysis

(Traffic signal added at end of Maple Street)

slide-20
SLIDE 20

Integrity • Competence • Service

TEAM NORTH

Traffic Signal Analysis

(End of Maple Street Closed/No temporary signal)

slide-21
SLIDE 21

Integrity • Competence • Service

TEAM NORTH

Traffic Signal Analysis

(Turn Lane added on Route 27 in front of Anni’s)

slide-22
SLIDE 22

Integrity • Competence • Service

TEAM NORTH

Traffic Signal- Summary

Option #1: 3 traffic signals, Maple Street open LOS: D/E Option #2: 2 traffic signals, Maple Street closed LOS: D Option #3:

2 traffic signals, left turn lane added, Maple Street closed

LOS: C Option #3: Recommended- Least impact.

slide-23
SLIDE 23

Integrity • Competence • Service

TEAM NORTH

Special Events

  • The temporary traffic signals will be turned off

and flaggers will be used during the following events:

– June 29, 2019- Kingfield POPS

  • 2 pm to 10 pm

– July20, 2019- Kingfield Days Parade

  • 11:30 am to 1:30 pm
slide-24
SLIDE 24

Integrity • Competence • Service

TEAM NORTH

Schedule

  • Plans complete 3/1/2019
  • Advertise 3/13/2019
  • Award Contract 4/18/2019
  • Construction in Summer of 2019 when school is

not in session

– Construction Begin -June 22, 2019 (estimated) – Construction End – August 27, 2019

slide-25
SLIDE 25

Integrity • Competence • Service

TEAM NORTH

Budget

  • Available Funds

– Preliminary Engineering $40,000 – Right of Way $0 – Construction $418,000 – Construction Engineering $50,000 – Total $508,000

slide-26
SLIDE 26

Integrity • Competence • Service

TEAM NORTH

PROJECT MANAGER: MICHAEL WIGHT michael.wight@maine.gov 592-2543

Comments or Questions?
